Automat Irrigation Private Limited

Material	Plastic
Brand	Automat
Flow Rate	12 - 16 m3/h
Cartridge Diameter	71.5 mm (with o ring)
Filtration Area	409 cm2
Inlet / Outlet Connection	1 1/4" BSP Female thread
Max. Working Pressure	8 Kg/cm2 (PPGF Filter)
Nominal Flow Rate	15 m3/h
Material Of Construction	Glass Filled Polypropylene / Polyamide
Screen Material	Polypropylene disc
Cartridge Length	258 mm
Available Mesh	120 mesh

Simple, compact & cost-effective fully automatic disc filter to protect & improve the efficiency of your irrigation system.

Material	PVC
Size	1.5 inch
Color	Black
Brand	Automat
Product Code	HT-AQ- 134Y
Shape	Y
Usage	Plumbing

2” Y-Type Disc filter (25m3) designed for outside to inside flow. Filter body and cap connected by threaded connection to sustain high pressure & easy opening and closing. Disc cartridge is spring loaded for uniform compression of discs. Filter designed for maximum operating pressure of 6 Bar.

Features

• Disc filters designed for outside to inside flow.
• Auxiliary connections: Two pressure gauge ports with ¼” male threaded connection.
• Filter body and cap connected by threaded connection to sustain high pressure and easy opening and closing.
• High Filtration efficiency
• Spring loaded Disc cartridge for uniform compression of discs.
• UV protected, chemical and high pressure resistant reinforced plastic material used.

Material	Plastic
Brand	Automat
Flow Rate	25 - 35 m3/h
Cartridge Diameter	122 mm (with o ring)
Inlet / Outlet Connection	2 1/2" BSP Male Thread
Nominal Flow Rate	30 m3/h
Filtration Surface Area	878 cm2
Material Of Construction	Glass Filled Polypropylene / Polyamide
Material Of Disc	Polypropylene Disc
Cartridge Length	305 mm
Available Mesh	150

We are offering Automat HT 135T (HC) Disc Filter to our valuable customers.

Available Mesh: 80, 120

Material	Plastic
Brand	Automat
Flow Rate	35 - 45 m3/h
Cartridge Diameter	122 mm (with o ring)
Inlet / Outlet Connection	2 1/2" BSP Male Thread
Nominal Flow Rate	40 m3/h
Filtration Surface Area	1193 cm2
Material Of Construction	Glass Filled Polypropylene / Polyamide
Material Of Disc	Polypropylene
Cartridge Length	388 mm
Available Mesh	150

We are offering Automat HT 135TL HC T Type Disc Filter to our valuable customers.

Available Mesh: 80, 120

Material	Plastic
Brand	Automat
Flow Rate	45 - 52 m3/h
Cartridge Diameter	122 mm (with o ring)
Filtration Area	1690 cm2
Inlet / Outlet Connection	3" BSP Male Thread
Nominal Flow Rate	50 m3/h
Material Of Construction	Glass Filled Polypropylene / Polyamide
Material Of Disc	Polypropylene
Cartridge Length	515 mm
Available Mesh	150
Max. Operating Pressure	6 kg/cm2
Clamp Material	Nylon Reinforced
Vacuum Breaker	For upside down installation
Drain port location	Front of the filter body

We are offering Automat HT 136T HC T Type Disc Filter to our valuable customers.

Available Mesh: 80, 120

Material	Plastic
Nominal Flow Line	176 GPM
Filtration Surface area	186 in2
Filter Medium Material	Metal
Brand	Automat
Flow Rate	500 cubic meters/hr
Color	Black

Features:

• Max. Operating Pressure: 8 kg/cm²
• Clamp Material: Stainless Steel
• Vacuum Breaker: Not fit with this design
• Drain port location: Below the Filter barrel

Specifications:

Additional Information:

• Item Code: AQ-136TS

Material	Plastic
Size	1.5 inch
Nominal Flow Line	110 GPM
Filtration Surface area	136 in2
Brand	Automat
Flow Rate	500 cubic meters/hr
Color	Black

Features:

• Max. Operating Pressure: 6 kg/cm²
• Clamp Material: Nylon Reinforced
• Vacuum Breaker: For upside up installation
• Drain port location: Front of the filter Body



Specifications:

Material	Plastic
Size	3 inch
Range of Flow Rate	50 -70 GPM
Cartridge Diameter	2.76
Filter Medium Material	Metal
Brand	Automat
Color	Black

Specifications:

Additional Information:

• Item Code: AQ-133T

Material	Plastic
Brand	Automat
Purpose	Vegetable Garden
Shape Of Dripline	Cylindrical
Color	Black
Model	AQ 131Y

Specifications:

Additional Information:

• Item Code: AQ-131Y

Material	Plastic
Brand	Automat
Model No.	HT-AQ- 131Y
Inlet/Outlet Connection	3/4 Inch BSP/NPT Thread
Max. Working Pressure	8 kg/cm2
Range Flow Rate	5 m3/h
Nominal Flow Rate	3 m3/h
Filteration Surface Area	147.5 cm2

3/4” BST/NPT Male thread connection size with 147.5 cm2 filtration coverage area.

Features

1. Disc filter designed for outside to inside flow.

2. Filter body and cap connected by threated connection to sustain high pressure and easy opening & closing.

3. High filtration efficiency.

4. Spring loaded disc cartridge for uniform compression of discs.

5. UV protected, chemical and high pressure resistant reinforced plastic material used.

Applications

      1. Landscape & turf, kitchen garden, small nurseries:

   -  Removes physical impurities which prevents clogging of emitting devices having        small aperture.

     2. Household water tank:

- Removes physical impurities from water supply collected in rooftop tanks.

- It further helps in reducing the load on R.O. filter & other appliances.

Material	Plastic
Brand	Automat
Model No.	HT- 534T
Recommended Flow	25 m3/h
Filter Disc	120 Mesh
Inlet/Outlet Connection	2" Male Threaded
Closing System	Polyproplene Glass Filled Clamp

Ideal for 2” male threatened inlet/outlet connection with 878 filtration surface area.

Features

• Flow passes through outside to Inside of disc cartridge.
• Threated brass insert, 2 pressure ports for increasing operational life of filter.
• Surface sealing design, O-ring on periphery of the barrel to ensure the sealing and prevent leakage with time.
• New complete plastic clamp for fast assembly and disassembly the filter housing.
• Easy Disc cartridges installation inside the filter.
• Barrels equipped with 1” Vacuum breaker to release/intake of air and prevent filter from damage.

Color	Black
Brand	Automat
Model No.	AQ-133YM
Max. Working Pressure	8 kg/cm2
Cartridge Dia.	71.5 mm
Cartridge Length	258 mm

1½” Y-Type Disc filter (15m3) designed for outside to inside flow. Filter body and cap connected by threaded connection to sustain high pressure & easy opening and closing. Disc cartridge is spring loaded for uniform compression of discs. Filter designed for maximum operating pressure of 6 Bar.

Features

1. Filter body and cap connected by threaded connection to sustain high pressure.

2. Connection size - 1½” Y-Type Disc filter

Covers 409 cm2 filtration area.

Material	Plastic
Size	2 inch
Color	Black
Brand	Automat
Model No.	AQ-132Y
Cartridge Dia.	48 mm
Cartridge Length	180 mm
Filtration Surface Area	147.5 cm2

Filter body and cap connected by threaded connection to sustain high pressure & easy opening and closing.

Features

1. Disc filter designed for outside to inside flow.

2. Filter body and cap connected by threated connection to sustain high pressure and easy opening & closing.

3. High filtration efficiency.

4. Spring loaded disc cartridge for uniform compression of discs.

5. UV protected, chemical and high pressure resistant reinforced plastic material used.

Material	Plastic
Color	Black
Brand	Automat
Model No.	AQ-131Y
Mesh	120
Cartridge Length	180 mm
Cartridge Dia.	48 mm

Filter body and cap connected by threaded connection to sustain high pressure & easy opening and closing.

Features

1. Disc filter designed for outside to inside flow.

2. Filter body and cap connected by threated connection to sustain high pressure and easy opening & closing.

3. High filtration efficiency.

4. Spring loaded disc cartridge for uniform compression of discs.

5. UV protected, chemical and high pressure resistant reinforced plastic material used.

Brand	Automat
Filtration Area	147.5 cm2
Flow Rate	5- 8 m3/h
Cartridge Diameter	48 mm (with o ring)
Inlet / Outlet Connection	1" BSP male thread
Max. Working Pressure	8 kg/cm2
Nominal Flow Rate	6 m3/h
Material Of Construction	Glass Filled Polypropylene / Polyamide
Screen Material	Polypropylene disc
Cartridge Length	180 mm
Available Mesh	120 mesh

Disc filter designed for outside to inside flow. Filter body and cap connected by threated connection to sustain high pressure and easy opening & closing.

Material	Plastic
Brand	Automat
Flow Rate	12 - 16 m3/h
Cartridge Diameter	71.5 mm (with o ring)
Inlet / Outlet Connection	1 1/2" BSP male thread
Max. Working Pressure	8 kg/cm2 (PPGF Filter)
Nominal Flow Rate	15 m3/h
Surface Area Filtration	409 cm2
Material Of Construction	Glass Filled Polypropylene / Polyamide
Screen Matertial	Polypropylene disc
Cartridge Length	258 mm
Available Mesh	120 mesh

1½” & 2” Y-Type Disc filter (15m3 & 20m3) designed for outside to inside flow. Filter body and cap connected by threaded connection to sustain high pressure .

Material	Plastic
Model	HT - 134 TS
Filter Medium Material	Metal
Flow Rate (cubic meters/hr)	0-500
Brand	Automat
Flow Rate	500 cubic meters/hr
Color	Black

Features:

• DuPont Nylon Hybrid Clamp with SS lock for high-pressure operations.
• PPGF Slip-on flange for easy installation (Optimal).
• Bigger drain port with ¾” ball valve for quick drainage.
• Disc Filters are made with special Helix system which gives better performance results.

Specifications:

Fitting Type	Disc & Screen type
Nominal Flow Line	220 GPM
Filtration Surface area	262 in2
Filter Medium Material	Metal
Flow Rate	500 cubic meters/hr
Brand	Automat
Color	Black

Features:

• Max. Operating Pressure: 6 kg/cm²
• Clamp Material: Nylon Reinforced
• Vacuum Breaker: For upside up installation
• Drain port location: Front of the filter Body



Specifications:

Material	Plastic
Color	Black
Brand	Automat
Model No.	AQ-136TS(HC)
Cartridge Dia.	122 mm
Cartridge Length	388 mm
Nominal Flow Rate	176 Gpm

The filters are made from special chemically bonded polymer which are weather resistant. Disc filter made with special Helix system which gives better performance and results.

Features

• Clamp made up of Nylon reinforced material for durability.
• Vacuum breaker for upside down installation.
• Drain port is located in front of the ration body.
• Maximum operating pressure is 6 kg/cm2.
• Flow passes through outside to inside of disc stake.

Size	2.5 inch
Material	Plastic
Brand	Automat
Model No.	AQ-524TL
Max. Working Pressure	8 kg/cm2
Recommended Flow	30 m3/h
Range of Flow Rate	32 m3/h
Cartridge Dia	122 mm

Connection size of inlet/outlet is 2” with 500 cm2 filtration surface area coverage.

Features

• Flow passes through outside to inside of screen cartridge.
• Threated brass insert, 2 pressure ports for increasing operational life of filter.
• Surface sealing design, O- ring on periphery of the barrel to ensure the sealing and prevent leakage with time.
• New complete Plastic Clamp for fast assembly and disassembly the filter housing.
• New skeleton design to strengthen the screen element and convert flow to laminar.
• Barrels equipped with 1” Vacuum breaker to release/intake of air and prevent filter from damage.

Material	Plastic
Color	Black
Brand	Automat
Model no.	HT-AQ-134YS
Max. Working Pressure	6 kg/cm2
Recommended Flow	20 m3/h
Cartridge Dia	70 mm

2” Y-Type Disc filter (20m3) designed for outside to inside flow. Filter body and cap connected by threaded connection to sustain high pressure & easy opening and closing. Disc cartridge is spring loaded for uniform compression of discs. Filter designed for maximum operating pressure of 6 Bar.

Features

• Disc filters designed for outside to inside flow.
• Auxiliary connections: Two pressure gauge ports with ¼” male threaded connection.
• Filter body and cap connected by threaded connection to sustain high pressure and easy opening and closing.
• High Filtration efficiency
• Spring loaded Disc cartridge for uniform compression of discs.
• UV protected, chemical and high pressure resistant reinforced plastic material used.

Material	Plastic
Color	Black
Brand	Automat
Model No.	AQ-136T(HC)
Max. Working Pressure	8 kg/cm2
Cartridge Dia.	122 mm
Cartridge Length	515 mm

The filters are made from special chemically bonded polymer which are weather resistant. Disc filter made with special Helix system which gives better performance and results.

Features

• Clamp made up of Nylon reinforced material for durability.
• Vacuum breaker for upside down installation.
• Drain port is located in front of the ration body.
• Maximum operating pressure is 6 kg/cm2.
• Flow passes through outside to inside of disc stake

Material	Plastic
Color	Black
Brand	Automat
Model No.	AQ-135TL(HC)
Cartridge Length	388 mm
Cartridge Dia.	122 mm
Max. Working Pressure	145 psi

2½” T-Type Disc filter (40m3) in which flow passes from outside to inside of disc stake. The filters are made from special chemically bonded polymer which are weather resistant. Disc filter made with special Helix system which gives better performance and results.

Features

• Clamp made up of Nylon reinforced material for durability.
• Vacuum breaker for upside down installation.
• Drain port is located in front of the ration body.
• Maximum operating pressure is 6 kg/cm2.
• Flow passes through outside to inside of disc stake.s

Material	Plastic
Color	Black
Brand	Automat
Model No.	AQ-135T (HC)
Max. Working Pressure	110psi
Nominal Flow Rate	176 Gpm
Cartridge Length	388 mm

2½” T-Type Disc filter (30m3) in which flow passes from outside to inside of disc stake. The filters are made from special chemically bonded polymer which are weather resistant. Disc filter made with special Helix system which gives better performance and results.

Features

• Clamp made up of Nylon reinforced material for durability.
• Vacuum breaker for upside down installation.
• Drain port is located in front of the ration body.
• Maximum operating pressure is 6 kg/cm2.
• Flow passes through outside to inside of disc stake.

Material	Plastic
Color	Black
Brand	Automat
Product Code	AQ-134TS(HC)
Max. Working Pressure	145 psi
Nominal Flow Rate	110 Gpm
Cartridge Dia.	122 mm

2” T-Type Disc filter (25m3) in which flow passes from outside to inside of disc stake. The filters are made from special chemically bonded polymer which are weather resistant. Disc filter made with special Helix system which gives better performance and result.

Features

• Clamp made up of Nylon reinforced material for durability.
• Vacuum breaker for upside down installation.
• Drain port is located in front of the ration body.
• Maximum operating pressure is 6 kg/cm2.
• Flow passes through outside to inside of disc stake.

Size	2 inch
Material	Plastic
Color	Black
Brand	Automat
Model No.	AQ-134T(HC)
Material Of Disc	Polypropylene Disc
Cartridge Dia.	122 mm
Cartridge Length	388 mm

2” T-Type Disc filter (30m3) in which flow passes from outside to inside of disc stake. The filters are made from special chemically bonded polymer which are weather resistant. Disc filter made with special Helix system which gives better performance and results.

Features

• Clamp made up of Nylon reinforced material for durability.
• Vacuum breaker for upside down installation.
• Drain port is located in front of the ration body.
• Maximum operating pressure is 6 kg/cm2.
• Flow passes through outside to inside of disc stake
