• DM&P SoC CPU Vortex86DX3- 1GHz
• PC/104 standard compliant
• 1GB/2GB DDR3 onboard
• Watchdog Timer, software programmable from 30.5 µsec. to 512 sec.
• Integrated 2D VGA chip, share system memory 16MB/32MB
• Integrated 10/100Mbps Ethernet
• Support SATA interface
• Operation Temperature: -20°C ~ +70°C, -40°C ~ +85°C (Optional)

• 128Kbytes battery backed SRAM (factory fit)
• 16-bit Soundblaster/Pro compatible interface
• 8 general purpose digital I/O signals
• AMD Geode GX1 300MHz-16k L1 write-back cache
• Award or General Software BIOS
• CRT/TFT Graphics controller (XVGA)-1280 x 1024,18-bit 3.3V/5V TFT panels,1.5 - 4Mbytes SDRAM Video Memory
• Expansion CompactFlash socket (Type I & II),PC/104 bus, PCI slot (5V)
• Extended temperature operation- -20 C to +60 C (-4 F to +140 F)
• FDD, HDD, Resident Flash, CompactFlash (on solder side)
• Four 16C550 compatible high speed UARTs-3 x RS-232, 1 x RS-232/422/485
• Hardware Watchdog timer(jumper selectable for 2 or 8 seconds)
• Industry standard EBX form factor
• LED indicators-Power/Suspend/Flash access
• National Semiconductor DP83815 10/100baseTx Ethernet via RJ-45
• Onboard temperature monitor
• PC peripherals Keyboard, mouse, LPT
• RoHS-5 compliant
• Two USB ports
• Two user links
• Up to 16Mbytes onboard Intel StrataFlash-Datalight FlashFX Flash media management
• Up to 256Mbytes 144-pin SODIMM socket (on solder side)

DDR3 1333/1600 MHz SODIMM, Up to 8 GB

»Gigabit Ethernet x 2, RJ-45 x 2

»CRT, 18/24-bit Dual-Channel LVDS LCD x 2, DVI

»2CH HD Audio

»SATA 6.0 Gb/s x 2 (RAID by BIOS), CFast™ x 1

»USB 3.0 x 2, USB2.0 x 6, COM x 4, 8-bit Digital I/O

»Mini-Card x 1

»+12V Only Operation

»Supports iAMT with Intel® QM77

»Onboard 4/5/8-wire Resistive Touch Screen Controller

»mSATA x 1 (Optional, Sharded Mini-Card Interface)

»IEEE 1588 Compatible

Additional Information:

• Production Capacity: Good
• Delivery Time: 1week
• Packaging Details: Good

CRT, 18/24-bit Dual-Channel LVDS LCD, HDMI (DP Sharded with HDMI/CRT, Optional)

»2 CH Audio

»SATA 3.0 Gb/s x 1 & mSATA (Sharded with Mini-Card)

»Supports 8-bit Digital I/O, USB2.0 x 3 , USB 3.0 x 1

»RS-232 x 2, RS-232/422/485 x 2

»Mini-Card Slot x 2 (Full-size x 1, Half-size x 1)»Wide DC Support 9~24V

»Supports TPM (Optional)

»4/5/8-wire Resistive Touch Screen Controller (Optional)

»Solder Design For System Assembly and Thermal

Additional Information:

• Production Capacity: Good
• Delivery Time: Ready Stock
• Packaging Details: Good

DDR3L 1866 MHz SODIMM x 1, up to 8 GB

»VGA/LVDS/LVDS2 (HDMI Co-layout with LVDS2 Optional)

»2 CH Audio, SATA 6.0 Gb/s x 1, eMMC up to 64G (Optional)

»Supports 8-bit Digital I/O , USB 2.0 x 2 , USB 3.0 x 2 , COM x 4

»Mini Card x 1 (Full-size), mSATA x 1 (Half-size)

»9~36V wide DC input or +12V only (Optional), AT/ATX Mode

»Supports TPM (Optional)

»4/5/8-wire Resistive Touch Screen Controller (Optional

Additional Information:

• Production Capacity: Good
• Delivery Time: Ready stock
• Packaging Details: Good

• DM&P SoC CPU Vortex86DX- 800MHz
• PC/104 standard compliant, PCI-104 (Optional)
• 256/512MB DDR2 onboard
• Watchdog Timer, software programmable from 30.5 µsec. to 512 sec.
• XGI Volari Z9s Chipset, onboard 32MB VGA Memory
• CM119 USB Audio Controller
• Integrated 10/100Mbps Ethernet
• Onboard 4MB SPI Flash Disk
• Support MSTI EmbedDisk Module
• 44-pin IDE to microSD (Optional)
• Operation Temperature: -20°C ~ +70°C, -40°C ~ +85°C (Optional)

Additional Information:

• Production Capacity: GOOD
• Delivery Time: AS PER Requirement

• DM&P SoC CPU Vortex86DX- 800MHz
• PC/104 standard compliant
• 256/512MB DDR2 onboard
• Watchdog Timer, software programmable from 30.5 µsec. to 512 sec.
• XGI Volari Z9s Chipset, onboard 32MB VGA Memory
• CM119 USB Audio Controller (Optional)
• Integrated 10/100Mbps Ethernet
• Onboard 4MB SPI Flash Disk
• Support Compact Flash Type I/II
• Support MSTI EmbedDisk Module
• 44-pin IDE to microSD (Optional)
• Operation Temperature: -20°C ~ +70°C, -40°C ~ +85°C (Optional)

Additional Information:

• Production Capacity: Good

• DM&P SoC CPU Vortex86DX- 800MHz
• PC/104 standard compliant
• 256/512MB DDR2 onboard
• Watchdog Timer, software programmable from 30.5 µsec. to 512 sec.
• XGI Volari Z9s Chipset, onboard 32MB VGA Memory
• Integrated 10/100Mbps Ethernet
• Realtek 8100B 10/100Mbps Ethernet Controller x2
• Onboard 4MB SPI Flash Disk
• Support 512KB SRAM (Optional)
• Support MSTI EmbedDisk Module
• 44-pin IDE to microSD (Optional)
• Operation Temperature: -20°C ~ +70°C, -40°C ~ +85°C (Optional)

Additional Information:

• Production Capacity: Good
• Delivery Time: As Per your Requirement
• Packaging Details: Best

• DM&P SoC CPU Vortex86DX- 800MHz
• PC/104 standard compliant, PCI-104 (Optional)
• 256/512MB DDR2 onboard
• Watchdog Timer, software programmable from 30.5 µsec. to 512 sec.
• XGI Volari Z9s Chipset, onboard 32MB VGA Memory
• CM119 USB Audio Controller
• Integrated 10/100Mbps Ethernet
• Onboard 4MB SPI Flash Disk
• Support MSTI EmbedDisk Module
• 44-pin IDE to microSD (Optional)
• Operation Temperature: -20°C ~ +70°C, -40°C ~ +85°C (Optional)

Additional Information:

• Production Capacity: Good
• Delivery Time: As per Requirement
• Packaging Details: Best
