I R Technology Services Pvt. Ltd.

Voltage AC220~240V

Frequency 50Hz

Current 1.4~2.1A

Compressor 0.295KW

power 0.40HP

Refrigeration capacity 1000W

Refrigerant R-134a

Precision + - 0.3 deg c

Reducer Capillary

Protection Overcurrent protection for compressor

Pump power 0.1 KW

Tank 10L

connector 1 Inlet and outlet External Ø10mm brass

Max lift 25M

Max. flow 16L/min

the chiller can be customized as per your requirements, the users can pick to choose the feature they want to add to

1. Ambient Temperature
2. Humidity
3. Remote Display

• Safety time-delay for compressor re-start 3 minutes (adjustable).
• Water filter of 100 micron at suction line of the pump.
• Compact brazed plate heat exchanger for high cooling efficiency.
• Powder coated MS body for corrosion free use.
• Castor wheels for easy movement.

Additional Information:

• Production Capacity: 10
• Delivery Time: 1 month

• Non-corrosive water pump & fittings for constant flow & line pressure.
• Fully automatic, closed loop operation
• Quick chilling even at full load conditions with compact plate heat exchanger

• X-ray diffractometers of any make & power range..
• X-ray fluorescence spectrometers.
• Analytical & Chemical systems, where heat dissipation is required.
• Laser, Diffusion, pumps, etc.

• Non-corrosive Positive displacement pump for higher pressure at constant flow rate.
• External control of chiller from main instrument.
• Water-cooled condenser unit in lieu of air-cooled.
• Multi pump options for multi circuit cooling.
• Programmable temperature control with RS232 communication port.
• Flow controls Remote ON/OFF controls for flow with different paths as per specific needs.
• Refrigerant gauges: For continuously monitoring and display of suction and discharge refrigerant pressures.
• Reservoir heater: Helps maintain constant fluid reservoir temperature during winter months. Also allows user to set higher fluid temperature for specific applications that require heating and cooling operations
• Filters: Online filters with specific micron levels can be assembled in the fluid line wherever additional filtration is required.
• Chiller inlet water temperature indicator
• Flow meter
• Audiovisual alarm signal.
• Hour Meter
• Non-Standard/ Larger reservoir
• Normal cooling capacity for water temperature of 15 deg C at ambient of 35 deg C. Extended cooling capacities optionally available up to -15 deg C
• Models available with reciprocation and scroll compressors.
• Multiple refrigeration circuit design is incorporated for capacities ranging from 7.5 TR onwards.
• Fractional capacities and higher than catalogue capacities can be designed and manufactured on the basis of requirement

• Hermetically sealed compressor of reputed brand with internal over load protection/ also scroll type compressor for specific needs
• 10 mm thick Polypropylene storage tank with external insulation to prevent heat loss ingress & condensation.
• Water level indicator, which controls the pump for low/high water levels.
