Capacitance Type Level Sensor
Leading Manufacturer of Capvel-Fuel - Volumetric Fuel Level Sensor, Ultrasonic Level Transmitter, Capacitance Type Continuous Level Transmitter - MPILC and Capacitance Type Level Transmitter-Loop Powered from Indore.
₹ 7,000/Unit
₹ 9,000/Unit
₹ 11,000/Unit
₹ 9,000/Piece
Interested in this product?
Get Best Quote
| Operating Temperature | 20dig C to 70dig C |
| Accuracy | +1 % FSL |
| Resolution | 5mm |
| Size | Medium |
| Usage | Industrial |
Capvel-FUEL is a compact fuel level transmitter which works on the principle of capacitance.
Features:
- Level to Volume Configuration
- Application Guided Installation
- Save and Reuse Tank Configuration Profiles
- On Site Adjustable Probe Length
- Convenient Outputs for Remote Monitoring Systems
- Algorithm for Turbulence Compensation
Applications:
- Only for liquids
- Oil, diesel, kerosene, gasoline, bio-diesel
- Not applicable in conductive materials
Mechanical Specification:
- Housing and Probe Material:Aluminium
- Probe Length:100 – 1500mm (standard length)
- Mounting:SAE 5-bolt pattern & 1.5″ BSP thread , SAE 6-bolt flange (optional)
- Insulation:PTFE, Delrin
- Operating Temperature:20°C to 70°C
- Accuracy:+/ 1% FSL
- Response Time:1 to 5 seconds (dynamic)
- Resolution:5mm
Electrical Specification:
- Power Supply:DC Supply: 7 – 30 V DC
- Power Consumption: Maximum=130 mA at 7 V DC
- Insulation:PTFE, Delrin
- Output:Voltage Output: 0.5 – 4.5 V / 0.1 – 4.9 V adjustable
- RS - 485 MODBUS
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Usage/Application | Industrial |
| Color | Silver |
| Temperature | 0dig C to 80dig C |
| High Temperature | Up to 300dig C |
| Internal Enclosure | ABS |
Capvel is suitable for continuous level measurement and controlling conductive and nonconductive liquids, granular materials of homogeneous composition that have stable dielectric constant. Capvel series is a family of capacitance level transmitters suitable for liquids.
Features:
- Internal temperature compensation
- Extrapolated calibration range (from any two points)
- Suitable for a wide range of liquids
- Low cabling cost
- Selfdiagnosis of error conditions during operation
- 3 digit LCD display
Application:
- Chemical Industry
- Vehicle Tracking
- DG sets (Telecom)
- Water treatment plants
- Edible Oil
- Distilleries
Mechanical Specifications:
- Housing: Cast aluminum Weatherproof, Flame-proof
- Mounting: Threaded=1 1.5" BSP/NPT (M) , Flanged=As per specification
- Material: MS (Plated)
- Cable Entry: 2 X 1/2" BSP / NPT, Brass
- Gland Type: Single / Double compression gland / PG 13.5
- Probe Length: Standard=100 mm , Extended (Rod)=Up to 3000 mm , Extended (Rope)=Up to 10 meter
Electrical Specifications:
- Indication: 2 LED's for Fault Indication & Calibration
- Input Supply: 24-50 VDC @ 750 ohm
- Current Consumption: 20 mA maximum
- Output: Analog (4 20mA)
- Temperature: Standard Model: 0°C to 80°C
- High Temperature Model: up to 300°C for nonconductive media
- Internal Enclosure:ABS
- Response Time: 2 sec. (typical)
Additional Information:
- Item Code: Capvel-ICT
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
| Country of Origin | Made in India |
| Power Consumption | 3.5 VA (approximately) |
| Power Supply | 90 to 260 V AC 50Hz; 24 V DC |
| Zero Setting Range | 30 to 1000 pF |
Technical Specifications:
| Housing | Cast aluminium, Weatherproof, Stoving enamel painted suitable for back panel / wall mounting |
| Type | Integral with sense rod or probe |
| Cable Entry | 3 Nos. 1/2" BSP / NPT |
| Mounting | Threaded / Flanged (as required) |
| Ambient Temperature | 20°C to 60°C |
| Power Supply Required | |
| Power Consumption | 3.5 VA (approximately) |
| Power supply | 90 to 260 V AC 50Hz; 24 V DC |
| Zero setting range | 30 to 1000 pF |
| Accuracy | +/ 12% of Full Measuring Span |
| Programming Interface | 5 Push Button Keys |
| Output | |
| Output | 3 sets of potential free change over contacts rated at 6A, 230V AC, 50Hz for noninductive loads |
| Utilizable span | Minimum 10% of zero setting to 4500 pF |
| Switching delay | Programmable up to 99 seconds |
| Sensing | |
| Measuring Frequency | 50 to 250 KHz |
| Response Time | Adjustable |
| Insulation | Part / Full PTFE: up to 200°C, Part Ceramic: up to 400°C |
Additional Information:
- Item Code: Capvel
View Complete Details
Yes, I am interested!
Interested in this product?
Get Best Quote
Capacitance Type Level Transmitter-Loop Powered
₹ 9,000/PieceGet Latest Price
| Material | Aluminium |
| Country of Origin | Made in India |
| Operating Temperature | 20dig C to 70dig C |
| Resolution | 5mm |
CAPVEL-LP is composed of specially developed Capacitance Change Gauging circuit. It uses fast RISC based processor to perform all the complicated jobs of evaluating the Level out of the capacitance.This capacitance is formed by the sense Rod and the metallic container wall. Where containers are non-metallic or not-uniformally wide or having turbulent fluid, a metallic stilling well is provided. The amount of capacitance is propor- tional to the level of material between the sense rod and metallic wall of stilling tube or container.
Features:
- Power Supply 24-50 VDC
- Analog Output 4-20mA Loop powered
- Temperature Durability Standard Model upto 60°C (High temp. models on demand)
- Internal Temperature Compensation
- Extrapolated Calibration range (From any two points)
- Suitable for wide range of Liquids
- Low Cabling Cost
- Self Diagnosis
Application:
- Chemical Industry
- DG sets (Telecom)
- Vehicle Tracking(Automobile)
- Water treatment plants
- Soya plants
- Distilleries
View Complete Details
Yes, I am interested!
