• Digital multimeter measures voltage, current, resistance, capacitance, frequency, and duty cycles
• Average-sensing meter provides accurate readings when measuring linear loads where the current or voltage has an undistorted waveform
• Measures duty cycles to 99.99%, indicating the percent of time a circuit is on
• Audible continuity sensor confirms a circuit conducts electricity, and a diode test detects proper functioning of a circuit's diodes
• Meets International Electrotechnical Commission (IEC) safety standard 61010 and is certified for Category II installations up to 600V and Category III installations up to 300V

• High Accuracy, High Performance and Reliable Measurements
• 0.09% basic DC accuracy
• Large display with 6,000 counts
• True-RMS Measurements
• Low-pass filter for motor drive measurements

• DC V	600.0mV/6.000/60.00/600.0/1000V (Input impedance: 10MΩ [600mV/60/600/1000V], 11MΩ [6V]) ±0.09%rdg±2dgt (Basic accuracy)
  AC V	600.0mV/6.000/60.00/600.0/1000V (Input impedance: 10MΩ<200pF [600mV], 11MΩ<50pF [6V], 10MΩ<50pF [60/600/1000V]) ±0.5%rdg±5dgt (Basic accuracy)
  DC A	600.0/6000µA/60.00/440.0mA/6.000/10.00A ±0.2%rdg±2dgt (Basic accuracy)
  AC A	600.0/6000µA/60.00/440.0mA/6.000/10.00A ±0.75%rdg±5dgt (Basic accuracy)
  Ω	600.0Ω/6.000/60.00/600.0kΩ/6.000/60.00MΩ ±0.4%rdg±1dgt (Basic accuracy)
  Continuity buzzer	600.0Ω (The buzzer turns on for resistances lower than 50±30Ω)
  Diode test	2.000V ±1%rdg±2dgt Open curcuit voltage: <3.5V (Approx. 0.5mA Measuring Current)
  Capacitance	10.00/100.0nF/1.000/10.00/100.0/1000µF ±2%rdg±5dgt (Basic accuracy)
  Frequency	10.00 - 99.99/90.0 - 999.9Hz/0.900 - 9.999/9.00 - 99.99kHz ±0.02%rdg±1dgt (Basic accuracy)
  Temperature	-50 - 600ºC ±2%rdg±2ºC (with the use of K-type Temperature probe)
  Other functions	Data Hold (D/H), Auto Hold (A/H), Range Hold (R/H), Zero Adjustment (Capacitor, Resistance), LCD backlight
  Applicable standards	IEC 61010-1 CAT IV 600V, CAT III 1000V Pollution degree 2, IEC 61010-031, IEC 61326-1 (EMC)
  Display	6,000 counts
  Power source	R6 (1.5V)×4 (Auto power off: approx. 20 minutes)
  Dimensions	192(L)×90(W)×49(D) mm
  Weight	Approx. 560g (including batteries)
  Included Accessories	Accessories 7220A (Test leads), R6×4, Instruction manual, 8926 (Fuse [440mA/1000V])×1 (included) 8927 (Fuse [10A/1000V])×1 (included)

Additional Information:

• Delivery Time: READY STOCK
• Packaging Details: BOX

Additional Information:

• Item Code: M266F
• Delivery Time: READY
• Packaging Details: Accessories: Instruction Manual, 1 Set Test Leads, 9 Volt Batteries, Carrying Cover. 1PCS CONTAIN WITH ONE BOX

• Count: 4000
• AVG responding
• Voltage: DC: 1000 volts; AC: 1000 volts; DC Accuracy: ± 0.5% + 3 digit; AC Accuracy: ± 1% + 3 digit
• Current: DC: 10 amps; AC: 10 amps; DC Accuracy: ± 1.5% + 3 digit; AC Accuracy: ± 1.5% + 3 digit
• Resistance: 40 M ohm; Resistance Accuracy: ± 1.5% + 3 digit
• Capacitance: 1000 μF; Capacitance Accuracy: ± 5% + 5 digit
• CAT III 600 volts safety rating
