Galaxy Instruments India

• 1000V AC/DC; 10A AC/DC (with test leads and current jacks); resistance to 50 M???; capacitance to 10,000 μF, frequency to 100 kHz; temperature from -40 ??? to 400 ???
• Robust, fast and accurate with manual and automatic ranging, Display Hold, Auto Hold, and Min/Max-Average recording
• Backlit digital display, analog bar graph, and built-in temperature measurements with included thermocouple.

• g-tech
• type:multimeter
• model name:g-tech mas 830l
• 600v ac/dc, 10 amp dc current, resistance
• diode, continuity, buzzer, transistor test, backlight
• contents in the box:01 no multimeter, 01 no test lead, 01 instruction manual

• DC Voltage : 400mV/4/40/400/1000V
• Accuracy :
• ± (0.5% rdg 4 dgt) on 400mV/4V; ± (0.7% rdg 4 dgt) on 40/400V
• ± (1.0% rdg 4 dgt) on 1000V
• AC Voltage : 4 / 40 / 400 / 750V
• Accuracy : ± (1.0% rdg 5 dgt) on all ranges except; ± (1.5% rdg 8 dgt) on 750V
• DC Current : 400/4000mA/40/400mA/4/20A
• Accuracy : ± (1.5% rdg 4 dgt)
• AC Current : 400/4000mA/40/400mA/4/20A
• Accuracy : ± (2.2% rdg 4 dgt)
• Resistance : 400V/4/40/400kV/4/40MV
• Accuracy :± (0.7% rdg 4 dgt) on all ranges except; ± (1.2% rdg 4 dgt) on 4MV;
• ± (2.5% rdg 4 dgt) on 40MV
• Capacitance : 40/400nF/4/40/100mF
• Accuracy : ± (5.0% rdg 10 dgt)
• Frequency : 9.999Hz ~9.999MHz
• Accuracy :± (0.5% rdg 2 dgt)
• Duty Cycle : 0.1% ~ 99.9%
• Accuracy :± (0.5% rdg 2 dgt)
• Temperature : -200C~13000C
• Accuracy : ± (2% rdg 4 dgt) (with appropriate sensor to be procured separately)
• Sp. Function : Diode Test, Audible Continuity, Data Hold
• Power : Two 1.5V Battery Eveready; Type 1015 or equivalent
• Low Battery : indicated
• Accessories : Supplied with pair of test leads, battery, K type thermocouple (upto 2600C), instruction manual & carrying case

• DC Voltage : 200mV/2/20/200/1000V
• Accuracy : ±(0.5%rdg 1dgt) on all ranges
• AC Voltage : 200mV/2/20/200/750V (50-500Hz)
• Accuracy : ±(1%rdg 4dgt) on all ranges except ±(1.5%rdg 4dgt) on 750V
• DC Current : 200mA/2mA/20mA/; 200mA/20A
• Accuracy : ±(1%rdg 1dgt) on all ranges except ±(2%rdg 3dgt) on 20A
• AC Current : 200mA/2mA/20mA/; 200mA/20A (50-500Hz)
• Accuracy : ±(1.2%rdg 4dgt) on all ranges except ±(2%rdg 4dgt) on20A
• Resistance : 200V/2kV/20kV/200kV/; 2000kV/20MV/200MV
• Accuracy : ±(0.8%rdg 1dgt) on all ranges, except ±(1%rdg 3dgt) on 200V; ±(3%rdg 3dgt) on 20MV; ±(5%rdg 10dgt) on 200MV
• Spl. Function : Audible Continuity, Diode Check, HFE Test
• Power : One 9V battery, Eveready type 216 or equivalent
• Low Battery : " " is indicated
• Battery Life : 200 hours typical
• Dimensions : 170 x 80 x 38 mm
• Weight : 250gms (approx.)
• Accessories : Supplied with pair of test leads, carrying case, battery, instruction manual and spare fuse

• Non-contact voltage detection
• AutoVolt automatic AC/DC voltage selection
• Prevent false readings caused by ghost voltage with selectable low-impedance mode

• Easy, modern operation with function keys instead of a dial Measurement parameter detection and selection via the socket assignment Prevents incorrect settings True root mean square measurement - TRMS Large, backlit display

•

• Easy, reliable work thanks to automatic measurement parameter detection

• Comfortable, one-handed operation without any dial

• Voltage range up to 1,000 V

• Additional functions, such as true root mean square measurement - TRMS, low-pass filter and temperature adapter

The testo 760-3 is the most high-performance model in Testo's digital multimeter family. In addition to automatic detection of measurement parameters, it is characterized by a voltage measuring range of up to 1,000 V along with large measuring ranges for frequency and capacitance. The digital multimeter is therefore also suitable for industrial applications.

• 6000 counts LCD dual display with white backlit
• Auto ranging, TRMS AC Voltage & Current measurement.
• Basic DC accuracy is A+-0.25%.
• Highly linear readings.
• 60 Position bar graph for trend indication

• 0.1AUA to 10A AC/DC Current measurements.
• Capacitance measurement up to 60mF with Auto discharge facility
• Functions: Auto Polarity, REL, MAX/MIN and Hz/Duty cycle, Diode, Low Battery indication & Auto Power off
• Safety - CE, CAT III 1000V, IP54, IEC61010-1 & EN61326-1

Additional Information:

• Production Capacity: 10000 per year
• Delivery Time: ready stock

Additional Information:

• Delivery Time: 3 weeks
• Packaging Details: LR6 (AA) Alkaline battery (built-in internal) ¿¿ 1, Humidity Sensor LR9504 ¿¿ 1, Instruction manual ¿¿ 1, Operation guide ¿¿ 1, Kickstand ¿¿ 1
