Selec Multifunction Meter Mfm384 96 X 96
₹ 4,999/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
Product Brochure Watch Video
| Phase | Single Phase |
| Model Name/Number | MFM 384 |
| Type | MULTIFUNCTION METER |
| Voltage | 85 to 270V AC, 50/60Hz (+-5%) |
| Display Type | LCD with Backlight, Bar graph Representation for Current |
| Usage/Application | Industrial |
| Dimension | 96 x 96mm |
| Mounting Type | Panel Mount |
| Display Configuration | 4 Rows of 4 Digits, 1 Row of 8 Digits |
| CT Secondary | 1 / 5 A ( Programmable ) |
| Certification | CE, RoHS, UL & MID |
| Accuracy | Accuracy Class 0.5S / Class 1 |
| Communication | RS485 and MODBUS RTU |
| Brand | Selec |
| Rated voltage Aux Supply | 85 to 300V AC / DC (45/65Hz) |
| Country of Origin | Made in India |
Brief Specifications
| Display Type | LCD with Backlight, Bar graph Representation for Current |
| Display Configuration | 4 Rows of 4 Digits, 1 Row of 8 Digits |
| Electrical Connection | 3Ø - 3W, 3Ø - 4W, 2Ø - 3W, 1Ø - 2W |
| Type of Output | Pulse Output |
| Features | %THD upto 31st Level, Max / Min Demand (Power), Max Demand Current, Phase Sequence Detection |
| Communication Protocol | RS485 and MODBUS RTU |
| CT Primary | 1 / 5 A to 10 kA (Programmable for Any Value) |
| CT Secondary | 1 / 5 A ( Programmable ) |
| PT Primary | 100 V to 500 kV (Programmable for Any Value) |
| PT Secondary | 100 to 500V AC (L - L) (Programmable for any value) |
| Rated Input Current | Nominal 5A AC (Min – 11mA; Max – 6A) |
| Supply Voltage | 85 to 300V AC / DC (45/65Hz) |
| Size | 96 x 96mm |
| Mounting Type | Panel Mount |
| Certification | CE, RoHS, UL & MID |
| Product Code | Supply Voltage | Output | Certification | |
|---|---|---|---|---|
| Pulse Output | Communication (RS485) | |||
| MFM384-C-CU | 85 to 270V AC, 50/60Hz (±5%) | Yes | Yes | CE RoHS & UL |
| MFM384-C-CE | 85 to 300V AC, 50/60Hz (±5%) | Yes | Yes | CE RoHS |
| MFM384-C-CU-MID | 85 to 300V AC (47/63Hz) | Yes | Yes | MID |
| MFM384-C-CE-CL05 | 85 to 300V AC, 50/60Hz (±5%) | Yes | Yes | CE RoHS |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
Energy Meter
₹ 998/PieceGet Latest Price
Our company Hi Tech Automation And Control was established in the year 2012. We are manufacturer/Trading of Electrical switchgears, cable and panel accesories . Our massive range of products that are very popular among our clients. These products are made of superlative quality raw materials at our vendors' end. Our prestigious clients have approved these products for their accurate and correct measurement.
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Type | Digital |
| Control Type | PID |
| Application Area | For Oven/ Furnace |
| Manual Reset Value | YES |
| Country of Origin | Made in India |
| Display Type | 7 Segment LED Single Display |
| Display Configuration | 4 digits |
| Type of Input | Thermocouple (J,K,T,R,S) / RTD (PT100) |
| Resolution | 0.1/1° for TC/RTD , (fixed 1° for R and S TC) |
| Accuracy | For TC (J, K, T) inputs: 0.25% of F.S. ± 1 ° For R & S inputs: 0.5% of F.S. ±2 (20min of warm up time) For RTD inputs: 0.1% of F.S ±1 |
| Control Output | RELAY or SSR. |
| Auxiliary Output | RELAY |
| Control Mode | Auto Tune PID / ON-OFF |
| Supply Voltage | 90 to 270V AC/DC |
| Size | 72 x 72mm |
| Mounting Type | Panel Mount |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Type | CT Operated |
| Phase | 3 Phase |
| Material | Plastic |
| Voltage | 440V AC |
| Country of Origin | Made in India |
| MOUNTING | PANEL MOUNTING |
Brief Specifications
| Display Type | 7 Segment LED Display |
| Display Configuration | 1 row of 6 digits |
| Electrical Connection | 3Ø - 3W, 3Ø - 4W, 2Ø - 3W, 1Ø - 2W |
| Type of Output | Pulse Output |
| Features | Active Energy monitoring (EM306) Active Energy monitoring with other multifunction parameters like Power, PF (EM306-C-D) |
| Power Consumption | 8VA Max |
| Communication Protocol | RS485 and MODBUS RTU (EM306-C-D) |
| CT Primary | 1 / 5A to 10kA (Programmable for Any Value) |
| CT Secondary | 1 / 5A (Programmable) |
| PT Primary | 100V to 500kV (Programmable for any value) |
| PT Secondary | 100 to 500V AC (L - L) (Programmable for any value) |
| Supply Voltage/D.G Sensing | 85 to 270 V AC 50/60Hz |
| Size | 96 x 96mm |
| Mounting Type | Panel Mount |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Display Type | LED DISPLAY |
| Model Name/Number | VAF39A |
| Usage/Application | INDUSTRIAL |
| Mounting Type | PANEL MOUNTING |
| Brand | SELEC |
| Accuracy | 0.5 |
| Current Range | 5A to 10kA |
| Enclosure | ABS |
| Input Voltage | 230V AC +-20% , 110V AC +-20% |
| Material | ABS |
| Part Number | VAF39A |
| Power Supply | 230V AC +-20% , 110V AC +-20% |
Brief Specifications
| Display Type | 7 segment LED, Integrated with Parameter Units |
| Display Configuration | 3 Rows of 3 Digits |
| Electrical Connection | 3Ø – 4W, 3Ø -3W, 2Ø-3W, 1Ø - 2W |
| CT Primary | 5A to 10kA (Programmable for any value) |
| CT Secondary | 5A Fixed |
| PT Primary | 100V to 500kV (Programmable for Any Aalue) |
| PT Secondary | 100 to 500V AC (L-L) (Programmable for Any Value) |
| Measuring Parameter | Voltage (L-N / L-L) (Individual / Average), Current (I1, I2, I3) (Individual / Average), Frequency, RPM, Run Hour |
| Supply Voltage | 230V AC ±20% , 110V AC ±20% |
| Size | 96 x 96mm |
| Mounting Type | Panel Mount |
| Certification | CE, RoHS & UL |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| VAF39A-1-230V-CE | 230V AC ±20% (50/60Hz) | CE, RoHS |
| VAF39A-110V-CU | 110V AC ±20% (60Hz) | CE, RoHS & UL |
| VAF39A-1 | 230V AC ±20% (50/60 Hz) | --- |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Usage/Application | Industrial |
| Model Name/Number | MA202 |
| Brand | SELEC |
| Material | ABS |
| CT Primary | 5 to 4000A |
| CT Secondary | 5A |
| Electrical Connection | 1 PHASE |
| Size | 72 x 72mm |
| Country of Origin | Made in India |
Brief Specifications
| Display Type | 7 Segment LED |
| Display Configuration | 1 row of 4 digits |
| Electrical Connection | 1Ø - 2W |
| Accuracy | ±0.5% of Full Scale |
| CT Primary | 5 to 4000A (Programmable in Steps) |
| CT Secondary | 5A |
| Supply Voltage | 240V AC ±20% |
| Size | 72 x 72mm |
| Mounting Type | Panel Mount |
| Certification | CE, RoHS |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| MA202-CE | 240V AC ±20% (50/60Hz) | CE, RoHS |
| MA202 | 240V AC ±20% (50/60Hz) | --- |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Display Type | LCD |
| Model Name/Number | VAF36A |
| Usage/Application | PANEL |
| Brand | SELEC |
| Accuracy | 0.5 |
| Current Range | 5A to 10kA |
| Enclosure | ABS |
Brief Specifications
| Display Type | LCD with Backlight and Analog Style Bargraph Indication |
| Display Configuration | 3 Rows of 3 Digits |
| Electrical Connection | 3Ø - 4W, 3Ø - 3W, 2Ø - 3W, 1Ø - 2W |
| CT Primary | 5A to 10kA ( Programmable for any value) |
| CT Secondary | 5A Fixed |
| PT Primary | 100V to 500kV (Programmable for Any Value) |
| PT Secondary | 100 to 500V AC (L-L) (Programmable for Any Value) |
| Measuring Parameter | Voltage (L-N / L-L) (Individual / Average), Current (I1, I2, I3) (Individual / Average), Frequency, RPM, Run Hour |
| Supply Voltage | 240V AC ±20%, 110V AC ±20% |
| Size | 96 x 96mm |
| Mounting Type | Panel Mount |
| Certification | CE, RoHS & UL |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| VAF36A-230V-CE | 230V AC ±20% (50/60Hz) | CE, RoHS |
| VAF36A-110V-CU | 110V AC ±20% (60Hz) | CE, RoHS & UL |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Current Rating | 5A |
| Type | Voltage Relays, Current Relay, Industrial Relay |
| Voltage Type | AC |
| Coil Type | Non Latching, Latching |
| Frequency | 50Hz |
| Country of Origin | Made in India |
| BRAND | SELEC |
Brief Specifications
| Measuring Parameter | Monitors True RMS Earth Leakage Current (upto 30A ) |
| Electrical Connection | 1Ø-2W, 3Ø-4W, 3Ø-3W |
| Supply Voltage | 90 - 270V AC/DC |
| Trip Leakage current range | 30mA - 30A |
| Display Current range | 15mA - 33A |
| Time Ranges | 0 to 999 sec |
| Response time | < 30ms (if trip current 5 x set value & Instantaneous trip is ON), < 50ms (if trip current = 1 x set value) |
| CBCT DETECTION | Yes, when CBCT absent or short |
| Accuracy | ± 5% setting of current, ± 5% time setting for ±100ms |
| Output Contact | 1 C / O (SPDT ) |
| Output Rating | NO / 5A@250V AC / 28V DC |
| Size | 96X96mm |
| Mounting Type | Panel mount |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| ELR341-1 | 90 to 270V AC / DC | - |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Brand | SELEC |
| Manufacturer Series | DIGIX |
| I/O Points | 8 |
| Output Type | Digital |
| Pulse Transmission Output | DIGITAL |
| Communication Port | RS485 |
| Display Type | LCD |
| Usage/Application | PLC |
Rail mount Blind PLCProduct: DIGIX-B
- Rail Mount Blind PLC with LED indications.
- 8 Digital Inputs and 5 Relay Outputs.
- 1 channel Fast Input upto 5 kHz.
- Power supply :18 to 30VDC.
- RJ25 MODBUS RS485 Serial Slave Port for Downloading and Communication.
| Display Type | LEDs for Input, Output & Communication Status |
| Size | 70 x 90mm |
| Digital Inputs | 6 (PNP Type) Including 1 Fast Input Channel |
| Analog Inputs | N/A |
| Digital Outputs | 5 Relay Outputs |
| Output Rating | 5A @230VAC / 24VDC |
| Analog Outputs | NA |
| RTC With Time Switch Function | N/A |
| Code Memory | 112KB |
| Communication Interface | RS485 Based MODBUS RTU Protocol |
| Expansion | N/A |
| Supply Voltage | 18 to 30 VDC |
| Mounting Type | DIN Rail Mount |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Analog Inputs | 4 Channel |
| Output Type | Digital |
| Communication Port | RS485 Modbus RTU Protocol (Master - Slave ), Ethernet (Slave), USB , CAN |
| Brand | SELEC |
| Manufacturer Series | MIBRX |
| I/O Points | 12 |
| Mounting Type | DIN Rail |
| Display Type | LCD |
| Country of Origin | Made in India |
- 6M Sized, Rail mount modular PLC with multiple pluggable LED/LCD Display options
- Offers Flexible IO Card selection
- Expandable via MOBBUS RTU
- RTC with time switch functions (Optional)
| Display Type | LED Display/LCD Display |
| Supply Voltage | 230VAC/24VDC |
| Size | 70(W) x 90(H) x 66.4(D)mm |
| Digital Inputs | 10+1* / 12 |
| Analog Inputs | 1 V(0-10V) + As per IO Card Selection |
| Digital Outputs | 4 relay + As per IO card selection |
| Analog Outputs | As per IO Card Selection |
| No. of Slots | 6 |
| RTC With Time Switch Function | Yes |
| Code Memory | 240Kb |
| Communication Interface | RS485 Modbus RTU Protocol (Master - Slave ), Ethernet (Slave), USB , CAN |
| Expansion | via modbus RTU RS485 |
| Mounting Type | Din Rail |
| FI / Maximum Counting Frequency | 1( 5kHz) / 2( 5kHz) |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
SELEC MFM391 ECONOMICAL LED MULTIFUNCTION METER
₹ 3,999/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
| Phase | Single Phase |
| Model Name/Number | MFM 391 |
| Type | MULTI FUNCTION METER |
| Voltage | 85 to 270V AC (45/65Hz) |
| Display Type | 7 Segment LED |
| Usage/Application | Industrial |
| Dimension | 96 x 96mm |
| Mounting Type | Panel Mount |
| Input Current | Nominal 5A AC (Min - 20mA Max - 6A) |
| Display Panel | 7 Segment LED |
| Display Configuration | 3 Rows of 3 Digits |
| CT Secondary | 1 / 5 A (Programmable) |
| Accuracy | Accuracy of +- 0.5% |
| Pt Primary | 100V to 500kV (Programmable for Any Value) |
| Brand | Selec |
| Rated voltage Aux Supply | 85 to 270V AC (45/65Hz) |
| Country of Origin | Made in India |
Brief Specifications
| Display Type | 7 Segment LED |
| Display Configuration | 3 Rows of 3 Digits |
| Electrical Connection | 3Ø -3W, 3Ø - 4W, 2Ø - 3W, 1Ø - 2W |
| Features | VAF meter with Power-Factor and Power, Run Hour and RPM measurement |
| Communication Protocol | NA |
| CT Primary | 1 / 5A to 10kA (Programmable for Any Value) |
| CT Secondary | 1 / 5 A (Programmable) |
| PT Primary | 100V to 500kV (Programmable for Any Value) |
| PT Secondary | 100V to 500V (Programmable for Any Value) |
| Rated Input Current | Nominal 5A AC (Min - 20mA Max - 6A) |
| Size | 96 x 96mm |
| Supply Voltage | 85 to 270V AC (45/65Hz) |
| Mounting Type | Panel Mount |
| Certification | -- |
| Product Code | Supply Voltage | Output | Certification | |
|---|---|---|---|---|
| Pulse Output | Communication (RS485) | |||
| MFM391 | 85V - 270V AC,50/60Hz | No | No | -- |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
SELEC MFM384-R-C Din Rail Multifunction Meter
₹ 3,999/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
| No. of Phases | Three Phase |
| Phase | 3 Phase |
| Material | Plastic |
| Country of Origin | Made in India |
Brief Specifications
| Display Type | LCD with Backlight |
| Display Configuration | 1 Row of 4 Digits, 2 Rows of 7 Digits |
| Electrical Connection | 3Ø - 3W, 3Ø - 4W, 2Ø - 3W, 1Ø - 2W |
| Features | Phase Angle Detection, Energy (Active / Reactive / Apparent), Import / Export Energy, Min / Max Demand Power |
| Communication Protocol | RS485 and MODBUS RTU |
| CT Primary | 1 / 5A to 10kA (Programmable for Any Value) |
| CT Secondary | 1 / 5A (Programmable) |
| PT Primary | 100V to 500kV (Programmable for Any Value) |
| PT Secondary | 100V to 500V AC (L – L) (Programmable for Any Value) |
| Supply Voltage | 85 to 270V AC (50/60Hz) |
| Size | 70mm |
| Mounting Type | Din Rail Mount |
| Certification | CE RoHS & MID |
| Product Code | Supply Voltage | Communication (RS485) | Certification |
|---|---|---|---|
| MFM384-R-C-CE | 85 to 270V AC, 50 / 60Hz | Yes | CE RoHS |
| MFM384-R-C-MID | 85 to 270V AC, 50 / 60Hz | Yes | MID |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| No. of Phases | Single Phase |
| Phase | 1 Phase |
| Material | Plastic |
| Country of Origin | Made in India |
Brief Specifications
| Display Type | 7 Segment LED Display |
| Display Configuration | 2 rows of 8 digits |
| Electrical Connection | 3Ø - 3W, 3Ø - 4W, 2Ø - 3W, 1Ø - 2W |
| Type of Output | Pulse Output |
| Features | Phase Angle Detection, (Max / Min) Demand Power, Run Hour, Auxiliary Interrupts |
| CT Primary | 1 / 5A to 10kA (Programmable for Any Value) |
| CT Secondary | 1 / 5A (Programmable) |
| PT Primary | 100V to 500kV (Programmable for Any Value) |
| PT Secondary | 100V to 500V AC (Programmable for Any Value) |
| Rated Input Current | Nominal 5A AC (Min – 20mA; Max – 6A) |
| Supply Voltage | 40V to 300V AC / DC (50/60Hz) |
| Size | 96 x 96mm |
| Mounting Type | Panel Mount |
| Product Code | Supply Voltage | Output | Certification | |
|---|---|---|---|---|
| Pulse Output | Communication | |||
| MFM376-CE | 40V-300V AC/DC,50/60Hz | Yes | -- | CE |
| MFM376-C-CE | 40V-300V AC/DC,50/60Hz | Yes | Yes | CE RoHS |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Usage/Application | Industrial |
| CT Primary | 1 to 999.0kA |
| CT Secondary | 1 or 5A |
| Electrical Connection | 1 PHASE |
| Size | 96 x 96mm |
Brief Specifications
| Display Type | 7 Segment LED |
| Display Configuration | 1 row of 4 digits |
| Electrical Connection | 3Ø – 4W, 3Ø -3W, 1Ø - 2W |
| Accuracy | ±0.5% of Full Scale |
| CT Primary | 1 to 999.0kA ( Programmable for Any Value ) |
| CT Secondary | 1 or 5A ( Programmable ) |
| Supply Voltage | 230 AC ±20% |
| Size | 96 x 96mm |
| Mounting Type | Panel Mount |
| Certification | CE, RoHS |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| MA335-230V AC | 230V AC ±20% (50/60Hz) | --- |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Analog Inputs | 6 Channel |
| Country of Origin | Made in India |
| DISPLAY | LED |
| BRAND | SELEC |
| MOUNTING | DINRAIL MOUNTING |
Brief Specifications
| Display Type | 7 Segment LED Display |
| Supply Voltage | 24VAC/24VDC |
| Size | 35(W) x 90(H) x 60(D)mm |
| Digital Inputs | 3 |
| Analog Inputs | As per IO Card Selection |
| Digital Outputs | As per IO Card Selection |
| Analog Outputs | As per IO Card Selection |
| No. of Slots | 2 |
| RTC With Time Switch Function | Optional |
| Code Memory | 112Kb |
| Communication Interface | RS485 Modbus RTU Protocol (Slave ) |
| Expansion | No |
| Mounting Type | Din Rail |
| FI / Maximum Counting Frequency | 1( 5kHz) |
| Product Code | Description | Certification |
|---|---|---|
| MiBRX-2M-1-0-0-24V AC | MiBRX 2M Base module - 2 slots, 3DI | CE RoHS |
| MiBRX-2M-1-0-0-24VDC | MiBRX 2M PS - 2 Slots, 3DI (incl 1FI) | CE, RoHS |
| MiBRX-DSP-AP-2M | MiBRX 2M Adapter Plate for independent display | CE RoHS |
| MiBRX-DSP-2M-0-1-06-A | MiBRX Display 2M - Blind, 6 LED | CE RoHS |
| MiBRX-DSP-2M-7-1-04-A | MiBRX Display 2M - 7 seg (4 digit), 6 LED | CE RoHS |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Output Type | Digital |
| Communication Port | RS485 Modbus RTU Protocol (Slave ) |
| Brand | SELEC |
| Manufacturer Series | MIBRX |
| I/O Points | 2 |
| Display Type | LED |
| Mounting Type | DIN Rail |
| Usage/Application | Automation |
| Number of Inputs | 9 Digits |
| Program Language | LADDER LOGIC |
Brief Specifications
| Display Type | LED Display |
| Supply Voltage | 230VAC/24VDC |
| Size | 96(W) x 48(H) x 69(D)mm |
| Digital Inputs | 5+1*/5+2* |
| Analog Inputs | 1 V(0-10V) + As per IO Card Selection / 3 [2-V(0-10V)/1-I(0-20mA)] + As per IO Card Selection |
| Digital Outputs | As per IO Card Selection |
| Analog Outputs | As per IO Card Selection |
| No. of Slots | 2 |
| RTC With Time Switch Function | Optional |
| Code Memory | 240Kb |
| Communication Interface | RS485 Modbus RTU Protocol (Slave ) |
| Expansion | No |
| Mounting Type | Panel Mount |
| FI / Maximum Counting Frequency | 1( 5kHz) |
| Product Code | Description | Certification |
|---|---|---|
| MiBRX-48-0-0-230V | MiBRX 48x96 PS - 2 slots, 5+1*DI (incl 1FI, 1AI-V), NTC | CE RoHS |
| MiBRX-48-0-0-24VDC | MiBRX 48x96 PS - 2 slots, 5+2*DI (incl 1FI, 2AI-V), 1AI-I, NTC | CE RoHS |
| MiBRX-DSP-48-7-2-11-A | MiBRX Display 48x96 - 7 Seg (3+4 & 4 digit), 6 LED, 10 Bar Graph LED | CE RoHS |
| MiBRX-DSP-48-7-2-14-B | MiBRX Display 48x96 - 7 Seg (8 & 6 digit), 8 LED | CE RoHS |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Type | Digital |
| Country of Origin | Made in India |
| BRAND | SELEC |
Brief Specifications
| Display | 3.5” Resistive touch screen |
| KEYS | Yes (5 nos) |
| KEYS Type | Capacitive Touch Pad type with integrated yellow green LEDs |
| Supply Voltage | 24V DC (non-isolated) |
| Product Code | Description | Certification |
|---|---|---|
| MiBRX-DSP-IND-96-8-0-00-C | MiBRX Independent Display 96x96 - 3.5 Inch Graphic Touch | CE RoHS |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| No.of Poles | Triple Pole |
| Rated Current | 50 |
| Type | C Curve |
| Breaking Capacity | 10 kA |
| Certification | IS/IEC 60898-1 |
| Frequency | 50 Hz |
| Voltage | 440 |
| Phase | 3 PHASE |
| Model Name/Number | 3POLE MCB |
FEATURES
- Tripping curves:C
- Breaking Capacity 10kA
- IP 20 degree protection
- Trip Free mechanism with padlocking facility
- Low Power Consumption
- Current limiting design – class 3
- Air Circulation
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| No.of Poles | Triple Pole |
| Rated Current | 40A |
| Type | C Curve |
| Breaking Capacity | 10 kA |
| Certification | IS/IEC 60898-1 |
| Frequency | 50 Hz |
| Voltage | 440 |
| Phase | 3 PHASE |
| Model Name/Number | CSMBS3C** |
FEATURES
- Tripping curves:C
- Breaking Capacity 10kA
- IP 20 degree protection
- Trip Free mechanism with padlocking facility
- Low Power Consumption
- Current limiting design – class 3
- Air Circulation
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
Ac Analog Voltmeter
₹ 299/PieceGet Latest Price
| Voltage Range | 500 V |
| Display Type | Needle Based |
| Country of Origin | Made in India |
| BRAND | SELEC |
| MOUNTING TYPE | PANEL MOUNT |
Brief Specifications
| Pointer | Knife Edge Pointer |
| Pointer Deflection | 0 to 90 degree |
| Measured Parameters | AC Voltage |
| Measuring Voltage Range | 0 to 300V/500V |
| Overload Capacity Continuously | 1.2 times rated Voltage |
| Frequency | 50 - 60 Hz |
| Accuracy | Class 1.5 |
| Mounting | Panel Mount |
| Size | 72X72mm |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -20°C to 60°C |
| Relative Humidity (non - condensing) | upto 75% |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
SELEC MV35 Digital voltmeter with wide Aux supply
₹ 2,999/PieceGet Latest Price
Product Brochure Watch Video
| Voltage Range | 1000 V |
| Operating Temperature | -10 DegreeC to +55 DegreeC |
| Electrical Connection | 1PHASE AND 3PHASE |
| Size | 96 mm x 96 mm |
| Weight | 155 gms |
| Country of Origin | Made in India |
Brief Specifications
| Display | 7 segment LED Display |
| Digits | 1 row of 4 digits |
| Electrical Connection | 3Ø - 4 Wire, 3Ø - 3 Wire, 1Ø - 2 Wire (MV35-1-G-40/300V-CE for single phase only) |
| Rated input voltage | 11 to 300V AC (L-N), 19 to 600V AC (L-L) |
| Accuracy | ±0.5% of Full scale |
| Auxiliary Supply | 40V to 300V AC / DC |
| PT Primary Setting | 100-999kV (Programmable for any value) |
| PT Secondary Setting | 100V-500V (Programmable for any value) |
| Operating Temperature | -10°C to +55°C (14°F to 131°F) |
| Storage Temperature | -20°C to +75°C (-4°F to 167°F) |
| Mounting | Panel mount |
| Bezel size | 96 mm x 96 mm |
| Weight | 155 gms |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| MV35-3-G-40/300V-CE | 40-300V AC/DC | CE |
| MV35-1-G-40/300V-CE | 40-300V AC/DC | CE |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Usage/Application | Industrial |
| Model Name/Number | MA2301 |
| Brand | SELEC |
| Material | ABS |
| Color | BLACK |
| Country of Origin | Made in India |
BRIEF SPECIFICATIONS
| Display Type | LCD with Backlight and Analog Style Bargraph Indication |
| Display Configuration | 4 Digits |
| Electrical Connection | 3Ø – 4W,3Ø – 3W, 1Ø – 2W |
| Accuracy | ± 0.5% of Full Scale |
| CT Primary | 5 to 5000A ( Programmable in Steps ) |
| CT Secondary | 5A ( Fixed ) |
| Supply Voltage | 240V AC ±20% (50/60 Hz) |
| Size | 72 x 72mm |
| Mounting Type | Panel Mount |
| Certification | CE, RoHS & UL |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| MA2301-230V-CE | 240V AC ±20% (50/60 Hz) | CE, RoHS |
| MA2301-230V | 240V AC ±20% (50/60 Hz) | --- |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Usage/Application | Industrial |
| Model Name/Number | MA32 |
| Brand | SELEC |
| Material | ABS |
| Color | WHITE |
| Operating Temperature | -20 DegreeC to +75 DegreeC (-4 DegreeF to 167 DegreeF) |
| Supply Voltage | 40 to 300V AC/DC |
| Voltage | 40 to 300V AC/DC |
| Panel Cut Out | 96 mm x 96 mm |
| Country of Origin | Made in India |
Brief Specifications
| Display | 7 segment LED Display |
| Digits | 1 row of 4 digits |
| Electrical Connection | 3Ø - 4W, 3Ø - 3W, 1Ø – 2W (MA32-1-G-40/300V-CE for single phase only) |
| Rated input current | 50mA – 5A AC |
| Accuracy | ±0.5% of F.S. |
| Auxiliary Supply | 40 to 300V AC/DC |
| PT Primary Setting | 1-999kA (Programmable for any value) |
| CT Secondary Setting | 1 / 5A (Programmable) |
| Operating Temperature | -10°C to +55°C (14°F to 131°F) |
| Storage Temperature | -20°C to +75°C (-4°F to 167°F) |
| Mounting | Panel mount |
| Bezel size | 96 mm x 96 mm |
| Weight | 165gms for MA32-3-G-40/300V-CE 150gms for MA32-1-G-40/300V-CE |
| Certification | CE, RoHS |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| MA32-3-G-40/300V-CE | 40-300V AC/DC | CE, RoHS |
| MA32-1-G-40/300V-CE | 40-300V AC/DC | CE, RoHS |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Voltage Range | 500 V |
| Electrical Connection | 1 PHASE |
| Size | 48 x 96mm |
| Country of Origin | Made in India |
Brief Specifications
| Display Type | 7 Segment LED |
| Display Configuration | 1 row of 3 digits |
| Electrical Connection | 1Ø - 2W |
| Accuracy | ±0.5% of Full Scale Over Rated Operating Condition |
| Measuring Range | 50 - 600V AC |
| Supply Voltage | 240V AC ±20% , 110V AC ±20% |
| Size | 48 x 96mm |
| Mounting Type | Panel Mount |
| Certification | CE, RoHS |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| MV15-CE | 240V AC ±20% (50/60Hz) | CE, RoHS |
| MV15-110V-CU | 110V AC ±20% (60Hz) | CE, RoHS & UL |
| MV15 | 240V AC ±20% (50/60Hz) | --- |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Voltage Range | 500 V |
| Electrical Connection | 1 PHASE |
| Size | 72 x 72mm |
| Country of Origin | Made in India |
| MOUNTING TYPE | PANEL MOUNTING |
Brief Specifications
| Display Type | 7 Segment LED |
| Display Configuration | 1 row of 3 digits |
| Electrical Connection | 1Ø - 2W |
| Accuracy | ±0.5% of Full Scale Over Rated Operating Condition |
| Measuring Range | 50 - 600V AC |
| Supply Voltage | 240V AC ±20% |
| Size | 72 x 72mm |
| Mounting Type | Panel Mount |
| Certification | CE, RoHS |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| MV205-CE | 240V AC ±20% (50/60Hz) | CE, RoHS |
| MV205 | 240V AC ±20% (50/60Hz) | --- |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Voltage Range | 500 V |
| Electrical Connection | 1 PHASE |
| Size | 96 x 96mm |
| Country of Origin | Made in India |
| MOUNTING TYPE | PANEL MOUNT |
Brief Specifications
| Display Type | 7 Segment LED |
| Display Configuration | 1 row of 3 digits |
| Electrical Connection | 1Ø - 2W |
| Accuracy | ±0.5% of Full Scale Over Rated Operating Condition |
| Measuring Range | 50 - 600V AC |
| Supply Voltage | 240V AC ±20% |
| Size | 96 x 96mm |
| Mounting Type | Panel Mount |
| Certification | CE, RoHS |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| MV305-CE | 240V AC ±20% (50/60Hz) | CE, RoHS |
| MV305 | 240V AC ±20% (50/60Hz) | --- |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Voltage Range | 500 V |
| Display Type | LCD |
| Electrical Connection | 1 PHASE |
| Size | 48 x 48mm |
| Country of Origin | Made in India |
| MOUNTING TYPE | PANEL MOUNT |
Brief Specifications
| Display Type | LCD with Backlight & Analog Style Bargraph Indication |
| Display Configuration | 1 row of 3 digits |
| Electrical Connection | 1Ø - 2W |
| Accuracy | ±0.5% of Full Scale Over Rated Operating Condition |
| Measuring Range | 50 - 480V AC (516V Max) |
| Supply Voltage | 240V AC ±20% , 110V AC ±20% |
| Size | 48 x 48mm |
| Mounting Type | Panel Mount |
| Certification | CE, RoHS |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| MV507-230V-CE | 240V AC ±20% (50/60Hz) | CE, RoHS |
| MV507-110V-CU | 110V AC ±20% (60Hz) | CE, RoHS |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Voltage Range | 1000 V |
| Electrical Connection | 1PHASE, 3PHASE |
| Size | 96 x 96mm |
| Country of Origin | Made in India |
| MOUNTING TYPE | PANEL MOUNT |
Brief Specifications
| Display Type | 7 Segment LED |
| Display Configuration | 1 row of 4 digits |
| Electrical Connection | 3Ø – 4W, 3Ø -3W, 1Ø - 2W |
| Accuracy | ±0.5% of Full Scale |
| PT Primary | 100V-999kV (Programmable to Any Value) |
| PT Secondary | 100V- 500V (Programmable to Any Value) |
| Supply Voltage | 230V AC ±20% |
| Size | 96 x 96mm |
| Mounting Type | Panel Mount |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| MV334-230V-CE | 230V AC ±20% (50/60Hz) | CE, RoHS |
| MV334-230V | 230V AC ±20% (50/60Hz) | --- |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Voltage Range | 500 V |
| Display Type | LCD |
| Operating Temperature | -10 DegreeC to +55 DegreeC |
| Electrical Connection | 3phase 4Wire 3phase 3Wire |
| Size | 72 x 72mm |
| Weight | 206 Gm |
| Country of Origin | Made in India |
Brief Specifications
| Display Type | LCD with Backlight and Analog Style Bargraph Indication |
| Display Configuration | 1 row of 3 digits |
| Electrical Connection | 3Ø – 4W, 3Ø -3W |
| Accuracy | ±0.5% of Full Scale Over Rated Operating Condition |
| Measuring Range | 50 - 480V AC (516V Max) |
| Supply Voltage | 240V AC ±20% , 110V AC ±20% |
| Size | 72 x 72mm |
| Mounting Type | Panel Mount |
| Certification | CE, RoHS & UL |
| Product Code | Supply Voltage | Certification |
|---|---|---|
| MV2307-230V-CE | 240V AC ±20% (50/60Hz) | CE, RoHS |
| MV2307-110V-CU | 110V AC ±20% (60Hz) | CE, RoHS & UL |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Mounting Type | WALL MOUNT |
| Country of Origin | Made in India |
Brief Specifications
| No. of phases | 1 phase & 3 phase |
| Measuring current | 80A to 250A measurement, 800A with converter |
| Mounting | Din rail & Wall mount |
| Product Code | No. of phase | Meauring current |
|---|---|---|
| CT 3PH-21x25mm-250A-G | 3 Phase | 250A |
| CT 3PH-D13mm-80A-G | 3 Phase | 80A |
| CT 1PH-30x10mm-250A-G | 1 Phase | 250A |
| CT 1PH-D13mm-80A-G | 1 Phase | 80A |
| 3PH 5A CONVERTER-G | 3 Phase | CONVERTER |
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Voltage Range | 500 V |
| Electrical Connection | 1 phase 2 wire |
| Size | 48X48mm |
| Weight | 150 GM |
| Country of Origin | Made in India |
Brief Specifications
| Display parameters | Voltage & Current |
| Display | 3 digit 7 segment LED display with dual rows |
| Colour | Red and Green |
| Electrical connection | 1Ø - 2W |
| Accuracy | (±1%) full scale |
| Supply voltage | 230V AC (± 20%) |
| Resolution | Voltage : 1V Current : 0.1A |
| Rated input voltage | 230V AC (± 20%) |
| Rated input current | 5 to 120% |
| Operating frequency | 50Hz (±5%) |
| Product Code | Current Measurement | Supply Voltage |
|---|---|---|
| MVA591-30A-230V | 30A | 230VAC, ±20%, 50 / 60Hz |
| MVA591-80A-230V | 80A | 230VAC, ±20%, 50 / 60Hz |
View Complete Details
Yes, I am interested!
Maximum Demand Controllers
₹ 5,990/PieceGet Latest Price
Get Price & Details
All Rights Reserved (Terms of Use)
- Developed and Managed by IndiaMART InterMESH Limited
