Acrifab Private Limited

Magnification	1000x
Resolution	1980x1020 pixels
Model Name/Number	DM9HC
Is It Portable	Non Portable
Photo Resolution:	16 Mega Pixel
Video Resolution:	1080FHD, 720P

The DM9HC is a high-performance digital microscope offering excellent clarity and flexibility for both close-up and distant viewing. With a 1/2.8" lens optic size and a maximum video pixel of 1080FHD, this microscope captures high-definition videos and sharp images.Photo Resolution: Ranges from 16M to VGA (1.3M), allowing users to choose from multiple resolution options based on their needs.Video Resolution: Offers 1080FHD and 720P for capturing smooth videos in AVI format.Focus Mode: Manual focus control with a focusing range of 10~40mm, and the ability to view distant objects.Illumination: Equipped with 8 adjustable LED lights for optimal lighting conditions.Image Transfer Rate: Up to 1280*720 at 25fps, ensuring clear real-time video transfer.White Balance and Exposure: Automatically adjusts to provide the best possible image.Compatibility: Supports Windows XP, Win7, Win8.1, Win10, and Mac OS x 10.5 or higher for seamless operation.Interface: Micro USB 2.0 and HDMI connections for signal transmission.Lens Features: The microscope uses a 5H+IR lens construction, with a 16° lens angle and F4.5 aperture for precise focusing and imaging.Durability: Operates reliably in temperatures ranging from -20°C to +55°C and humidity levels of 30% to 85%.Power: Consumes just 3W with a working current of 600mA.

Magnification	200x
Model Name/Number	MC-H7S-4KHU
Eyepiece	2
Features	-Precise positioning -Versatile base compatible with various microscope models -Built-in sliding gui
Warranty	1 year
Optical Magnification	6.0-60X (optional auxiliary objective)
Is It Portable	Non Portable

Introducing our new designed universal sliding base series for stereo microscopes, developed in response to customer demands.



This innovative base offers anti-static and high-temperature resistance, precise positioning, and corrosion resistance. The base is versatile and compatible with various microscope models, with dimensions of 300*400mm. It features a built-in sliding guide rail, allowing the microscope to move laterally with a sliding range of 290mm.

Magnification	25-230X
Optical magnification	0.7-5.0X continuous zoom
External device	Monitor + PC
Resolution	3840X2160P@4K
Sensor	1/1.8 inch Sony sensor, 8 megapixels

Product Name: MC-D-4KHU Digital MicroscopeThe MC-D-4KHU is a cutting-edge digital microscope designed for precision imaging and versatile use, offering exceptional image quality and advanced functionality.Sensor: Equipped with a 1/1.8 inch Sony sensor featuring 8 megapixels, this microscope delivers stunning image clarity.Resolution: Captures images at an ultra-high 3840X2160P resolution in 4K, ensuring every detail is preserved.Output Interface: Features HDMI + UVC dual output, allowing connection to both a monitor and a PC for flexible usage.Optical Magnification: The continuous zoom ranges from 0.7X to 5.0X, offering a magnification range of 25-230X for detailed inspection.Durable Metal Base: Comes with a robust 320X260mm metal base and a 280mm column, ensuring stability during operation.Light Source: The adjustable LED ring light provides customizable brightness for optimal lighting in various working conditions.Camera Features: Includes advanced features such as local magnification, preview, image flipping, magnification display, and electronic zoom. The built-in measurement system allows for accurate measurements, while U disk storage offers convenient data saving.Comparison Tools: Supports two/four screen comparison for enhanced analysis and precision.This microscope is perfect for applications that require high-resolution imaging, precise magnification, and reliable measurement capabilities, making it an ideal tool for professionals in inspection, research, and education.

Resolution	1980x1020 pixels
Magnification	200x
Model Name/Number	MC-AF200
Is It Portable	Non Portable
Digital Imaging	Yes

The MC-AF200 is a high-performance digital microscope designed for versatile imaging needs, offering both HDMI and USB dual output for flexible connectivity to HD monitors and computers.Resolution: Provides sharp image quality with a resolution of 1920X1080P at a smooth 60FPS.Sensor: Features a 1/2.8 inch sensor with a pixel size of 2.0μmX2.0μm, capturing detailed and precise visuals.Optical Magnification: Offers 0.7X to 4.5X continuous zoom, providing excellent flexibility in magnification levels for close inspections.Electronic Magnification: With 26-180X magnification, expandable up to 360X, this microscope is perfect for detailed observations.Sturdy Metal Base: Comes with a 375X265mm metal base and a 330mm height column, providing a stable platform for use in various environments.Light Source: Features an adjustable LED ring light for customizable illumination, ensuring clear visibility under different lighting conditions.Camera Features: Includes advanced capabilities such as electronic zoom in/out, wide dynamic range, mirror flip, and same screen comparison for side-by-side analysis. Additionally, the auto-focus function ensures sharp and clear images with minimal effort.The MC-AF200 is ideal for professionals in industries such as electronics, materials science, and quality control, where precision and versatility are key.

Magnification	200x
Resolution	3648x2736 pixels
Usage/Application	-Electronic repairing -Soldering and welding -PCB inspection -SMT testing -Electronic components coa
Model Name/Number	MC-HD-4KHU
Light Source	LED
Is It Portable	Non Portable
Material	Metal
Digital Imaging	Yes
Sensor-	: 1/1.8 inch Sony sensor, 8 megapixels
Resolution-	3840X2160P@4K
Output interface	HDMI+UVC dual output
Optical magnification	0.7-5.0X continuous zoom
Magnification-	25-230X

Ideal for:-Electronic repairing-Soldering and welding-PCB inspection-SMT testing-Electronic components coating-Mobile phone repairing Key Features:-2D/3D Free Switching observation-Precision slide design-Precise positioning-Versatile base compatible with various microscope models-Built-in sliding guide rail for elastic movement Specifications:- Model: MC-HD-4KHU- Sensor: 1/1.8 inch Sony sensor, 8 megapixels- Resolution: 3840X2160P@4K- Output interface: HDMI+UVC dual output- External device: Monitor + PC- Optical magnification: 0.7-5.0X continuous zoom- Magnification: 25-230X- Metal base: 320X260mm, metal base column 280mm- Light source: brightness adjustable LED ring light source- Camera features: local magnification, preview, image flipping, magnification display, electronic magnification/reduction, built-in measurement system, U disk storage, two/four screen comparisonuniversal sliding base dimention:300*400mmSliding range of base: 290mm

Magnification	200x
Model Name/Number	MC-D-AF200
Is It Portable	Non Portable
Resolution	1920*1080P@60FPS
Optical magnification	0.7-5.0X continuous zoom
External device	Monitor + PC

Our innovative inspection microscope simplifies the process, enabling 360° observation of various surface structures, defects, solder joint quality, and more, enhancing efficiency by enabling autofocus for components of varying heights without manual adjustments.

Magnification	200x
Resolution	1920x1080 pixels (Full HD)
Sensor	1/3 Image CMOS
Signal Interface	USB2.0/USB1.1
Power Consumption	0.75W MAX

Digital USB Microscope is a creative device that it is an amazing and easy to use handheld digital microscope with USB interface. It broke the conception of traditional microscope, it realized these functions: measurement, save, copy, transfer image and video which are difficult for a traditional microscope. It is a small, easy to operate and portable.
