Timer
Industry College And School Automatic Bell Manual Button Type (Optional Bell)
₹ 3,500/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
Watch Video
| Material | Mild Steel |
| Usage/Application | School industrial college bell |
| Display Type | LCD display |
| Alarm Range | 230 voltage any range optional |
| Warranty | 12 month warranty |
| Color | White |
| Voltage | 230volt |
| Brand | KISAN GANGA |
| Country of Origin | Made in India |
| 100mm 140mm 60mm | Less then 1 kg |
Electrical 230volt school college industrial bell
For RTC Timer based trigger
https://youtu.be/4rjcp4ZljRI
View Complete Details
| Current Rating | 20A |
| Usage/Application | Industrial |
| Input Voltage | 230vac |
| Number Of Programing Channels | 2 channel |
| Awg Gauge | 2 Square mm or above |
| Fixing Mode | Din Rail mount |
| Connections-Terminals | Screw terminals |
Top Highlights Work Two AC load up to 20A Two modes available Auto and Manual In auto mode gap time 30 Minute, 1Hrs, 2Hrs, 3Hrs, 4Hrs In manual mode choose AC-1 & AC-2 as per requirement Din channel mounting for easy installation Description AC changeover Timer useful for the change AC load change alternatively on regular duration of time. It can be useful in ATM machine room for change air condition on off alternatively. The timer is suitable for any load up to 16 Amps (16A On both Output). This timer finds application in both domestic as well as industrial fields. Cyclic timer, where On and Off duration can be programmed by the user. Do not connect electrical loads exceeding 16 amps to avoid damage to the product, otherwise the manufacturer will not be responsible.16 amp MCB must be connected between the power supply and the device. Equipment should only be installed by a qualified electrician to prevent risk of electric shock. Install the device out of the reach of children.
View Complete Details
| Current Rating | 8A |
| Display | Analog |
| Material | ABS |
| Mounting Type | Din Rail Mounting |
| Usage/Application | Industrial |
| Brand | SELEC |
| Switch Type | Shutter Timer |
| Voltage | 230V |
Selec 800 Sq A Din Rail Mounting Timer
View Complete Details
Dry Run Cyclic Timer 3phase Voltage Low Reverse Protection
₹ 3,800/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
Watch Video
| Pump Power | 10 HP |
| Input Voltage | 415 V |
| Phase | Three Phase |
| Mounting Type | Wall Mount |
| Control Method | Current Sensing |
| Suitable For | Submersible Pump, Openwell Pump, Borewell Pump, Monoblock Pump |
| Country of Origin | Made in India |
Main Highlights:
1. Power ON Display Information
- Shows voltage, current, two or three phase status, and operating mode (Auto or Manual)
- Displays I as ampere setting value
- Live current shown when motor is ON
- COTR = Cyclic ON Timer (minutes)
- CFTR = Cyclic OFF Timer (minutes)
- RT = Run Time (minutes)
- TT = Total Timer
2. RYB LED Phase Indicators
- Three LEDs show RYB phase condition
- If all phases are OK, all three LEDs glow continuously
- If any phase is missing or faulty, the respective LED blinks
- LEDs work only in normal mode, not in setting mode
3. Button and Rotary Controls
- Rotary Knob: Rotate to adjust values
- Short Press (2 seconds): Save the adjusted value
- Green Button: Move up or next option
- Red Button: Move down or previous option
- Overcurrent Setting: Keep 2 amps above live running current
Example: If motor draws 10A, set overcurrent as 12A
4. HP Setting Mode
- Long press Rotary Knob for more than 5 seconds
- HP range available from 3HP to 40HP
- Existing Panel option:
ON = Simple ON/OFF operation
OFF = Star-Delta operation with additional relay
- Long press again for 5 seconds to exit and save
5. Advanced Setting Mode
- Press and hold Rotary Button and Red OFF Button together for 5 seconds
- Display shows: "Setting mode press key to continue"
- Use Green Button to navigate options
- Use Rotary Knob to increase or decrease values
- You can adjust each setting one by one and save all settings together in one step
Available Settings:
1. Auto delay 3 phase
2. Star delta delay
3. Over voltage limit setting
4. Dry run trip amps
5. Dry run trip delay
6. Dry run restart in minutes
7. Unbalance trip percentage
8. CT coil ratio
9. Cyclic timer ON or OFF
10. Cyclic ON timer in minutes
11. Cyclic OFF timer in minutes
6. Save and Exit
- After completing all adjustments, long press the Rotary Button for 5 seconds
- Display shows "Exit and Save" and all settings are stored
7. Important Notes
- RYB LEDs indicate supply condition in normal mode
- Settings should be made only when the motor is OFF
- Always set overcurrent slightly above actual running current
- Cyclic timers are especially useful for borewell applications for automatic rest and restart
ANAGHA AUTOMATION – Smart Control, Reliable Performance
