Sensing Range	1000-1500 cm
Material	Plastic

Series 2Operating principle Diffuse reflection principle with background suppressionApplication Detection of small partsSpecial version Permanently set rangeSmall light spot (S)Operating range, white 90% 0.005 ... 0.028 mOperating range, gray 18% 0.006 ... 0.024 mOperating range, black 6% 0.007 ... 0.02 mOperating range limit, white 90% 0.001 ... 0.035 mOperating range limit, gray 18% 0.003 ... 0.033 mOperating range limit, black 6% 0.004 ... 0.032 mPermanently set operating range 0.03 mLight source LED, RedSupply voltage UB 10 ... 30 V, DCResidual ripple 0 ... 10 %, From UBOpen-circuit current 0 ... 20 mASwitching element Transistor, NPNSwitching principle Light switchingSwitching frequency 700 HzResponse time 0.72 msType of connection CableCable length 2,000 mmNumber of conductors 4 -wireDimension (W x H x L) 8 mm x 23.1 mm x 12 mmHousing material PlasticPlastic housing TPELens cover material Plastic/PCNet weight 50 gType of fastening Through-hole mountingAmbient temperature, operation -30 ... 55 °CDegree of protection IP 67

Additional Information:

• Production Capacity: 1000
• Delivery Time: Exstock
• Packaging Details: Standard

Leuze electronic Sensor Model : PRK 46C/4P-M12 Part Number : 50127012 Authorized Distributor/ Dealer Gujarat Diffused Photoelectric sensor

Brand	Daheng Imagine
Operation System	1/3.6" PYTHON480 Global shutter CMOS
Power	12 ~ 24 VDC
Sensor Type	CMOS
Model Name/Number	MER2-051-120GM---MERCURY2
Digital I/O	1 input and 1 output with opto-isolated, 2 programmable GPIOs
B/W/Color	MONO

MER2-051-120GM



The MER2-051-120GM camera is a monochrome GigE Vision camera with the ON PYTHON 480  CMOS sensor. Thanks to the extremely compact (29mm×29mm), robust metal housings and locking screw connectors, the MERCURY2 cameras can secure the reliability of cameras deployed in harsh environments. The MER2-051-120GM camera has opto-isolated I/Os. The GPIOs give cameras maximum flexibility to adapt to specific needs.

Additional Information:

• Production Capacity: 1000
• Delivery Time: Exstock
• Packaging Details: standard

Brand	Leuze Electonics
Sensing Distance	4mm
Supply Voltage	18 ... 30 V, DC
Part Number	50142874
Sensor Type	Ultrasonic fork sensor
Material	Metal
Model Name/Number	IGSU14E/LWT.3SD-M12
Switching Frequency	2,000 Hz
Usage/Application	gap sensor
Connection Type	Connector M12
Number of Wires	4 Wire
Response frequency	0.2 ms
Body Material	metal
Body Style	Rectangular
Degree of Protection	IP 65
Operating Frequency	2,000 Hz
Operating Temperature	0 ... 60 DegreeC
Dimension (W x H x L)	22 mm x 46.9 mm x 96 mm
Switching Mode	NO/NC
Output Type	light switching PNP (switching on the splice), dark switching NPN (switching on the web)

We at "Joy Engineering" provides Fiber Optic Sensors,Proximity SensorSwitch Mode Power Supply,Ultrasonic Proximity Sensors, Proximity Switches,Inductive Proximity Sensor,Colour Mark Sensor,Machine Vision Systems,Label Sensors,Diffuse Sensor,Photoelectric Sensor,Machine Vision Cameras with high Quality at Resonable Price.

Additional Information:

• Production Capacity: 1000
• Delivery Time: Exstock
• Packaging Details: Standard

Brand	Leuze electronic
Model Number	KRT18B
Supply Voltage	12 to 24 V DC
Degree of Protection	IP67
Operating Temperature	-40 to 125 Deg C

We have available Eye mark Sensor , Contrast Sensor , Color Mark Sensor , Mark Sensor . Make : Leuze Model : KRT21 Model : KRTM 3B Model : KRT18B All Sensor Available Ex Stock . Call/Email for Best Price .
