Vibration Meter

         Features:

• Micro controller based.
• Measuring vibration Displacement, Acceleration and Velocity.
• T-RMS measurement.
• Sealed Membrane Key pad.
• Suitable for monitoring machinery vibration caused by Imbalance, Misalignment and gear faults,
• Back light display.
• Auto power off
• Low battery indication.
• Pocket Size & light weight.



  Technical Data.
  Displacement Measuring Range	0.5-2800 Microns(0.0005-2.800mm) PK-PK True RMS
  Velocity Measuring Range	0.1-200mm/S True-RMS & PEAK PK
  Acceleration measuring range	0.1-200m/s2 PEAK-PK & True-RMS
  Resolution	0.1mm/s
  Accuracy	±(2% +0.1mm/s
  Frequency	10-1kHz(60 to 60000)cpm
  Temperature range	O to 55C
  Power Supply	9V-6F22
  Display	2 x 8 Dot Matrix LCD Large Characters.
  Casing	ABS
  Size	135 x 70 x 25 mm
  Weight	200gms.







  Standard Delivery

  • Vibration tester AVD-80.

.International Instruments Industries introduce  Lutron Digital Vibration meter model VB-8201HA



VIBRATION METER

Model : VB-8201HA

FEATURES

* Applications for industrial vibration monitoring : * RMS & Peak measurement.

All industrial machinery vibrates. The level of *Wide frequency range.

vibration is a useful guide to machine condition. * Data hold button to freeze the desired reading.

Poor balance, misalignment & looseness of the *Memory function to record maximum and

structure will cause the vibration level increase, it minimum reading with recall.

is a sure sign that the maintenance is needed. * Separate vibration probe, easy operation.

* Frequency range 10 Hz - 1 kHz, sensitivity * Super large LCD display.

relative meet ISO 2954. *Microcomputer circuit, high performance.

* Professional vibration meter supply with vibration * Auto shut off saves battery life.

sensor & magnetic base, full set. * Built-in low battery indicator.

* Velocity measuring range 200 mm/s. * Heavy duty & compact housing case.

* Acceleration measuring range 200 m/s2. * Complete set with the hard carrying case.

SPECIFICATIONS

Display 61 mm x 34 mm supper large Memory Maximum & Minimum value.

LCD display. Sampling time Approx. 1 second.

15 mm ( 0.6" ) digit size. Operating 0 to 50 ??? ( 32 to 122 ??? ).

Measurement Velocity, Acceleration RMS temperature

value, Peak value, Data hold, Operating Less than 80% RH.

Max. & Min. value. humidity

Range Velocity : Power supply Alkaline or heavy duty type,

200 mm/s : 0.5 to 199.9 mm/s DC 9V battery, 006P,

Acceleration : MN1604 (PP3) or equivalent.

200 m/s2 : 0.5 to 199.9 m/s2 Power Approx. DC 6 mA.

Frequency 10 Hz to 1 KHz consumption

range * Sensitivity relativive during Weight Meter 274 g/0.60 LB

the the frequency range meet Probe with 38 g/0.08 LB

ISO 2954 magnetic base

Accuracy ± ( 5 % + 2 d ) reading Dimension Meter :

@ 80 Hz, 160 Hz. 185 x 78 x 38 mm

@ 23 ± 5 ??? ( 7.3 x 3.1 x 1.5 inch ).

Calibration Velocity : 50 mm/s (160 Hz) Vibration sensor probe:

point Acceleration : 50 m/s2(160 Hz) Round 16 mm Dia. x 29 mm.

Circuit Exclusive microcomputer circuit. Accessories Instruction manual................. 1 PC.

Data hold Freeze the desired reading. included Vibration sensor ( VB-81A )

Peak To measure the peak value. .......................................... 1 PC.

measurement Cable.................................... 1 PC.

Power off Auto shut off, saves battery life, Magnetic base....................... 1 PC.

or manual off by push button. Carrying Case........................ 1 PC.
