India Medtronic Private Limited

Blade Type	Macintosh
Light Source	LED
Usage Type	Reusable
Brand	Medtronic
Blade Material	Stainless Steel
Material	Fog-free medical-grade optical polymer
Application Area	Adult Pediatric
Weight	180 g
Power	3.6V lithium battery pack (c. 250 minutes)
Display	2.5" LCD color display
Size	180 mm x 68 mm x 110 mm
Camera	CMOS
Warranty	36 months

Safeguard you — and your patients during intubation
Video laryngoscopy used in the operating room supports first-attempt success of airway intubation. Research also shows that video laryngoscopy can help prevent clinician exposure to droplet-borne pathogens and further improve your safety.3 Recent guidelines highlight the risks of contracting COVID-19 among those caring for infected patients.3 The guidelines recommend that airway management clinicians take precautions to further protect against droplet-borne pathogens.

The McGRATH™ MAC video laryngoscope is proven to improve first time success rate,1,2 reduce time,5 and lessen hemodynamic response to intubation6 when compared to the traditional direct visualization technique.

Proven Technology
Make your first attempt your best. Every time.
The next-generation McGRATH™ MAC video laryngoscope is an enhanced, more robust device, designed to be used routinely in fast-paced hospital and EMS environments. The latest design offers:

• Enhanced optics
• Increased durability
• Intelligent battery management

Familiar Technique- Evolved
The McGRATH™ MAC video laryngoscope combines line-of-sight video from its portrait display with the familiar Macintosh technique. So you retain your traditional laryngoscopy skills.

Simple, Smart, Versatile
The minute-by-minute battery indication and auto- off feature effectively optimize battery life. One handle with multiple blade options. From pediatric to adult patients and routine to extreme airways.

Display Size	10.1 inch
Type of display	LCD
Brand	Medtronic
Model	INVOS Cerebral/Somatic Oximeter
Weight	4.95 kg (10.9 lbs.)
Height	24 cm (9.5")
Width	29 cm (11.25")
Depth	19 cm (7.5")
Cable Type	Preamplifier
Length	4.5 m (15 feet)

The INVOS Cerebral/Somatic Oximeter monitor is a noninvasive oximeter which simultaneously monitors changes in regional blood oxygen saturation in the brain and skeletal muscle (somatic) tissue of the body. It may be used for cerebral oximetry, somatic oximetry or both simultaneously.

Monitor Type	Mac monitor
Parameters	EEG+MAC
Screen Size	10 inch
Brand	Medtronic
Screen Type	Touch
Battery Backup	Up to 2 Hour
Mounting	Portable
Usage Area	OT, ICU
Condition	New
Weight	211 g (7.44 oz) without cables. 434 g (0.96 lb) with cables
Usage/Application	Hospital
Size	98 mm (3.85") diameter x 63.5 mm (2.5") height (including clamp)
Integrated clamp size for pole	Up to 32 mm in diameter
Host Monitor Cable	2.7 m (9 ft) with Hypertronics Hypergrip connector

Utilizes state-of-the-art technology to process EEG information and provides a direct measure of the patient’s level of consciousness thus providing insight into the effects of anesthesia on the brain.

Monitor Type	Bedside
Display Size	13.3 Inch
Parameters	Multipara
Screen Size	13 inch
Battery Backup	5 hour
Screen Type	Touch
Mounting	Bedside
Is It Portable	Yes

Addressing respiratory compromise starts with detectingit — the earlier the better.With the RespArray™ patient monitor, you can continuouslymonitor every patient from anywhere in the hospital. It’sdesigned for areas of care where spot checking mightnot be enough, like in medical-surgical units, or whereadditional parameters are needed, such as capnography inprocedural sedation.Helping you detect respiratory compromise early andintervene sooner.

Device Type	Patient Warmer
Application Area	ICU
Temperature Range	38-45 C
Type	Portable
Patient Type	Adult & Paediatric
Warming Mode	Pre Warm Mode
Power Source	230 V AC
Model Name/Number	Calima convective forced air patient warming system
Brand	Medtronic
Usage/Application	Hospital
Accessories	Full Body Blanket
Usage Pattern	Reusable
Mounting Type	Portable

It’s widely known that inadvertent hypothermia is common among surgical patients and can lead to seriouscomplications. Unwarmed patients can lose up to 1.6°C during the first hour under general anesthesia, as they areunable to regulate their temperature.1 Forced air warming has proven to be one of the most effective methodsof warming a patient to maintain normothermic temperatures and prevent the complications associated withhypothermia. And now maintaining normothermia has never been so easy with our comprehensive portfolio ofoverbody and underbody blankets — including the WarmTouch™ blankets.

Display Size	88.9 mm (3.5 in), measured diagonally
Brand	Medtronic
Pulse Rate Range	20 to 250 beats per minute (bpm)
SPO2 Measurement Range	1% to 100%
Weight	1.6 kg (3.5 lbs)
Pulse Amplitude Measurement Range	0.03% to 20%
Saturation Accuracy	(% SpO2 +- 1 SD)
Adult Accuracy	70% to 100% +- 2 digits
Neonate Accuracy	70% to 100% +- 3 digits
Pulse Rate Accuracy	20 to 250 bpm +- 3 digits
Low Perfusion Accuracy	20 to 250 bpm +- 3 digits
Power	100 to 240 VAC, 50/60Hz, 45 VA
Fuse Rating	Fast-acting 2A 32VAC/DC, fast-acting 500mA 32VAC/50DC
Battery Type	Lithium ion
Battery Capacity	Minimum of five hours using new, fully charged battery with no alarms
Instrument Operating Temperture	5 DegreeC to 40 DegreeC (41 DegreeF to 104 DegreeF)
Transport/Storage Temperature (In Shipping Carton)	-20 DegreeC to 60 DegreeC (-4 DegreeF to 140 DegreeF)
Operating Humidity	15% to 93% noncondensing
Operating Altitude	-170 m to 4877 m (-557 ft to 16,000 ft)
Size	82 H x 255 W x 165 D (mm), (3.23 H x 10.04 W x 6.50 D (in))
Mode of Operation	Continuous
Electromagnetic Compatibility	IEC 60601-1-2:2007
Liquid Ingress	IPX2
Degree of Safety	Not suitable for use in the presence of flammable anesthetics

Monitor with confidence
The Nellcor™ bedside SpO2 patient monitoring system incorporates the latest Nellcor™ digital signal processing technology for accurate, reliable readings even during low perfusion and other forms of signal interference, providing clinicians with access to the most critical information regarding their patients’ respiratory status.

With improved functionality, including continuous SpO2 and pulse rate monitoring, trending data and SatSeconds alarm management, clinicians have the information they need to detect respiratory complications earlier and intervene sooner.

Features:

• Multicolor display screen with a black background for contrast
• Backup audible alarm
• Multiple-language graphical user interface to support variety of users
• 96-hour trend memory with data captured every four seconds
• Distinctive digital signal processing technology
• Simple, intuitive operation with a space-saving design
• Displays plethysmographic waveforms, pulse amplitude and current measured SpO2 and pulse rate

Compact. Affordable. Intuitive
The Nellcor™ bedside SpO??? patient monitoring system features a compact design, improved functionality, a built-in handle and an intuitive, easy-to-read color user interface, making it simpler for clinicians to review and download critical patient data.

With its innovative features, advanced technology, and small footprint, this easy-to-use patient monitoring system helps clinicians save time and space.

• A variable pitch beep tone enables clinicians to hear point-by-point changes in SpO2.
• Patient trend data can be stored on a PC for archive and analysis.
• An easy-to-use jog dial enables simple navigation and control of the display and monitoring system functions.
• On-screen help messages assist with the use of the monitor.
• Biomedical engineers and technicians can simply and effectively set institutional defaults as well as easily replace the battery, perform diagnostics to troubleshoot performance issues and generally maintain the monitor within the hospital.
