• Calibrated ready for use

• Instant readings on a clear, easy to read scale

• Fully portable, battery operated and non-destructive

Types of Moisture Meters

On porous materials such as concrete, plaster, brick, wood, the moisture content of the substrate should be measured, as the presence of moisture within a material will result in poor adhesion, premature coating failure and poor appearance.

It is not sufficient to simply ensure that the surface is dry as often the surface of the substrate is the driest point – due to evaporation. It is important to establish the moisture content within the substrate itself.

When powder coating wooden panels, for example, if the wood (or mdf) has too high a moisture content, as the panel passes through the oven, the moisture is heated, generating steam – causing significant coating finish issues.

Applying a coating to a concrete floor which is too damp can cause premature adhesion failure. Moisture meters have been developed to specifically determine the level of moisture in a substrate and come in two forms:

Pin-type moisture meters:
Invasive pins are pushed firmly into the surface of the substrate being measured and by measuring the electrical resistance between the pin electrodes provide the percentage moisture content (%MC) in the substrate.

On porous materials such as concrete, plaster, brick, wood, the moisture content of the substrate should be measured, as the presence of moisture within a material will result in poor adhesion, premature coating failure and poor appearance.

It is not sufficient to simply ensure that the surface is dry as often the surface of the substrate is the driest point – due to evaporation. It is important to establish the moisture content within the substrate itself.

When powder coating wooden panels, for example, if the wood (or mdf) has too high a moisture content, as the panel passes through the oven, the moisture is heated, generating steam – causing significant coating finish issues.

Applying a coating to a concrete floor which is too damp can cause premature adhesion failure. Moisture meters have been developed to specifically determine the level of moisture in a substrate and come in two forms:

Dry (green); 70 - 169

At risk (yellow); 170 - 199

Wet (red); 200 - 999

7.9% to 99% WME (pin measurement)

Dry (green); 7 - 16.9

At Risk (yellow); 17 - 19.9

The Elcometer 213/2 Digital Waterproof Thermometer offers the latest microprocessor technology, superior durability and is designed for reliability and ease of use.

Features:

• Rubber bumper seals for impact resistance
• Waterproof case (IP66 & IP67 protection)
• Extruded aluminium case for superior durability
• °C/°F switchable
• Easy to read LCD display

Probes are available to purchase separately.

Additional Information:

• Packaging Details: Elcometer 213/2 Digital Waterproof Thermometer, battery, carry case and operating instructions, Magnetic Surface Probe; 13mm (0.51") Diameter, Surface Probe; 130 x 4.2mm (5.11 x 0.17¿¿¿) Diameter, Liquid Probe; 130 x 3mm (5.11 x 0.12¿¿¿) Diameter, Needle Probe; 130 x 3mm (5.11 x 0.12¿¿¿) Diameter

This product is an infrared camera that integrates surface temperature measurement and real-time thermal image. The traditional inferred thermometer needs to measure every component one by one while it is not necessary for infrared imaging camera, thus saving time. The potential problems may be displayed on color display screen clearly. Moreover, the central point measurement cursor is used to locate quickly and accurately to measure the temperature of the target object.In order to increase the differentiation, the product is provided with a visible light camera. The thermal images and visible images are stored in the device and can be read through USB or stored in a computer to generate a report or for print. With small volume, the product is easy to operate and has strong function. it is the ideal selection for electric power, electronic manufacturing, Industrial inspection and other fields.

It is often important to ensure the temperature of the paint to be applied is at a temperature which will ensure correct application.

The Elcometer 210 Paint Thermometer is supplied with a clip to enable the thermometer to be hooked on to the edge of a paint can allowing accurate temperature measurement of the paint.

The magnetic thermometers are based on a bimetallic strip and therefore do not require batteries but do require time to adjust to the temperature.

Available in a number of scale ranges, the Elcometer 113 surface thermometer is also available as an economy version.

Additional Information:

• Packaging Details: Elcometer 113 Magnetic Thermometer and protective pouch

we are engaged in providing the broad assortment of Dewpoint and relative humidity meters, thermometers, digital thermometers, hygrometers, data loggers, moisture meters and anemometers to monitor climatic conditions.

Using state of the art electronics "Dewpoint Meter" is rugged instrument designed to measure and record all relevant climatic parameters required to determine the all critical conditions. Dewpoint meter can be used as a hand-held gauge with data logger - ideal for monitoring climatic conditions over a period of time.

large and easy to use illuminated display, users can record climatic parameters and use the 10 reading rolling memory.

• A hand-held Dewpoint meter with manual and interval data logging in one gauge
• Integrated magnets allow remote data monitoring on steel substrates
• Dustproof and waterproof gauge with fully sealed sensors (equivalent to IP66)
• Visual and audible indication of user defined limits against any or all parameters
• Large, customer definable illuminated display operates over the full temperature range
• Store 25,000 records in up to 999 batches
• USB and Bluetooth data output to a PC or PDA
• Readings are switchable between Celsius and Fahrenheit
• Time and date stamp is recorded for each set of readings
• Arrow indicators show temperature trends
• Integrated K-Type connector allows measurement of surface temperature during remote logging
• Hold/freeze function allows manual readings to be taken and reviewed before being logged into memory
• Adjustable limits can be set for each measurement parameter which triggers visual and audible alarms whenever a limit is exceeded - even if it is not displayed on the screen
• Clear, illuminated display showing up to five parameters from
  RH % Relative Humidity
  Ts Surface Temperature
  Ta Ambient Air Temperature
  Td Dewpoint Temperature
  T the difference between the Td and Ts
  Tdb Dry Bulb Temperature
  Twb Wet Bulb Temperature
  SH Specific Humidity
• Data can be downloaded to a PC via USB or Bluetooth and evaluated using ElcoMaster 2.0 Software

A well-integrated service support is provided from service centre with team of trained customer support group headed by a Service Manager, who double up for technical & application support to our customers.

The lightweight impeller with high precision jewel bearings provides very accurate airflow measurements even at low speeds. The anemometer's impeller can easily be replaced without the need to return the unit to Elcometer.

The wind speed can be displayed in various measurement units; indicating current speed, maximum speed or average speed.

• Rugged and durable: Anemometer is made from high impact injection moulded plastic and corrosion resistant materials.

• Waterproof: Waterproof equivalent to IP67 with fully sealed electronics. Will also floatin water if dropped.

• Clear LCD Display: Easy to read, large 9mm digits.

• Choice of measurement units:
  • Beaufort Force
  • Knots
  • Kilometres per hour
  • Metres per second
  • Miles per hour
  • Feet per minute

Incorporating a fast response stainless steel liquid or surface probe, the Elcometer 212 provides temperature readings in under four seconds.

Housed in a water resistant case with integrated rubber seals and a moulded flush window, preventing dirt and leaks damaging the LCD display, the Elcometer 212 is ideal for use in the harshest of environments.

The probe conveniently folds back into the side of the instrument, preventing damage when not in use.

• Liquid or surface probe options available
• User switchable between °C and °F
• Resolution can be set to 0.1°C (0.1°F) or 1°C (1°F)

Additional Information:

• Packaging Details: Elcometer 212 Digital Pocket Thermometer with batteries fitted and operating instructions

Delta T (TΔ) is the difference between the surface temperature (Ts) and the dewpoint temperature (Td). When TΔ is less than 3ºC (5ºF) painting should not occur.

Relative Humidity (RH)- expressed as a percentage, RH is the ratio of the amount of water vapour actually held by the air compared to the maximum amount of water vapour the air could hold at a given temperature. Typical maximum RH values specified by paint manufacturers are between 75% and 85%.

Delta T Hygrometer key features include:

• Rugged design: Suitable for use in extreme environments the digital hygrometer is dustproof and waterproof with fully sealed sensors.

• High / Low Limits: Displayed on screen graphically as either (?) or (X) with flashing Red or Green LED’s to indicate pass or fail.
  • Delta T Temperature: TΔ is pre-set at >3ºC (>5ºF), the industry norm.
  • Relative Humidity: User definable upper limit can be set for RH

• Measurement Hold / Release function: With a single button press readings are ‘frozen’ on the screen. These can then be recorded before, simply pressing the button again to ‘unfreeze’ the screen and then take further readings as necessary.

• Backlight: Provides clearly lit information – ideal in dark or confined spaces.

ø Slim probe, ideal for grilles diffusers.

ø Combination of hot wire and standard thermistor, deliver rapid and precise measurements

ø Records maximum/minimum readings with recall data hold.

ø Microprocessor circuit assures maximum possible accuracy, provides special functions and features.
Super large LCD display with backlight, reading the air velocity temp. at the same time.

ø Data Hold.

ø Power supply by 3.7V Rechargeable Battery.

ø The portable anemometer provides fast, accurate readings, with digital readability Multi-functions for air flow measurement: m/s, km/h, ft/min, MPH, Knots build in temperature ºC / ºF Thermistor sensor for Temperature measurement, fast response time.

ø Probe length for shortest 0.32m, 1.15m for the longest elongation.

ø Line Length is 1.75m Applications: Environmental testing, Air conveyors, Flow hoods, Clean rooms, Air velocity, Air balancing, Fans/motors/blowers, Furnace velocity, Refrigerated case and Paint spray booths.

The thin pins allow easy measurement of the moisture content of sawn timber/Wood, chipboard and fibreboard materials up to a maximum thickness of 25mm (0.98”) as well as normal gypsum and mixed plaster.

• Completely automatic instrument setting
• No separate electrodes or leads required
• Handy, quick and pocket-sized for fast measurements
• Correction for two groups of wood species
• Measurement of plaster moisture content with a direct readout in percentage of dry weight
• The Elcometer Moisture Meter uses the conductivity measurement method

The electrodes transmit parallel low frequency signals, calibrated to give average moisture content by comparing the change in impedance between damp and acceptably dry concrete.

• Calibrated ready for use on concrete
• Instant readings on a clear, easy to read scale
• Fully portable, battery operated and non-destructive
