SFP MODULE
SFP module comes in various types on the basis of different classification standards. It works with copper or fiber optics.
On the fiber optics side, there are single mode SFP module and multimode SFP module, which allows users to select the appropriate transceiver according to the required optical range for the network. The most common optical transceivers are the 850nm wavelength for a maximum of 550 meters with multimode fiber optics and the 1310nm wavelength for a maximum of 20km with single mode fiber optics. Copper-based SFP modules primarily are 1000BASE-T and 1000BASE-TX SFP modules used in gigabit Ethernet networking within 100 meters.
+ Read More
CISCO-10G-LR SFP TRANSCEIVER MODULE
₹ 2,650/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
Product Brochure Watch Video
| Data Rate | 10Gbps |
| Distance | 40 km |
| Fiber Type | Single Mode |
| Power | LC |
| Form Factor | SFP+ |
| Wavelength | 1310 nm |
| Interface | LC Duplex |
| Frequency Range | 40KM |
| Usage/Application | switches |
| Color | Black |
| Tx Power | 0 dBm |
| Brand | Cisco |
| Operating Temp | -10 to 70 C |
| Connector Side | Dual Fiber |
| DDM Support | Yes |
CISCO-10G-LR SFP TRANSCEIVER MODULE SFP module is still being utilized as an industry standard by worldwide manufacturers and providers today. It has been an industry workhorse for over 20 years in many networks such as SONET, Gigabit Ethernet, Fibre Channel, PON, SFP module
Additional Information:
- Item Code: 10G-LR
- Production Capacity: 500
- Delivery Time: Ready
- Packaging Details: PACKING
View Complete Details
Syrotech Sfp Optical Transceiver
₹ 500/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
Product Brochure Watch Video
| Number of Ports | 8 Port |
| Fiber Type | Single Mode |
| Distance | 10 km |
| Wavelength | 1310 nm |
| Interface | LC Duplex |
| Connector Side | Dual Fiber |
| Output Current | YES |
| Transmission Distance | 10KM |
| Wave Length | YES |
| Center Wavelength | YES |
| Material | METAL |
| Dimensions | YES |
| Model | SY 1G SM |
| DDM Support | Yes |
| Operating Temp | -10 to 70 C |
| Country of Origin | Made in India |
| Data Rate | 1.25 Gbps |
| Network Speed | 1 Gbps |
Features Dual data-rate of 1.25Gbps/1.063Gbps operation 1310nm FP laser and PIN Photo detector for 20km transmission Compliant with SFP MSA and SFF-8472 with duplex LC receptacle Digital Diagnostic Monitoring: Internal Calibration or External Calibration Compatible with SONET OC-24-LR-1 Compatible with RoHS +3.3V single power supply Operating case temperature: Standard: 0 to +70°C Industrial: -40 to +85°C
Additional Information:
- Item Code: SFP
- Production Capacity: 1000
- Delivery Time: Ready
- Packaging Details: BOX
View Complete Details
