Additional Information:

• Production Capacity: Proline Prosonic Flow E 100
• Delivery Time: 6 to 8 week

Additional Information:

• Delivery Time: 6 to 8 weeks

• Max. measurement error

  Volume flow (standard):
  ‐ ±1.0 % o.r. for 3 to 40 m/s (9.84 to 131.23 ft/s)
  ‐ ±2 % o.r. for 0.3 to 3 m/s (0.98 to 9.84 ft/s)
  Volume flow (optional calibration):
  ‐ ±0.5 % o.r. for 3 to 40 m/s (9.84 to 131.23 ft/s)
  ‐ ±1.0 % o.r. for 0.3 to 3 m/s (0.98 to 9.84 ft/s)
  Corrected volume flow (standard):
  ‐ ±1.2 % o.r. for 3 to 40 m/s (9.84 to 131.23 ft/s)
  ‐ ±2.1 % o.r. for 0.3 to 3 m/s (0.98 to 9.84 ft/s)
  Corrected volume flow (optional calibration):
  ‐ ±0.8 % o.r. for 3 to 40 m/s (9.84 to 131.23 ft/s)
  ‐ ±1.2 % o.r. for 0.3 to 3 m/s (0.98 to 9.84 ft/s)
  Sound Velocity: ±0.2 % o.r.

Additional Information:

• Delivery Time: 6 to 8 weeks

• Measured variables

  Volume a. c., volumetric flow a. c., gas velocity, volume s. c. (*), volume flow under s.c. (*)
  (*) additional function included with integrated volume correction

• Measuring Medium

  Natural gas (dry, odorized), air

• Nominal pipe size

  DN 50 (2") … DN 150 (6")

Additional Information:

• Production Capacity: FLOWSIC550
• Delivery Time: 6 to 8 weeks

Additional Information:

• Item Code: F300
• Delivery Time: 6 to 8 weeks

• Max. measurement error

  Flow: ±5 % o.f.s.

• Measuring range

  226 to 14 100 000 l/h (60 to 3 730 000 gal/h)
  (under reference conditions)

• Medium temperature range

  –20 to +100 °C (–4 to +212 °F)

• Max. process pressure

  PN 40

Additional Information:

• Item Code: flowmeter
• Production Capacity: Proline t-mass flow meter
• Delivery Time: 6-8 week

• Max. measurement error Gas: 1.0% o.r. (10 to 100% o.f.s.), 0.1% o.f.s. (1 to 10% o.f.s.) • Measuring range 20 to 733501 kg/h (44 to 1669340 lb/h) • Medium temperature range -40 °C to +180°C (-40 °F to +356°F) • Max. process pressure -0.5 to 20 bar_g (-7.25 to 290 psi_g)

  Insertion flowmeter with long-term stability as remote version with up to 4 I/Os
• Digital communication HART, Modbus RS485 Power supply DC 24V AC 100 to 240V

Additional Information:

• Item Code: t-massI500
• Production Capacity: flow measurement
• Delivery Time: 6 to 8 weeks

• Max. measurement error

  Mass flow (liquid): ±0.10 %
  Volume flow (liquid): ±0.10 %
  Mass flow (gas): ±0.50 %
  Density (liquid): ±0.0005 g/cm³

• Measuring range

  0 to 180 000 kg/h (0 to 6600 lb/min)

• Medium temperature range

  –50 to +150 °C (–58 to +302 °F)

• Max. process pressure

  PN 100, Class 600, 63K

• Wetted materials

  Measuring tube: Titanium grade 9
  Connection: Titanium grade 2

Additional Information:

• Delivery Time: 6 to 8 weeks

Additional Information:

• Delivery Time: 6 to 8 weeks

• Max. measurement error

  Mass flow (liquid): ±0.10 %
  Volume flow (liquid): ±0.10 %
  Mass flow (gas, Tantalum only): ±0.50 %
  Density (liquid): ±0.0005 g/cm³

  • Measuring range

    0 to 70 000 kg/h (0 to 2570 lb/min)

  • Medium temperature range

    Tantalum: –50 to +150 °C (–58 to +302 °F)
    Zirconium: –50 to +205 °C (–58 to +401 °F)

  • Max. process pressure

    PN 40, Class 300, 20K

  • Wetted materials

    Measuring tube: Tantalum 2.5W; 702 (UNS R60702)
    Connection: Tantalum; 702 (UNS R60702)

Additional Information:

• Production Capacity: Proline Promass H 500 Coriolis flowmeter
• Delivery Time: 6 to 8 weeks

Additional Information:

• Delivery Time: 6 to 8 weeks

• Max. measurement error

  Mass flow (liquid): ±0.1 %
  Volume flow (liquid): ±0.1 %
  Mass flow (gas): ±0.5 %
  Density (liquid): ±0.0005 g/cm3

• Measuring range

  0 to 1000 kg/h (0 to 37 lb/min)

• Medium temperature range

  –50 to +200 °C (–58 to +392 °F)

• Max. process pressure

  PN 40, Class 300, 10K, 400 bar (5800 psi)

• Wetted materials

  Measuring tube: 1.4539 (904L)
  Connection: 1.4539 (904L); 1.4404 (316/316L)

Additional Information:

• Delivery Time: 6 to 8 weeks

Additional Information:

• Item Code: 150
• Production Capacity: NA
• Delivery Time: 3 to 4 working week
• Packaging Details: NA
