Nexus Automech Private Limited

Brand	Allen-Bradley
Country of Origin	Made in India
Color	Red
Packaging Type	Box
Usage/Application	Industrial
Shape	Rectangular

1Meets PLe to ISO 13849-12Solid-state OSSD outputs series connectable to ISO 141193RFID uniquely coded door target4Available in Power to Release or Power to Lock models5Easy QD connection TLS-Z GD2 Guard Locking Switch is an interlock switch that has a uniquely coded RFID door sensor with inductive door position sensing technology. This switch can detect if an actuator key breaks or becomes separated from its door mounted position.

Current Rating	2 A
Brand	Sick
Rated Insulation Voltage	240 V
Model Name/Number	i16S
Housing Material	Glass-fiber reinforced polybutylene terephthalate (PBT)
Rated Impulse Withstand Voltage	2,500 V
Color	Black and Yellow
Weight	0.14 kg
Enclosure Rating	IP67

Safe and economical door monitoring with retaining force, Compact plastic housing, Rigid and mobile actuators, Available with M20 X 1.5 cable entry glands or Flexi Loop-compatible M12 plug connector (depending on variant), Slow-action switching elements with two contacts, High retaining force, IP 67 enclosure rating.

Current Rating	3 A
Brand	Sick
Power/Voltage	24 V DC and 240 V AC
Housing Material	Glass-fiber reinforced thermoplastic
Rated Impulse Withstand Voltage	2,500 VAC
Short Circuit Protective Device	F15
Packaging Type	Box
Frequency	50 Hz
Enclosure Rating	IP67

Safe door monitoring directly at the hinge, Standardized plastic housing, Stainless steel solid shaft with Ø 10 mm, 1 cable entry M16 x 1.5, Slow action switching element with up to 3 contacts, Adjustable switching point, IP67 enclosure rating.

Switch Type	Hazard Warning
Brand	Sick
Power/Voltage	24 VDC
Ip Rating	IP 67
Color	Yellow and Black
Material	Zinc Die Cast (Housing)
Ambient Temperature	-25 to +70 Degree C
Dimensions	H40 x W40 x D66 mm
Installation Type	Non-flush
Connection	M12 plug 4 pin

Safe, non-contact position monitoring, Two OSSD safety outputs for direct connection of sensors to a single safety controller,Response range of up to 20 mm,LED status indicator, Up to performance level PL e / Cat. 4 (EN ISO 13849),Flexi Loop-compatible M12 plug connector

Current Rating	50 mA
Brand	Sick
Power/Voltage	24 VDC
Power Consumption	50 mA
Response Time	40 ms
Dimensions	40 x 18 x 26 mm
Weight	436 gm
Storage Temperature	-30 Degree C to +70 Degree C
Ambient Operating Temperature	-30 Degree C to +70 Degree C

Compact, safe, and flexible, Response range of up to 14 mm,Small housing with flexible mounting options,Sensor activation possible from three sides,Four different actuators available,Universally coded, uniquely coded, and permanently coded sensors,PL e (EN ISO 13849), SIL3 (IEC 61508),Safe series connection of up to 30 sensors possible

Current Rating	Less then or Equal to 100 mA
Brand	Sick
Power/Voltage	+24 V DC
Model Name/Number	L27
Switch Size	1 Module
Packaging Type	Box

Single-beam photoelectric safety switches comprise either self-testing senders and receivers or testable senders and receivers combined with an evaluation unit. They have long sensing ranges and come in a variety of types and sizes. They comply with Type 2 or Type 4 to EN 61496, and PL c or PL e to EN ISO 13849. Fields of application include robots, processing machinery, machining centers, palletizer systems, high-bay warehouses, and transfer lines.

Brand	Sick
Operating Temperature	-25 Degree C - +70 Degree C
Increased Response Ranges	Max. 15 mm
Contact Type	Male Connector M12, 4-pin
Housing Material	Nickel-Plated Brass
Packaging Type	Box

IME2SCylindrical inductive safety switch for position monitoringThe inductive safety switches of the IME2S product family are used for safe position and area monitoring. Thanks to the very compact design and wide range of connection variants, they offer optimum integration into the machine design. The IME2S switches work without making contact and are low-wear. The inductive safety switches do not require a separate actuator to do their monitoring tasks. On the contrary, they are generally activated by metals, for example on machines. Due to the large response range, the safety switches allow for assembly tolerances, simplifying mounting and adjustment. The IME2S can be connected to a safe control solution via its self-monitoring switching outputs (OSSDs), allowing for high safety with PL d (EN ISO 13849).

Switch Type	Hazard Warning
Brand	Allen-Bradley
Power/Voltage	24 VDC
Packaging Type	Box
Color	Red and White
Usage/Application	Industrial

Product Details:

Designed for partial body access guard doors. This switch combines microprocessor technology with an RFID coded actuator, and it features a locking bolt drive mechanism that locks only when the correct actuator is detected.

Brand	Allen Bradley
Mounting Type	DIN Rail
Part Number	Ex. 1794-IA8 and ex. 1794-OB8
Number Of Outputs	256 digital inputs/outputs with 32-point modules
Rated Supply Voltage	24 VDC
Warranty Period	6 month
Model Name/Number	1794 FLEX I/O Modules
Input Type	Digital or Analog

Our Bulletin 1794 FLEX™ I/O modules offer flexibility for your application with digital, analog, HART analog, and specialty I/O, with 4 - 32 points per module. You can mix and match digital and analog I/O with mounting and wiring options.

Switch Type	Hazard Warning
Brand	Banner
Model Name/Number	SI-LS & SI-QM100 Series
Housing Material	Thermoplastic
Color	Red and Black
Packaging Type	Box
Solenoid Voltage	24 V AC/DC
Contact Configuration	2 NC/1 NO; 1 NC

Details:Chieves Cat 4, PL e, or SIL CL 3 safety ratings with a single swicth deployed on a guardMechanically coded actuators use two independent operating elements, making it difficult to bypass safety functionsRotating head requires little or no tools to adjust to one of four positionsCan be used to prevent access to a hazard, ensure critical processes are not interrupted, or secure material and equipment from theft or tamperingOnce locked, a machine guard door will not open, eliminating an opportunity for nuisance trips, even if exposed to frequent impact or prolonged vibrationIP67-rated safety devices that resist dust, dirt, and some exposure to water and similar environmental challengesDesign meets positive opening requirements for safety interlocksAvailable in power-to-lock and power-to-unlock models with rigid and flexible in-line actuators and a wide range of solenoid voltages

Current Rating	200 mA
Model Name/Number	TR4
Power/Voltage	24 VDC
Usage/Application	Industrial
Output	Semiconductor
Brand	Sick
Electrical Durability	10 x 106 switching cycles
Packaging Type	Box
Color	Yellow

Intelligent and non-contact door monitoring with very effective tamper protection, Response range of up to 25 mm,Unique and universally-coded sensors up to enclosure rating IP 69K,Up to performance level PL e (EN ISO 13849), Two OSSD safety outputs, Reliable series connection of up to 30 sensors possible (depending on the variant), LED status indicator.

Switch Type	Waterproof
Brand	Banner
Power/Voltage	230 V
Housing Material	Zinc Alloy Die-Cast
Operating Temperature	-25 Degree C to +70 Degree C
Ip Rating	IP 67
Frequency	50 Hz

Details:Three types are available—load-bearing hinge, hinged lever and rotating hinge.Safety switching point can be set anywhere within 0-270° operating range on some styles.One-piece switch eliminates need for alignment, engagement and risk of breakage of a separate actuator.Design meets positive opening requirements for safety interlocks.

Switch Type	Hazard Warning
Brand	Banner
Power/Voltage	230 V
Model Name/Number	SI Series
Certification	CE
Housing Material	Thermoplastic
Switch Operation	One Way
Application	Industrial
Packaging Type	Box
Frequency	50/60 Hz

Details:Four actuator types are available—lever, spindle-mount lever, plunger, and rollerMechanically coded actuators use two independent operating elements to minimize intentional tampering or defeatRotating head and top or side engagement allows for eight different actuator positionsOne-piece switch eliminates need for alignment, engagement and risk of breakage of a separate actuatorDesign meets positive opening requirements for safety interlocksIEC IP65 switch housing rating increases to IEC IP67 with addition of a screw to the wiring chamber door

Current Rating	100 mA
Brand	Sick
Power/Voltage	24 V DC
Material	Plastic
Operating Temperature	-20 to +60 Degree C
Enclosure Rating	IP 67
Safe Switch Off	20 mm

Simple and established non-contact door monitoring, Response range up to 7 mm, 2 or 3 contacts, Up to performance level PL e (EN ISO 13849), Sensors with plug connector or connected cable, Flexi Loop-compatible M12 plug connector (depending on variant)

Brand	Sick
Weight	0.46 kg
Current Rating	1 Ampere
Model Name/Number	i10
Material/Body	Plastic
Ip Rating	IP67
Packaging Type	Box
Insulation Voltage	250 V
Resolution	30 mm
Connection Type	Cable gland,3 x M20
Color	Yellow and Black

Safe and economical door monitoring with high locking force,Narrow plastic housing,Rigid or mobile actuators,Available with M20 X 1.5 cable entry glands or Flexi Loop-compatible M12 plug connector (depending on variant),Power to lock or power to release variants,Lock and door monitoring,IP 67 enclosure rating.

Brand	Allen-Bradley
Usage/Application	Industrial
Color	Silver
Flow Rate	3 m/sec
Environment	IP67
Digital Display	Four digit 14-segment

839E Flow Switches monitor and display liquid media flow rate from 0.03 to 3 m/sec (0.1 to 9.84 ft/sec). This sensor measures both flow and temperature and is available with two different probe insertion lengths.

Material	HDPE
Brand	Sick
Color	Black
Number of Positive Action N/C Contacts	3
Rated Operating Current (Voltage)	3 A (240 V AC)
Enclosure Rating	IP67
Length of Cable	25 m

Safety command devices from SICK ensure that dangerous movements are stopped safely or critical machine functions are put into operation. The portfolio contains four product groups: Emergency stop pushbuttons, reset pushbuttons and multiple pushbuttons, rope pull switches and enabling switches. This wide variety of products provides the right solutions for a range of applications.

Models:

• i150RP,
• E100,
• I100RP,
• ES21,
• ER21,
• ES11.
