Adaptek Automation Technology

Form Factor	ATX
Brand	Advantech - Adaptek
Model Name/Number	AIMB- 788g2
Chipset	Intel
Usage/Application	IIndustrial
Country of Origin	Made in India

AIMB-788

LGA1700 12th/13th/14th Generation Intel® Core™ i9/i7/i5/i3 ATX Motherboard with DP/HDMI/VGA, DDR4, USB 3.2, M.2

• Intel® 12th/13th/14th generation Core™ i9/i7/i5/i3 & Pentium®/Celeron® processor with Q670E chipset
• Four DIMM sockets up to 128 GB DDR4 3200
• Triple display DP/HDMI/VGA and dual GbE LAN
• M.2, SATA RAID 0, 1, 5, 10, USB 3.2 Gen 2
• Advantech iBMC remote out-of-band power management solution on DeviceOn
• AWS (Amazon Web Service) IoT Greengrass qualified
• Note 1: Legacy platform is not supported
• Note 2: dTPM 2.0 module is required to enable Intel vPro and TPM technologies
• Note 3: Intel® Platform Trust Technology (Intel® PTT) ready for Windows 11

Additional Information:

• Delivery Time: imediate

Form Factor	Micro Atx
Chipset	Intel
Usage/Application	Industrial micro atx motherboard
Brand	Advantech
Maximum Ram Capacity	16 GB
Speed	10/ 100/ 1000 Mbps
Voltage	12V
Weight	1.2 kg (2.64 lb), weight of total package
Vedio Graphics	CRT1: Up to 2048 x 1563 @ 60Hz CRT2: Up to 1920 x 1200 resolution
Dual Socket	2 x 240-pin DIMM
USB Type	USB2.0

AIMB-501G2-KSA1E-

√  MicroATX with VGA/LVDS 10 COM/10 USB/DUAL LAN
√  Supports Intel® Core™ i7/i5/i3 processor with H61 chipset.
√  Two DIMM sockets support up to 16 GB DDR3 1066/1333 MHz SDRAM
√ Supports dual display of VGA, DVI, LVDS and two GbE LAN.
√ Supports 10 COM, LPT, TPM 1.2 (Optional).
√ Supports 10 USB 2.0 or 2 USB 3.0 and 8 USB 2.0..,
√ Supports WISE PaaS/RMM and Embedded Software APIs.

Processor Support	Intel Celeron
Chipset	Intel
Operating Temp	-20 to 60 C
Form Factor	SBC
Usage/Application	INDUSTRIAL
RAM Type	DDR3
Power Input	ATX 24 pin
I O Ports	Dual LAN, 4 x COM, 4 x USB
Graphics Card Type	Integrated
Storage Interface	SATA
Display Output	VGA
Model Number	PCA-6178VE, Industrial Motherboard

PCA-6178VE Advantech Industrial Motherboard -

* Features :

√ Socket 370 Pentium III processor up to 700+ MHz
√ Intel 82440BX PCI set, supports FSB 100 MHz
√ Three DIMM sockets for SDRAM up to 768MB, supports ECC
√ On-board security for CPU fan, thermal and voltage monitoring
√ On-board VGA/AGP with 4 MB SGRAM
√ On-board 10/100Base-T networking controller
√ On-board Ultra II SCSI controller.
√ ISA High Drive 64 mA (HISA).



Processor Support	Intel Celeron
Form Factor	"full size sbc
Operating Temp	-20 to 60 C
RAM Type	DDR3
Power Input	ATX 24 pin
Operating Temperature	-20 DegreeC ~ 60 DegreeC
CPU	LGA1150 Intel Xeon E3,Core(TM) i3,Pentium or Celeron processor supported
Storage Interface	SATA
Display Output	VGA
Ethernet	GbE1 Intel I217LM with Intel AMT 9.0 support GbE2 Intel I210-AT PCIe controller with NCSI support
Product Type	Board Computer
LAN	2 x 2-pin
SMBus	1 x 4-pin wafer

NEXCOMM- PEAK777 Single Board Computer-

• PICMG 1.3 full-size server grade solution.
• Supports dual independent display by VGA and iDP interface.
• Supports PCIe Mini devices and mSATA via PCIe Mini socket.
• Intel® PCIe GbE with Intel® AMT 9.0 support.
• Supports RAID function via SATA 6Gb/s.
• TPM V1.2 hardware security function supported by TPM module.
• Stiffener bars.
• IEI jumper-less function.
• Support IPMI 2.0 via iRIS-2400 module.

                      Specification:

Additional Information:

• Item Code: PEAK-872VL2

Brand	Intel
Processor	CORE 2 DUO CPU
Model Name/Number	PEAK - 777
Chipset	Intel
Usage/Application	CNC Machine
Form Factor	ATX
Graphics Card Type	Integrated
Warranty	1 Year

PEAK-777 CNC Motherboard:-

• Core 2 Quad/Duo LGA775 with 2 x PCI Express Gigabit LAN/SATA/VGA/USB2.0.
• PEAK 777VL2 is a PICMG 1.0 full-size Single Board Computer (SBC), which supports Intel 45nm Core 2 Duo/ Quad technology.
• Featuring Intel G41 and ICH7 chipsets, the PEAK 777VL2 support socket LGA775 of Intel Core 2 Quad/ Core 2 Duo/ Celeron processor with 800/ 1066/ 1333MHz FSB.
• The Intel G41 supports dual channel non-ECCDDR3 memory up to 4GB maximum with two DIMM slots and an integrated graphics controller.
• The South Bridge ICH7 manages SATA HDD ports, and parallel.
• Furthermore, it supports other versatile I/O ports such as two serial ports, six USB ports and two PCI Express Gigabit LAN ports.

Additional Information:

• Item Code: PEAK777
• Delivery Time: Immediate

Brand	Intel
Form Factor	EATX
Model Name/Number	ESM-945GSX-A1
Usage/Application	INDUSTRIAL
Warranty	1 Year

ESM-945GSX- A1


Product name -  ESM-45GSXA1
Interface  - VGAPower supply
eATXLAN2* 1000M LAN
USB2.0

Processor Support	Intel Core i7
CPU Sockets	Single socket
Operating Temp	0 to 60 C
Form Factor	ATX
Socket Type	LGA1151
Usage/Application	INDUSTRIAL SERVER
RAM Type	DDR3
Power Input	ATX 24 pin
Max RAM Capacity	128 GB
I O Ports	4 x COM, Dual LAN, 8 x USB
Model Name/Number	ASMB-784 Xeon
Warranty	1 YEAR
Storage Interface	SATA
Display Output	VGA
Mounting Type	Chassis mount
Brand	ADVANTECH SERVER Motherboards

* ASMB - 784 Advantech Industrial Server Motherboard-

• LGA 1151 Intel® Xeon® E3 v5/v6 & 4th/5th Generation Core™ ATX Server Board with DDR4, 4 PCIe, 3 PCI, 6 USB 3.0, 6 COM, 6 SATA3, Quad/Dual LANs
• Supports LGA 1151 Intel® Xeon® E3-1200 v5/v6 and 6th/7th Generation Core™ i7/i5/i3 processors.
• DDR4 2400/2133/1866/1600/1333 MHz ECC/Non-ECC UDIMM up to 64 GB
• One Gen 3.0 PCIe x16 link (or two PCIe x16 slots with x8 link), two PCIe x4, and three PCI slots.
• Rackmount optimized placement with positive air flow design.
• 0 ~ 60° C ambient operation temperature range.

Processor Support	Intel Core i3
Form Factor	ATX
Operating Temp	-20 to 60 C
RAM Type	DDR3
Power Input	ATX 24 pin
Processor Type	i5
I O Ports	Dual LAN, 4 x USB
Operating Temperature	0 ~ 60 DegreeC (32~140 DegreeF); Depends on CPU frequency and cooler solution
Internal Memory	2 GB
Usage/Application	Industrial Motherboard
Temperature	-40 ~ 85 DegreeC and 60 DegreeC @ 95% RH Non-Condensing
Interface	10/100/1000 Mbps
Operation Humidity	10% ~ 90%

PCA - 6028 Industrial Motherboard

• Supports Intel® Core™ i7/i5/i3/Pentium LGA1150 processors with H81

• Dual Channel (Non-ECC) DDR3 1333/1600 up to 16 GB
• Supports USB 3.0, SATA3.0
• Dual Display with VGA and DVI-D(optional)
• Supports Advantech LPC modules.
• Supports SUSIAccess and Embedded Software APIs

RAM	4 GB
Processor Type	Pentium 3
Highest Voltage Potection	Industrial SBC
Warranty	1 year
Product Type	Industrial Motherboards
Model Name/Number	SBC -8168

SBC8168 Rev.B3 B4 B5 A2 industrial Motherboard-



Processor Type	Intel Core 2 Quad, Core 2 Duo Pentium D LGA775 processors 533/800/1066 FSB
Model Name/Number	ISA SLOT MOTHERBOARD
Brand	Intel
Form Factor	ATX
Chipset	G31
Graphics Card Type	Integrated
Warranty	1 Year
Country of Origin	Made in India
Slot	ISA
Type	Industrial

-P4BWA Industrial Motherboard-

• MB-P4BWA industrial motherboard is a long-life ATX motherboard with FOUR 32-bit PCI slots, 2 ISA slots, and 1 each PCIe x16 and PCIe x4 slots.
• This motherboard is Socket 775 for Intel Quad Core, Core 2 Duo, Pentium D, and Pentium 4 processors.
• The Intel Q965 chipset has integrated GMA 3000 graphics supporting up to 2 independent displays, and takes advantage of features such as Intel Fast Memory Access.
• On-Board VGA, HD Audio, Serial ATA, Dual LANs, Serial MB-P4BWA industrial motherboard has dual gigabit LANs, supports 5 serial ports and a parallel port, and makes available 6 SATA II devices.
• There are 6 USB 2.0 ports on the rear panel, and 4 additional via internal headers.
• Supports Intel Core 2 Quad, Core 2 Duo & Pentium D LGA775 processors 533/800/1066 FSB.
• 4 x 240-pin DDR2 533/667/800 MHz RAM up to 8 GB.
• Intel Q965 & ICH8DO chipset.
• Built-in Intel Extreme GMA 3000 video (up to 256 MB shared RAM).
• 6 X SATA II interface with 300 MB/s transfer rate.
• Supports RAID 0, 1, 5, 10.
• 2 x Intel 82573L Gigabit Ethernet & Realtek ALC888 high defination audio.
• 1 x PCI-Express X16, 1 x PCI-Express X4, 1 x mini-PCI, 4 x PCI & 2-ISA (No DMA support for ISA).
• 4 x USB 2.0 ports.

keywords : ISA slot motherboards ; ISA SLOT INDUSTRIAL MOTHERBOARD; ROCKY-4786 EVG SBC; ROCKY -4782EV SBC..,

Additional Information:

• Item Code: P4BWA

Model Name/Number	ROCKY - 4786 EVG Indsutrial CPU Card
Usage/Application	Computer
Form Factor	ATX
Graphics Card Type	Integrated
Warranty	1 Year
Country of Origin	Made in India

specification :-

Additional Information:

• Packaging Details: Features: 1x 10/100Mbps i82562ET Ethernet, 1x 10/100/1000Mbps i82547 Ethernet by CSA 2x 10/100Mbps i82559 Ethernet (ROCKY-4786E2V) ATX power control function : meet ACPI 1.1 Compact Flash Type socket Hardware monitoring (CPU Vcore ; CPU/System Fan speed and Thermal) Integrated in Intel 865G Intel 865G + ICH5 Socket-478 for Intel Pentium 4 with 533/800MHz FSB

Brand	AMD
Model Name/Number	G41 ISA
Usage/Application	INDUSTRIAL
Form Factor	ATX
Graphics Card Type	Integrated
Warranty	1 Year
Expansion Slots	4*PCI and 3*ISA
Chipset	Intel G41 / ICH7

CNC Industrial Pc Motherboard

Processor Support	Intel Core i7
CPU Sockets	Single socket
Operating Temp	0 to 60 C
Form Factor	ATX
Usage/Application	Industrial
Socket Type	LGA2011
RAM Type	DDR3
Power Input	ATX 24 pin
Max RAM Capacity	1 TB
I O Ports	4 x USB, Dual LAN
Brand	ADVANTECH
Model Name/Number	ASMB-785
Warranty	1 YEAR

ASMB-785 Advantech server Motherboards

LGA 1151 Intel® Xeon® E3 v5/v6 & 6th/7th Generation Core™ ATX Server Board with 4 DDR4, 4 PCIe, 3 PCI, 6 USB 3.0, 6 COM, 6 SATA3, Quad/Dual LANs, IPMI

• Supports LGA 1151 Intel® Xeon® E3-1200 v5/v6 and 4th Generation Core™ i7/i5/i3 processors
• DDR3 2400/2133/1866/1600/1333 MHz ECC/Non-ECC UDIMM up to 64 GB
• One Gen 3.0 PCIe x16 link (or two PCIe x16 slots with x8 link), two PCIe x4, and three PCI slots
• Triple display - two DVI-D and one VGA ports
• Supports up to ten RS-232 or six RS-232 and four RS-422/485 ports
• Rackmount optimized placement with positive air flow design
• 0 ~ 60 °C ambient operation temperature range

Processor Support	Intel Celeron
Brand	Advantech
Chipset	Intel
Operating Temp	-20 to 60 C
Form Factor	sbc
Usage/Application	INDUSTRIAL
RAM Type	DDR3
Power Input	ATX 24 pin
I O Ports	Dual LAN, 4 x USB, 4 x COM
Model Name/Number	6186ve
CPU	LGA1150 Intel Xeon E3,Core(TM) i3,Pentium processor
Graphics Card Type	Integrated

PCA-6186VE industrial motherboard-

PCA-6186 Rev.B2 CPU Board 100% tested ok with warranty

1, PCA-6186VE industrial motherboard.

2, 100% full tested working
3, CPU Board.

Industrial Computer Motherboard Advatnech Industrial PC Motherboard
6186VE Indsutrial Motherboard

Form Factor	ATX
Chipset	Intel
Usage/Application	Industrial PC

                      AIMB-788 Advantech Industrial Motherboard

LGA1700 12th/13th/14th Generation Intel® Core™ i9/i7/i5/i3 ATX Motherboard with DP/HDMI/VGA, DDR4, USB 3.2, M.2

• Intel® 12th/13th/14th generation Core™ i9/i7/i5/i3 & Pentium®/Celeron® processor with Q670E chipset
• Four DIMM sockets up to 128 GB DDR4 3200
• Triple display DP/HDMI/VGA and dual GbE LAN
• M.2, SATA RAID 0, 1, 5, 10, USB 3.2 Gen 2
• Advantech iBMC remote out-of-band power management solution on DeviceOn
• AWS (Amazon Web Service) IoT Greengrass qualified
• Note 1: Legacy platform is not supported
• Note 2: dTPM 2.0 module is required to enable Intel vPro and TPM technologies
• Note 3: Intel® Platform Trust Technology (Intel® PTT) ready for Windows 11

Additional Information:

• Production Capacity: 100
• Delivery Time: immediate

Form Factor	Extended ATX
Model Name/Number	NOVA-945GSE-N270
Brand	IEi -Taiwan

NOVA - 945GSE -N270-R20

1.6GHz Intel® Atom™ N270 processor with fanless support

» 400/533 MHz DDR2 SO-DIMM memory up to 2 GB
» Support dual PCIe Mini card/PCI slot for expansion
» Dual LVDS support dual display output
» CF socket for storage expansion
» TPM support
» IEI One Key Recovery solution allows you to create rapid OS backup and recovery
DisplaySystem - CPUChipsetIntel® 945GSE+ICH7M
Memory Max.One 200 pin 400/533MHz DDR2 SDRAM SODIMM
supports up to 2GB
CPU SocketOn BoardI/O InterfaceEthernet
Digital I/O1 x 8-bit digital I/O (2x5 pin)
AudioAC’97 ALC655 codecI/O InterfacePowerPower consumption
EnvironmentOperating Temperature Humidity10% ~ 95%, non-condensing
Optioni RISStorage
StorageExpansion
SlotsExpansion Slots
FSBFSBWatchdog
TimerWatchdog Timer
CPU Cooler CPU CoolerI/O InterfaceI/O Interface3 x RS-2321 x RS-422/4856 x USB 2.0

Form Factor	Micro ATX
Brand	Intel
Model Name/Number	NOVA-945GSE
Chipset	Intel
Usage/Application	INDUSTRIAL

NOVA -945GSE 5.25” SBC, Intel® Atom™ N270 1.6GHz

1.6GHz Intel® Atom™ N270 processor with fanless support
» 400/533 MHz DDR2 SO-DIMM memory up to 2 GB » Support dual PCIe Mini card/PCI slot for expansion
» Dual LVDS support dual display output
» CF socket for storage expansion
» TPM support
» IEI One Key Recovery solution allows you to create rapid OS backup and recovery

Additional Information:

• Delivery Time: immediate

Model Name/Number	industrial motherboard
Product Type	Embedded Industrial Motherboard
Form Factor	Slot PC
Graphics Card Type	Integrated
Application	Desktop,Server
Model No.	Rocky 4784 EVG

 ROCKY-4786EVG  Single Board Computer-

• CPU: Socket 478 for Intel P4/Prescott/Celeron with 533/800 MHz FSB.
• System Chipset: Intel 865GV+ ICH5.
• System memory: Dual channel DDR333/400 SDRAM socket support up to 2GB .
• Ethernet: Intel 82562 ET for 10/100Mbps and 82547 for 10/100/1000 Mbps I/O.
• Interface: 2 x RS-232 serial port by pin header 1x LPT by pin header (support SPP/EPP/ECP mode) 8 x USB 2.0 by pin header 1x PS/2 for KB/MS 2x IDE ATA-100(40pin header with 2.54mm pitch) 1x Floppy (34-pin with 2.54mm pitch) 2 x Serial –ATA 150 1x IrDA.
• Display: Integrated in Intel865GV
• SSD:1x Compact Flash Type II socket
• Audio: AC’97 Audio CODEC.
• Power Consumption: +12V@7.52A, -12V@500mA, 5V@6.98A (P4 3.0GHz FSB800 MHz; Dual channel DDR 400 512 SDRAM).
• Temperature: 0 ~ 60°C( 32 ~ 140°F).
• Watchdog timer: software programmable supports 1~255 sec. system reset.
• Weight: 1.1Kg.

Additional Information:

• Item Code: VDX-6324D-FD

Processor Support	Intel Core i5
Brand	Intel
Operating Temp	0 to 60 C
Form Factor	Micro Atx
RAM Type	DDR3
Usage/Application	Computer
Power Input	ATX 24 pin
I O Ports	4 x COM, Dual LAN, 4 x USB
Chipset	Q67
Model Name/Number	AIMB- 581G2
Graphics Card Type	Integrated, Non-Integrated
Warranty	1 Year

AIMB -581 G2 Advantech Industrial Motherboard -
Advantech Industrial Motherboard
Advantech Motherboards.

Processor Support	Intel Celeron
Brand	Intel
Operating Temp	-20 to 60 C
Form Factor	ATX
Usage/Application	INDUSTRIAL
RAM Type	DDR3
Power Input	ATX 24 pin
I O Ports	4 x USB, 4 x COM
Chipset	IntelG31 + ICH7 chipsets
Model Name/Number	ISA Slot Motherboard
Storage Interface	SATA
Display Output	VGA
Expansion Slots	4x PCI,2x ISA

ISA Slot Motherboard - Model - IMBA-G31-02 -

* FEATURES :

• IMG31 is a high-performance Intel Pentium 4 motherboard.
• The system core logic is based on IntelG31 + ICH7 Chipsets.
• It is integrated with two RTL8111C Ethernet controllers.
• Support FSB 533/800/1066 CPU.
• Support Intel Pentium 4 CPU.

Chipset:

• IntelG31 + ICH7 chipsets.
• ITE IT8712F LPC controller.
• RTL8111C Ethernet controller.

Main Memory:

·Four 240-pin DDRII sockets.
·Support DDRII 400/533/667 SDRAM up to 4GB.
·VGA: Integrated Graphics controller in GM350 GMCH.
·Integrated Intel Graphics Media Accelerator 950
· One VGA Port it can accelerate DirectX 9 performance of hardware,400MHz core frequency, up to 224MB display memory.

Ethernet:

• Onboard two RTL8111C 10/100/1000 Base-T Ethernet controllers.
• Full-Duplex supported.

IDE SATA & FDD:

• One enhanced PCI IDE channels which support up to 2 IDE devices.
• Four SATA devices.
• Support ATA-100, data transfer rate up to 100MB/sec.
• One FDC supports 1.2M/1.44M/2.88M FDD.

PCI-E PCI ISA AUDIO COM &LPT:

• Support One PCI-E X16 devices
• Support five PCI devices
• Support two ISA devices
• Support 7.1 HD Audio
• Support two COM
• Support one LPT

System BIOS:

• Award BIOS with 4MB Firmware Hub.
• ACPI/PnP supported.
• Software Watch Dog supported .
I/O Output:

• Two COM port & one Printer port
• One DB-15 VGA port
• PS/2 mouse and keyboard connectors
• Double Deck downstream USB 2.0 ports
• Two RJ-45 LAN ports

Expansion Slots:

• Five PCI slot
• Two ISA slot

Form Factor: Flex-ATX @ 305 mm (L) × 244 mm (W), 4 Layers

Brand	Adaptek
Standard Size	21.5 Inch (512 X 304.5 mm)
Border Width	17.8 mm
Response Speed	3-10 ms
Event Detection	Touch Start,Hold,End
Sensor	Infrared Ray
Output Resolution	32767 x 32767 mm

ASMB-786

LGA 1151 Intel® Xeon® E & 8th/9th Generation Core™ ATX Server Board with 4 DDR4, 7 PCIe, 6 USB 3.1, 8 SATA3, Quad/Dual LANs, IPMI

• LGA 1151 Intel® Xeon® E & 8th/9th Generation Core™ i7/i5/i3 processors with C246 chipset
• DDR4 2666/2400/2133 MHz ECC/Non-ECC UDIMM up to 128 GB
• One Gen 3.0 PCIe x16 link (or two PCIe x16 slots with x8 link), two PCIe x4, and three PCIe x1 slots
• Triple displays - DVI-D, VGA and HDMI 2.0 ports
• Eight SATA3 ports and six USB 3.1 ports
• Rackmount optimized placement with positive air flow design
• 0 ~ 60° C ambient operating temperature range

Processor Support	Intel Celeron
Brand	CNC Motherboards
Form Factor	Single Board Computer
Onboard RAM	1 GB
Operating Temp	-20 to 70 C
Storage Support	SATA
Usage/Application	industrial cnc mC
Processor	Core2 DUo
Memory Size	up to 16GB DDR3 1600/1333MHz Memory
Operating Temperature	o deg to 45 deg
Model Name/Number	Full Size CPU Card
Internal Memory	4gb
Physical Interface	Intel core 2 Duo SBC
Support OS	PEAK-715
Chipset	478
No. Of Ports	2 COM Ports,4 SATA ports,8 USB ports
CPU	p4
Color	Green
Ethernet	2 LAN
USB	2

PEAK 715-HT Series CPU Board, Intel Socket 478 Pentium 4/Celeron with VGA and Dual LAN

*- PEAK-715 Industrial Motherboard

• PICMG 1.0 Full-size Single Computing Board .
• Deal with AAEON / Avalue / IEI/ NEXCOMM and many Taiwan
• Manufacturer Industrial Motherboards.
• Full-size PICMG 1.3 server grade solution.
• LGA1155 Intel Xeon E3/Core i3/Pentium/Celeron processors supported.
• Up to 16 GB 1333 MHz dual-channel DDR3 SDRAM.
• Supports dual independent display by VGA and DVI-D (DVI model).
• Supports PCIe Mini expansion.
• Intel PCIe GbE with Intel AMT 7.0 support.
• Supports RAID function via SATA 6Gb/s and SATA 3Gb/s.
• High-speed I/O Interface provided through the 2nd gen PCIe add-on card and SATA 6Gb/s connectors.
• TPM V1.2 hardware security provided by the TPM module.
• One Key Recovery solution allows you to create rapid OS backup and recovery.

Processor Support	Intel Core
CPU Sockets	Single socket
Form Factor	ATX
Power Supply	9VDC power input
Storage Temperature	-40 to 85deg
Dimension	3.15 X 1.33 X 0.70 in
RAM Type	DDR4 ECC
Max RAM Capacity	1 TB
Brand	Adaptek Automation
LAN Ports	2 x LAN
Warranty	5 Year Replacement Warranty
Model	RS232
Power	1500 W

-ASMB-782G2 Industrial Server Motherbaord

LGA 1155 Intel Xeon E3 V2 ATX Server Board with 2 PCIe x16 slots (x8 link), 2 PCIe x4, USB 3.0, PCIe Gen III, Dual LAN

  Advantech ASMB-785G2  LGA 1151 Intel Xeon E3 v5/v6 & 6th/7th Generation Core ATX Server Board with 4 DDR4, 4 PCIe, 3 PCI, 6 USB 3.0, 6 COM, 6 SATA3, Quad/Dual LANs,

 Supports LGA 1151 Intel® Xeon® E3-1200 v5/v6 and 6th/7th Generation Core™ i7/i5/i3 processors

– DDR4 2400/2133/1866/1600/1333 MHz ECC/Non-ECC UDIMM up to 64 GB– One Gen 3.0 PCIe x16 link (or two PCIe x16 slots with x8 link), two PCIe x4, and three PCI slots– Rackmount optimized placement with positive air flow design– 0 ~ 60° C ambient operation temperature range

Model Name/Number	WSB-9454-R40
Feature	Fanless
Input Voltage	DC100-240V AC
Input Frequency	50-60 Hz
Output Voltage	DC 12V~3A/5A
Operating Temperature	0-70 Deg Centigrade (32 Deg F~140 Deg F)
Storage Temperature	-20+85 Deg Centigrade
Relative Humidity	0%~90% (non-condensing)
Power Consumption	15 W~28 W
Net Weight	1.6 Kg
Gross Weight	2.6 Kg

-WSB-9454 - r40 -Industrial IEI make Motherbaord

FEATURES :

• CPULGA775 Intel® Core™2 Duo, Pentium® D, Pentium® 4, and Celeron® D desktop processors with a 533 MHz, 800 MHz or 1066MHz FSB
• System ChipsetIntel® 945G+ ICH7

BIOSAMI BIOS

• System Memory Four 240-pin 1 GB (max.) 667 MHz, 533 MHz or 400 MHz dual-channel DDR2 SDRAM DIMMs supported (system max. 4 GB)
• Ethernet Dual Realtek RTL8111E PCIe GbE chipset with ASF 2.0

I/O Interface

• 2 x RS-232;1 x IDE;1 x FDD;1 x LPT;1 x Infrared;4 x SATA 3Gb/s;1 x Keyboard and mouse (PS/2);1 x 5-pin header for keyboard;7 x USB 2.0 (1 on bracket, 6 on board)

• Digital I/O 8-bit digital I/O, 4-bit input/4-bit output
• Audio
• 5.1 channel AC' 97 audio kit with Realtek ALC655 codec
• 7.1 channel HD audio kit with Realtek ALC888 supports dual audio streams
• Display Interfaces VGA integrated in Intel® 945G
• DVI by Silicon Image SIL1362 (WSB-9454DVI Only)
• Watchdog Timer Software programmable supports 1~255 sec. system reset
• Power Supply AT/ATX Power.
• Power Consumption 5V@7.68A, 12V@0.15A, Vcore@2.26A (Intel® Core™2 Duo E7400 2.8 GHz/1066 MHz CPU with four 1GB 800 MHz DDR2).
• Operating Temperature 0°C ~ 60°C (32°F ~ 140°F).
• Storage Temperature -10°C ~ 70°C.
• Humidity 5% ~ 95%, non-condensing.
• Dimensions 338mm x 122mm.
• Weight GW: 1.2Kg.

Brand	Intel
Model Name/Number	IMBA-845-03 3ISA Slot Motherboard
Usage/Application	Industrial PC
Form Factor	ATX
Graphics Card Type	Non-Integrated
Warranty	1 Year
Expansion Slots	4 PCI

* ISA Slots Motherboard-

Features:-

• ISA Slots Motherboard are available with the industrial motherbaords.

From the day of our inception in this highly competitive industry, we have come up with a wide gamut of ISA Slots Motherboard.
There are two CPU board slots of PICMG specification.
(ISA Bus slot combination).
Since a PCI slot is on the left-hand side of a backplane, even if it equips almost all chassis, a full-sized PCI board can be mounted on four sheets.

Model Name/Number	ATK-ISM
Usage/Application	Industrial
Brand	Intel
Form Factor	ATX
Graphics Card Type	Integrated
Warranty	1 Year
Country of Origin	Made in India
Input Support	Intel 7th / 6th Gen (Kabylake-S / Skylake-S) Core Processors.

D3076-S11 GS3 Industrial Server Motherboard :-

FUJITSU D3076-S11 GS3 socket 1155 server motherboard is an ATX motherboard that has room for 4 DDR3 memory modules.

Model Name/Number	Indsutrial Motehrboards
Usage/Application	Industrial
Brand	Intel
Form Factor	ATX
Chipset	Q470E
Graphics Card Type	Integrated
Warranty	1 Year
Country of Origin	Made in India

          IMB-1711ATX Motherboard:-

* FEATURES :

• Intel 10th Gen (Cometlake-S) Core Processors with Q470E chipset.
• 4 x 288-pin Long-DIMM, Support Dual Channel DDR4 2933 (i9 / i7 CPU / 2666) (i5 / i3 CPU) / 2400 (Pentium / Celeron CPU), up to 128GB.
• 1 x PCIe x16 Gen3, 1 x PCIe x8 Gen3, 3 x PCIe x4 Gen3, 2 x PCI.
• 4 x USB 3.2 Gen2, 4 x USB 3.2 Gen1, 4 x USB 2.0.
• 1 x M.2 Key E, 1 x M.2 Key M, 1 x M.2 Key B, 6 x COM, 6 x SATA3.
• 1 x Intel 1 Gigabit LAN, 1 x Intel 2.5 Gigabit LAN.
• Support Triple display, 1 x DP 1.2, 1 x VGA, 1 xHDMI 2.0a.
• TPM 2.0 onboard.
• ATX-PWR (24+8-pin)....

Internal Memory	4GB DDR2
Chipset	Intel 945GC/ICH7
CPU	Core(TM) 2 Duo
LAN	GbE
USB	8 (2.0)
Model Name/Number	PCA-6010VG-00A1E
Memory Size	4GB DDR2

                        Overview:-

• PCA-6010VG-00A1E Advantech LGA775 Intel® Core™2 Duo SBC with Dual GbE and DVI.
• Advantech Intel® 945GC platform - Supports duo core processor up to 3.06 GHz.
• Supports dual channel DDR2 533/667 SDRAM up to 4 GB - Compliance with PICMG 1.0 - One Gigabit Ethernet delivers excellent network performance.
• Compact system with full configuration & expandability.
• Supports up to five full-size add-on cards.
• Accepts standard optical drive, FDD, and 3.5" HDD.

ADVANTECH SBC ; ADVANTECH INDUSTRIAL PC ; ADVANTECH PC ; ADVANTECH DEALER IN INDIA^.

Processor Support	Intel Core
Brand	Axiomtek
CPU Sockets	Single socket
Form Factor	ATX
Usage/Application	INDUSTRIAL
RAM Type	DDR4 ECC
Max RAM Capacity	128 GB
Model Name/Number	IMB 700
Graphics Card Type	Integrated
LAN Ports	2 x LAN
Storage Interface	SATA
Board Condition	New

 >>IMB -700 Inustrial Server board-

• Intel® Xeon® Scalable processor (Ice Lake-SP)
• Six 288-pin DDR4-3200 RDIMM for up to 384GB of memory
• 3 PCIe x16, 3 PCIe x8
• Supports M.2 Key M
• TPM 2.0 supported (optional)
• Supports multiple graphic cards
• Supports internal USB dongle

Introduction

The IMB700 is powered by the latest dual LGA4189 socket 3rd Gen Intel® Xeon scalable processors (code name: Ice Lake-SP) with the Intel® C621A chipset.
The IMB700 offers rich expandability with three PCIe x16 slots, three PCIe x8 slots and M.
2 Key M 2280 interface with PCIe x4 signal for adding GPUs, capture cards, RAID cards, high-speed NVMe storage, etc.
Six SATA-600 ports with integrated RAID 0/1/5/10 are available for reliable data storage and protection.
For a wide range of I/Os, it has an internal USB dongle, six USB 3.1 Gen1 ports, seven USB 2.0 ports, one RS-232/422/485 port, two GbE LAN ports with Intel® Ethernet controller i210-AT, one VGA port, eight-channel programmable digital I/O port, one HD Codec audio, SMBus, and one PS/2 keyboard and mouse.
Trusted Platform Module 2.0 (TPM 2.0) is available to ensure critical information security.
Furthermore, it can operate under a wide temperature range from 0°C to +60°C for use in harsh environments.
More features include watchdog timer and hardware monitoring functions.
Featured with built-in AI and crypto acceleration functions as well as advanced security capabilities, the IMB700 is targeted at markets requiring accelerating performance, high security, high-performance computing for efficient machine and deep learning workloads.



Model Name/Number	ROCKY-3782EV V2.0 Industrial Motherboard
Form Factor	CPU Card
Material	PCB
Model No	RS232
Power Source	12vDC

Rocky-3782EV V2.0 Industrial PC- Motherboard

• IEI ROCKY-3782EV V2.0 V2.1 industrial motherboard CPU Card .

Processor Support	Intel Atom
Form Factor	Mini-ITX
Operating Temp	-20 to 60 C
RAM Type	DDR3
Power Input	ATX 24 pin
I O Ports	Dual LAN, 4 x COM, 4 x USB
Graphics Card Type	Integrated
Warranty	1 year
Storage Interface	SATA
Usage/Application	Industrial
Brand	D525 Mini ITX

ATOM D525 MINI ITX MOTHERBOARD DC12V-
Embedded Intel Atom D525 dual core processor(1.86GHz)

Processor Support	Intel Core i5
Brand	Advantech
Operating Temp	-20 to 60 C
Form Factor	ATX
Model Name/Number	Advantech Industrial PC Mini-iITX Motherboard
Graphics Card Type	Integrated
Color	Green

* Advantech AIMB - 784G2 Industrial  Motherboards. -

>>FEATURES :<<

• Supports Intel Core i7/i5/i3 processor with Q87 chipset.
• Four DIMM sockets support up to 32 GB DDR3 1333/1600.
• Supports triple display VGA/2 DVI-D and dual GbE LAN.
• Supports SATA RAID 0, 1, 5, 10, AMT9.0, USB 3.0.
• Supports Advantech LPC modules of TPM.
• Software APIs: SM Bus / H/W Monitor / Watchdog.
• Utilities: Monitoring.

Additional Information:

• Item Code: MANO800

Usage/Application	Computer
Form Factor	ATX
Model Name/Number	ASMB-786
Warranty	1 YEAR
Country of Origin	Made in India

Features

IMG31 is a high-performance Intel Pentium 4 motherboard.

The system core logic is based on IntelG31 + ICH7 Chipsets.

It is integerated.

IMG31 is a high-performance Intel Pentium 4 motherboard.

The system core logic is based on IntelG31 + ICH7 Chipsets.

It is integrated with two RTL8111C Ethernet controllers.

CPU
 - SUPPORT 5XPCI , 2 * ISA SLOTS.
- Support FSB 533/800/1066 CPU.
- Support Intel Pentium HT(Hyper Threading Technology)CPU.
- Support Intel Conroe Socket775 CPU.
- Support Intel Conroe-L Socket775 CPU.
- Support Intel Pentium D Socket775 CPU.
- Support Intel Pentium 4 Socket775 CPU.
- Support Intel Celeron D Socket775 CPU
Chipset.
- IntelG31 + ICH7 chipsets
- ITE IT8712F LPC controller
- RTL8111C Ethernet controller

Main Memory

- Four 240-pin DDRII sockets.
- Support DDRII 400/533/667 SDRAM up to 4GB.
VGA - Integrated Graphics controller in GM350 GMCH
- Integrated Intel Graphics Media Accelerator 950
- One VGA Port it can accelerate DirectX 9 performance of hardware,400MHz core frequency,up to 224MB display memory.
Ethernet
- Onboard two RTL8111C 10/100/1000Base-T
Ethernet controllers
- Full-Duplex supported
IDE SATA & FDD
- One enhanced PCI IDE channels which support up to
2 IDE devices
- Four SATA devices
- Support ATA-100, data transfer rate up to 100MB/sec
- One FDC supports 1.2M/1.44M/2.88M FDD
PCI-E PCI ISA AUDIO COM &LPT
- Support One PCI-E X16 devices
- Support five PCI devices
- Support two ISA devices
- Support 7.1 HDAudio
- Support two COM
- Support one LPT
System BIOS
- Award BIOS with 4MB Firmware Hub
- ACPI/PnP supported
- Software WatchDog supported
I/O Output
- Two COM port & one Printer port
- One DB-15 VGA port
- PS/2 mouse and keyboard connectors
- Double Deck downstream USB 2.0 ports
- Two RJ-45 LAN ports
Expansion Slots
- Five PCI slot
- Two ISA slot
Form Factor:
- Flex-ATX @ 305 mm (L) x 244 mm (W), 4 Layer

Usage/Application	Industrial
Model Name/Number	PCM-9584
Brand	Advantech

ADVANTECH PCM-9584 REV.A2

Processor Series	Intel Pentium
Brand	Intel
Processor Generation	p4
Processor Speed	2.0 GHz
Usage/Application	Industrial PC
Processor Socket	Socket 370
Number Of Cores	4 Core
Compatible Brand	Advantech
Memory Size	4 GB
Model Name/Number	PCA-6011 Advantech Single Board Computer for Industrial PC
Support OS	windows XP
Memory Card Slot	2
Usage	Industrial
Warranty	3 Months
Packaging Type	Antistatic Package
Material	Mild steel
Colour	Green
Product type	CPU

PCA-6011VG-

• Industrial PC Mainboard Full-Size CPU Card PICMG1.0
• 2-Ethernet with CPU RAM.

Additional Information:

• Delivery Time: Immediate

Form Factor	ATX
Brand	Intel
Usage/Application	Industrial Motherbaord


 AIMB-750 Industrial Motherboard

Form Factor

ATX

Ethernet Chipset

Intel 82541

System Chipset

Intel 855GME

Video Chipset

Intel 855GME

-20 ~ 70° C (-4 ~ 158° F)

System

1.5 GHz and above (400 FSB)

System

4.09 A 2.77 A 0.75 A 2.0A

System

512/1024 KB

System

Audio

2 (Line-Out and Mic-In)

Battery

AGP 2.0 with 4x, 1.5V

BIOS

Award 4 Mbit FWH

Channel

2

Channel: 2 (Max. 4 devices)

System

Chipset

Intel 855GME + 6300ESB

Connector

RJ-45 x 2

Controller

Chipset integrated VGA controller
LAN 1: Intel 82551QM (FE); Intel 82541PI (Gigabit)

CPU

Intel Pentium M

Dimensions

304.8 x 243.6 mm (12" x 9.6")

EIDE

Mode: ATA 100/66/33

Environment

Operating Temperature:

FDD

1

FSB

400 MHz

Input

10/100Base-T or 10/100/1000Base-T

Intel Celeron M

System

Interval: Programmable 1 ~ 255 sec.

System

L2 Cache

1024/2048 KB

LAN 2: Intel 82551QM (FE); Intel 82541PI (Gigabit)

System

LVDS

1 (single channel 18-bit/ dual channel 36-bit)

Max Capacity

2 GB

Max Data Transfer Rate

150 MB/s

Max. Speed

2.1 GHz and above (400 FSB)

Parallel

1 (SPP/EPP/ECP)

PCI

32-bit/33 MHz, 4 slots

PCI Express

64-bit/66 MHz, 2 slots

Power Consumption

Pentium M

Processor

Intel Pentium M

PS/2

2 (keyboard and mouse)

Serial

4 (RS-232, 1 port and 3 onboard pin headers)

Socket

184-pin DIMM x 2

Technology

Single channel DDR 200/266/333 SDRAM with ECC/non-ECC support

USB

4 (USB 2.0, 480 Mbps; 2 headers and 2 external ports)

VGA

1

VRAM

Dynamically shared system memory up to 64 MB

Watchdog Timer

Output: Reset

Features



• AGP 4X slot
• Chipset integrated VGA
• CMOS automatic backup and restore to prevent accidental data loss of BIOS setup data
• Compatible with Advantech’s 1U, 2U, 4U, 5U and 7U chassis
• Intel 855GME with 6300ESB chipset 400 MHz FSB
• Onboard LVDS connector support 36-bit dual channel LVDS
• Supports 2 64-bit/66 MHz PCI-X expansion
• Supports Dual 10/100Base-T Ethernet or 10/100/1000Base-T Ethernet
• Supports single channel DDR 200/266/333 SDRAM with ECC/non-ECC support
• Supports up to two devices with software Serial ATA RAID 0, 1

Type	Single Board Computers
Model Name/Number	WSB-9454
Usage/Application	Industrial Motherboard
Brand	Advantech
Humidity	5% ~ 95%, noncondensing
Memory Max.	240-pin 1 GB (max.) 667 MHz, 533 MHz or 400 MHz dual-channel DDR2 SDRAM DIMMs supported (system

-WSB-9454 PICMG 1.0 Full-Size CPU Card

• Support LGA775 Socket for Intel® Core 2 Duo/Pentium D Processor
• Intel® 945G+ICH7 Chipset
• 4x 240-pin DDR2 SDRAM DIMMs (Max. 4GB)
• 2x Gigabit Ethernet Controller
• 7x USB2.0 Port and 2x COM Port
• 4x SATA 3.0Gbps Port

Additional Information:

• Production Capacity: 1
• Delivery Time: immediate

Chipset	Intel
Brand	TYAN boards
Model Name/Number	TYANS5217
Usage/Application	INDUSTRIAL
Graphics Card Type	Integrated

 TYAN
-S5217-Industrial motherboards

FEATURES : -

SBC MIPS Intel, Kentsfield/Yorkfield/Conroe/Wolfdale Dual Core 8MB Flash.

Model Name/Number	ARCOM SBC GX-FX Series Motherboard
Form Factor	ATX
Power Consumption	9 W
Mechanical	5.25 Form Factor
Operating Temperature	0 To +60 Deg C (standard) -20 To +60 Deg C (extended)
Compliant Power Supply	Single +5v Dc

-Specification:-

• Defense Architecture: 5.25 form factor.
• CPU: AMD Geode GX533 400MHz Integrated CRT or TFT graphics controller.
• Memory: Up to 512 MB 266MHz DRAM (SO-DIMM soldered inside) Up to 32MB onboard AMD Mirror Bit Flash Memory 256kB battery-backed SRAM Compact Flash (CF+).
• Video: Dual display with TFT/DSTN/CRT support.
• Touchscreen : 4-wire analogue touchscreen controller (UCB1400).
• Audio : AC97 Audio CODEC
• Ethernet: Dual 10/100baseTx
• Ethernet Serial Ports: 3x RS232 1x RS232/RS422/RS485.
• USB: 2x USB 2.0 2x USB 1.1
• Integrated Security: Atmel AT97SC3201 (TPM) .
• User Jumpers: 2x user selectable jumpers.
• Other Interfaces: IDE ATA-66 hard drive port Floppy drive and USB 1 EPP/ECP bidirectional Mouse Keyboard ports 8-bit (TTL) digital I/O port.
• Expansion: PC/104+ (PCI 32-bit) PC/104 (ISA 16-bit) RoHS. Compliant.
• Power Supply: Single +5V DC.
• Power Consumption: 9W typical.
• Mechanical: 5  form factor
• Dimension: 203 x 146 mm (7.99x 5.75).
• Operating Temperature: 0 to +60°C (standard) -20 to +60°C (extended)
• Operating Systems Supported:Linux, Windows CE 5.0, Windows XP Embedded



Chipset	AMD
Usage/Application	INDUSTRIAL
Form Factor	ATX
Brand	portwell
Graphics Card Type	Integrated

-RUBY-D718VG2AR6th Gen Intel Core based Industrial ATX Motherboard-

>>Features :

• 6th generation Intel® Core™ processor family (formerly Skylake)
• Four long DIMMs support DDR4 ECC/Non-ECC SDRAM up to 64GB
• One PCIe x16 (Gen3), two PCIe x4 (Gen3), four PCI
• Dual Gigabit Ethernet
• Triple Display: VGA/DVI-D/HDMI
• Six SATA III ports
