Additional Information:

• Delivery Time: 1 Day

We offer our customers an excellent quality range of 100 rpm bo-1 series motors. Low cost high performance dc geared motor with wide operating voltage range of 3~12 volts dc and good output torque capability. Technical specifications 1. Operating voltage: 3v ~ 12v dc 2. Rpm: Approximately 100,150,300 rpm 3. No load current: 40 ~ 80ma.

Additional Information:

• Delivery Time: 1 Day

150 RPM – 12V Centre Shaft DC Geared Motors are generally a simple DC motor with a gearbox attached to it. This can be used in all-terrain robots and variety of robotic applications. These motors have a 3 mm threaded drill hole in the middle of the shaft thus making it simple to connect it to the wheels or any other mechanical assembly.

150 RPM 12V DC geared motors widely use for robotics applications. Very easy to use and available in standard size. Also, you don’t have to spend a lot of money to control motors with an Arduino or compatible board. The most popular L298N H-bridge module with onboard voltage regulator motor driver can be used with this motor that has a voltage of between 5 and 35V DC or you can choose the most precise motor diver module from the wide range available in our Motor divers category as per your specific requirements.

Nut and threads on the shaft to easily connect and internally threaded shaft for easily connecting it to the wheel.DC Geared motors with robust metal gearbox for heavy-duty applications, available in the wide RPM range and ideally suited for robotics and industrial applications.Very easy to use and available in standard size. Nut and threads on the shaft to easily connect and internally threaded shaft for easily connecting it to the wheel.

The 150 RPM Dual Shaft BO Motor Plastic Gear Motor BO series straight motor gives good torque and rpm at lower operating voltages. It is a low-cost geared DC Motor which is an alternative to metal gear DC motors. It is most suitable for lightweight robots running on voltages between 5V-9V. Out of its two shafts, one shaft can be connected to the wheel, while the other can be connected to an encoder

Connections

1. Connect the power source to two leads and see it spinning.
2. One end of the shaft can be connected to the wheel while the other end can be connected to an encoder.

Features

• Gears materials are made up of plastic
• Generates a large force at a low speed
• Low density, lightweight, and low Inertia
• It has a uniformity of parts
• Capability to absorb shock and vibration as a result of elastic compliance
• Ability to operate with minimum or no lubrication, due to inherent lubricity
• Relatively low coefficient of friction
• Corrosion-resistance; elimination of plating, or protective coatings
• Consistency with the trend to greater use of plastic housings and another component
• The quietness of operation.
• Tolerances are often less critical than for metal gears, due in part to their greater resilience.
• Consistency with the trend to greater use of plastic housings and other components.
• Ability to operate with minimum or no lubrication, due to inherent lubricity.

Applications

• Arduino
• Raspberry-Pi
• DIY Projects.
• Battery-operated toys.
• Disk drives Steel rolling mills Paper.
• Machines Medical equipment.
• Radio-controlled aircraft.
• Automobiles Drive systems Positioning.
• Industrial and consumer actuators Winches Robotics Mixers.
• Robotic projects.

This N20-3V-200 Rpm Micro Metal Gear Motor is a small volume, big torsion, all metal gear, durable, not easy to wear DC motor. Great replacement for the rusty or damaged DC geared speed reduce motor on the machine. Widely used on Boat, Car, Electric Bicycle, Fan, Home Appliance.

Selecting the right DC gear motor is troublesome for the robotics project. However, This DC Geared motor can be used for heavy-duty applications, robotics, or in any industrial or educational applications. It has a wide range of features for obtaining the optimal performance characteristics. It is very easy to use and does not need expensive motor control circuitry. This DC Motor has 100RPM and the voltage rating of 12Volts that is a useful specification to make this geared motor as a retro fitable in all-terrain robots and a variety of robotic projects. The motors shaft has a 3 mm threaded drill hole in the middle which is very useful for mechanical assembly. Geared motor features and specification: Specification: Gear Type: Plastic RPM: 100 Working Voltage (VDC): 7-12V (12V recommended and maximum) Torque (kg - cm): 5 Load Current Max: 300mA No-Load Current (mA): 60mA Geared Motor Applications: Robotics Controlling Wheels Industrial application Educational projects Different motor related applications

TB6600 Arduino Stepper Motor Driver is an easy-to-use professional stepper motor driver, which could control a two-phase stepping motor. It is compatible with Arduino and other microcontrollers that can output a 5V digital pulse signal. TB6600 Arduino stepper motor driver has a wide range of power input, 9~42VDC power supply. And it is able to output 4A peak current, which is enough for the most of stepper motors. The stepper driver supports speed and direction control. You can set its micro step and output current with 6 DIP switch. There are 7 kinds of micro steps (1, 2 / A, 2 / B, 4, 8, 16, 32) and 8 kinds of current control (0.5A, 1A, 1.5A, 2A, 2.5A, 2.8A, 3.0A, 3.5A) in all. And all signal terminals adopt high-speed optocoupler isolation, enhancing its anti-high-frequency interference ability. As a professional device, it is able to drive 57, 42-type two-phase, four-phase, hybrid stepper motor. TB6600 Stepper Motor Driver Controller 4A 9~42V TTL 16 Micro-Step CNC 1 Axis Upgraded Version of the 42/57/86 Stepper Motor segment increased to 32 segments, suitable for high subdivision applications. Suitable for step motor :57, 42, 86Type 4 phase 2 phase (4 line 6 line 8). Features : H bridge bipolar constant current drive. The biggest 4.0 A Eight kinds of output current are optional. The biggest 32 To subdivide 6 kinds of subdivision modes selectable. Input signal high-speed photoelectric isolation. A total of standard single pulse interface. Offline retention function. The semi-enclosed casing can adapt to a more stringent environment. Provide energy saving half automatic current lock function. Package Includes : 1 x TB6600 Stepper Motor Driver Controller 4A 9~42V TTL 16 Micro-Step.

Category: Stepper Motor Drivers Tag: Double BTS7960 43A H-Bridge High-Power Stepper Motor Driver Module

TB6600 Arduino Stepper Motor Driver is an easy-to-use professional stepper motor driver, which could control a two-phase stepping motor. It is compatible with Arduino and other microcontrollers that can output a 5V digital pulse signal. TB6600 Arduino stepper motor driver has a wide range of power input, 9~42VDC power supply. And it is able to output 4A peak current, which is enough for the most of stepper motors. The stepper driver supports speed and direction control. You can set its micro step and output current with 6 DIP switch. There are 7 kinds of micro steps (1, 2 / A, 2 / B, 4, 8, 16, 32) and 8 kinds of current control (0.5A, 1A, 1.5A, 2A, 2.5A, 2.8A, 3.0A, 3.5A) in all. And all signal terminals adopt high-speed optocoupler isolation, enhancing its anti-high-frequency interference ability. As a professional device, it is able to drive 57, 42-type two-phase, four-phase, hybrid stepper motor. TB6600 Stepper Motor Driver Controller 4A 9~42V TTL 16 Micro-Step CNC 1 Axis Upgraded Version of the 42/57/86 Stepper Motor segment increased to 32 segments, suitable for high subdivision applications. Suitable for step motor :57, 42, 86Type 4 phase 2 phase (4 line 6 line 8). Features : H bridge bipolar constant current drive. The biggest 4.0 A Eight kinds of output current are optional. The biggest 32 To subdivide 6 kinds of subdivision modes selectable. Input signal high-speed photoelectric isolation. A total of standard single pulse interface. Offline retention function. The semi-enclosed casing can adapt to a more stringent environment. Provide energy saving half automatic current lock function. Package Includes : 1 x TB6600 Stepper Motor Driver Controller 4A 9~42V TTL 16 Micro-Step.

Combo of 5 Pcs Dc High Speed Toy Motor and 5 Pcs Toy Motor Fan (Propeller).

High Power DC Motor Speed Controller lets you control the speed of a DC motor using a Pulse Width-Modulated (PWM) DC voltage with a Duty Cycle fully adjustable from 10%-100%. It can be used to drive all DC Brushed Motors that work between 12V-40V DC and consume up to 10A of current.

Features:

• Control the speed of a DC motor with this controller
• High efficiency, high torque, low heat generating
• With reverse polarity protection, high current protection
• Low heat generating control the speed of a DC motor with this controller with reverse polarity protection,
• High current protection working voltage

Applications:

• For Speed Control Of all Types of DC Brush Motors
• For Controlling Automotive Cooling Fan Speed, Auto Fan Speed, Windshield Wipers, Auto Air Conditioning.
• For Controlling Belt Speed, Pipeline Exhaust Fan Speed, Treadmill Speed, Multi-Speed Parallel Computer Fan, Electronic Fan Speed

• Dc voltage: 3 - 6v
• No load rated current: 0.05a or less
• Flow rate: 70 - 120l / h
• Noise: 40db max (background noise 35db, 0.5m or less)
• Load rated current: 0.18a

• Dimensions 3.3 x 3.7 x 0.2 cm ; 150 g
• Weight 400g

Additional Information:

• Item Code: B01N1TRBBC

This L298 Based Motor Driver Module is a high power motor driver perfect for driving DC Motors and Stepper Motors. It uses the popular L298 motor driver IC and has the onboard 5V regulator which it can supply to an external circuit. It can control up to 4 DC motors, or 2 DC motors with directional and speed control

This motor driver is perfect for robotics and mechatronics projects and perfect for controlling motors from microcontrollers, switches, relays, etc. Perfect for driving DC and Stepper motors for micro mouse, line following robots, robot arms, etc.

An H-Bridge is a circuit that can drive a current in either polarity and be controlled by Pulse Width Modulation (PWM).

Pulse Width Modulation is a means of controlling the duration of an electronic pulse. In motors try to imagine the brush as a water wheel and electrons as the flowing droplets of water. The voltage would be the water flowing over the wheel at a constant rate, the more water flowing the higher the voltage. Motors are rated at certain voltages and can be damaged if the voltage is applied to heavily or if it is dropped quickly to slow the motor down. Thus PWM. Take the water wheel analogy and think of the water hitting it in pulses but at a constant flow. The longer the pulses the faster the wheel will turn, the shorter the pulses, the slower the water wheel will turn. Motors will last much longer and be more reliable if controlled through PWM.

The L298N driver module, using ST L298N chip can directly drive two 3-30V DC motor, and provides a 5V output interface can 5V single-chip circuitry to supply, support 3.3VMCU control, you can easily control the DC motor speed and direction, you can also control the 2-phase stepper motor, smart car essential

L293D is a monolithic integrated, high voltage, high current, 4-channel driver.Basically this means using this chip you can use DC motors and power supplies of up to 36 Volts, thats some pretty big motors and the chip can supply a maximum current of 600mA per channel, the L293D chip is also what's known as a type of H-Bridge. The H-Bridge is typically an electrical circuit that enables a voltage to be applied across a load in either direction to an output, e.g. motor. Specifications- Multi-Motor Driver Shield (2-L293D) Four H-Bridges: Two L293D Motor driver chips L293D is rated at 0.6A per bridge (1.2A peak) with thermal shutdown protection, internal kickback protection diodes. Motor Voltages from 4.5VDC to 16VDC. (up to 36V if C6 and C7 are upgraded) Up to 4 bi-directional DC motors with individual 8-bit speed selection (256 speeds) Up to 2 stepper motors (unipolar or bipolar) Pull down resistors keep motors disabled during power-up Separate Logic and Motor power connections Terminal block connectors for motors and power 2 connections for 5V 'hobby' servos

Additional Information:

• Delivery Time: 1

ema17 4.2 kg-cm Single Shaft Stepper motor can provide 4.2 kg-cm of torque at 1.7A current per phase. The stepper motors move in precisely repeatable steps, hence they are the motors of choice for the machines requiring precise position control.*Step Angle: 1.8 °, Current: 1.2 A/Phase, Holding Torque: 4.2 kg-cm, Detent torque: 2.2 N.cm (Maximum), Lead Wires: 4 Shaft, diameter: 5 mm

PWM DC Motor Speed Regulator is a Mini Style DC Motor Speed Regulator controls the speed of a DC motor by adjusting Pulse-Width-Modulated (PWM).

Pulse Width Modulation (PWM) is a common method used to apply a proportional control signal to an external device using a digital output pin. For example, servo motors use the pulse width of an incoming PWM signal to determine their rotation angle.

The L298 is an integrated monolithic circuit in a 15- lead Multiwatt and PowerSO20 packages. It is a high voltage, a high current dual full-bridge driver designed to accept standard TTL logic levels and drive inductive loads such as relays, solenoids, DC and stepping motors. Two enable inputs are provided to enable or disable the device independently of the input signals. The emitters of the lower transistors of each bridge are connected together and the corresponding external terminal can be used for the connection of an external sensing resistor. An additional supply input is provided so that the logic works at a lower voltage. Features: Low saturation voltage Over-temperature protection High noise immunity Applications: Motor Drive & Control Operating Supply Voltage Up To 46 V Total Dc Current Up To 4 A Low Saturation Voltage Overtemperature Protection Logical “0” Input Voltage Up To 1.5 V (High Noise Immunity) Package Includes: 1 x L298N Multiwatt-15V Dual Full-bridge Driver

Supply Voltage : 8-35 VDC. Current : 1.0A (no heatsink ). Current : 2.0A (with heat-sinking). Logic input : 3 – 5.5V . Automatic current decay mode detection / choice. Mixed with slow current decay mode.

It provides high performance, superpower, and brilliant efficiency. These motors are perfect for medium size quadcopters with 8-inch to 10-inch propellers.

This is a brushless (BLDC) outrunner motor specifically made for quadcopters and multirotors. It is a 1400kV motor. It provides high performance, super power and brilliant efficiency.

This driver controller is suitable for building not only amateur CNC systems but also professional ones based on high power engines. Compared to the previous generation of the TB6560AHG, the output of the TB6600HG has increased to 200W (as we see a practical doubling in power value), the operating voltage is raised from 35V (TB6560AHG) to 50V, the operating current is increased to 4.5A (5A peak value).

The main aspects of this driver include intelligent current control and the use of PWM modulation, which makes it possible to connect stepper motors of any supply voltage and current to the driver – at a fixed level; the chip itself will limit the maximum current.

The maximum operating frequency has been increased.

SKU: FK073 Availability : In Stock Categories: All products Discount (Excl RPI category) Best selling products DC Motors New products

Stepper Motor 28BYJ-48 is a uni-polar 5V stepper motor that takes electrical signals as input and rotates by converting these input signals into the mechanical rotation. It has 4 stationary coils rated at +5V. These coils are known as a stator and make a ring around the rotor. It has a 1/64 reduction gear set and therefore moves in precise 512 steps per revolution. These motors are silent in comparison to other DC motors and servo motors. You can achieve positional control easily without needing extra circuitry and components.

Stepper Motor 28BYJ-48 specifications:

• Voltage: 5V DC
• Step Angle: 5.625° /64
• Frequency: 100Hz
• Self-positioning Torque: >34.3mN.m
• Friction torque: 600-1200 gf.cm

ULN2003 Stepper Motor Driver is small size and easy to use. It is based on ULN2003 driver chip to amplify the control signal from the Arduino or other development boards. This Ultra Lightweight and cheap option commonly used to run and control the small applications stepper motors.

It uses the ULN2003 DARLINGTON ARRAYS to drive the 4-phase 5-wire stepper motor (5v-12v).It’s easy to use Arduino or other development platform to drive the stepper motor by this diver board.

It sounds like you're referring to a Yellow Gear Right-Angle Helical Bevel Gear Transmission, specifically with 24 teeth (24T). Here's a breakdown of what this means:

This is the cheapest ever 1000KV Brushless DC motor + ESC + propeller for drones. This set is recommended to newbie drone enthusiasts and wise pilots who are not willing to ruin the motors at the test stages.

Mini Vibration Motor Electric Toys Motor Dc 3v 4x8mm 20000 Rpm 20000 Rpm mini -Vibration Motor Typical application:

Wide Supply-Voltage Range: 4.5 V to 36 V*High-Noise-Immunity Inputs

Operating Voltage Range: 3 to 6V DC, Shaft Diameter: 2 mm

L293D Dual Motor Driver Module For Raspberry Pi, Arduino, DSP, ARM, AVR, PIC, 8051

EnGeniusLab introduces the L293D Motor Driving Module with voltage protection feature on board, perfect for driving DC motor & Stepper Motors. It uses the most popular L293D Motor driver IC. It can drive 4 DC Motor in One direction, or drive 2 DC motor in both direction. It is standalone module for many motor driver applications & projects

L293D motor driver module, Male burg stick connectors for supply, ground and input connection & Screw terminal connectors for easy motor connection. This motor driver is perfect for robotics and mechatronics projects for controlling motors from microcontroller, switches, relays, etc. Perfect for driving DC and Stepper motors, Apart from it we can further extend it for many more other projects for same without using microcontrollers like, Line Follower Robot, Edge Avoider Robot, Remote/Joystick Controlled Robot, Wireless Controlled Robot, Mobile phone Controlled Robot & Many More. The best feature of this motor driving board is that we can used in line follower robot where we don’t need any microcontroller for functionality of it.
