Micro Teknik

GEAR PUMP TEST RIG

CODE: MTK-1642GP

Specification:

Being the leading names in the industry, we offer our clients an extensive range of Gear Pump Test Rig that is manufactured with utmost accuracy. The Gear Pump Test Rig consists of a gear pump driven by electric motor. Our entire product range is quality assured in nature. They are as per the set industrial standards and are delivered at most affordable rates.

Features:

•        High efficiency

•        Optimal performance

•        Sturdy construction

Additional Information:

• Item Code: MTK-1642GP
• Production Capacity: 10
• Delivery Time: 1 WEEK

CODE: JKA-230BM Product Specification

·         Usage/Application: BIO MEDICAL WASTE INCINERATOR

·         Type Of Incinerator: Hospital Waste Incinerator

·         Waste Type: Bio - Medical waste

·         Capacity: 200 Kg/batch

·         Brand: Teknik

·         Average burn out time: 3 Hrs

·         Power Source: Diesel

·         Burning Ability: 200 Kg/time

·         Material of Construction: Mild Steel power coated

·         I Deal In: New Only

·         Features: Automatic Door / Manual door , Conveyor Belt (Optional), Human Skin Protective paint.

·         Control Panel: Automatic

·         Weight :7-8 tones

·         Chamber: Dual Chamber

·         Furnace Chamber Temperature: 850 Degree To 1050 Degree

·         Air Blower: Centrifugal

·         Burning Efficiency: 99.9%

·         Condition: New

·         Chimney Height: 30 MTR AS PER CPCB NORMS

·         Voltage: 220/440V

·         Minimum Order Quantity: 1

·         Body Type Material: M.S

·         Heater Power: Yes

·         Country of Origin: Made in India

·         Minimum Order Quantity: 1

·         Minimum Order Quantity: 1

Product Description

·         ITEM CODE: JKA-230BM

·         BIO-MEDICAL HOSPITAL INCINERATOR

DESIGN:

·         The design is based on the guidelines set by Central Pollution Control Board (CPCB)-India and normally adopted by military installation all over the country and worldwide. The Efficient power is supplied by electricity as well as oil burners for larger installation. The incinerator combustion chamber is designed for easy maintenance of all internal parts including refractory and isolation.

SPECIFICATIONS:

·         Combustion efficiency 99%.

·         Combustion Chamber : Dual Chamber

·         Temperature of primary chamber is up to 1000°C and the secondary chamber is up to 1450°C.

·         The secondary chamber gas residence time at is two seconds.

·         Power Requirement: Diesel, Electrical

·         AVAILABLE LOADING CAPACITY : 10/25/50/100/150/200/250/500 Kg/Hr.

 MTH-956FD  FORMALDEHYDE DETERMINATION APPARATUS

·         Material: Borosilicate Glass

·         The spiral condenser: 400mm

·         Reduction adapters

·         Filter insert (Porosity 100m to 160m)

·         Perforator attachment: 1000ml

·         R.B. flask: 1000ml

·         Double bulb tube with absorption bulb.

·         Complete with heating mantle capacity: 1000ml

·         Stands qand clamps to hold the apparatus vertically straight.

Accessories:

·         Heating Mantle, Laboratory jack, Stands and Clamps

CAVITATIONS APPARATUS

CODE: MTK-974CA

Specification:

·        The apparatus has been designed to demonstrate the phenomenon of cavitation. The present set-up consists of a test section made of Acrylic having conversion and diversion section. Pressure tapings at appropriate position are provided. This test section is having one control valve at upstream side to regulate the water flowrate. Two pressure gauges are connected to these taping which give the pressure readout at the time of flow passing through this test section. Present set-up is self-contained water re-circulating unit, provided with a sump tank, centrifugal pump etc. Water is pumped by means of centrifugal pump and passing through the test section, it returns back to the sump which make the system re-circulating type. Flow of water is diverted either to measuring tank or sump tank with the means of a flow diverter, when needed. Flow control valve and by-pass valve are fitted in water line to conduct the experiment on different flow rates. Flow rate of water is measured with the help of measuring tank with piezometer and stopwatch. The supplied set-up is complete in all respect. Only water supply and electricity supply is to be provided by the end user for running the set-up.

Product Specification

·         Test Section: Material Acrylic

·         Pressure Gauge: 0-4 kg/cm2

·         Vacuum Gauge: 0-760 mmHg

·         Water Circulation: By Pump, Crompton/Standard make.

·         Flow Measurement: Using Measuring Tank, Capacity 40 liters

·         Sump Tank Capacity: 60 Ltrs.

·         Stop Watch: Electronic

Additional Information:

• Item Code: MTK-974CA
• Production Capacity: 10
• Delivery Time: 16 DAYS

·         CODE: MT- 101341

·         We are engaged in offering a wide array of Slip and Creep Measurement Apparatus for measure co-efficient of friction between pulley material and different belt materials. To measure belt slip speed and observe the limited value of load constant speed when the slip just starts. The motor speed is varied by Thyristor Control D.C. Drive. A double channel digital speed indicator indicates driving and driven pulley speeds. With the help of Stroboscope (not in the scope of supply) it is possible to demonstrate the slip of belt on driving and driven pulley. Used in major experimental applications, this range is inclusive of very salient features.

Scope of Experimentation:

·         To measure co-efficient of friction between pulley material and different belt materials

·         To measure power transmitted with varied belt tension

·         To measure percentage slip at fixed belt tension by varying load on the Brake drum and plot the graph of  v/s percentage slip i.e. Slip Characteristics Finding a Creep Zone from graph

·         To measure belt slip speed and observe the limiting value of load at constant speed when the slip just starts

·         To study creep of belt

Utilities Required:

·         Electricity : 0.5 kW, 220 V, Single Phase

·         Stroboscope

Technical Details:

·         Motor Variable speed DC Motor 1HP, 1500 RPM

·         Pulleys Driving and driven pulleys of equal diameters (flat pulleys)

·         Loading Arrangement Brake drum along with spring balance and rope arrangement is provided to load the system

·         Belts Flat belts of fixed length of following belt material like Fabric Belt, Canvas Belt, Leather Belt

·         Belt tightening arrangement Bearing block is sliding and dead weight can be applied to set the initial tension in belt

·         Speed Indicator 2 Channel digital speed indicator with switch to change the channel

·         CODE: MT-P-21

·         LEVER APPARATUS

·         Material: Mild Steel

·         Color: Multicolor

·         Size/Dimension: Small

MTC-7
·         STRUCTURE OF ATOM

·         3D model of atomic structure, showcasing proton, neutron, and electron configuration, perfect for hands-on learning and visualization of atomic physics concepts

DEEP BED FILTER COLUMN APPARATUS

CODE: MTK-15412

Specification:

The present set-up is designed to study the characteristics of a filter column. It consists of a column filled with packing to ensure the good water distribution.20 Slotted pressure tapings are mounted on the column for measuring the pressure drop across the bed per unit length. These tapings are connected to a differential manometer. These tapings can also be used for drawing the samples from the column and change in concentration of the suspension can be determined. The unit is complete with 2 Nos. of feed tanks. A centrifugal pump is provided to circulate the water through the column. Water supplied to the column is regulated and controlled by rotameter.

Product Specification

·        Water Circulation: FHP Pump

·        Column Material: Stainless Steel/Perspex

·        Column ID: 100 mm (approx.)

·        Column Length: 1350 mm (approx.)

·        Feed Tank Capacity: 200 Ltrs. (approx.)

·        Flow Measurement: Rotameter for Water, 0.5 to 5 L/min.

·        Pressure Tapings: 20 Nos.

·        Sampling Ports: 20 Nos.

Additional Information:

• Item Code: MTK-15412
• Production Capacity: 6
• Delivery Time: 2 WEEKS

Physics Lab

Chemistry lab

Bio Lab

Math Lab

Nursing Lab

Civil Lab

Mechanical Lab

Physics Lab

Chemistry lab

Bio Lab

Math Lab

Nursing Lab

Civil Lab

Mechanical Lab

·         Physics Lab

·         Chemistry lab

·         Bio Lab

·         Math Lab

·         Nursing Lab

·         Civil Lab

·         Mechanical Lab

NOZZLE METER TEST RIG APPARATUS

CODE: MTK-958NM

Specification:

·       Nozzle meter test rig apparatus

·       The apparatus consists of a Nozzle meter. The flow can be regulated by the valve provided at the downstream Present set-up is self-contained water re-circulating unit, provided with a sump tank and a centrifugal pump.

·       Flow control valve and by-pass valve are fitted in water line to conduct the experiment on different flow rates. Flow rate of water is measured with the help of measuring tank and stop watch Experiments To measure discharge through Nozzle meter and to calibrate it Utilities Required Electric supply 0.5 kW, 220 V AC, Single Phase Water Supply Tap water connection.

Experiment

·       To determine the co-efficient of discharge for nozzle meter at different flow rates.

Requirements

·        Consisting of Transparent acrylic Nozzle meter,

·        Manometer and Piezometer,

·        0.5 hp pump,

·        Sump tank and delivery tank,

·        Pressure tapping valves and controlling valves.

Additional Information:

• Item Code: MTK-958NM
• Production Capacity: 10
• Delivery Time: 15 DAYS

WIND TUNNEL TEST RIG

CODE: MTFM-01A

Specification:

·       The Wind Tunnel is simple and safe in operation. It is supplied as a complete self-contained facility mounted on castors for ease of movement. Main equipment comprises the tunnel with a two-component balance system and an air speed indicator. Air enters the test section through a carefully designed contraction followed by an aluminum honeycomb flow straightened designed to ensure that the flow is steady in both magnitude and direction and has a flat transverse velocity profile. A low angle diffuser at the outlet end contributes to flow stability in the test section.

·       A five bladed fan is located at the outlet of the diffuser section. The fan is driven by an AC motor supplied from an inverter speed control unit allowing smooth control of air speed. The parallel octagonal test section is manufactured from clear acrylic and may be retracted on rails to permit unobstructed access to the models. The two-component balance consists of a pair of balances supported on knife edges on mutually perpendicular axes parallel to and normal to the axial center of the tunnel.

·       Lift and drag components of force exerted on the models under test are balanced by sliding weights along the arms of the balance until a state of null deflection is reached. Graduations in units of force allow lift and drag to be read directly. The complete assembly is linked to a simple oil filled damping pot. Models are mounted on the balance within the working section and a protractor with cursor allows angles of incidence to be changed quickly and accurately while the tunnel is running. The accuracy of the tunnel and its instrumentation make it suitable for undergraduate and simple research work.

TECHNICAL SPECIFICATIONS: -

·       Suitable for undergraduate and simple research work.

·       Working section: 304mm wide x 304mm high x 457mm long (octagonal cross- section)

·       Contraction area ratio: 3:1

·       Motor rating: 1.5 KW

·       Flow visualization studies around an aerofoil and cylinder

·       Measurement of pressure distribution around an aerofoil at various angles of attack or around a cylinder

·       Measurement of lift and drag on an aerofoil with leading edge slot and trailing edge flap

·       Velocity and pressure distribution measurements using a pitot static tube and yaw probe

·       Measurement of drag for models of different shapes but common equatorial diameter

·       Demonstration of flutter of an aerofoil

·       Calibration of the wind tunnel velocity indicator using a pitot static tube

·       Investigation of the wake behind a cylinder or aerofoil using a wake survey rake

Additional Information:

• Item Code: MTFM-01A
• Production Capacity: 3
• Delivery Time: 1 WEEK

MT-CRA This standard cell production roller culture apparatus allows flexibility for scale-up and production of monolayer cell cultures in standard roller bottles. The system consists of a base drive unit and five-position roller deck to which additional roller decks can be added. A powerful DC motor, with soft-start speed control, drives the bottles through a series of durable non slip belts. The all-position drive is a positive traction drive system for lightweight plastic bottles, in which each roller is individually driven.

Feature:

Accepts bottles from 108 to 121 mm in diameter and up to 550 mm in length

Smooth ramping digitally controlled rotation, accurate to 0,1 rpm

Maintenance-free precision brushless motor

Bright LCD for easy operation

Multiple decking and capacity configurations available for process flexibility

·         CODE: MPH-M-49B

·         FREE FALL WITH MECHANICAL GATE

·         Material: Stainless Steel

·         Phase: Single Phase

·         The apparatus consists of a release mechanism that also acts as the start switch, a switch plate that acts as the stop switch, and conducting balls.

·         The release mechanism and the switch plate are both connected to the Student Timer.

·         CODE: JCR-1

·         CRYOSTAT

·         Specimen Orientation X and Y Axis : 8 degree

·         Horizontal Specimen Feed : 25 mmm

·         Motorized Coarse Feed : 480mm/sec

Features:

·         Motorised Feed Control

·         LCD Screen

·         User Friendly

·         Control Panel

·         Anti-Static

·         Disposable Blade Holder

·         UV Sterilization

·         Cryo Chamber temperature:-1 to -35°C adjustable.

MT-241DI Digital Ivf Incubator,

·         Usage/Application: Pharmaceutical

·         Size: 23 L x 23 W x 7.5 H cm

·         Voltage: 220 V

·         Frequency: 50 Hz

·         Display Type: LCD

·         Power: 50 Watt

·         Weight : 2.5 kg

• Made with Die casted material.
• Specially design for catching object up to 75mm dia object.
• Jaws covered with silicon sleeves to insure secure grip on object.
• Attached aluminum casted boss head.
• Duly powder coated finishing

Panel Mounted Borosilicate Glass Boiler with inbuilt heater and Borosilicate Glass Condenser. Complete with stand, Clamps etc. Conductivity of Distilled water produced is less than 1u5 cm1. PH 6-7 suitable for HPLC. Output approx. 2.0 Lt/Hr.

ANAEROBIC CHAMBER

 CODE: MT- 522A

Specification:

·       Livestock disease laboratory type

·       This product is composed of operation room,

·       Cultivating room,

·       Sampling room,

·       Gas path,

·       Control system,

·       Bottle holder and disinfector,

·       Its ingeniously designed to from a stable anaerobic environment in the operation room

R.T.D. STUDIES IN CONTINUOUS STIRRED TANK REACTOR APPARATUS

CODE: MTK-9584RTD

Specification:

DESCRIPTION:

·        Real reactors do not satisfy the idealized flow patterns, back mix flow or plug flow deviation from ideality can be due to channeling of fluid through the vessel, recycling of fluid within the vessel or due to the presence of stagnant region or pockets of fluid in the vessel. To predict the exact behavior of a vessel as a Chemicals reactor, RTD or stimulus response technique is used. The setup consists of one feed tank through which water is fed to the reactor. The flow rate can be varied by changing the speed of peristaltic pump. The continuously stirred tank reactor made of Stainless Steel is provided for understanding the R.T.D. characteristics.

EXPERIMENTATION:

·        To plot RTD curve for a CSTR. Using pulse tracer.

·        To determine the Dispersion No.

Product Specifications

·        Material: Metal

·        Power: 500 Watt (w)

·        Voltage: 220 Volt (v)

·        Usage For: College and University

·        Equipment Materials: SS

SPIN INNING BASKET REACTOR APPARATUS

CODE: MTK-9809SP

Specification:

Description

·        Any catalytic liquid-liquid or liquid-gas reaction involving the use of a catalyst placed in basket can be studies in this set-up. Kinetic parameter of a specific reaction can be estimated & parametric studies can be conducted. The set-up consists of a reactor centrally having one spinning basket derived through a variable speed motor. The metered flow of reactant from feed tank is fed to the reactor at the bottom. The set-up can be used as batch wise of as continuous type. Sampling points are provided for analysis. Port connection for gas inlet is provided at the bottom of the reactor

Experimentation/Learning Objectives

•       To determine the kinetic parameters for a given reaction

Utilities Required

•        Electricity Supply: Single Phase, 220 V AC, 50 Hz, 5-15 Amp combined socket with earth connection. Earth voltage should be less than 5 volts.

•        Compressed air supply@1 Bar.

•        Water Supply.

•        Floor Drain.

•        Floor Area Required: 1.0 m x 0.75 m.

•        Instruments, Laboratory Glassware and Chemicals required for analysis as per the system adopted

Technical Details

·        Reactor Vessel: Material Stainless Steel Effective Volume: 1000 ml.

•        Basket: Material Stainless Steel, Fitted with appropriate Stainless Steel.

•        Drive for Basket: DC Motor with Thyristor controlled DC Drive for Variable Speed.

•        Packing: Catalyst

•        Feed Tank (1Nos.): Material Stainless Steel, Capacity 10 Ltrs.

•        Flow Measurement: By Rotameter

•        Pressure regulator: Range 0-2 kg/cm²

•        Pressure Gauge: Bourdon Type, 0-2 kg/cm²

•        Receiver: Material Stainless Steel, Capacity 10 Ltrs.

•        Piping: Stainless Steel and PVC.

•        Hot water Circulation: Magnetic Pump of Poly propylene (in outer Jacket) to circulate Hot Water maximum working temp. 85°C

•        Hot water tank: Made of Stainless Steel, Double wall, insulated with Ceramic Wool.

•        Capacity: 10-15 ltrs.

Additional Information:

• Item Code: MTK-9809SP
• Production Capacity: 3
• Delivery Time: 1 WEEK

HEAT TRANSFER IN AGITATED VESSEL APPARATUS

CODE: MTK- 101368

Specification:

·         The unit consists of a vessel with class wool insulation ail around. A helical coil made of copper is fixed inside the vessel. A motorized agitator is fixed at the center of the coil. The vessel is provided with an electric heater and a controller is also provided for vessel. Heater heats water in the jacket while cold water is circulated through coll. Temperature of circulated water and water in vessel Is measured and thus heat transfer coefficient at various agitator speeds can be determined.

SPECIFICATIONS:

·        Vessel approx. 20 lit. Capacity, provided with glass wool insulation all around and electric heater at the bottom.

·        Agitator 150 mm dia, with 1/8 HP motor to drive the agitator.

·        Helical coil - 200 dia, 8 turns, made of 3/8" dia. copper tube.

·        Controllers for heater and agitator motor.

·        Temp. Indicator for vessel water temperature and circulated water inlet and outlet.

SERVICES REQUIRED:

·        Single phase 230V, 15 A stabilized supply.

·        Water flow at the rate of 4 to 5 lit. Per min.

·        Suitable drain arrangement for water.

·        Floor area -1.5 mtr. X 1 mtr. X 1 mir height.

Additional Information:

• Item Code: MTK-101368
• Production Capacity: 5
• Delivery Time: 2 week

Micro Teknik is a leading manufacturer with a wide range of histopathology and Pathology equipmen. with a commitment to producing high-quality products, the company has become a leading supplier of laboratory equipment for researchers, healthcare professionals, and educational institutions around the world.

The company’s extensive range of products includes microtomes, tissue processors, cryostats, embedding centers, Slide warmers , wax or floatation bath and Gross working Stations with other histology equipment. Our products are designed to meet the demands of modern laboratory research, ensuring that scientists and researchers have access to the latest technology and equipment for their work.

he goal of our laboratory microscope is to produce clear, high-quality images, whether an optical microscope, which uses light to generate the image, a scanning or transmission electron microscope (using electrons), or a scanning probe microscope (using a probe). Upright microscopes are the most common type, with the lighting system below the stage and the lens system above; inverted microscopes, particularly useful for cell culture, reverse this configuration. Applications include biotechnology, pharmaceutical research, nanophysics, microelectronics, and geology.

MT-108PR Inner immersion well

Material of immersion well – Quartz

Maximum Operating Temperature – 1200 degree Celsius

Application – To hold UV lamp and for water circulation

Port – Inlet and outlet for water circulation, inner well used for UV lamp

Outer Jacket

Material of outer jacket – Glass / Borosilicate

Maximum Operating Temperature – 600-degree Celsius

Application – Catalyst charging, Sampling of vent and thermowell for measurement of temperature

Port – Three port (Customization of port is also available)

The photochemical reactor is used to carry out a photochemical reaction, water splitting, and photo chlorination reaction.

The reaction takes place in the presence of photon and catalyst.

Hence it is called as photo catalysis reaction or photochemical reaction.

The reactor is also known as the photocatalytic reactor.

The photochemical reactors complete setup includes triple jacketed immersion well, medium and high-pressure mercury lamp, lamp power supply, a chiller for cold water circulation, safety cabinet and magnetic stirrer.

Capacity – 250ml

Capacity – 500ml

Capacity – 1000ml

Capacity – 2000ml

·         Fully automatic for double distillation, suitable for both bench and wall mounting.

·         Single distillate: approx. 2.2 µs/cm at 25 °C

·         Double distillate: approx. 1.6 µs/cm at 25 °C

·         Electronic level control during the whole distilling process.

·         Electronic impurity detector

·         Double-action low water cut-off

·         Condenser (cooler): 1st stage made of stainless steel; 2nd stage including the baffle made of DURAN® Borosilicate glass 3.3.

·         Evaporator easily accessible for cleaning purposes.

·         Distillate withdrawal: valve made of Borosilicate glass 3.3 with PTFE plunger for single distillate, outlet with dust guarde shield made of Borosilicate glass 3.3 for double distillate.

·         CO₂ degassing through outlet in the condenser.

·         Heating element and evaporator made of stainless steel.

·         Double-walled housing.

·         Water supply through a built-in solenoid valve with connection for pressure hose 1/2" (inner ø approx. 12.7 mm).

·         Cooling water outlet with hose connection 3/4" (ø approx. 19.0 mm).

MODEL: MTK- 9547CIS   ISOTHERMAL CONTINUOUS STIRRED TANK REACTOR (C.S.T.R.) APPARATUS

Specification:

DESCRIPTION:

·        In an ideal CSTR (i.e. an ideal steady state flow reactor) the contents in reactor are well mixed and have uniform composition throughout. Thus the exit stream has the same composition as the fluid within the reactor. This type of reactor is known as mixed flow reactor. This set-up is used to study a non-catalytic homogeneous second order liquid phase reaction under isothermal condition. The set up consists of two feed tanks through which two reactants are fed to the reactor. The flow rate can be varied by changing the speed of peristaltic pump. The CSTR is fitted with stirrer for proper mixing. From top outlet of it samples are collected for analysis. Constant temperature water bath arrangement is provided to conduct the experiment at various temperatures.

EXPERIMENTATION:

·        Saponification Reaction study in Isothermal CSTR.

·        To determine the Reaction Rate Constant and effect of temperature on it.

Product Details:

·        Voltage: 220 Volt (v)

·        Usage: Laboratory

·        Material: Metal

·        Equipment Materials: SS

·        Temperature Range: 30 Celsius (DEGREE C)

·        Display Type: Digital

Additional Information:

• Item Code: MTK-9547CIS
• Production Capacity: 3
• Delivery Time: 2 WEEK

For analysis of pesticides, operative with standalone and software both, having built in validation function.

Photometric system/Optics Double beam.

Spectral Band width 1.0 nm

Wavelength range 190 to 1100 nm

Wavelength accuracy 0.5 nm

Wavelength repeatability/ Reproducibility 0.1nm

Photometric Range 4 Abs or better

Photometric accuracy 0.005 Abs (at 1.0Abs)

Maximum Scan Rate 3,200 nm/ min

Maximum Measurement Rate 80 Hz

Lamp Life Time Typical Life time of 10 Years (Guaranteed 3 years) or 1000 hours whichever is earlier

Detectors 2 Silicon Diode Detectors for Simultaneous sample beam and reference beam measurements

For analysis of pesticides, operative with standalone and software both, having built in validation function.

Photometric system/Optics Double beam.

Radiation source Xenon Flash Lamp

Spectral Band width 1.5nm

Wavelength range 190 to 1100 nm

Wavelength accuracy 0.5 nm

Wavelength repeatability/ Reproducibility 0.1nm

Photometric Range 4 Abs or better

Photometric accuracy 0.005 Abs (at 1.0Abs)

Maximum Scan Rate 24,000 nm/ min

Maximum Measurement Rate 80 Hz

Lamp Life Time Typical Life time of 10 Years (Guaranteed 3 years)

Detectors 2 Silicon Diode Detectors for Simultaneous sample beam and reference beam measurements

Accessories:

Cells fused silica (10mm) =02 Pair.

Halogen Lamp =01No.

Power Requirement 220 V AC 50-60 Hz

DOUBLE BEAM UV- VISIBLE SPECTROPHOTOMETER

Optics Concave diffraction grating / Double Beam Principle

Wavelength Range 190nm -1100 nm

Spectral Bandwidth 1.5 nm

Stray Light 0.05% (220nm NaI, 340nm NaNO2)

Wavelength Accuracy 0.3nm

Photometric Range Absorbance: A-3 to +3, T: 0% to 300%T

Concentration: 0,000 to 9,999

Wavelength Scan Speed 0.1,0.2,0.5,1,2,5 nm/minute

Baseline Stability 0.0003 Abs/hr (500nm, after 2 hours)

Noise Level 0.0003 Abs (500nm)

Light Source Tungsten-Halogen and Deuterium Lamps

Light Source Switching Automatic switching selectable from 325nm to 370nm

Detector Silicon Photodiode

Display Back-lit LCD 190(W) x 138(H) mm

Built in Silicon photodiode detector and built in deuterium and halogen lamp shaving automatic change over

CODE: JEQ-1R

·         Inner Chamber is made up of thick non-magnetic steel of 304/316 quality and jacket is made out of rolled steel. Single door made of rolled steel lined with S.S. sheets has radial locking system.

·         All units are hydraulically tested upto 40psi.

·         The space between outer cover made of thick rolled steel sheet and the steam jacket is filled with asbestos sheet or glass wool to minimize thermal losses.

·         Boiler is made of thick stainless steel sheet and is located under the sterilizer.

·         Unit is fitted with water level indicator, safety valve, pressure gauge, and water inlet and drain valves.

·         Unit is also fitted with low-water level cut-off device and automatic pressure control device.

·         Rectangular sterilizes are fitted with SELF LOCKING SAFETY DOOR device.

·         The door cannot be opened when chamber is under pressure.

·         Two separate valves are provided for evacuating steam from inner chamber and jacket, as and when desired.

·         Fitted with safety valve as a safety device.

·         Drain valve is fitted at the side bottom for easy draining/cleaning.

·         Fitted with vacuum breaker to break vacuum in case of formation of vacuum due to steam condensation.

·         Triple Walled with Steam Jacket and Separate Boiler. Sterilization cycle is controlled by Multiport Valve. The unit is fitted with all standard accessories.

·         To work on 440 volts, 3 Phase, A.C. Supply.

DIMENSION MM        LITRE

·         450 x 450 x 900           182

·         450 x 600 x 900           243

·         600 x 600 x 900           324

·         600 x 600 x 1200         432

·         600 x 750 x 1200         540

·         600 x 900 x 1500         810

·         900 x 900 x 1500         1215

CODE: JEQ-1R

·         Inner Chamber is made up of thick non-magnetic steel of 304/316 quality and jacket is made out of rolled steel. Single door made of rolled steel lined with S.S. sheets has radial locking system.

·         All units are hydraulically tested upto 40psi.

·         The space between outer cover made of thick rolled steel sheet and the steam jacket is filled with asbestos sheet or glass wool to minimize thermal losses.

·         Boiler is made of thick stainless steel sheet and is located under the sterilizer.

·         Unit is fitted with water level indicator, safety valve, pressure gauge, and water inlet and drain valves.

·         Unit is also fitted with low-water level cut-off device and automatic pressure control device.

·         Rectangular sterilizes are fitted with SELF LOCKING SAFETY DOOR device.

·         The door cannot be opened when chamber is under pressure.

·         Two separate valves are provided for evacuating steam from inner chamber and jacket, as and when desired.

·         Fitted with safety valve as a safety device.

·         Drain valve is fitted at the side bottom for easy draining/cleaning.

·         Fitted with vacuum breaker to break vacuum in case of formation of vacuum due to steam condensation.

·         Triple Walled with Steam Jacket and Separate Boiler. Sterilization cycle is controlled by Multiport Valve. The unit is fitted with all standard accessories.

·         To work on 440 volts, 3 Phase, A.C. Supply.

DIMENSION MM        LITRE

·         450 x 450 x 900           182

·         450 x 600 x 900           243

·         600 x 600 x 900           324

·         600 x 600 x 1200         432

·         600 x 750 x 1200         540

·         600 x 900 x 1500         810

·         900 x 900 x 1500         1215
