The Engineering Science Apparatus Workshop

Country of Origin	Made in India
Binocular	Straight Binocular Head or 45A Degree Binocular =160
Visual field	8.5-78mm
Light intensity	Min. 25000 LUX
Type	LED 3V/10W
CCD Camera	LC-8
No of Wheel	4 Wheel

Other Details:

Usage/Application	Laboratory
Country of Origin	Made in India
Power Source	Electric
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP56
Packaging Type	Box
Color	White and Black

microscope camera pixel: 0.3MP
microscope category :Student, USB Microscope
microscope color :Black
microscope head style :Monocular
microscope light shape :Built-in
microscope light type :LED
microscope number of bulbs :8
microscope power supply :USB
microscope sensor :CMOS
microscope stand Table Stand: track

Usage/Application	Laboratory
Country of Origin	Made in India
Power Source	Electric
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP52
Packaging Type	Box

Style Monocular
Eyepiece 10x
Nosepiece Double
Objectives 2/3, 1/6
Focusing Separate coarse & fine adjustment
Stage Stage clips
Substage Disc diaphragm
Light Source Mirror

Usage/Application	Laboratory
Country of Origin	Made in India
Power Source	Electric
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP46
Packaging Type	Box

Viewing Head: Sliding Binocular head, Inclined at 45°, 360° Rotatable, 55-75mm Interpupillary Distance. Anti-Fungus.
Eyepiece: Wide Field Eyepiece WF 10×/18
Nosepiece: Quadruple Nosepiece
Objective: Plan Achromatic Objectives 4x, 10x, 40x, 100x
Total Magnification: With 10x eyepiece: 40x, 100x, 400x, 1000x
Stage: Double Layers Mechanical Stage 140mm×140mm/ 75mm×50mm
Focus: Coaxial Coarse & Fine Adjustment, Moving Range 28mm, Fine Division 0.002mm
Condenser: Abbe NA 1.25 with Iris Diaphragm & Filter
Illumination: LED Illumination 3W (or)
Halogen Lamp 6V/20W (optional), Brightness Adjustable
Body/Power: Body with firm backing of aluminum and a built-in power supply 110-230V

Light Source	LED
Power	Input 220v - 240v AC
Eyepiece	Wide field focusable paired eyepiece WF 18x/18mm, with foldable eye
Warranty	1
Country of Origin	Made in India

1) Eyepieces: Wide field focusable paired eyepiece WF 18x/18mm, with foldable eye
guard, lockable, antifungas coating
2) Nosepiece: Quadruple nosepiece (Ball bearing type) with rubber grip.
3) Objectives: LP series DIN plan Achromatic Objectives – 4x, 10x, 40x (spring
loaded), 100x (spring loaded, oil)
4) Mechanical Stage: with Co‐axial drive, highly smooth on Ball sides, Stainless Steel
Holders for Slide 75 x 50mm movement.
5) Condenser: Sub‐stage Abbe condenser NA 1.25 with aspheric lens and Iris
diaphragm with blue filter. Rack and pinion movements on metal guides.
6) Focusing: Co‐axial coarse and fine focusing on ball drive system for smooth
movement.
7) Illumination: Halogen 6V‐20W illumination with variable illumination control.
8) Power supply: Input 220v – 240v AC

Usage/Application	Laboratory
Material	MS
Country of Origin	Made in India
Color	Black and White
Packaging Type	Box
Operating Mode	Manual
Weight Capacity	2 kg Approx
Brand	Kern

Observation Head: Monocular observation head inclined at 45¡, rotateable through 360 degrees.
Main body: All parts die-cast to provide long life & good mechanical strength.
Focusing: Precise and Separate coarse and fine focusing controls with ergonomically placed knobs on both directions.
Magnification Configurations: 40X, 60X, 100X, 150X, 400X, 600X, 1000X, 1500X
Eyepiece: Widefield 10x, 15x pairs
Objectives: SEMI-PLAN ACHRO Din objectives 4x, 10x, 40/45x s. L. 100x oil immersion (s. L.).
Nosepiece: Quadruple nosepiece revolves on ball bearing.
Mechanical stage: Co-axial low positioned mechanical x-y stage of size 120 x 125 mm with stage fine vernier graduation.

Usage/Application	Laboratory
Color	White and Black
Country of Origin	Made in India
Power Source	Electric
Voltage	230 V
Frequency	60 Hz
Phase	Single Phase
IP Rating	IP56
Packaging Type	Box

Eyepiece: Wide field WF10X (Field No. 20mm)
Objectives (Mag/N.A.): Infinite Plan Achromatic 4X/0.1
Infinite Plan Achromatic 10X/0.25
Infinite Plan Achromatic 20X/0.4
Infinite Plan Achromatic 40X/0.6
Infinite Plan Achromatic 100X/0.8 (optional)
Objectives (Mag/Working Distance) : 4X / 28 mm
10X / 10 mm
20X / 5.8 mm
40X / 2.9 mm
100X / 2 mm (optional)
Trinocular head: Inclined 30 degrees, interpupillary distance 48-75 mm
Focusing system: Coaxial coars/fine focus
Nosepiece: Quintuple
Mechanical stage: X-Y mechanical stage
Illumination: 6V/30W Halogen Lamp
Color filters: Grey color filter
Blue color filter
Green color filter
Ground glass
Electrical specification 110V/60 Hz; 220V/50 Hz

Material	Metal
Illumination	Halogen
Packaging Type	Box
Revolving Arm	yes
Nose Piece	Reversed, quadruple, ball bearing with wide rubber grip for easy rotation
Voltage	110-240V
Color	White and Black
Country of Origin	Made in India
Power Source	Electric
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP52

Other Details:

• Viewing Head: Binocular Siedentopf type, inclined 30°; interpupillary distance adjustment 48-75mm, 360° rotatable
• Eyepieces:HWF Plan 10x eyepiece, 20mm field of view with built-in diopter adjustment; a pointer is standard in one eyepiece; eyepieces can be locked-in to prevent tampering. Eyepiece accepts a 21mm reticle
• Nosepiece: Reversed, quadruple, ball bearing with wide rubber grip for easy rotation
• Objectives: Infinity Plan 2x, 4x, 10x
• Condenser: N.A. 1.25 Abbe condenser with diffusing slider for use with 2x objective
• Stage: Mechanical stage, 140 x 132mm with X-Y movement range of 76 x 50mm
• Illumination: 3 watt LED with variable intensity control. Universal power supply for 110v-240v.
• Focusing: Coaxial focusing system with adjustable tension control and upper limit stop to prevent accidental damage to slides; all metal gears, brass fine focus gear

Usage/Application	Laboratory
Country of Origin	Made in India
Power Source	Electric
Voltage	210 V
Frequency	50-60 Hz
Phase	Single Phase
IP Rating	IP56
Packaging Type	Box
Color	White and Black
Display Type	Digital

1. Stunning, easy-to capture images
2. Bright LED light sources
3.Constant light intensity
4.Less expensive to own and maintain.
5.Hard-coated filter sets for higher transmission efficiency
6.High-resolution cameras and a choice of objectives
7.Compact, efficient design
8.Enhanced safety, minimal handling
9.Powerful, intuitive software

Country of Origin	Made in India
Type	Compound Microscope
Head	Trinocular 30 Degree Siedentopf. 47 to 78mm interpupillary, +-5mm adjustment on both eyepieces tube. Vertic
Objective Magnification	Plan Achromatic 4x/0.10, 10x/0.25, 20x/0.40, S40x/0.65 and S100x/1.25 oil immersion infinity correct
Eyepiece Magnification	SWF10x/25mm
Applications	Advanced life science applications
Power Source	Electric
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP56
Packaging Type	Box

Other Details:

• Type Compound Microscope
• Head Trinocular 30° Siedentopf. 47 to 78mm interpupillary, ±5mm adjustment on both eyepieces tube. Vertical tuve light path 100/0 - 80/20 - 0/100
• Illumination3W NeoLed™ Koehler and push-in/out neutral density filter
• Objective MagnificationPlan Achromatic 4x/0.10, 10x/0.25, 20x/0.40, S40x/0.65 and S100x/1.25 oil immersion infinity corrected EIS objectives
• Eyepiece MagnificationSWF10x/25mm
• QuantityEA
• ApplicationsAdvanced life science applications

Usage/Application	Laboratory
Country of Origin	Made in India
Power Source	Electric
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP56
Packaging Type	Box
Color	White and Black

Head: Trinocular viewing head
Eyepieces: 10×/20mm high eyepoint eyepieces
DIC Components: Polarizer, analyzer, condenser prism K, and prism D for 100x objective
Objectives: Hi Plan 4x, 10x, 40x, N Plan 100x
Stage: Mechanical XY
Condenser: Universal condenser w/ flip top lens
Focus: Coaxial coarse & fine focus
Illumination: Variable LED
Misc: Dust cover, power cord, manual

Usage/Application	Laboratory
Packaging Type	Box
Country of Origin	Made in India
Power Source	Electric
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP56
Color	White and Black

Optical System: 40x - 1000x High Contrast achromatic Universal infinity corrected optical System
(High intensity and uniform co-Illumination) (upgradable to Fluorescence, Dark Field, DIC, phase)
Viewing Head: Trinocular three way distribution Compensation, Siedentopf design super wide field
trinocular headwith variable viewing angle 30° rotatable through 360° I.P.D of 48-75mm and Dioptric adjustment on both sides.
with F.O.V 22 mm. port to mount the camera on to the microscope Four additional heads Siedentopf binocular ergonomic eyepiece tube with
variable inclination angle of 30° With Butterfly movement may increase viewing height by 60mm IPD:48-75mm. Optional Tilting head 0° to 35
Eyepiece : Wide Field 10x eye-piece with 22mm F.O.V with eye guards (5 Pairs) anti- fungus type high eye point eyepiece
diopter adjustment on both sides Prism incorporated butterfly movement to increase viewing height by60mm.
Nosepiece : Sextuple Nosepiece reversed position revolving coded nosepiece to accommodate 6 objectives at a
time intelligent nosepiece which memorizes light intensity for each objective position polarizer & analyzer.
optional Motorized Nosepiece with R otating Buttons Automatically R otating Nosepieces and adjusting the light intensity.
Objective: Infinity Color Corrected objectives Multicoated, high contrast and resolution lead free
All optics are anti-fungal and anti-reflection Coated CCIS plan Achromat Objective EC-H-PL 4x/0.10 CCIS plan
Achromat Objective EC-H-PL 10x/0.25 CCIS plan Achromat Objective EC-H-PL 20x/0.45-0.40 CCIS plan Achromat Objective
EC-H-PL 40x/0.65/Spring loaded CCIS plan Achromat Objective EC-H-PL 100x/1.25/Spring loaded (Oil)

Eyepiece	Pair of DIN HWF plan 10x/22mm eyepieces
Illumination	Reflected Kohler 50W halogen Intensity adjustable with internal 100-240V power supply. Fuse holder 3
Eye Piece (Anti Fungus)	Pair of DIN HWF plan 10x/22mm eyepieces
Revolving Nose Piece	Revolving quintuple nosepiece on ball-bearings
Country of Origin	Made in India
Stage Size	250 x 230 mm
Power Source	Electric
Voltage	210 V
IP Rating	IP56

Other Details:

• Eyepieces Pair of DIN HWF plan 10x/22mm eyepieces
• Nosepiece Revolving quintuple nosepiece on ball-bearings
• Objectives Infinity color corrected long working distance 5x/0.15, 10x/0.14, 20x/0.45 plan achromatic, plan semi apochromatic S50x/0.55 IOS objectives.
• Optional plan semi apochromatic S100x/0.80 IOS objective.
• No cover glass correction.
• All optics are anti-fungus treated and anti-reflection coated for maximum light throughput.
• Condenser Abbe condenser with iris diaphragm
• Stage Large stage 250 x 230mm equipped with a coaxial mechanical 120 x 78mm X-Y stage, metallic insert standard with ∅ 12mm diameter hole and ∅ 25mm diameter hole, metallic insert with hole for mechanical stage.
• Illumination Reflected Köhler 50W halogen Intensity adjustable with internal 100-240V power supply. Fuse holder 3.15A / 250V.
• Focusing Coaxial 25 mm coarse and fine adjustments, 2 μm precision and with friction adjustment
• Polarization Standard polarization filter and 360° rotating analyzer.
• Filters Blue and green filter mounted in slider, that can be inserted at the back of the illumination attachment. Polarization filter in slider, to be inserted under nosepiece.

Country of Origin	Made in India
Usage/Application	Laboratory
Power Source	Electric
Voltage	230 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP56
Packaging Type	Box

Eye piece Type Compensating
Eye Piece with magnification Set of Two For Binocular 10x
Objective Type semiapochromatic
Objective Magnification 20 x
Numerical Apperture of Objective 0.5
Extra eyepieces (inclusive in the scope of supply) 10 x

Usage/Application	Laboratory
Country of Origin	Made in India
Power Source	Electric
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP56
Packaging Type	Box
Color	White and Black

Viewing Bodies Trinocukar head, siedentopt type, I.P. adjustment 53mm to 75mm, graduated diopter on left eyetube (30.0mm I.D. eyetube)
Eyepiece SWH10X Widefield high eyepoint eyepiece, Field No. 22, tube O.D. 30.0 mm
Nosepiece Ergonomic Quintuple Nosepiece, ball bearing mounted
Objectives Infinity Corrected Planachromat Semi Apo 2.5x,4x, 10x, 20x, 40x
Mechanical stage Ceramic coated flat-top stage, 190mm x 140mm, with 80mm x 52mm X-Y movement and right hand drop-down coaxial controls
Condenser Abbe condenser NA 0.90 with swing-out top lens and iris diaphragm in dovetail mount
Focusing Coaxial coarse and fine focusing controls with graduation reading 2 microns per division. Range of travel is 23mm. Incorporates tension adjustment and safety Auto-focus stage stop lever.
Illumination 6V 30W Halogen or 3W LED Koehler illumination with Integrated Automatic Voltage Sensing Power Supply
Power Cord Removable AC Electric cord with plug for 115V models

Country of Origin	Made in India
Power Source	Battery
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP56
Packaging Type	Box

Observation Head: Monocular observation head inclined at 45¡, rotateable through 360 degrees.
Main body: All parts die-cast to provide long life & good mechanical strength.
Focusing: Precise and Separate coarse and fine focusing controls with ergonomically placed knobs on both directions.
Magnification Configurations: 40X, 60X, 100X, 150X, 400X, 600X, 1000X, 1500X
Eyepiece: Widefield 10x, 15x pairs
Objectives: SEMI-PLAN ACHRO Din objectives 4x, 10x, 40/45x s. L. 100x oil immersion (s. L.).
Nosepiece: Quadruple nosepiece revolves on ball bearing.
Mechanical stage: Co-axial low positioned mechanical x-y stage of size 120 x 125 mm with stage fine vernier graduation.

Usage/Application	Laboratory
Country of Origin	Made in India
Power Source	Electric
Voltage	230 V
Frequency	50 Hz
Phase	Single Phase
Operating Mode	Manual

Observation Head: Monocular observation head inclined at 45¡, rotateable through 360 degrees.
Main body: All parts die-cast to provide long life & good mechanical strength.
Focusing: Precise and Separate coarse and fine focusing controls with ergonomically placed knobs on both directions.
Magnification Configurations: 40X, 60X, 100X, 150X, 400X, 600X, 1000X, 1500X
Eyepiece: Widefield 10x, 15x pairs
Objectives: SEMI-PLAN ACHRO Din objectives 4x, 10x, 40/45x s. L. 100x oil immersion (s. L.).
Nosepiece: Quadruple nosepiece revolves on ball bearing.
Mechanical stage: Co-axial low positioned mechanical x-y stage of size 120 x 125 mm with stage fine vernier graduation.

Brand	Labomed
Material	Metal
Magnification	7x to 45x
Illumination	Halogen
Packaging Type	Box
Power	AC 110V - 60Hz
Country of Origin	Made in India
Power Source	Electric
Frequency	50 Hz
IP Rating	IP56

Head Binocular of Trinocular, Inclined 45°, rotates 360°, Interpupillary distance 50mm-75mm
Eyepieces 10x/20 high point eyepieces with rubber eye guards, Reticle installed for sizing embryos
Objectives 0.7x to 4.5x hard-coated zoom objectives
Magnification 7x to 45x
Focus Large dual focusing knobs with metal rack & pinion. Maximum height 7.5" (190.5mm) from stage to scope
Illumination 12v 15w Halogen Reflector bulb, Moveable Light assembly (base mount or upper bracket mount), Double-sided mirror (clear and diffused) for transmitted light, Adjustable upper illuminator bracket for incident lighting, Light control unit with 4-position brightness control
Stage Mirror angle adjustment knob, Frosted stage plate, Specimen clips
Power AC 110V - 60Hz

Usage/Application	Laboratory
Country of Origin	Made in India
Power Source	Electric
Voltage	230 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP53
Packaging Type	Box
Color	White and Black

Mechanical stage with left handle Stage stroke: X: 50 mm x Y: 43 mm, including stage insert plate (ø25 mm), stage insert plate exchangeable (Ø110 mm)
Cross stage with right handle Stage stroke: X: 50 mm x Y: 50 mm, including stage insert plate (ø25 mm), stage insert plate exchangeable (Ø110 mm)
Mechanical stage with right handle Stage stroke: X: 114 mm x Y: 75 mm, stage position locking function
Condenser Motorized middle long working distance condenser NA 0.5, W.D. 45 mm, 4 positions for optical devices (for ø50 mm, Relief Contrast optical devices rotatable)
Mid long working distance relief contrast NA 0.5, W.D. 45 mm, 4 positions for optical devices (for ø50 mm, Relief Contrast optical devices rotatable)

Usage/Application	Laboratory
Country of Origin	Made in India
Power Source	Electric
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP52
Packaging Type	Box

Head: Binocular, or trinocular, Inclined 30° and rotatable 360°, Interpupillary distance adjustment
Eyepieces: WF10x/18.5mm field of view; a pointer is standard in one eyepiece; eyepieces are locked-in to prevent tampering and accept 19mm reticles
Nosepiece: Rear facing, quadruple, ball bearing with positive click stops to ensure parcentration
Objectives: DIN Semi-Plan Achromat 4x, 10x, 40x
Stage: Rackless XY Stage size 150mm x 139mm; travel area 75mm (X) x 32mm (Y) movement with right hand control; vernier scale reading to 0.1mm
Condenser: N.A. 1.25 Abbe condenser on rack and pinion with iris diaphragm and swing-out filter holder
Stand: Cast alloy aluminum; built in fixed focus stop allows for rapid focusing while protecting specimens; built-in carry handle and cord hanger
Focusing: Coaxial coarse and fine focus controls with an adjustable tension control; all metal gears
Illumination: Variable LED illumination; bulb life rated for 20,000 hours
Accessories: Dust cover, immersion oil and instruction manual included

Usage/Application	Laboratory
Country of Origin	Made in India
Power Source	Electric
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP56
Packaging Type	Box
Color	White and Black

Style Monocular
Eyepiece 10x
Nosepiece Double
Objectives 2/3, 1/6
Focusing Separate coarse & fine adjustment
Stage Stage clips
Substage Disc diaphragm
Light Source Mirror

Country of Origin	Made in India
Stage	Compucentric, 5-axis fully motorized
Field of view	6.4 mm at working distance of 10 mm
Acceleration voltage	200 V to 30 kV
Probe current	2 pA to 200 nA
Internal size of chamber	230 mm
Maximum Specimen Height	81 mm
Width of Door	148 mm

Other Details:

Usage/Application	Jewelry
Power Source	Electric
Country of Origin	Made in India
Drawtube	Binocular
Color	White
Lighting	LED Ring Light
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase
IP Rating	IP56

The premium Sachi jewellery microscope is the preferred choice for all Micro-setters. This microscope comes with 10X WF eyepiece and has an optical zoom of 0.7X to 4.5X giving . It's crossbar design gives the user enough working space and also a movable slider makes for swift movement while working on large designs. It is supplied with an LED Ring light for enough illumination while working. It has a 45 degrees inclined head and 360 degrees swiveling binocular.

Usage/Application	Laboratory
Magnification	50x-1000x
Illumination	50W Kohler illumination/LED
Country of Origin	Made in India
Nosepiece	Reversed quintuple/quadruple nosepiece
Power Source	Electric
Voltage	210 V
Frequency	50 Hz
Phase	Single Phase

Mechanical Stage : 210mm X 180mm

Moving Range : 50mmX50mm

Interpupillary Distance : 53mm to 75mm

Eyepiece : 10X (paired) F.O.V. 22mm

Features	Celleste Analysis
Warranty	1 Year
Weight	11.8 kg
Color	White and Black
Country of Origin	Made in India
Size	53.6 x 47.0 x 40.4 cm
working Distance	5.9 mm
Objective	20x fixed fluorite

Other Details:

• Dimension: 53.6 x 47.0 x 40.4 cm (21.1 x 13.9 x 15.9 in.
• Weight :11.8 kg (26 lb)
• working distance :5.9 mm
• Objective: 20x fixed fluorite
• Camera Monochrome: high-sensitivity interline CCD camera
• Objective range: 20x
• Fluorescence channels: 3
• Monochrome or color camera option Mono
• Celleste analysis software Optional

Usage/Application	Jewelry
Light Source	LED
Magnification	8-50X
Eyepiece Protector Range	10X Adjustable Eyepiece
Country of Origin	Made in India
Total Magnification	8-50X
System Working Distance	115 mm

Other Details:

• Optical System : Finite
• System Optical Magnification :8-50X
• Expandable System Optical :4-300X
• Magnification (Optional Parts Required): 4-300X
• Total Magnification : 8-50X
• Standard Eyepiece :10X Adjustable Eyepiece
• Standard Objective : lx Built-in Objective
• System Field of View : Dia. 4.4-27.5mm
• Expandable System Field of View : Dia. 2.2-55mm
• System Working Distance : 115mm
• Expandable System Working Distance : 45-220mm
