Esab India Limited

Flux Type	Submerged Arc
Grade	Rutile
Packaging Size	25 kg
Material	Flux
AWS Classification	F7AZ-EM12K
Current Type	AC DC
Application	Fabrication
Usage/Application	General fabrication, Beams fabrication
Brand	ESAB
Classifications	AWS A5.17: F7AZ-EL8/EL12, F7AZ-EM12K
Elongation	30%
Yield Strength	420 MPa
Tensile Strength	500 MPa

ESAB 81PB is an agglomerated submerged arc welding fux designed for fillet and butt welding of non-alloyed steels. Its unique design delivers good welding characteristics. It provides uniform welds with good slag release and weld bead appearance. With its Mn & Si alloying design, the fux is best suited for high speed welding forlimited number of passes.

Flux Type	Open Arc
Grade	Rutile
Packaging Size	25 kg
AWS Classification	F7AZ - F7PZ - EM12K
Current Type	DC
Application	Pipe Welding
Brand	ESAB
Classifications	EN ISO 14174 : S A AB 1 77 DC
Slag Type	Aluminate-basic
Alloy Transfer	Silicon and Manganese alloying
Density	nom 1.3 kg/dm3
Usage/Application	General fabrication, Beams fabrication

Agglomerated aluminate-basic flux for Submerged Arc Welding. General purpose flux specially designed for fillet welding applications at high speeds primarily with single & twin wire systems for all carbon steels operated in DC. Further attributes include very good surface finish, slag detachability, concave horizontal fillets & uniform toe wetting. Major applications include pre-engineered buildings (PEB's), general construction etc.

Flux Type	Agglomerated Neutral
Packaging Size	25 kg
AWS Classification	F6A2, F7A4, EM12K
Current Type	DC
Grain Size	mesh
Basicity Index	nom: 1.5
Brand	ESAB
Classifications	EN ISO 14174:S A AB 1 67 AC H5
Diffusible Hydrogen	Max 5 ml/100g weld metal (Redried flux)
Slag Type	Aluminate-basic
Alloy Transfer	Slightly Silicon and moderately Manganese alloying

OK Flux 10.71L is an agglomerated, basic flux for submerged arc welding. It is used for single and multi-run weldingof all plate thicknesses. It can be combined with a wide range of wires and thus it is suitable for all kinds of steels.OK Flux 10.71L combines good toughness values with excellent weldability. It is used for single & multi-wire proceduressuch as tandem, twin-arc, tandem-twin welding and many more, for butt, overlap and fillet welds. It works equally well onDC and AC current. The good slag detachability and limited alloying of Si and Mn makes it well suited for multi-pass thicksection welding.
