| | Paperless Recorder We offer clients a wide range of digital paperless recorder, which are available in different specifications and successfully meet the application requirements at client's end. The range we offer include: AI-1000C Type Color Paperless Recorder (new product in 2007) AI-1000C color paperless recorders, based on intelligent, digital & networking philosophy of design, adopts intlligent conditioning, dexterous bus, industrial network, LCD and electronic storage technology. With excellent performance, high reliability and lower maintenance, it is the first choice for medium and small enterprises in customized production automation. - 5.6 inch TFT LCD, high-luminance, wide visual field and excellent display.
- Display mode: overview, real-time trend, history trend, digital display & supplementary graphs.
- Record Interval: 1-240 seconds,supporting history data inquiry at fixed point.
- Channel Function: supports 16 channel universal inputs, 1-6 channel passive contact outputs and 1-8 channel of 4-20mA current intelligent outputs.
- Storage medium: 0-248M, FLASH, non-volatile memory, supporting access to USB mobile memory.
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
| | Electromagnetic Flow Meter Electromagnetic Flow Meter - Full bore type line size 15 NB to 2000 NB.
- Microprocessor based version with remote convertor option.
- Indication through 16 * 2 LCD/0.3" Red LED.
(4 digit flow rate & 8 digit totalized flow) - Easy maintenance as no moving parts.
- Viscosity : 200cp max.
- Output : 4-20 mA DC/pulsed,Accuracy: /-0.5%F.S.
- Electrode : SS 316/SS 316L/ HastalloyC.
- Lining : Neoprene/ PTFE/ Other on request.
- Power Supply : 230 V AC/ 24 V DC.
- Transmitter Enclosure : Flame-proof, IP-65, IIA, IIB, CMRI certified.
- Process connections : ASA 150#, Flanged.
- Mounting : Inline, Horizontal or vertical.
Turbine Flow Meter - 2 wire or 4 wire system/ Battery operated.Easy maintenance.
- Microprocessor based.
- Line size : 15NB to 200 NB.
- Viscosity : 100cp max.
- Display : 0.3", 7 Seg, RED LED/ 8*1 LCD
- (digit flow rate & 8 digit totalized flow)
- Output : 4-20 mA DC/pulsed.
- Accuracy : /- 1% F.S., Turn Down ratio 10:1.
- Material of construction : Body Bearings, Support & flange- SS 316.
- Rotor : SS410/ SS 410 with PTFE coating.
- Power Supply : 24 V DC.
- Transmitter Enclosure : Flame-proof, IP-65, IIA, IIB, CMRI certified.
- Process connections : Flanged/Threaded/Tri-clover.
- Mounting : Inline, Horizontal or vertical.
Flow Indicator Totalizer - Flow indiacation totalisation with optional pressure- temperature compensation
- Microprocessor based, programmable low flow cut-off.
- Operating modes: Normal/ Batch/ Monthaly
- Input : 4-20mA/ Pulses(linear / square root/ 10 Points linearisation table.)
- Accuracy : Better than 0.25% of F.S
- Power Supply : 230 V AC/ 24 V DC/ 24 V AC
- Display : 8*2 LED/ 16*2 LCD
(4 digit flow rate & 8 digit totalized flow)
|
| |
|
|
|
|
|
|
