Sparko India

No. of Pins	4
Application	Oil and Lubricant Resistant
Operating Voltage	Max. 30 V AC/DC
Thread Size	M8
Type	Female
Operating Temperature	-25 to 80 Deg C
Degree of Protection	IP 65, IP 67

Basic data Application Chemical resistant Electrical data Performance data Operating voltage 50 V AC / 60 V

Application	Oil and Lubricant Resistant
Operating Voltage	Max. 250 V AC/DC
Thread Size	M12
Type	Female
Cable Length	2000 mm
Operating Temperature	-25 to 80 Deg C
Degree of Protection	IP 65, IP 67

Connection cable

Part no.: 50130692

KD U-M12-4W-P1-020

Application	Chemical Resistant
Operating Voltage	50 V AC / 60 V DC
Thread Size	M8
Type	Female
No. of Pin	4
Operating Temperature	-5 to 80 Deg C
Degree of Protection	IP 65, IP 67

Basic data Application Chemical resistant Electrical data Performance data Operating voltage 50 V AC / 60 V DC Connection Connection 1 Type of connection Connector Thread size M8 Type Female Handle body material PUR No. of pins 4 -pin Version Angled Connector, LED No Lock Screw fitting, nickel-plated diecast zinc, recommended torque 0.6 Nm, selflocking Connection 2 Type of connection Open end Cable properties Number of conductors 4 Piece(s) Wire cross section 0.25 mm² AWG 24 Sheathing color Black Shielded No Silicone-free Yes Cable design Connection cable (open on one end) Cable diameter (external) 4.7 mm Cable length 5,000 mm Sheathing material PVC Wire insulation PVC Suitability for drag chains No Properties of the outer sheathing Free of CFC, cadmium, silicone and lead, easily machine-processable Resistance of the outer sheathing Good oil, gasoline and chemical resistance, flame retardant in accordance with UL 1581 VW1 / CSA FT1 Electrical connection Connection 1 Type of connection Connector Thread size M8 Type Female Handle body material PUR No. of pins 4 -pin Version Angled Connector, LED No Lock Screw fitting, nickel-plated diecast zinc, recommended torque 0.6 Nm, self-locking Mechanical data Width across flats 9 mm Net weight 167 g Bending radius, flexible laying, min. Min. 10 x cable diameter Bending radius, stationary laying, min. Min. 5 x cable diameter Operation and display Environmental data Ambient temperature, operation, flexible use -5 ... 80 °C Ambient temperature, operation, stationary use -30 ... 80 °C Certifications Degree of protection IP 65 IP 67 Certifications c UL US

Operational Voltage	Max. 250 V AC/DC
Type of Connection	Connector
Thread Size	M12
Type	Female
Material	Metal
Handle Body Material	Plastic
Operating Temperature	-25 to 85 Deg C
Degree of Protection	IP 67

Leuze Connector

Part no.: 50031323

KD 095-4A

Application	Chemical Resistant
Operating Voltage	Max. 250 V AC/DC
Thread Size	M12
Type	Female
Operating Temperature	-5 to 80 Deg C
Degree of Protection	IP 65, IP 67

 Connection 2  Cable properties

Application	Chemical Resistant
Operating Voltage	Max. 250 V AC/DC
Thread Size	M12
No. of Pins	4
Type	Female
Cable Lenght	2000 mm
Operating Temperature	-5 to 80 Deg C
Degree of Protection	IP 65, IP 67

Basic data Application Chemical resistant Electrical data Performance data Operating voltage 50 V AC / 60 V
