Esab India Limited

Welding Process	MMA
Output Current	200 Amp
Welding Current	200 A
Technology	Inverter
Phase	Single Phase
Duty Cycle	60 %
Input Voltage	220 V
Weight	3.70 Kg
KVA	7.04
Electrode	Suitable for upto 4.00 mm electrodes
Enclosure class	IP21S
Power factor at maximum current,%	83
Dimensions	300 x 115 x 232 mm

HandyArc 204i is an IGBT based single phase welding inverter machine for stick welding.

Features:

• Suitable for E6013, E7018 & SS electrodes upto 4.00 MM electrodes
• Powerful Stick welding.
• Continuous Welds.
• Excellent Weldability.
• Thermal Protection Indicator.
• Package - Power Source with 2.3m mains cable and plug, Electrode Holder with 2m cable, Ground clamp with 2m cable, Shoulder strap.

Additional Information:

• Packaging Details: Machine, Electrode Holder Set, Earth Clamp Set, Main Cable, Shoulder Strap

Welding current	200 A
Output Current	200 Amp
Welding process	MMA
Phase	1 phase
Input voltage	220 V
Duty cycle	60 %
Compatible rod dia	2.5 mm
Electrode	Suitable for 3.15 mm electrodes
Enclosure class	IP21S
Weight, Kg	3.50
Rated Power , KVA	5.50
Power factor at maximum current,%	82

HandyArc 203i is an IGBT based single phase welding inverter machine for stick welding.

Features:

• Suitable for E6013, E7018 & SS electrodes.
• Powerful Stick welding.
• Continuous Welds.
• Excellent Weldability.
• Thermal Protection Indicator.
• Package - Power Source with 2.3m mains cable and plug, Electrode Holder with 2m cable, Ground clamp with 2m cable, Shoulder strap.

Welding Current	250 A
Output Current	250 Amp
Technology	Inverter
Phase	Single Phase
Duty Cycle	60 %
Input Voltage	220 V
Welding Process	MMA
Suitable Electrode Rod	E7018
Frame Material	Metal
Brand	ESAB
Model	Xpert Weld 253i
Weight	15 Kg
Package	2.5m mains cable, 5m remote and 2 OKC cable connectors
Warrenty	1 Year

Xpert Weld 253i is an IGBT based inverter-controlled power source with robust and reliable design for MMA welding. The compact design enables easy portability with continuous welding capabilities

Additional Information:

• Item Code: 4610210302
• Packaging Details: 2.5m mains cable, 5m remote and 2 OKC cable connectors
