Anton Paar India Private Limited

Measurement Range	500 kg/m³ to 2000 kg/m³
Technology	Vibrating U Tube
Mounting	Inline
Accuracy	1 kg/m³
Temperature Range	-10 to 60 °C
Display Type	No Display
Application	Pharma, Chemical, Food And Beverage, Oil And Gas
Process connection	Flange plate & adapters
Process density range	500 kg/m cube to 2000 kg/m cube
Process temperature	95 degree C for max. 30 min.
Dimensions	99 mm x 34 mm x 34 mm
Communication	RS-232
Flow rate	10 L/h to 70 L/h



The L-Dens 2300 liquid density sensors are compact OEM modules with an accuracy of 1 kg/m³. Their small size makes them easy to integrate into measurement systems. The 2 mm oscillating U-tube requires only very low flow rates, and particles with a size of up to 0.7 mm can be handled with ease.

The instruments are available with a stainless steel or glass oscillator. Use them to measure the density of non-corrosive media, such as fuels, and aggressive media, such as sulfuric acid.



Additional Information:

• Delivery Time: 3-4 weeks

Usage/Application	Laboratory
Process density range	500 kg/m cube to 2000 kg/m cube
Density measurement	Minus 10 degree Celsius to 60 degree Celsius
Ambient temperature	Minus 10 degree Celsius to 40 degree Celsius
Flow rate	10 L/h to 70 L/h
Dimensions	165 mm x 155 mm x 91 mm
Material of the wetted parts	Borosilicate glass

L-Dens 3300: An entry-level model for all industries

·       Get 3-digit accuracy at an excellent price-performance ratio with these inline density meters
·       Stay flexible with integrated applications
·       Measure non-corrosive liquids, like cleaning fluids, as well as aggressive liquids, such as sulfuric acid, with a stainless steel or glass oscillator
·       Use the L-Dens 3300 in every industry

Additional Information:

• Delivery Time: 3-4 weeks

Process density	Max. 3000 kg/m cube
Standard adjustment range	600 kg/m cube to 1200 kg/m cube
Process temperature	Minus 40 degree Celsius to 125 degree Celsius
Recommended flow rate	100 L/h to 500 L/h
Dimension Non Ex version	245 mm x 145 mm x 185 mm
Density measurement	0.1 kg/m cube
Model	L-Dens 7400



The L-Dens inline density meters are more than just state-of-the-art measuring instruments – they’re the result of over 40 years of practical experience in process density measurement. The L-Dens 7000 series combines high accuracy and a compact design, making it the first choice for precise density and concentration measurements. Thanks to the modular system and the wide range of integration options, these instruments can be easily integrated into measurement systems or production equipment.
