The 1734-IB8S is a POINT Guard I/O Safety Module designed for safety-critical applications. It offers 8 input channels with current sinking capability, ensuring reliable and safe signal processing in industrial environments.

Technical Specifications

• Input Type: Current sinking
• Number of Inputs: 8
• Input Voltage Range: 19.2V to 28.8V DC
• On-State Input Voltage: 11V to 30V DC
• On-State Input Current: 3.3 mA (minimum), 5 mA (maximum)
• Off-State Input Current: 1.3 mA (maximum)
• Input Delay Time (On to Off): 16.2 ms (maximum)
• Power Dissipation: 3.4 W (maximum)
• Thermal Dissipation: 11.62 BTU/hour
• PointBus Current (no load): 25 mA
• Isolation Voltage: 50V (continuous)
• Dimensions: 77 x 25 x 55 mm (3.03 x 0.98 x 2.17 inches)
• Weight: 62.4 grams (2.2 ounces)
• Mounting: Horizontal or vertical
• Enclosure Type: Open-style
• Series: Available in Series A and B
• Network Compatibility: Ethernet/IP and DeviceNet via 1734-AENT, 1734-AENTR, or 1734-PDN adapters
• Certifications: TUV General Safety, IECEx Scheme

                Features

• Signal Delay Adjustments: Each channel has individually adjustable ON and OFF signal delays to prevent false positives and negatives due to signal fluctuations.
• External Wiring Short Check: Enables detection when input channels are wired in combination with test outputs.
• Pulse Test Outputs: Equipped with 4 test outputs (T0, T1M, T2, T3M) for muting lamp control and other diagnostic purposes.
• IEC 61131-2 Input Type: Complies with Type 3 standards for industrial input devices.
• Safety Protocols: Supports CIP Safety protocol extensions for integration with SmartGuard, GuardLogix, and Compact GuardLogix controllers .

Additional Information:

• Item Code: 1734-IB8S
• Production Capacity: 3.4 W (maximum)
• Delivery Time: 3 to 4 week
• Packaging Details: Box Packing

The Allen-Bradley 1734-OB8 is an 8-point digital output module in the POINT I/O series, designed for use in modular automation systems. It provides 24V DC sourcing outputs, suitable for controlling devices like relays, solenoids, and motor starters.

• Output Type: Sourcing (positive logic)

• Output Voltage: 24V DC nominal

• Output Current:

  • 2.0 A maximum per point

  • 3.0 A maximum per module

• Power Supply: 24V DC (bus powered)

• Current Draw: Approximately 45–75 mA from the POINTBus

• Temperature Range:

  • Operating: -20°C to 55°C

  • Storage: -40°C to 85°C

• Humidity: 5–95% non-condensing

• Shock/Vibration:

  • Operating Shock: 30 G

  • Non-operating Shock: 50 G

  • Vibration: 5 G at 10–500 Hz

• Thermal Dissipation: 6.8 BTU/hr

• Dimensions: 118 mm (H) × 25.4 mm (W) × 71.5 mm (D)

• Weight: Approximately 270 grams

• Type: 8-point Safety Sourcing Output Module

• Output Type: Solid-state transistor outputs

• Voltage: 24V DC

• Mounting: DIN rail

• Temperature Range: Operating: –20°C to 55°C; Storage: –40°C to 85°C

• Dimensions: Width: 56.6 mm; Height: 77.5 mm; Depth: 12.1 mm

• Weight: 88.84 g

• Certifications: TÜV General Safety, IECEx.

  Safety Features

  • Single-Channel Mode: Supports Safety Category 2, up to Performance Level d (PL d), SIL CL2. Suitable for applications with process safety times ≥600 ms and demand rates ≤1 per minute.

  • Dual-Channel Mode: Supports Safety Category 3 or 4, up to Performance Level e (PL e), SIL CL3. Enables redundant control for higher safety requirements.

  • Pulse Testing: Capable of pulse-testing outputs to detect field wiring short circuits.

  • Fault Detection: Automatically switches outputs OFF upon fault detection; outputs remain OFF until the fault is cleared and the system is reset.

The Allen-Bradley 1734-TB is a terminal base module designed for the POINT I/O system, facilitating the integration of I/O modules into a distributed control architecture.

• Terminal Type: Removable IEC screw terminals (Cage-Clamp RTB)

• Number of Terminals: 8

• Temperature Rating: –20°C to 55°C (–4°F to 131°F)

• Mounting: DIN rail (horizontal or vertical)

• Weight: Approximately 36.9 g

• Dimensions:

  • Height: 56.0 mm

  • Width: 12.0 mm

  • Depth: 75.5 mm

• Power Dissipation:

  • Maximum: 1.86 W at 750 Ω load per output

  • Thermal Dissipation: 6.34 BTU/hr at 750 Ω load per output

• Isolation Voltage: 50V continuous, tested at 1500V AC for 60 seconds between outputs and field power

• Supply Voltage:

  • Backplane: 5V DC

  • Field Power Input: 10–28.8V DC (includes 5% AC ripple), 220 mA, Class 2

• Wire Size: 0.25–2.5 mm² (23–13 AWG) solid or stranded copper wire, rated at 100°C (212°F) or greater, with a maximum insulation thickness of 1.2 mm (3/64 in.)

• Enclosure Type Rating: None (open-style)

• Certifications: China CCC, Registro Italiano Navale, IECEx Scheme

• Part Number: 1769-ECR

• Module Type: Right End Cap

• Current Draw:

  • 5 mA at 5.1 VDC

  • 0 mA at 24 VDC

• Operating Temperature: 0°C to 60°C (32°F to 140°F)

• Operating Altitude: Up to 2,000 meters (6,562 feet)

• Enclosure Type: Open style (no IP rating)

• Operating Vibration: 5 g, 10–500 Hz

• Operating Shock:

  • 20 g (DIN rail mount)

  • 30 g (Panel mount)

• Power Consumption: 33.6 W

• Power Dissipation: 7.5 W

• Weight: Approximately 130 g (0.286 lb)

• Series Compatibility: Series A and B

• Input Channels: 4 (Differential or Single-Ended)

• Input Signal Types:

  • Voltage: ±10V, 0–10V, 0–5V, 1–5V

  • Current: 0–20mA, 4–20mA

• Input Impedance:

  • Voltage: 220 kΩ

  • Current: 250 Ω

• Resolution: 14 bits (unipolar); 14 bits plus sign (bipolar)

• Conversion Type: Delta-Sigma ADC

• Accuracy:

  • Voltage: ±0.2% of full scale at 25°C

  • Current: ±0.35% of full scale at 25°C

• Temperature Coefficient:

  • Voltage: ±0.003% per °C

  • Current: ±0.0045% per °C

• Common Mode Voltage Range: ±10V DC max per channel

• Common Mode Rejection Ratio:

  60 dB at 50/60 Hz



• Normal Mode Rejection Ratio: -50 dB at 50/60 Hz

• Power Consumption:

  • 5V DC: 120 mA

  • 24V DC: 60 mA

• Power Dissipation: 2.52 W

• Operating Voltage: 30V AC/DC

• Operating Temperature: 0°C to 60°C (32°F to 140°F)

• Storage Temperature: -40°C to 85°C (-40°F to 185°F)

• Vibration:

  • Operating: 5 g at 10–500 Hz

  • Non-operating: 30 g

• Shock:

  • Operating: 30 g

  • Non-operating: 40 g

• Mounting Type: DIN Rail or Panel Mount

• Enclosure Type: Open Style (no IP rating)

ey Specifications

• Input Types: Supports voltage and current inputs, including ±10V, 0–10V, 0–5V, 1–5V, 0–20mA, and 4–20mA.
• Input Configuration: Each channel can be configured as differential or single-ended.
• Resolution: 16-bit for unipolar signals and 15-bit plus sign for bipolar signals.
• Accuracy:
  • Voltage: ±0.2% of full scale.
  • Current: ±0.35% of full scale.
  • Non-linearity: ±0.03%.
  • Repeatability: ±0.03%.
  • Drift: ±0.003% per °C (voltage), ±0.0045% per °C (current).
• Input Impedance:
  • Voltage: 220 kΩ.
  • Current: 250 Ω
• Overload Protection:
  • Voltage inputs: ±30V DC continuous at 0.1 mA.
  • Current inputs: ±32 mA at ±7.6V DC.
• Power Consumption:
  • 5V DC: 120 mA.
  • 24V DC: 70 mA
• Operating Temperature: 0°C to 60°C (32°F to 140°F).
• Dimensions: 118 mm (H) x 87 mm (D) x 52.5 mm (W); height including mounting tabs is 138 mm.
• Weight: Approximately 450 grams (0.99 lbs).

• Processor: 512 KB user memory

• Embedded I/O:

  • Inputs: 16 x 24V DC digital inputs (sink)

  • Outputs: 16 x 24V DC digital outputs (source)

• Communication Ports:

  • 2 x Ethernet/IP ports (supporting Device Level Ring topology)

  • 1 x USB 2.0 port

• Expansion: Supports up to 8 POINT I/O modules

• Programming Languages: IEC 61131-3 compliant (Relay Ladder, Structured Text, Function Block, Sequential Function Chart)

• Mounting: DIN Rail

• Power Supply: 24V DC

• Current Draw: 1A @ 5V DC

• Power Consumption: Approximately 11.5W

• Operating Temperature: 0°C to 60°C (32°F to 140°F)

• Dimensions: 11.43 cm (H) x 13.716 cm (W) x 19.812 cm (D)

• Weight: 0.748 kg

• Certifications: UL, CE, RoHS

detailed specifications for the Allen-Bradley 1769-L30ERMS Compact GuardLogix 5370 L3 controller:

Product Overview

• Model: 1769-L30ERMS
• Series: Compact GuardLogix 5370 L3
• Manufacturer: Rockwell Automation (Allen-Bradley)
• Lifecycle Status: Active Mature
• Mounting: DIN Rail
• Power Supply: Compatible with 1769-PA2, 1769-PB2, 1769-PA4, or 1769-PB4

Key Specifications

• User Memory: 1 MB
• Safety Memory: 0.5 MB
• Embedded I/O: None (requires external I/O modules)
• Communication Ports:
  • Ethernet/IP: 2 ports (supports Device Level Ring topology)
  • USB: 1 port
• Expansion: Supports up to 8 POINT I/O modules
• Ethernet Nodes: Up to 16 nodes
• Programming Languages: IEC 61131-3 compliant (Relay Ladder, Structured Text, Function Block, Sequential Function Chart)
• Task Management:
  • Number of Tasks: 32
  • Programs per Task: 100
• Non-Volatile Memory: 1 GB (replaceable)
• Current Draw: 1.54 A @ 5V DC
• Power Consumption: Approximately 12W
• Operating Temperature: 0°C to 60°C (32°F to 140°F)

Additional Information:

• Delivery Time: Ex Stock

Additional Information:

• Delivery Time: 3 TO 4 WEEK

• Model: 1769-L18ER-BB1B

• Series: CompactLogix 5370 L1

• Type: CompactLogix Processor Unit (CPU)

• Manufacturer: Allen-Bradley / Rockwell Automation

• Controller Type: Embedded CompactLogix Controller

• Ethernet Ports: 2 integrated Ethernet ports (for dual-IP or DLR support)

• I/O Capacity: Supports up to 16 I/O modules (8 local + 8 via expansion)

• Integrated I/O:

  • 16 Digital Inputs (24V DC)

  • 16 Digital Outputs (24V DC, sourcing)

• Communication Protocols:

  • EtherNet/IP

  • USB (for programming)

• Memory:

  • 0.5 MB User Memory

• Programming Software: Studio 5000 Logix Designer

• Small to medium-sized machine control

• Industrial automation requiring Ethernet/IP connectivity

• Distributed control systems with remote I/O

Additional Information:

• Delivery Time: 3 To 4 Week

Additional Information:

• Delivery Time: 3 to 4 week

Additional Information:

• Delivery Time: 3 TO 4 WEEK

• Input, output, and relay output modules
• Wide variety of voltages
• Point-level output fault states for short-circuit and wire-off diagnostics
• Field-side diagnostics on select modules
• Choice of direct-connect or rack-optimized communications
• POINT Guard I/O™ modules for safety applications
• Configurable modules
  • Each point can be configured as a DC input or output
  • Available with DeviceLogix™ technology
