Hoffmann Quality Tools India Private Limited

Brand Name	Holex
Article No.	412805
Standard	ISO 13385
Size	150 mm
Scale dDvisions	0.01 mm
Measurement Technology	Digital

Version:Large, sharp-contrast digital display. The measuring faces are precision-lapped.Digital caliper with absolute scale, no zeroing required. Electronics switch off automatically after approx. 5 minutes and switch on again as soon as the tool is moved.

• Very high accuracy due to the glass scale.
• The electronics are decoupled from the casing and incorporated directly in the sliding part. The gauging force is transmitted directly to the measurement jaws. This reduces the liability of the caliper to errors and increases the working life.
• With sturdy metal body.

Supplied with:Battery No. 081560 size CR1632.

Optional extras:Keyboard interface No. 498969 size USB.

Stock : India Warehouse

Size	100mm
Brand Name	Holex
Article No.	412821
Standard	ISO 13385
Scale Divisions	0.01 mm
Jaw Length	30 mm

Version:Large high-contrast digital display. The measuring faces are precision-lapped.Incremental measuring system without absolute scale.

Stock : India Warehouse

Brand Name	Holex
Article No.	412751
Size	100 mm
Scale Divisions	0.01 mm
Standard	ISO 13385
Jaw Length	40 mm

Version:Large high-contrast digital display. The measuring faces are precision-lapped. The caliper is resistant to water and dust. After 2 hours without movement, the control system shuts down the caliper automatically. Shock-resistant plastic casing.

Function:IP67: Protected against intermittent immersion in water and protected against penetration by dust (dust-tight), also completely protected against touching.

Stock : India Warehouse

Measuring Range	150 mm
Material	Stainless Steel
Size	150 mm
Brand Name	Garant
Article No.	412690
Standard	ISO 13385
Scale Divisions	0.01 mm
Measurement Technology	Digital

Version:Digital calipers to IP67with data output. Easy-to-read, high-contrast LCD display with 11.5mm character height. Very long battery running time due to modern energy-efficient measurement system. The system switches automatically into power-saving mode after 20 minutes; moving the caliper reactivates it. There is no loss of the measurement value or zero point.
2-component body with easy-grip Haptoprene surface. The calipers are resistant to water, coolant, oil, and dust − even when fitted with a data cable. The measuring faces are precision-lapped. With preset (dimension selection in advance).

Function:IP67: Protected against intermittent immersion in water and protected against penetration by dust (dust-tight), also completely protected against touching.

Supplied with:1 battery No. 081560 size CR2032.

Stock : India Warehouse

Brand Name	Holex
Article No.	410640
Size	150 mm
Standard	ISO 13385
Scale Divisions	0.05 mm
Jaw Length	40 mm

Version:Satin chromium plated anti-glare reading parts. Fine, high-contrast scale, precision lapped measuring faces. Flat vernier scale for parallax-free reading.
With locking screw at top and rod type depth gauge.

Stock : India Warehouse

Brand Name	Holex
Article No.	410200
Size	100 mm
Standard	ISO 13385
Scale Divisions	0.05 mm
Jaw Length	30 mm

Version:Satin chromium plated anti-glare reading parts.
Locking screw at the top.Without inch graduation.

Supplied with:Including thread table No. 412180 for caliper back.

Stock : India Warehouse

Material	Stainless Steel
Brand Name	Holex
Article No.	410625
Standard	ISO 13385
Size	150 mm
Scale Divisions	0.05 mm
Jaw Length	40 mm

Version:Satin chromium plated anti-glare reading parts. Fine, high-contrast scale. Precision lapped measuring faces.

Stock : India Warehouse

Brand Name	Garant
Article No.	410100
Scale Divisions	0.05 mm
Standard	ISO 13385
Jaw Length	40 mm
Measurement Technology	Analogue

Version:Satin chromium plated anti-glare scales.
Fine, high-contrast scale.
Locking screw at the top.
Ergonomically optimised caliper.
Precision lapped measuring faces.Better reading due to a colour-contrast scale.

Optional extras:Thread table No. 412180 for caliper back.

Stock : India Warehouse

Brand Name	Garant
Article No.	410105
Standard	ISO 13385
Scale Divisions	0.02 mm
Jaw Length	40 mm
Measurement Technology	Analogue

Version:Satin chromium plated anti-glare scales.
Fine, high-contrast scale.
Locking screw at the top.
Ergonomically optimised caliper. Better reading due to a colour-contrast scale.
Precision lapped measuring faces.

Optional extras:Thread table No. 412180 for caliper back.

Stock : India Warehouse

Brand Name	Garant
Size	150 mm
Article No.	412680
Standard	ISO 13385
Scale Divisions	0.01 mm
Jaw Length	40 mm
Power Supply	Battery Powered

Version:Digital calipers to IP54 with data output. Easy-to-read, high-contrast LCD display with 11.5 mm character height. Very long battery running time due to modern energy-efficient measurement system. The system switches automatically into power-saving mode after 20 minutes; moving the caliper reactivates it. There is no loss of the measurement value or zero point. With preset (dimension selection in advance). Ergonomic housing with easy-grip Haptoprene component. The measuring faces are precision-lapped.

Advantage:

• Ergonomic housing with easy-grip Haptoprene component.
• Long battery life.
• Large high-contrast LCD display with 11.5 mm character height.
• New modern design.

Function:IP54: Protected against splashed water from all directions and protected against penetration of dust into the inside (protected against dust), also completely protected against touching.

Stock : India Warehouse

Brand Name	Holex
Article No.	410650
Standard	ISO 13385
Size	150 mm
Scale Divisions	0.05 mm
Jaw Length	40 mm
Measurement Technology	Analogue

Version:Satin chromium plated anti-glare reading parts. Fine, high-contrast scale, precision lapped measuring faces. Flat vernier scale for parallax-free reading.

Stock : India Warehouse

Measuring Range	150 mm
Material	Stainless Steel
Size	150 mm
Brand Name	Holex
Article No.	412749
Standard	ISO 13385
Scale Divisions	0.01 mm
Measurement Technology	Digital

Version:Large high-contrast digital display. The measuring faces are precision-lapped. The caliper is resistant to water and dust. After 2 hours without movement, the control system shuts down the caliper automatically. Shock-resistant plastic casing.

Function:IP67: Protected against intermittent immersion in water and protected against penetration by dust (dust-tight), also completely protected against touching.

Stock : India Warehouse

Measuring Range	150 mm
Material	Stainless Steel
Size	150 mm
Brand Name	Holex
Article No.	412818
Standard	ISO 13385
Scale Divisions	0.01 mm
Jaw Length	40 mm

Version:Large high-contrast digital display. The measuring faces are precision-lapped.Digital caliper with absolute scale, no zeroing required. Electronics switch off automatically after approx. 5 minutes and switch on again as soon as the tool is moved.

• Very high accuracy due to the glass scale.
• The electronics are decoupled from the casing and incorporated directly in the sliding part. The gauging force is transmitted directly to the measurement jaws. This reduces the liability of the caliper to errors and increases the working life.
• With sturdy metal body.

Stock : India Warehouse

Measuring Range	150 mm
Material	Stainless Steel
Size	150 mm
Brand Name	Garant
Article No.	412692
Standard	ISO 13385
Scale Divisions	0.01 mm
Jaw Length	40 mm

Version:Digital calipers to IP67with data output. Easy-to-read, high-contrast LCD display with 11.5mm character height. Very long battery running time due to modern energy-efficient measurement system. The system switches automatically into power-saving mode after 20 minutes; moving the caliper reactivates it. There is no loss of the measurement value or zero point.
2-component body with non-slip Haptoprene surface. The calipers are resistant to water, coolant, oil, and dust − even when fitted with a data cable. The measuring faces are precision-lapped. With preset (dimension selection in advance).

Function:IP67: Protected against intermittent immersion in water and protected against penetration by dust (dust-tight), also completely protected against touching.

Supplied with:1 battery No. 081560 size CR2032.

Optional extras:Data cable No. 498948, keyboard interface No. 498963.

Stock : India Warehouse

Measuring Range	150 mm
Material	Stainless Steel
Size	150 mm
Brand Name	Holex
Article No.	418742
Standard	ISO 13385
Scale Divisions	0.01 mm

Version:Measured result is displayed in easy-to-read digits. The measuring faces are precision lapped.

Supplied with:1 battery No. 081560 size CR2032

Stock : India Warehouse

Material	Stainless Steel
Brand Name	Holex
Article No.	418000
Standard	ISO 13385
Vernier Length	39 mm
Measuring Range	150 mm
Size	100 mm

Version:Measuring beam and vernier with clearly engraved scales. Precision ground contact faces. Vernier satin chrome-plated.Measuring beam equipped with a hardened, fine gauging pin at the front (1.0 mm ⌀, 8 mm long). Reversible beam.

Stock: India Warehouse

Size	150 mm
Brand Name	Garant
Article No.	412682
Standard	ISO 13385
Scale Divisions	0.01 mm
Measurement Technology	Digital

Version:Digital calipers to IP54 with data output. Easy-to-read, high-contrast LCD display with 11.5 mm character height. Very long battery running time due to modern energy-efficient measurement system. The system switches automatically into power-saving mode after 20 minutes; moving the caliper reactivates it. There is no loss of the measurement value or zero point. With preset (dimension selection in advance). Ergonomic housing with easy-grip Haptoprene component. The measuring faces are precision-lapped.

Advantage:

• Ergonomic housing with easy-grip Haptoprene component.
• Long battery life.
• Large high-contrast LCD display with 11.5 mm character height.
• New modern design.

Function:IP54: Protected against splashed water from all directions and protected against penetration of dust into the inside (protected against dust), also completely protected against touching.

Supplied with:1 battery No. 081560 size CR2032.

Stock : India Warehouse
