Ergo Handlers

Diameter(in mm)	10
Automation Grade	Semi-Automatic
Material	Mild Steel
Model Name/Number	Rigid Arm Liftronic Air Overhead Arm
Air Pressure	0,65 MPa (6,5 bar)
Power supply	115/230V A/C 50/60Hz
Power consumption	100VA
Enclosure Protection	IP54

Main features

• Air pressure 0,65 MPa (6,5 bar)
• Power supply 115/230V A/C 50/60Hz
• Power consumption 100VA
• Enclosure protection IP54
• Noise level < 70 dB(A)
• Lifting capacity limiter
• Lift speed from 15 to 30 m/min
• Main column axis brake
• Intermediate joint axis brake
• Column rotation 360°
• Tool axis rotation 550°
• Slow descent in case of pressure failure
• Balancing type: load preset or self balancing (it depends from the tooling)

Usage/Application	Industrial
Material	Stainless Steel
Brand	Indeva
Color	Green
Air Pressure	0,65 MPa (6,5 bar)
Noise Level	< 70 dB (A)

MAIN FEATURES

• Air pressure 0,65 MPa (6,5 bar)
• Noise level< 70 dB (A)
• Lift speed from 15 to 30 m/min
• Main column axis brake
• Intermediate joint axis brake
• Continuous column rotation (not available with motorized sliding trolley)
• Slow descent in case of pressure failure
• Load balancing: standard, 1 load preset

Material	Stainless Steel
Sterile/ Non Sterile	Sterile
Disposable/ Reusable	Reusable
Packaging Type	Box
Air pressure	0,65 MPa (6,5 bar)
Power supply	115/230V A/C 50/60Hz
Power consumption	100VA
Noise Level	< 70 dB(A)

Main features

• Air pressure 0,65 MPa (6,5 bar)
• Power supply 115/230V A/C 50/60Hz
• Power consumption 100VA
• Enclosure protection IP54
• Noise level < 70 dB(A)
• Lifting capacity limiter
• Lift speed from 15 to 30 m/min
• Main column axis brake
• Intermediate joint axis brake
• Column rotation 360°
• Tool axis rotation 550°
• Slow descent in case of pressure failure
• Balancing type: load preset or self balancing (it depends from the tooling)

Automation Grade	Semi-Automatic
Material	Mild Steel
Model Name/Number	Rigid Arm Pn Ergo Column Arm
Air Pressure	0,65 MPa (6,5 bar)
Noise Level	< 70 dB (A)
Lift Speed	30 m/min
Feature	Continuous Column Rotation

MAIN FEATURES

• Air pressure 0,65 MPa (6,5 bar)
• Noise level< 70 dB (A)
• Lift speed from 15 to 30 m/min
• Main column axis brake
• Intermediate joint axis brake
• Continuous column rotation
• Slow descent in case of pressure failure
• Load balancing: standard, 1 load preset

Automation Grade	Semi-Automatic
Material	Mild Steel
Model Name/Number	Rigid Arm PN Compatto Versions Overhead Arm
Voltage	220 V
Lift Speed	30 m/min
Control	Pneumatic
Air Pressure	Min 6 Bars

PN COMPATTO are pneumatic industrial manipulators with rigid vertical arm, suitable for applications in small size, low ceiling work areas.

Main features:

• Lift speed from 15 to 30 m/min
• Control: pneumatic
• Air pressure: min 6 bars
• Work Temperatures: from +5° to +50° C
• Noise level: <70 dB
• Main column axis brake
• Intermediate joint axis brake
• Continuous column rotation
• Safety devices: in case of pressure failure a safety devices retains the grip on the load, and the tooling descends slowly till the floor. Special brakes keep the arm and gripping tool still when not used

Available options

• Rotating joint on the articulate axis
• System lock for the lift capacity
• Brake for up/down movement
• Double braking force on the main and intermediate axis
• Special painting
• Sliding trolley

Pneumatic industrial manipulators PN Compatto with jointed arm fixed to an overhead rail Ceiling mounted model is also available.

Usage/Application	Industrial
Material	Stainless Steel
Brand	Indeva
Color	Gray
Max Load Capacity	80 Kg
Control	Pneumatic
Air Pressure	6,0 Bar
Work Temperatures	Rrom +5 Degree to +50 Degree C

Pneumatic industrial manipulators, light and compact, suitable for applications with a short vertical excursion and quick work cycles.

Main features:

• Max load capacity: kg 80
• Control: pneumatic
• Air pressure: 6,0 Bar
• Work Temperatures: from +5° to +50° C
• Noise level: <70 dB
• Safety devices: in case of pressure failure slow descent till the floor

Available options

• Conformity to the ATEX
• Regulations for applications in controlled environment with danger of explosion,
• Special painting
