Hitech Automation And Control

Current	50 A
Mounting Type	DIN Rail
Electricity Type	AC
Model Name/Number	MNX 50
Phase	Three Phase
Voltage	415 V
Number Of Poles	3 Poles

Featuresl Conforms to IS / IEC 60947-4-1 & IEC 60947-4-1l Range from 9A – 650A AC-3l Click fit type construction up to 40Al Coil on top design in 95A and abovel Spares available for entire range. For individuals in need of a dependable and long-lasting contactor, the L&T MNX-50 50A 3 Pole Power Contactor is an excellent option. This contactor has a long lifespan and is constructed from premium materials. Three-pole contactor L&T MNX-50 has two current ratings: 50 amp AC3 and 85 amp AC1. It fits your budget well and is FR-3 sized. This contactor is an excellent option for your electrical needs because it also has a long lifespan.Look through comprehensive selection of Power Contactors. Browse other L&T Power Contactors online at where they are offered at the most affordable prices.
Get best price of L&T MNX 50 Power Contactor at ₹2999/-.

Model Name/Number	LC1E0601
Number Of Poles	4 POLE
Brand	SCHNEIDER
Switching Current	6 AMP
Voltage	415
Mounting Type	DIN Rail
Current	6 AMP
Phase	Three Phase
Electricity Type	AC
Country of Origin	Made in India

Conformance to IEC 60947-4-1, CE MarkingCurrent Rating: 20A to 125A, AC-1 ratingAvailable in 4NO and 2NO+2NC Power Pole combinationWide Band Coil for all ratings in 220 & 415V AC

Line Frequency	50Hz
Weight	250 gm
Frequency	50 Hz
Dimension	96*96 mm
Country of Origin	Made in India
Brand	Selec
Model No	AM-PF-3

Brief Specifications Product Variants

Model Name/Number	LC1E1801
Number Of Poles	4 POLE
Brand	SCHNEIDER
Switching Current	18 AMP
Voltage	415
Mounting Type	DIN Rail
Current	18 AMP
Phase	Three Phase
Electricity Type	AC
Country of Origin	Made in India

Conformance to IEC 60947-4-1, CE MarkingCurrent Rating: 6A to 630A, AC-3 RatingType 2 RSC available with Fuse, MPCB and MCCB

Model Name/Number	LC1D09
Number Of Poles	3 POLE
Brand	SCHNEIDER
Switching Current	9 AMP
Voltage	415
Mounting Type	DIN Rail
Current	9 AMP
Phase	Three Phase
Electricity Type	AC
Country of Origin	Made in India

Conformance to IEC, UL, CSACurrent Rating : 9A to 150AAvailable with AC (50/60Hz Dual frequency), DC & DC lowconsumption coil optionsHigh Operating ambient temperature, no derating upto 60 Deg CInbuilt 1NO + 1NC auxiliary contacts upto 150AHigh electrical and mechanical lifeFuse-less Type 2 Co-ordination Charts availableEverLink® terminal for 40, 50, 65 & 80A contactorsInbuilt surge suppressor in DC coil for 9-80A

Our company Hi Tech Automation And Control was established in the year 2012. We are manufacturer/Trading of Electrical switchgears, cable and panel accesories . Our massive range of products that are very popular among our clients. These products are made of superlative quality raw materials at our vendors' end. Our prestigious clients have approved these products for their accurate and correct measurement.

Our company Hi Tech Automation And Control was established in the year 2012. We are manufacturer/Trading of Electrical switchgears, cable and panel accesories . Our massive range of products that are very popular among our clients. These products are made of superlative quality raw materials at our vendors' end. Our prestigious clients have approved these products for their accurate and correct measurement.

Contactor Type	AC Power Contactors
Number of Poles	4 Pole
Voltage	415
Electricity Type	AC
Usage/Application	Industrial

Specification and Features

• Current ratings : 12A,16A, 20A, 25A, 32A & 40A
• Compact and robust construction using high grade moldings
• Wide band coil options
• Conform to latest Standard IEC 60947-4-1
• Weld resistant Silver alloy contacts
• High Electrical Endurance (AC3) : 1 Million Operations
• High Mechanical Endurance : 5 million operations.
• Encapsulated coil for high withstand capacity
• Standard coil voltages : 24, 48, 110, 220-240, 275-420, 260-400, 380-415V 50 Hz etc.
• Coil operating voltage range : + 10% – 15% of rated voltage
• Coil consumption (max) : Inrush 80VA, Sealed 13.2VA
• Insulation class of coil : E
• Maximum frequency of operation : 600 ops/hour
• Operating time of contactor : 20 milli seconds (average)
• Terminal Capacity Main contacts : 1 x 16 mm2 or 2 x 10 mm2 cable

Additional Information:

• Packaging Details: Block 1E 216, Acharya Jagadish Chandra Bose Road, Kolkata – 700 017
