Temperature Instruments
QCA manufactures wide range of temperature measuring instruments such as temperature sensors (RTD, Thermocouple, non-contact thermometers), temperature transmitters, Temperature indicators, Temperature PID controller, Temperature Program/Profile controllers, Humidity/Temmperature Transmitters and thermostats .
| Control Type | PID On/ Off |
| Application Area | for Oven/ Furnace |
| No of digits | 3+7 |
| Mounting Type | Flush Mounting |
| Usage/Application | PID |
| Display Size | 48*48 mm |
| Output type | Relay |
| Brand | TOHO, Autonics, Yudian |
| Controller Type | Proportional, PID, On/Off Control |
| Input Sensor | Thermocouple, RTD, mA, mV, DC Volts |
| Sensor Input | Thermocouple |
| Temperature Range | -200 deg C to 1800 deg.C |
| IP Rating | IP65 |
| Usage | Industrial Use |
| Display Type | LED/LCD |
| Power Supply | 80 - 240VAC |
| Application | Industrial |
QIS offer various range of Ditigal tmeprature controllers.
Features:
- Auto-Tuning PID: Most appropriate PID constant is automatically reckoned up for control objects. PID constant is calculated when making alteration of setting value, or it is corrected when occurring disturbance/hunting etc
- Blind Function: At the request, desirable parameters screen is only displayed and set up.
- Simplified Timer: On/Off setting control is available after some certain interval. Function of On/Off alarm output is independently usable.
- Priority Display: Demanding parameter screens are monitored and set up under operational mode screen (max. 9 screens)
- Multiple Inputs: Thermocouple/R.T.D. (Pt 100 & JPt 100) are selectable by front key
- Compact Size: It is a compact size. The depth is only 77 mm
- Manual Control (Balance less & Bump less): Manual output function is applicable for versatile applications of instrumentation systems
- Digital PV Filter: For abrupt alteration of input value, filter effect is operational on software
- PID Over-Shoot Protection: It is functional to inhibit PID
- Heating/Cooling Control: PID control is available on cooling
- Other: Shift setting of Off position during On/Off control, for both output 1 & 2
View Complete Details
| Measurement Type | Non Contact |
| Type | IR Non Contact |
| Sensing Range | -50 to 1030 Deg.C |
| Output Type | 0-10 V |
| Model Name/Number | OPTCSTCLT15 |
| Response Time | 50ms |
| Material | Stainless Steel |
| Brand | Optrics |
| Usage/Application | Industrial |
| Ambient Temperature Range | 55 deg.C |
| Item Model Number | OPTCSTCLT15 |
| Feature | Bracket |
| Output | 0 -10VDC |
| Operating Voltage | 10 - 24VDC |
| Temperature range | -50 to 1050 |
The infrared pyrometer optris CS LT is perfectly suited for temperature measurement in small and narrow environments. The robust measuring heads have been developed for use in temperature ranges from -50°C to 1,030°C and can be employed in ambient temperatures of up to 80°C without additional cooling.
The inexpensive IR pyrometers are perfectly suited for OEM solutions. They also work ideally for multiple employments of infrared measurement points.
Important specifications
- Temperature range:
-50 °C to 1,030 °C - Spectral range: 8 to 14 µm
- Response time: 14 ms
- Starting at 95 €
Additional Information:
- Delivery Time: Ex. Stock
View Complete Details
| Input Type | Thermocouple |
| Control Type | PID |
| No of digits | 4+4 |
| Display Size | 48*48 mm |
| Output type | Analog |
| Sensor Input | Thermocouple |
| Voltage | 220-240 V |
| Mounting Type | Flush Mounting |
QIS can supply WEST make Temperature Controller
Model : 6100+
Input : RTD or Thermocouple
Output : Relay, SSR, 4-20mA, 0-10VDC
Control Type : PID, On/Off
Ramp/Soak function : Yes available
Size : 48 x 48
Power supply : 230VAC
View Complete Details
| Current | 15 A |
| Temperature Range | 0 - 600 deg.C |
| Material | SS316 |
| Voltage | 250 VAC |
| Packaging Type | Box |
JUMO Panel-Mounted Thermostat, Type 606220
- Liquid expansion
- Microswitch with snap-action switch system
- Compact design
- Can be directly applied in zones 1 and 2 or 21 and 22
- Switching capacity 16 A as standard, optionally 25 A
- Admissible ambient temperature -55 °C to +70 °C
- Thermowell for zone 0 available as an accessory
- Single thermostat and double thermostat
- Fluid expansion
- Self-monitoring
- Safety swtich-off
- 1, 2, 3 or 4 single-pol snap switches possible
- Fluid expansion
- Micro switch as snap switch
- Temperature compensation
- Safety switch-off
- Cadmium-free, RoHS conform
- Fluid expansion
- Micro switch
- Self-monitoring (STB/STW)
- Safety switch-off (STB/STW)
- Sturdy housing
- Fluid expansion
- Micro switch
- Self-monitoring (STB/STW)
- Safety switch-off (STB/STW)
- 2 separate measuring and switching systems
- Liquid expansion
- Microswitch with snap-action switch system
- Temperature compensation
- Push-In® terminals
- UL-approval possible
- Rod length expansion
- Micro switch
- Automatic reset
- Breaking cut-out
- DIN reg. no. ATW 86205
- Liquid expansion
- Microswitch with snap-action switch system
- 2, 3, or 4 single-pole switching steps
View Complete Details
I Therm AI 5982 Digital Temperature Controller
₹ 1,050/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
| Brand | iTherm |
| Model No. | AI 5982 |
| Size | 96 x 96 mm |
| Control Type | Proportional/On-Off |
| Control output Type | Relay/SSR |
| Temperature Range | -200 to 1200 Deg.C |
| Accuracy | +/-0.3%FS |
| Country of Origin | Made in India |
Dual Display Digital Temperature Controller:
Ø Selectable sensor Input (T/C & RTD)
Ø Control action : T.P. control / ON-OFF
Ø Input Signal Conditioning (Digital Filter & Zero Offset)
Ø Programmable Lower and Higher Setpoint Limit Ø Program Lock function
Ø Alarm Acknowledge function
Ø Alarm Inhibit function
Ø Soak timer function
Ø Settable soak time delay
Ø Time Delay for Compressor
Ø Universal supply voltage 90 to 270 VAC
Ø 24 VDC Available on Request
View Complete Details
| Model Name/Number | DTM-903 |
| Product Type | K Type |
| Temperature Range | -40 to 1300 Deg.C |
| Brand | Metravi |
Wide Temperature Range, High Accuracy, Battery Operated, Selectable Thermocouple between K / J type, MAX / MIN / AVG Recording, Data Hold to Freeze Displayed Data, Backlit Display. Measures Temperature from -50 to 1300°C using K-type Sensor and from -50 to 1200°C using J-type Sensor. Accuracy: ±0.5%.
View Complete Details
| Temperature Range | 0 to 400 Deg C |
| Dial Size | 150 mm |
| Measuring Range | -50 to 1200 Deg C |
| Mounting Type | Every Angle |
| Usage/Application | Industrial |
| Material | SS |
| Brand | Baumer, WIKA |
| Accuracy | +/- 1% |
| Temprature Range | 80 to 320 Degree F |
| Diameter | 8 mm |
QIS is able to supply superior quality Bimetallic Temperature Gauge. This temperature gauge is made using two different metals (stainless steel & drawn steel) having varied thermal expansion coefficients. Offered product is thoroughly tested on various quality parameters with our in-house testing facilities.
· Nominal Size(mm) -50.. to 0..to..600deg C
· Thread Connection 3/8' BSP & NPT
· Mounting of Gauge Bottom,back, surface, panel
· Case and Bezel Drawn steel and SS 304
· Pressure Elements Bimetal helix
· Wetted Parts SS 304 and SS316
View Complete Details
| Output Signal | 4–20 mA |
| Mounting Type | Duct Mount |
| Accuracy | +-0.5 centigrade |
| Humidity Range | 0~100 percent |
| Power Supply | 12 VDC |
| Display Resolution | 0.1 degree C (temperature greater than 100 degree C) |
Hygro and Hygrothermal Transducer (Capacitive) for Air Conditioning Applications
For measuring relative air humidity and temperature
- For versatile climatic applications and ventilation
- For indoor and duct versions
- Compact rod models with connecting cable or form J terminal head
- With current and voltage outputs as well as passive Pt100 temperature output
- With fast-response capacitive humidity sensor
For measuring relative humidity and temperature
as well as carbon dioxide concentration
- For building automation, storage rooms, and climate/ventilation control
- Available in the indoor, wall-mounted, and duct version
- Miniature rod version for OEM applications
- With current or voltage outputs as well as passive temperature output
- Hygro thermometer as tabletop/wall-mounted indicator
View Complete Details
Humidity and Temperature Sensor for HVAC Application
₹ 7,500/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
| Sensing Type | Resistive |
| Humidity Accuracy | +-1% RH |
| Output Type | Analog Current |
| Temperature Accuracy | +-0.2 Deg C |
| Mounting Type | Duct Mount |
| Brand | FSM Germany |
| Humidity Range | 0 to 100% RH |
| Type | Humidity & Temperature Sensor |
| Supply Voltage | 24VDC |
| Temperature Range | 0.0 to 50 Deg.C |
| Part Number | FHT-R-X-A-W-X |
| Output | 4 -20mA or 0 - 10vdc |
| Response Time | 5 Sec |
The humidity and temperature transmitter feel FHT is perfectly suited for precise measurement of ambient conditions in the room or duct. Due to the sensitive measuring element and high-resolution measuring electronics, accuracies of ± 2 % rH and ± 0.3 K are achieved. For convenient commissioning, a snap-in frame or a duct flange is supplied depending on the version. Parameters such as measuring range, unit or output signal can be adapted to the on-site conditions by the user via DIP switch or software. A high-resolution 2.8" TFT display can be selected as an option.
View Complete Details
Eurotherm EPC3000 Programmable Controller
₹ 29,500/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
| Control Type | PID |
| Brand | Eurotherm |
| Input Type | Thermocouple |
| Output Type | Current Output |
| Voltage | 240V AC |
| Current | 2 A |
| Phase | Single Phase |
| Display Type | LED |
EPC3000 programmable controllersThe EPC3000 range of programmable single loop process and temperature controllers maximizes efficiency and repeatability and is certified for cybersecurity communications robustness
DescriptionAccuracy and Repeatability
Process inputs are fast and accurate, with exceptional thermal stability, aiding precise and consistent control over long periods without calibration drift. Recalibration and user calibration correction functions are available to further improve accuracy.
The industry-leading Eurotherm PID algorithm delivers fast reacting and repeatable control and has been enhanced in the EPC3000 range to further reduce overshoot. Rapid rise to operating temperature and low oscillation helps improve yield. PID settings may be adjusted to suit specific process operating regions, helping deliver optimum performance.
Connectivity and CybersecurityThe EPC3000 controller range is Ethernet enabled as standard and is the first Eurotherm controller to be designed and certified to meet the stringent cybersecurity requirements of Achilles® Communications Robustness Testing Level 1. Ethernet communications are supported via a standard RJ45 connector, providing fast access to process and diagnostic information as well as connectivity to external PLCs, SCADA systems and IIoT technologies.
Modbus RTU serial communication is also supported.
A PC-based configuration app, Eurotherm iTools, may be downloaded free of charge for use with Ethernet or Serial Modbus, or with an optional USB connector. The USB connector powers the instrument for convenient desktop configuration.
Specification
| Panel size (DIN) |
1/16, 1/4, 1/8 |
|---|---|
| IP Rating |
Washdown: IP66, NEMA4x (Indoor Use), Standard: IP65, NEMA 12 |
| Display Type |
High Visibility LCD three color multifunction display, 3008/3004 4.5,5 Digit PV, 2 starburst, 3016 4 Digit PV, 1 starburst |
| Supply Voltage |
24V dc/ac, 85-264V ac |
| Safety-approvals |
Achilles CRT Level 1 Cybersecurity, EN13849 PLc, Factory Mutual (FM) approved |
| Input Type |
TC, PT100/PT1000 RTD, mV, mA, Zirconia |
| PV Accuracy |
<0.1% low thermal drift |
| Control Types |
On/Off, PID, VP, Carbon Potential |
| Special Features |
Application Templates, Atmosphere Control, Gain Scheduling, Maths and Totalizer Function, Native Ethernet, Recipes, Text Messaging, Dual input control |
| SP Programmer |
Up to 20 programmes of 8 segments or 10 programmes of 24 segments |
| Analogue IP/OP |
3008/3004: 2PV, 1CT, 3 Isolated DC OP, 3016: 1PV, 1CT, 1 Aux (RSP), 2 Isolated DC OP, In 4, Out 3 |
| Digital IP/OP |
8 (max) Open Collector DIO 3008/3004, In 5, Out 4 |
| Digital Comms |
BACNet, EIA-485, EtherNet/IP, Modbus RTU, Modbus TCP |
| User Wiring |
Yes |
| Alarm Types |
Hi, Lo, Dev, Sensor fault, Heater fail, Rate of Change, Event |
View Complete Details
| Model Name/Number | QIS-4-P |
| Mounting Type | Wall Mounted |
| Display Type | LED |
| Usage/Application | Industrial |
| Accuracy | 0.5%FS |
| Power Supply | 230VAC |
| Range | Engineering Units |
| Color | RED |
| Shape | Rectangle |
| Input Voltage | RTD, TC, 4-20mA, 0-10VDC, Frequency |
| Material | MS Powder coated |
| Power Consumption | Less than 20W |
| Product Type | Industrial |
| Resolution | 0.1 |
| Temperature | 20 to 60 Deg.C |
| Brand | QIS |
| Country of Origin | Made in India |
QIS can supply 1", 2", 6", 8" and 10" LED Temperature and Process Display Units.
Input : RTD, TC, 0-10VDC, 4-20mA, Pulse
Output : Relay
LED Size : 1", 2", 4", 6", 8" and 10"
Power supply : 230VAC
View Complete Details
| Function | Indicator + Alarm |
| Input Type | Thermocouple + RTD |
| Display Type | LED |
| Size | Jumbo |
| Supply Voltage | 85–270 VAC |
| Output Type | Relay Alarm |
| Digits | 4 Digit |
iTherm make Jumbo Indicator with Relay output4" x 4 LED's
Features
- Universal Sensor Input
- Programmable Analog Range (-1999 to 9999)
- Programmable Input Signal Conditioning (Digital Filter & Zero Offset)
- Excitation Voltage : 5 VDC / 10 VDC / 12 VDC / 24 VDC
- Program lock function (To prevent unauthorized tampering)
- User Calibration Available for Analog Inputs
- Universal supply voltage ranges from 90 to 270 VAC
- Supply 24 VDC Available on Request
View Complete Details
Non Contact Temperature Transmitter - Laser Type
₹ 14,700/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
| Input Type | Non Contact |
| Output Signal | 0–10 V |
| Mounting Type | Field Mount |
| Temperature Range | -200 deg.C to 1800 deg.C |
| Accuracy | +/- .5% |
| Power Source | 24VDC, Loop powered |
| Application | Industrial |
| Storage temperature | -20 deg C to 85 deg C |
| Relative humidity | 10 - 95 percent, non condensing |
The infrared pyrometer optris CS LT is perfectly suited for temperature measurement in small and narrow environments. The robust measuring heads have been developed for use in temperature ranges from -40°C to 1,030°C and can be employed in ambient temperatures of up to 80°C without additional cooling.
The inexpensive IR pyrometers are perfectly suited for OEM solutions. They also work ideally for multiple employments of infrared measurement points. The plug version optris CSmed LT additionally allows for a quick assembly and removal, e.g. for regular calibration of medical devices.
Measurement Details
Temperature range (scalable via software): -40°C to 1,030°C
Spectral range: 8 to 14 µm
Optical resolution (90% energy): 15:1
CF-lens (optional): 0.8 mm @ 10 mm
System accuracy (at ambient temperature 23 ± 5°C): ± 1.5% or ± 1.5°C1)
Repeatability (at ambient temperature 23 ± 5°C): ± 0.75% or ± 0.75°C1)
Temperature coefficient: ± 0.05 K/K oder ± 0.05 % K3)
NETD: 0.1 K2)
Response time (90%): 25 ms (adjustable up to 999 s)
Emissivity / Gain (adjustable via 0-10 V DC input or software): 0.100 - 1.100
Transmissivity (adjustable via software): 0.100 - 1.100
Signal processing (parameter adjustable via software):peak hold, valley hold, average, extended hold function with threshold and hysteresis
General Details
Environmental rating: IP 63
Vibration: IEC 68-2-6: 3 G, 11-200 Hz, any axis
Shock: IEC 68-2-27: 50 G, 11 ms, any axis
Weight: 58 g
Electrical Details
Output / analog: 0-5 V or 0-10 V free scalable, thermocouple type K or alarm with adjustable voltage levels
Output / alarm: 0-30 V/50 mA (open collector)
3-state alarm output: adjustable threshold values and voltage level for: no alarm, pre-alarm, alarm
Output/ digital: uni / bidirectional, 9.6 kBaud, 0/3 V digital level / USB optional
Input(0-10V): programmable functional input for external emissivity setting/ambient temperature adjustment, triggered signal output or peak-hold function
LED-functions: alarm indication, automatic aiming support, self diagnostic, temperature indication (via temperature code)
Cable length: 1 m (standard), 3 m, 8 m, 15 m
Power supply: 5-30 V DC
Current draw: 4 mA (without LED) / 10 mA
Versions
Part number: temperature range / spectral range / optics / output
OPTCSLT15: -40-1,030 °C / 8-14 μm / 15:1 / emissivity: 0.95 preset / mV output
OPTCSTCLT15: -40-1,030 °C / 8-14 μm / 15:1 / emissivity: 0.95 preset / mV- or t/c type K output (selectable)
1) object temperature > 0°C; whichever is greater
2) at time constant 100 ms and TObj 25°C
3) for ambient temperatures <18°C and >28°C; whichever is greater
Additional Information:
- Delivery Time: Ex stock
View Complete Details
| Output Type | Relay + SSR |
| Input Type | RTD, Thermocouple |
| Control Type | PID/On-Off |
| Display Type | 3 Digit/7 Segment |
| Size | 48 x 48 mm |
| Brand | Selec |
| Frequency | 50/60 Hz |
| Voltage | 90-270 VAC/DC |
| Mounting Type | Panel |
| Resolution | 0.1/1 Degree C for TC/RTD (fixed 1 Degree C for R and S TC) |
| Control output Type | Relay/SSR |
| Model No. | TC533BX |
Temperature control is a process in which change of temperature of a space, or of a substance, is measured or otherwise detected, and the passage of heat energy into or out of the space or substance is adjusted to achieve a desired temperature.
Dual Display, Single Set Point Short Depth Temperature Controller, Size : 48 x 48mm [TC533BX]
| Display Type | 7 Segment LED Dual Display |
| Display Configuration | 3 + 3 Digits |
| Type of Input | Thermocouple (J,K,T,R,S) / RTD (PT100) |
| Resolution | 0.1/1° for TC/RTD (fixed 1° for R and S TC) |
| Accuracy | For TC (J, K, T) inputs: 0.25% of F.S. ± 1 ° For R & S inputs: 0.5% of F.S. ±2 (20min of warm up time) For RTD inputs: 0.1% of F.S ±1 |
| Control Output | RELAY or SSR. |
| Control mode | Auto Tune / Selftune PID / ON-OFF |
| Supply Voltage | 90 to 270V AC/DC |
| Size | 48 x 48mm |
| Mounting Type | Panel Mount |
| Certification | CE |
View Complete Details
| Temperature Range | -40 to 200 Deg C |
| Measuring Range | 0 to 200 °C |
| Dial Size | 150 |
| Usage/Application | Industrial |
| Mounting Type | Bottom Mount |
| Material | Stainless Steel |
| Model Name/Number | A52/100 |
| Brand | WIKA |
| Scale Range | -20....500 |
| Bourdon Material | SS216 |
| Movement Material | SS316 |
| Case And Bezel | SS316 |
| Glass | Instrument Glass |
| Over Range Protection | 1.5 times |
WIKA make Bimetal Temperature Gauge
Dial Size : 150mm
Stem dia. : 8mm
Stem length : 80mm to 250mm
Window : Instrument Glass
Dial : Aluminium
Pointer : Adjustable pointer
Accuracy : class 1 as per EN13190
Connection : 1/2" BSP
View Complete Details
Eurotherm Picolo P116 Temperature Controller
₹ 14,650/PieceGet Latest Price
| IP Rating | IP65 |
| Transmitter Power Supply | 24VDC |
| Digital IP OP | Yes |
| Digital Comms | RS-485, Modbus RTU |
| Alarm Types | Low, High, Low/High, Sensor break |
piccolo™ Controller P116 / P108 / P104
General Purpose Temperature and Process Controller
piccolo™ controllers offer precision PID control of temperature and other processes with many advanced features not normally found in this class of controllers.
DescriptionFeatures:
- Precision PID control
- Easy to use and apply
- High reliability and quality
- Three year warranty
- Ramp-soak timer and soft start
- Overshoot elimination
- Energy usage estimation
- Heater failure detection
- Modbus RTU digitalm communications
- Digital setpoint retransmission
- Analogue retransmission
- Simplified and customisable operator HMI
- High visibility three colour
- LED display
- Wipedown front fascia
- Recovery point “undo” function
- Configuration adaptor
- iTools Wizard
Designed to offer outstanding performance in an affordable package providing a complete solution for a wide variety of applications, this range guarantees extremely easy access to parameterization and operation in a high quality unit.
Despite their advanced features, the controllers are easy to use and apply and may be customised for ease of operation. Full autotune is provided.
Ramp-soak timer and soft startA ramp soak timer is provided for time based profiling of temperature sequences. These can be used to gradually vary the temperature in a control zone before maintaining it at a defined level, and is typically used to avoid the dangers of damage due to thermal shock.
Overshoot eliminationThe unique cutback system ensures precise control to setpoint and when correctly tuned inhibits temperature overshoot.
Ideal for:
- Precision PID controller
- Plastics Extrusion
- Food and Beverage
- Furnaces and Ovens
- Incubators
- Laboratory equipment
Specification
| Input Type |
mA, mV, RTD, TC, Volts |
|---|---|
| Auxiliary Switches |
No |
| Panel size (DIN) |
1/16, 1/4, 1/8 |
| PV Accuracy |
<0.2% |
| Digital OUT Relay/ SSR |
3 (1/16), 4 (1/8 – 1/4) |
| Analogue IP/OP Out |
1 |
| Digital IP/OP In |
1 (1/16), 2 (1/8 – 1/4) |
| Load Failure Detection (CT Input) |
fail/leakage, Heater |
| IP Rating |
IP66, NEMA12 |
| Display Type |
2 x 4 dig LED, 3 x 4 dig LED |
| Control Types |
On/Off, PID |
| Alarm Types |
Dev, Hi, Lo, Sensor Break |
| Supply Voltage |
24V dc/ac, 85-264V ac |
| Transmitter Power Supply |
(1/8 –1/4), 24V dc |
| SP Programmer |
– |
| Digital Comms |
RS485 Modbus |
| Timer |
Delay Soft Start, Ramp Soak |
View Complete Details
Eurotherm 3500 Advanced Temperature Controller
₹ 24,500/PieceGet Latest Price
| IP Rating | IP65 |
| Transmitter Power Supply | 24VDC |
| Real Time Clock | Yes |
| Digital IP OP | Yes |
| Digital Comms | Modbus RTU RS-485, TCP/IP |
| Alarm Types | Low, High, Low/High, Deviation Low/High |
500 Advanced Temperature Controller and Programmer3504, 3508 – Precision control of temperature and process variables
The latest range of advanced process controllers from Eurotherm provide precision control of temperature and a host of other process variables together with an abundance of advanced options making it the most adaptable product in its class.
PID Controller features:
- 2 PID loops
- 50 Programs
- Precision PV input
- Carbon potential
- Maths/logic/timers
- Custom user interface
- Recipes
- Modbus RTU
- Ethernet Modbus TCP
- DeviceNet network
Specification
| Input Type |
mA, mV, RTD, TC, Volts |
|---|---|
| PV Accuracy |
<0.1% |
| IP Rating |
IP65, NEMA12 |
| Display Type |
4 line alphanumeric, Main PV: 5 digit plus |
| Control Types |
On/Off, PID, VP |
| Alarm Types |
Dev, Event, Heater fail, Hi, Lo, Sensor Break |
| Supply Voltage |
24V dc/ac, 85-264V ac |
| SP Programmer |
50 Programmes, 500 Segments max |
| Real Time Clock |
Day and Time |
| Safety-approvals |
None |
| Special Features |
User wiring, Master comms |
| Analogue IP/OP In |
5 |
| Analogue IP/OP Out |
6 |
| Digital IP/OP In |
40 |
| Digital IP/OP Out |
41 |
| Digital Comms |
DeviceNet, Ethernet, Modbus, Modbus Master |
View Complete Details
Eurotherm 3216 Programmable Temperature Controller
₹ 17,850/PieceGet Latest Price
Minimum Order Quantity: 1 Piece
| IP Rating | IP65 |
| Transmitter Power Supply | 24VDC |
| Digital IP OP | Yes |
| Digital Comms | Modbus RS-485, TCP/IP |
| Alarm Types | Low, High, Low/High, Deviation Low/High |
| Special Features | PID, Ramp/Soak |
3200 Temperature/ Process Controller3204, 3216, 3208, 32h8 Temperature / Process Controllers
The innovative range of 3200 series controller offers precision control of temperature and other process variables together with a host of advanced features not normally found in this class of controller.
Features:
- 8 Segment programmer
- Heater failure detection
- Current monitoring
- Internal timer
- Scrolling text messages
- Recipes
- Modbus comms
- Modbus SP retransmission
- Analog retransmission
- Remote setpoint
| Input Type |
CT, mA, mV, RTD, TC |
|---|---|
| PV Accuracy |
<0.25% |
| IP Rating |
IP65, NEMA 12 / NEMA 4X (3216 Only) |
| Display Type |
Main: 4 digits Lower: 5 character starburst (3216/08/04) 9 character starburst (32h8) |
| Control Types |
On/Off, PID, VP |
|---|---|
| Alarm Types |
Dev, Event, Heater fail, Hi, Lo, Sensor Break |
| Supply Voltage |
24V dc/ac, 85-264V ac |
| SP Programmer |
4 Ramp + 4 Dwell |
| Real Time Clock |
– |
| Safety-approvals |
EN14597 TR |
| Special Features |
Recipes, Text Messaging |
| Analogue IP/OP In |
2 |
| Analogue IP/OP Out |
3 |
| Digital IP/OP In |
3 |
| Digital IP/OP Out |
4 |
| Digital Comms |
Modbus |
View Complete Details
Eurotherm 2416 Temperature Controller
₹ 8,750/PieceGet Latest Price
| IP Rating | IP65 |
| Transmitter Power Supply | 24VDC |
| Digital IP OP | Yes |
| Digital Comms | Modbus RS-485 |
| Alarm Types | Low, High, Low/High, Deviation Low/High |
| Special Features | PID, Ramp/Soak |
2404, 2408 and 2416 Controller / Programmers
The 2404/2408/2416 is a versatile, high stability temperature or process controller, with self and adaptive tuning, in 1/4 DIN, 1/8 DIN and 1/16 DIN sizes. It comes with a standard 8 segment setpoint programmer, with options for one, four or twenty programs of 16 segments each. It has a modular hardware construction which accommodates a wide range of plug-in modules.
Specification
| Input Type |
mA, mV, RTD, TC, Volts |
|---|---|
| Panel size (DIN) |
1/16, 1/4, 1/8 |
| PV Accuracy |
<0.2% |
| IP Rating |
IP65 |
| Display Type |
2 x 4 dig LED |
| Control Types |
On/Off, PID, VP |
| Alarm Types |
Dev, Event, Heater fail, Hi, Lo, Sensor Break |
| Supply Voltage |
24V dc/ac, 85-264V ac |
| SP Programmer |
20 x 16 segments |
| Special Features |
Dual input control |
| Analogue IP/OP In |
2 |
| Analogue IP/OP Out |
3 |
| Digital IP/OP In |
11 |
| Digital IP/OP Out |
11 |
| Digital Comms |
DeviceNet, Modbus, Profibus |
View Complete Details
| Control Type | PID On/ Off |
| Application Area | for Oven/ Furnace |
| No of digits | 3+7 |
| Mounting Type | Flush Mounting |
| Display Size | 96*96 mm |
| Output type | Relay |
| Sensor Input | Thermocouple |
| Voltage | 220-240 V |
- Single Channel PID Temperature Controller
- AI-208 / AI-218 / AI-509 / AI-516 / AI-519 / AI-526 / AI-716 / AI-719
- Programmable Single Channel PID Temperature Controller
- AI-216P / AI-516P / AI-526P / AI-716P / AI-719P
- Multi-channel PID Temperature Controller
- AI-7048 / AI-70482
- Input : Universal (RTD, TC, mA, DC Voltage)
- Output : Relay, SSR, mA, DC Voltage
- Control function : On/Off, PID, Ramp/Soak
- Communicaiton : RS-485 Modus protocal
View Complete Details
Hand Held Thermometers - Fluke
₹ 2,300/NumberGet Latest Price
| Temperature Range | - 199 to 999 |
| Accuracy | 0.5% |
| Color | Yellow |
| Thermometer Type | Probe Thermometers |
| Auto Off Function | Yes |
| Response Time | 1 Sec |
| Working temperature | 0 to plus 50 degree C |
| Units | Selectable degree C/ degree F |
| Dimensions | 147x70x39 mm |
| Range | 50 to 1,300 degree C |
The 305 handheld portable digital thermometer is the "lead in" model of the Quantum range of handhelds. The unit features a large, 3 1/2 digit LCD display and is housed in a rugged molded case with inbuilt stand. The N305 accepts a single "K" type thermocouple via a standard "mini plug" connector. A probe is supplied, 1m long PTFE insulated wire with a bare "bead" tip for fast response.
Details:
Sensor: K Type Thermocouple (Supplied)
Adjustment: Offset Adjustment available
Sampling: 2.5 per second
View Complete Details
| Function | Indicator + Alarm |
| Control Type | On/Off |
| Input Type | Thermocouple + RTD |
| Application Area | for Oven/ Furnace |
| Display Type | Digital |
| Size | 4" LED |
| Temperature Range | -1999 to 1999 |
| Model Name/Number | QIS-JD-4-T |
| Usage | Industrial |
| Usage/Application | Industrial |
| Material | Mild Steel |
| Color | RAL7035 |
| Brand | QIS |
| Diameter | 120 x 400 |
| Frequency | 50 |
| Pack Type | Box |
| Temp Range | -1999 - 9999 |
| Humidity Range | 0 - 95 |
| Mounting Type | Wall mounting or hanged from roof |
| Power Supply | 230VAC |
| Country of Origin | Made in India |
QIS offers Jumbo Temperature/Process Indicator accept input RTD, Thermocouple. The Indicator suitable for Temperature.
Type : Microprocesser Large LED display
Display size : 2". 4". 6" and 8"
Digits : 4 (9999 or 999,9)
Input : RTD, TC, mA, mV, DC volts
Size : 120 x 400 mm
Power supply : 230VAC
Transmitter power supply : 24VDC
Quantum also offers multi point indicators and multi zone indicator like Temperature, pressure, flow or all zone temperature or humidity as your requirement of application.
Large display (1”, 2”, 4”, 8”) indicator is available.
The indicator is compact size, priced very competitive. The unit can be drawn from the front for easy servicing.
View Complete Details
K Type Thermocouple Compensating Cable
₹ 40/MeterGet Latest Price
| Conductor Size | 7/0.3 mm |
| Thermocouple Type | K-Type |
| Conductor Type | Cr-Al |
| Color | Red |
| Size | 12, 14, 16, 18, 20, 22,24 AWG |
| Brand | Eltec/Quantum |
| Insulation Material | PTFE |
| Material | PVC |
Thermocouple Cables are manufactured from wire materials which is same as that of thermocouple with standard & special grade limits of error (thermal tolerance) as per ANSI MC 96.1 and CLASS 1, 2 & 3 as per IEC 60584-2. As they are of high accuracy in thermal tolerance, these cables are normally used directly for sensor manufacturing.
Thermocouple Compensating Cable: For certain noble metal thermocouples like S, R, B and also K & N, compensating grade cables are being designed with different metal than those of thermocouple whose accuracy is also limited up to 200 °C. They are used as an extension cables from thermocouple sensor to the control unit.
Insulation Materials : PVC, Silicon Rubber, FEP, PFA, PTFE, KAPTON, Glass Fibre, Ceramic Fibre,
Wire size : 14, 16,18,20,22, 24, 24M, 30 AWG
View Complete Details
| Control Type | PID/On-Off |
| Frequency | 50/60 Hz |
| Control output Type | Relay |
| Voltage | 100 V - 240 V |
| Model No. | DTB4848 |
The Delta Temperature Controller DTB & DTD Series offers advanced features. In addition to its primary functions the DTB model is equipped with a linear voltage signal output and dual output control. This allows for simultaneous heating and cooling controls in a temperature control system ensuring fast and accurate temperature regulation. Temperature controllers are essential measurement devices used for precise temperature control. They can be categorized into thermocouple type and resistor type controllers. These electronic temperature controllers gather temperature data from sensors and transmit the measured information to the electronic processor for further analysis and control. Get Best Price of Delta DTB4848 Temperature Controller at ₹3900/-
View Complete Details
| Input Type | RTD |
| Output Signal | 4~20 mA |
| Head Type | DIN B |
| Input Types | Temperature |
| Power Source | 24VDC |
| IP Rating | IP42 |
| Working Temperature | -25 to 80 Deg.C |
| Accuracy | 0.2 % |
| Country of Origin | Made in India |
QIS can supply, head mount type Temperature Transmitters
Input : Universal (RTD, TC)
Output : 4-20mA, 2 Wire
Power Supply : 24VDC
View Complete Details
Fluke Infrared Thermometers (Hand held)
₹ 2,600/NumberGet Latest Price
| Range (degree C) | -50 deg.C to 1700 deg.C |
| Display | Digital |
| Accuracy(+/-) | 0.2 degree celcius |
| Packaging Type | Box |
| Power | 40 W |
Newly designed, latest electronic innovative technology Light weight and easy to operate.It have many functions like Emissivity adjustment, Max/Min made, Differential mode, average mode, alarm setting at High&Low at both temperature limits,suitable for many field such as Metallurgy, Petroleum, Railways, Electronic Oven supply, Chemical, Textiles, Rubber, Plastic, Paper making, Food, Medicine Tobacco, Glass, Thermal Power plants as well as energy saving.
View Complete Details
| Voltage | 250 VAC |
| Accuracy | 3,0 percent r.h. within measuring range less than 40 percent r. h. |
| Operating Temperature | 0 plus 60 degree C |
| Use | Temperature Controller |
Hygrostats (Hygrometric) (907032)
For easy two-state control of relative air humidity
- For indoor and duct versions
- Also available with covered setpoint adjuster
- Duct version can be used continuously in areas of high humidity
- Indoor version also suitable for flush-mounted box installation
- With potential-free changeover contact(s)
- No voltage supply required (passive operation)
- Sensing element is maintenance-free when operated in a clean environment
View Complete Details
Autonics Temperature Controllers TZN/TZ Series
₹ 2,250/PieceGet Latest Price
| Temperature Range | -1999 to 9999 |
| Current | 2 A |
| Controller Type | PID |
| Size | 48*48 mm |
| Power | 100 to 240 VAC |
| Input Sensor | Universal |
| Control Output | Relay |
- Dual PID auto tuning function: High-speed response of PID control to reach to the desired value fast, low-speed of response of PID control to minimize the overshoot even though response is a little bit slow.
- High display accuracy: ±0.3%(by F.S. value of each input)
- 2-Steps auto tuning control function
- Multi-input function (13 kinds of multi-input selection function): Temperature sensor, voltage and current selection function.
- Various sub output function: Includes in LBA, SBA, 7kinds of alarm output and 4 kinds of alarm option function, PV transmission output(DC4-20mA), RS485 communication output
- Display the decimal point for analog input
View Complete Details
| Control Type | On/Off |
| DIN Size | 96*96 mm |
| Display Type | LED |
| Usage/Application | Industrial |
Humidity controllers monitor and maintain proper humidity levels in environmental test applications, food storage areas, and electronic equipment rooms.
Features
- Temperature Input : RTD, mA, Volt
- %rH Input : mA, Volt
- PID or On-Off Control for Temperature & rH
- Compressor Control Output with Time Delay
- Programmable Alarm for Temperature & rH
- Low Water Level Input & Door Open Input
- Optional Serial Communication Port
- Universal supply voltage from 90 to 270 VAC
- Supply 24 VDC Available on Request
View Complete Details
Refrigeration Temperature Controller
₹ 2,500/PieceGet Latest Price
| Body Material | Plastic |
Autonics TC3YF refrigeration temperature controllers will provide reliable and optimal cooling control with diverse features and functions.
The controller provides on/off control using compressor ouput and with defrost ouput and evaprator fan outputs. Operation cycle programming also possible to protect contents of the refrigirator in case of error.
Features :
On/Off Control
Thermistor input
3 Digit display
Control ouput for Refrigeration (Compressor output, Compressor + Defrost output, Compressor+Defrost+Evaprator -fan output
Power supply : 100 - 240VAC
View Complete Details
- Developed and Managed by IndiaMART InterMESH Limited
