Pathak Machines Industries

Brand	T.L. PATHAK GROUP
Condition Of Machine	New
Country of Origin	Made in India
Model	GH 450
Maximum Dia. of Spur Gear	18"
Minimum Dia. of Spur Gear	1/2"
Maximum Module	5 Module
Maxmum Travels of Hob Slide	10"
Maximum Helical Gear Cutting - LH/RH	45" LH/RH
Diameter of Work Table	16"
Work Table Bore	2"
Maximum Distance b/w Hob & Work Table	11"
Maximum Dia. of Hob	4"
Mounting Taper of Hob Spindle	Mt3
Hob Spindle Speed	6
Main Motor Power	3 H.P
Rapid Motor Power	1.5 H.P

Universal Gear Hobbing Machine is used for perform the operation of hobbing on the gears to create the desired teeth profiles. It is gradually creates cut into the martial, usually cylindrically shaped, to form teeth or splines with the help of a special cutting tool, known as the hob. The teeth profiles generated with the gear hobbing machine are quite accurate. It is usually preferred for manufacturing and producing squr and helical gears. The Motor of the machine is mounted on the tailstock that powers the entire operation of the machine. Raw material is first mounted on the chuck rigidly and then the hob is fed to it in order to generate tooth profile

Brand	T.L. PATHAK GROUP
I Deal In	New Only
Country of Origin	Made in India
MODEL	PHB-65
Alloy Steel Work Spindle Hardened & Ground - Diameter	65
MorseTaper Number	4
Max.Longitudinal Movements of Working Spindle	410
Number of Spindle Speeds	9
Range of Spindle Speeds - R.P.M.	20 to 300
Longitudinal Work Spindle Feeds Nos.	9
Max.Height of The Spindle Axis from Table Surface	800
Min.Height of The Spindle Axis from Table Surface	20
Dimensions of The Rotary Table	840 x 1050
Longitudinal Table Traverse	1500
Long.Table Traverse Feeds (Including one Rapid)	10
Transversal Table Travel Feeds (Including one Rapid)	10
Vertical Head Stock Travel Feeds Including one Rapid	4
Max.Cross Movement of The Table	910
Max.Distance between Stay Bearing & Facing Head	2150
Facing Head Diameter	450
Weight Approximate in kgs. (With packing & Accessories)	7500
Weight Approximate in kgs. (Without packings Accessories)	7000
Power Motor (HP)	3 & 1.5

T.L Pathak Leading Manufacturer and Exporter of Horizontal Boring Machine. For More Details Visit our Showroom or call us today.

Material	Mild Steel
Power	3 Kw
Phase	2 Phase
Frequency	50 Hz
Brand	T.L. PATHAK GROUP
Country of Origin	Made in India
Voltage	240-280 V
MODEL	SLP-1
Rotary table	275
Longitudinal Movement	200
Cutting speed of ram stroke	29,60,90
Ram ajustment	150
Throat depth	200
H.P. adjustment	1.5
Distance from the tool rest to the main coloum	350
Height between table & head	300
Gross weight (kgs.)	975
Width depth height of machine	800*1100*1550
Size of packing case W D H	925*1225*1725

T.L Pathak Leading Manufacturer and Exporter of Slotting Machine. For More Details Visit our Showroom or call us today.

Brand	T.L. PATHAK GROUP
I Deal In	New Only
Country of Origin	Made in India
MODEL	SS30
Maximum Working Stroke	32"
Length of ram without tool slide	60"
Ram bearing in Column	37''
Ram bearing width	12.5''
Tool Slide Traverse	9"
Maximum distance from table to ram	18"
Maximum distance from table to ram	2"
Horizontal traverse of the table	30''
No of speed	4
Length and width of cross slide	43''*12.5''
Top clamping surface of table	31''*16''
Size of base plate	76''*24''
Power required	5 H.P.
Approximate net weight	2300 kg.

T.L Pathak Leading Manufacturer and Exporter of All Geared Shaping Machine Model PSG-600. For More Details Visit our Showroom or call us today

Brand	HIPAT
Material	Mild Steel
Voltage	400-440 V
Frequency	50-60 Hz
Phase	3 Phase
Power Source	Electric
Current	0-200 A

SHAPING MACHINE COMPLETE WITH VICE AND ELECTRICALS , STROKE ADJUSTMENT OPTION

Brand	T.L. PATHAK GROUP
Model Number	JS 8
Maximum Diameter of Spur Gear	787 mm
Maximum Module	8 Module
Maximum Helical Gear Cutting	45 degree LH/RH
Diameter of Work Table	624 mm
Work Table Bore	76.2 mm
Maximum Diameter of Hob	130 mm
Hob Spindle Speed	8

We are one of the top most names in the industry for the manufacturing and supplying of the best quality range of industrial machines like Universal Gear Hobbing Machine. These machines are designed by our experienced team in order to meet the satisfaction of the clients in every possible aspect.



Some important features are:

• Available in varied Models
• Capacities ranging from 5 to 25 Module
• Oil Lubricated
• Highly Versatile machine for production of Helical, Worm Gears, Serrations, Splines, Richet Wheels and Spiral
• Gears from 500 to 2500mm

Warranty	1 year
Country of Origin	Made in India
Length of bed	114 inch 3657 mm
Length of Table	106 inch 2692 mm
Max. Travel of Table	96 inch 2438 mm
Max. height under cross rail	48 inch 1219 mm
Max.Planing width	48 inch 1219 mm
Tool post down feed	8 inch 204 mm
Cutting Speed P.M.	480
Return Speed P.M.	640
Table width	30 inch
No.of Tool post on the cross rail	1
H.P.required	5
Approximate weight in kg.	6000
BRAND	T.L. PATHAK GROUP

The Pathak Planing machine has sufficient rigidity against heavy and accurate cutting operation. The bed, double column, table & cross rail are of rigid heavy box section casting duly seasoned. Automatic lubricating system on two V-guides for the table provided and table drive is by spur gear & rack arrangement.
8FT x 4FT x 4FT

Brand	T.L. PATHAK GROUP
I Deal In	New Only
Country of Origin	Made in India
Length of bed	114 inch 2895 mm
Length of Table	79 inch 2006 mm
Max. Travel of Table	72 inch 1829 mm
Max. height under cross rail	36 inch 914 mm
Max.Planing width	36 inch 914 mm
Tool post down feed	8 inch 204 mm
Cutting Speed P.M.	480
Return Speed P.M.	640
Table width	27 inch 689 mm
No.of Tool post on the cross rail	1
H.P.required	3
Approximate weight in kg.	3500

The Pathak Planning machine has sufficient rigidity against the heavy and accurate cutting operations. The bed double column table & cross rail are of rigid heavy box sections casting duty seasoned. Automatic lubricating system on two v-guides for the table provided and table,the drive is by super gear & racks.  The main bearings are cast solid with the bed and gear teeth are hobbing machine cut. Gun metal bearing has been provided for all the shafts and bearings for loose pulleys. Extra tool holders automatic lubrication system, automatic tool. Lifting arrangement, speed control gearbox provided at extra cost if ordered.
16 FT X 5 FT X 5FT

Brand	HIPAT
Material	Mild Steel
Voltage	400-415 V
Electric Motor	2 HP
Angular Movement of Table	+- 60 deg
Frequency	50 - 60 Hz
Power Source	Electric

SHAPING MACHINE COMPLETE WITH VICE AND ELECTRICALS , STROKE ADJUSTMENT OPTION

Model Name/Number	SS36
Material	Mild Steel
Voltage	415-440 V
I Deal In	New Only
Brand	T.L. PATHAK GROUP
Country of Origin	Made in India
Frequency	50 Hz
Phase	3 Phase
Maximum Working Stroke	42"
Length of ram without tool slide	75"
Ram bearing in Column	44''
Ram bearing width	14''
Tool Slide Traverse	11''
Maximum distance from table to ram	24"
Maximum distance from table to ram	3"
Horizontal traverse of the table	36"
No of speed	4
Length and width of cross slide	51''*15''
Top clamping surface of table	40''*20.5''
Size of base plate	90''*30''
Power required	7.5 H.P.
Approximate net weight	4000 kg.

SHAPING MACHINE COMPLETE WITH VICE AND ELECTRICALS , STROKE ADJUSTMENT OPTION

Model Name/Number	SS12
Material	Mild Steel
Voltage	440-480 V
Power	2-3 Hp
I Deal In	New Only
Brand	T.L. PATHAK GROUP
Country of Origin	Made in India
Frequency	50 Hz
Phase	3 Phase
Maximum Working Stroke	14"
Length of ram without tool slide	30"
Ram bearing in Column	20"
Ram bearing width	7.5"
Tool Slide Traverse	5"
Maximum distance from table to ram	14"
Maximum distance from table to ram	2"
Horizontal traverse of the table	16"
No of speed	3
Length and width of cross slide	25''*10.5''
Top clamping surface of table	14''*11''
Size of base plate	40''*16.5''
Power required	1 H.P.
Approximate net weight	800 kg.

SHAPING MACHINE COMPLETE WITH VICE AND ELECTRICALS , STROKE ADJUSTMENT OPTION

I Deal In	New Only
Country of Origin	Made in India
Table Size (mm)	800 x 2100/2800/3800
Table Stroke (mm)	1800/2500/3500
No. of T - Slots	5
Width of T - Slots (mm)	20
Distance Between T -Slots (mm)	145
Table Feed Stepless (mm/min)	40-600
Table Rapid Stepless (mm/min)	3000
Table Feed Motor (hp)	2/3
Width Between Column (mm)	1200
Maximum Height under Spindle (mm)	1000
Vertical Traverse of cross Rail (mm)	1030
Vertical Feed of Cross Rail (mm/min)	300
Cross Rail Feed Motor (hp)	3
Horizontal Traverse of one Saddle (mm)	1700
Saddle Cross Feed Motor (hp)	3
Saddle Cross Feed Stepless (mm/min)	40-600
Saddle Cross Rapid Stepless (mm/min)	2200
RPM	80-500
Spindle Nose	150-50
Quill Traverse (manual) (mm)	100
Overall Size ( L x B x H)	2700/3750/5250 x 3035 x 2900
Swivel (manual)	45''
BRAND	T.L. PATHAK GROUP

Milling machines are used to form materials with different shapes and sizes and they operate in all sorts of industries. It is quite important to choose the right kind of machine from the docking range as they vary a lot in terms of power, size, built quality, etc.

I Deal In	New Only
Country of Origin	Made in India
BRAND	T.L. PATHAK GROUP
Table Size (mm)	950 x 2800/3800/4800
Table Stroke (mm)	2500/3500/4500
No. of T - Slots	6
Width of T - Slots (mm)	20
Distance Between T -Slots (mm)	150
Table Feed Stepless (mm/min)	40-600
Table Rapid Stepless (mm/min)	3000
Table Feed Motor (hp)	3/5
Width Between Column (mm)	1600
Maximum Height under Spindle (mm)	1000
Vertical Traverse of cross Rail (mm)	1030
Vertical Feed of Cross Rail (mm/min)	300
Cross Rail Feed Motor (hp)	3
Horizontal Traverse of one Saddle (mm)	2100
Saddle Cross Feed Motor (hp)	3
Saddle Cross Feed Stepless (mm/min)	40-600
Saddle Cross Rapid Stepless (mm/min)	2200
RPM	80-500
Motor (hp)	5
Spindle Nose	150-50
Quill Traverse (manual) (mm)	100
Maximum Cutter Die (mm)	125/160
Swivel (manual)	45''
Overall Size ( L x B x H)	3750/5250/6750 x 3435 x 2900

Milling machines are used to form materials with different shapes and sizes and they operate in all sorts of industries. It is quite important to choose the right kind of machine from the docking range as they vary a lot in terms of power, size, built quality, etc.

Material	Mild Steel
Power	2 Kw
Ram Adjustment	Yes
Phase	3 Phase
Frequency	50 Hz
Brand	T.L. PATHAK GROUP
Country of Origin	Made in India
Voltage	330-360 V
MODEL	MI-250
Working Stroke	10mm To 250mm
Longitudinal Traverse	245mm
Cross Traverse	85mm
Speed Adjustment	3 Speed
Motor Requirment	1.5 H.P
A- Distance from Body to Ram	310 mm
B- Distance from Body to T-Slot Slide	370 mm
C-T-Slot Table Size	280mm x 330 mm

T.L Pathak Leading Manufacturer and Exporter of Mini Slotting Machine. For More Details Visit our Showroom or call us today.

Model Name/Number	SS40
I Deal In	New Only
Brand	T.L. PATHAK GROUP
Country of Origin	Made in India
Maximum Working Stroke	42''
Length of ram without tool slide	75"
Ram bearing in Column	44"
Ram bearing width	14"
Tool Slide Traverse	11"
Maximum distance from table to ram	24"
Maximum distance from table to ram	3"
Horizontal traverse of the table	36"
No of speed	4
Length and width of cross slide	51''X15''
Top clamping surface of table	40''X20.5''
Size of base plate	90''X30''
Power required	7.5 H.P.
Approximate net weight	4000 kg.

T.L Pathak Leading Manufacturer and Exporter of Cone Pulley Type Shaping Machine Model SS30. For More Details Visit our Showroom or call us today.
