Hoffmann Quality Tools India Private Limited

Brand	Garant
Article No.	231605
Product Size	9 mm
Series	HiPer-Drill
Version	3xD
Overall Length	92 mm

Version:

• Very high feed rates and maximum performance due to optimally matched geometries and materials.
• Precise positioning of the cutter insert due to Vee insert seating and secure clamping by the centre bore.
• High concentricity when assembled. (For holes up to IT9 accuracy)
• Shank support for optimum stability in operation.

Created by an additive procedure.

Application:For stationary and rotating use. For holes up to IT9 accuracy.

Note:The insert screw must be replaced after every fifth change of cutter insert.
Further sizes up to ⌀ 50.99 mm available on request.
Clamp in a hydraulic chuck (such as No. 302026 size 20) for optimum radial run-out.
For optimum stability, clamp the drill so the overhang is as short as possible.

Stock : Germany Warehouse

Brand	Garant
Article No.	231610
Product Size	9 mm
Series	HiPer-Drill
Version	5xD
Overall Length	110 mm

Version:

• Very high feed rates and maximum performance due to optimally matched geometries and materials.
• Precise positioning of the cutter insert due to Vee insert seating and secure clamping by the centre bore.
• High concentricity when assembled. (For holes up to IT9 accuracy)
• Shank support for optimum stability in operation.

Created by an additive procedure.

Application:For stationary and rotating use. For holes up to IT9 accuracy.

Note:The insert screw must be replaced after every fifth change of cutter insert.
Further sizes up to ⌀ 50.99 mm available on request.
Clamp in a hydraulic chuck (such as No. 302026 size 20) for optimum radial run-out.
For optimum stability, clamp the drill so the overhang is as short as possible.

Stock : Germany Warehouse

Brand	Garant
Article No.	231615
Series	HiPer-Drill
Product Size	9 mm
Version	8xD
Overall Length	138 mm

Version:

• Very high feed rates and maximum performance due to optimally matched geometries and materials.
• Precise positioning of the cutter insert due to Vee insert seating and secure clamping by the centre bore.
• High concentricity when assembled.
• Shank support for optimum stability in operation.

Created by an additive procedure.

Application:For stationary and rotating use. For holes up to IT9 accuracy.

Recommendation:Drill the pilot hole.

Note:Further sizes up to ⌀ 50.99 mm available on request.
The insert screw must be replaced after every fifth change of cutter insert.
reduce vf values by 20 %.
Clamp in a hydraulic chuck (such as No. 302026 size 20) for optimum radial run-out.
For optimum stability, clamp the drill so the overhang is as short as possible.
For process reliability when using the drill, initial pilot drilling to 1.5×D with the drill No. 231600 with the same cutter insert size and type is necessary. The generation of a pilot hole improves process reliability.

Stock: Germany Warehouse

Brand	Garant
Article No.	234010
Series	Power Drill
Product Size	14 mm
Shank	ISO 9766
Machining Strategy	HPC

Version:The helical coolant ducts ensure very high stability, since they do not weaken the core of the drill.
Bore tolerance: −0.1 / +0.35 mm

Description:For maximum performance and dimensional accuracy. Even for very difficult drilling situations up to 5×D.

Suitable for:Inserts SOGX 050204.

Note:Other intermediate sizes in 1/10 increments available on request.

Stock : Germany Warehouse

Brand	Holex
Article Number	122160
Product Size	0.5 mm
Coating	TiN
Tool Material	Solid Carbide
Tolerance Nominal	h7
Overall Length	20 mm

Version: Similar to DIN 6539 (extra short).
Nominal ⌀ and shank ⌀ equal.
TiN coating.

Note: Flute length LC = L2 + 1.5 × DC.Non slip clamping in drill chuck No. 341050 with diamond coated jaws.

Stock : India Warehouse

Brand	Holex
Article Number	122301
Product Size	0.5 mm
Coating	TiN
Tool Material	Solid Carbide
Number of cutting edges Z	2
Overall Length	34 mm

Version:Similar to DIN 338.
Nominal ⌀ and shank ⌀ equal.
TiN coating.

Note:Flute length LC = L2 + 1.5 × DC.
Non slip clamping in drill chuck No. 341050 with diamond coated jaws.

Stock : Germany Warehouse

Brand	Holex
Article No.	122390
Product Size	1 mm
Series	Pro Inox
Tool Material	Solid Carbide
Point Angle	140 degrees
Overall Length	45 mm

Version:

• Efficient drilling especially for use in stainless and acid-resistant steels.
• Straight main cutting edges with optimised cutting edge design for improved chip breaking behaviour. Enlarged flutes for excellent chip evacuation. Increased wear resistance due to improved carbide substrate and high temperature resistant coating.

Note:

• Flute length LC = L2 + 1.5 × DC.
• HB and HE shanks are available at the same price as HA.
• For HB shanks: use order no. 122391.
• For HE shanks: use order no. 122392.

Stock : India Warehouse

Size	1mm
Brand	Holex
Article No.	122490
Series	Pro Inox
Tool Material	Solid Carbide
Version	4xD
Point Angle	140 Degrees
Overall Length	45 mm

Version:

• Efficient drilling especially for use in stainless and acid-resistant steels.
• Straight main cutting edges with optimised cutting edge design for improved chip breaking behaviour. Enlarged flutes for excellent chip evacuation. Increased wear resistance due to improved carbide substrate and high temperature resistant coating.

Note:

• Flute length LC = L2 + 1.5 × DC.
• HB and HE shanks are available at the same price as HA.
• For HB shanks: use order no. 122391.
• For HE shanks: use order no. 122392.

Stock : India Warehouse

Size	1mm
Brand	Holex
Article No.	122504
Series	Pro Steel
Tool Material	Solid Carbide
Version	4xD
Point Angle	140 degrees
Overall Length	45 mm

Version:

• Straight major cutting edges and a special flute profile ensure good chip evacuation. The robust cutter geometry ensures high-performance drilling with good process reliability.
• A wide range of applications in steel materials thanks to a combination of tough ultra-fine grain carbide and an extremely wear-resistant coating.
• Up to ⌀ 1.9 with 4 facets, from ⌀ 2 with relieved cone.

Note:

• Flute length LC = L2 + 1.5 × DC.
• Versions with HB and HE shank available at the same price as HA.
• For HB shanks: use order no. 122507.
• For HE shanks: use order No. 122508.

Stock : India Warehouse

Size	1mm
Material	Solid Carbide
Brand	Holex
Shank Diameter	DIN 6535 HA to h6
Article No.	122776
Series	Pro Steel
Coating	TiAlN
Overall Length	45 mm

Version:

• Straight major cutting edges and a special flute profile ensure a good chip evacuation. The robust cutter geometry ensures high-performance drilling with good process reliability. A wide range of applications in steel materials thanks to a combination of tough ultra-fine grain carbide and an extremely wear-resistant coating.
• Up to ⌀ 1.9 with 4 facets, from ⌀ 2 with relieved cone.

Note:

• Flute length LC = L2 + 1.5 × DC.
• Versions with HB and HE shank available at the same price as HA.
• For HB shanks: use order no. 122777.
• For HE shanks: use order No. 122778.

Stock : India Warehouse

Material	Solid Carbide
Brand	Holex
Article No.	122685
Version	6xD
Stock Availability	India Warehouse
Diameter Range	2 - 20 mm

Version:

• Efficient drilling especially for use in stainless and acid-resistant steels.
• Straight main cutting edges with optimised cutting edge design for improved chip breaking behaviour. Enlarged flutes for excellent chip evacuation. Increased wear resistance due to improved carbide substrate and high temperature resistant coating.

Note:

• Flute length LC = L2 + 1.5 × DC.
• HB and HE shanks are available at the same price as HA.
• For HB shanks: use order no. 122686.
• For HE shanks: use order no. 122687.

Stock : India Warehouse

Size	1mm
Material	Solid Carbide
Brand	Holex
Article No.	122771
Version	6xD
Point Angle	140 degrees
Overall Length	55 mm

Version:

• Tool specially matched to drilling holes without through-coolant. Concave major cutting edges and a special flute profile ensure a good chip evacuation. The sturdy cutter geometry with special point geometry and 4 cutting edges ensures drilling with good process reliability. A wide range of applications in steel materials thanks to a combination of tough ultra-fine grain carbide and extremely wear-resistant and heat-resistant coating.

Note:

• Flute length LC = L2 + 1.5 × DC.
• Form HB and HE supplied at the same price as HA.
• Form HB: order with No. 122772.
• Form HE: order with No. 122773.

Stock : India Warehouse

Brand	Holex
Article No.	235000
Product Sixe	14 mm
Series	Holex Pro
Shank	ISO 9766
Shank Length	50 mm

Version:HOLEX Pro Drill indexable drills combine cost efficiency with technically fully developed capability.
For use up to 4×D in challenging drilling applications.

Bore tolerance: -0.1 / +0.25 mm

Application:With indexable inserts No. 235030 – 235082.
Both SOMT inserts for the outer insert seat and also XOMT inserts for the inner insert seat are required.

Supplied with:With insert screws (supplied without indexable inserts).

Stock : India Warehouse

Brand	Holex
Article No.	235005
Series	Holex Pro
Shank	ISO 9766
Shank Length	50 mm
Overall Length	110 mm

Version:HOLEX Pro Drill indexable drills combine cost efficiency with technically fully developed capability.
For use up to 4×D in challenging drilling applications.

Bore tolerance: -0.1 / +0.25 mm

Application:With indexable inserts No. 235030 – 235082.
Both SOMT inserts for the outer insert seat and also XOMT inserts for the inner insert seat are required.

Supplied with:With insert screws (supplied without indexable inserts).

Stock : India Warehouse

Brand	Holex
Article No.	235010
Product Size	14 mm
Series	Holex Pro
Machining Strategy	HPC
Overall Length	124 mm

Version:HOLEX Pro Drill indexable drills combine cost efficiency with technically fully developed capability.
For use up to 4×D in challenging drilling applications.

Bore tolerance: -0.05 / +0.3 mm

Application:With indexable inserts No. 235030 – 235082.
Both SOMT inserts for the outer insert seat and also XOMT inserts for the inner insert seat are required.

Supplied with:With insert screws (supplied without indexable inserts).

Recommendation:When spot-drilling reduce the feed rate to 70%.

Stock : India Warehouse

Brand	Garant
Article No.	234005
Series	Power Drill
Product Size	14 mm
Shank Length	50 mm
Machining Strategy	HPC

Version:The helical coolant ducts ensure very high stability, since they do not weaken the core of the drill.
Bore tolerance: −0.1 / +0.3 mm

Description:For maximum performance and dimensional accuracy. Even for very difficult drilling situations up to 5×D.

Suitable for:Inserts SOGX 050204.

Note:Other intermediate sizes in 1/10 increments available on request.

Stock : Germany Warehouse

Brand	Garant
Article No.	234015
Product Size	14 mm
Series	Power Drill
Shank	ISO 9766
Shank length	50 mm

Version:The helical coolant ducts ensure very high stability, since they do not weaken the core of the drill.
Bore tolerance: −0.1 / +0.35 mm

Description:For maximum performance and dimensional accuracy. Even for very difficult drilling situations up to 5×D.

Suitable for:Inserts SOGX 050204.


Recommendation:When spot-drilling reduce the feed rate to 70%.


Note:Other intermediate sizes in 1/10 increments available on request.

Stock : Germany Warehouse

Size	1mm
Brand	Holex
Article No.	122501
Overall Length	45 mm
Series	Pro Steel
Coating	TiAlN
Tool Material	Solid Carbide
Version	4xD

Version:

• Straight major cutting edges and a special flute profile ensure a good chip evacuation. The robust cutter geometry ensures high-performance drilling with good process reliability.
• A wide range of applications in steel materials thanks to a combination of tough ultra-fine grain carbide and an extremely wear-resistant coating.
• Up to ⌀ 1.9 with 4 facets, from ⌀ 2 with relieved cone.
• Cutting chisel edge with high centring accuracy due to strong core and special point geometry. Straight major cutting edges with slightly honed edges and special flute profile produce short chips.

Note:

• Flute length LC = L2 + 1.5 × DC.
• Versions with HB and HE shank available at the same price as HA.
• For HB shanks: use order no. 122502.
• For HE shanks: use order No. 122503.

Stock : India Warehouse
