Sparko India

Desin	Fork
Mouth Width	5 mm
Mouth Depth	220 mm
Switching Frequency	5000-10000 Hz
Material	Stainless Steel
Housing Material	Metal

 Optical data  Electrical data  Performance data  Outputs  Switching outputs  Switching output 1  Time behavior  Connection  Connection 1  Mechanical data

Type	Light Sensor
Material	Metal
Accuracy	1
Activation current	4 mA
Active Area	india
Operating temperature	AMBIENT

 Optical data  Electrical data  Performance data  Outputs  Switching outputs  Switching output 1  Switching output 2  Time behavior  Connection  Connection 1  Mechanical data  Operation and display  Environmental data  Certifications

Additional Information:

• Production Capacity: 10
• Delivery Time: Ex-stock

Material	Plastic
Type	Light Sensor
Accuracy	0.01
Activation current	4 mA
Operating temperature	Ambient
Country of Origin	Made in India

LEUZE PRK5/4P Polarized retro-reflective photoelectric sensor Part no.: 50117705
PRK5B/PPolarized retro-reflective photoelectric sensor

• Series: 5B
• Operating principle: Reflection principle
• Operating range, max.: 0.02 ... 5 m
• Design: Cubic

Additional Information:

• Item Code: 8536
• Production Capacity: 50
• Delivery Time: ex-stock
• Packaging Details: bbbbbbb

Material	Plastic
Operating temperature	-40 DegreeC ... 60 DegreeC
Sensor Type	Photoelectric Sensor
Dimension	14 mm x 32.5 mm x 20.2 mm
Net Weight	20 g
Type of Display	LED
Switching Frequency	500 Hz
Response Time	1 ms
Wavelength	620 nm

Technical data sheet Polarized retro-reflective photoelectric sensor Part no.: 50117706 PRK5/4P-M8

Material	Plastic
Wavelength	645 nm
Switching Frequency	1000 Hz
Dimension (W*H*L)	11 mm*32.4 mm*20 mm
Net Weight	44 g
Display Type	LED
Operational Controls	Multitum Potentiometer
Operational Temperature	-40 to 60 Deg C
Degree of Protection	IP67

Diffuse Sensor With Background Suppression

Part no.: 50148002

HT5B/4

Material	Plastic
Operating temperature	-40 to 60 Deg C
Wavelength	640 nm
Supply Voltage	10 to 30 V DC
Switching Frequency	500 Hz
Dimension (W*H*L)	15 mm*42.7 mm*30 mm
Net Weight	15 g
Display	LED
Degree of Protection	IP 67

PRK15/4X-M12

Polarized retro-reflective photoelectric sensor

Part no.: 50134362

Type of Proximity Switch	Inductive Proximity Switch
Shape	Cylindrical
Supply Voltage	10 to 30 V DC
Operating Frequency	3000 Hz
Thread Size	M18 x 1 mm
Type of Display	LED
Operating Temperature	-25 to 70 Deg C
Degree of protection	IP 67

Leuze Inductive Switch

Part no.: 50129981

IS 118 MM/4NO-8E0-M12

Housing Material	Plastic
Series	MC336
Response Time	3 ms
Cable Length	2000 mm
Design	Cubic
Dimension (W x H x L)	26.2 mm x 13 mm x 36 mm
Operating Temperature	-20 to 70 DegreeC
Degree of Protection	IP 67

Technical data Basic data Series MC336 Functions Functions Integration in control circuits up to category 4 in accordance with EN ISO 13849-1 Safety system in combination with an evaluation unit such as the MSI-MC310 safety relay or the MSI 400 safety controller. Characteristic parameters Mission time TM 20 years, EN ISO 13849-1 Category Up to 4, depending on evaluation, 1 sensor connected, EN ISO 13849-1 B10d 20,000,000 number of cycles Electrical data Protective circuit Current limitation Short circuit protected, Via e.g. MSIMC310, MSI 400 Contact allocation 1NC + 1NO Contact type Reed contacts (magnetically sensitive) Requirement on the voltage supply when used acc. to cULus (UL 508) Class 2 Circuits Outputs Max. switching voltage 27 V AC/DC Switching current, max. 500 mA Time behavior Response time 3 ms Connection Number of connections 1 Piece(s) Connection 1 Function Contact connection Type of connection Cable with wire-end sleeves Cable length 2,000 mm Sheathing material PVC Cable color Gray Number of conductors 4 -wire Mechanical data Design Cubic Dimension (W x H x L) 26.2 mm x 13 mm x 36 mm Housing material Plastic Plastic housing Glass fiber reinforced (PPS), selfextinguishing Net weight 149 g Housing color Red Type of fastening Through-hole mounting Installation position Arbitrary, provided housing markings are aligned Switch type Type 4 interlock device, contactless actuation, EN ISO 14119 Approach actuation directions 3-dimensional Mechanical life time 10,000,000 actuation cycles External actuator Magnetically coded Cut-out point (OFF), min. 8 mm Assured cut-out distance (Sar), min. 11 mm Assured cut-in distance (Sao), max. 3 mm Switching tolerance (without ferromagnetic materials in immediate vicinity) -1 ... 1 mm Distance to other magnetic sensors, min. 50 mm

Type of Proximity Switch	Inductive Proximity Switch
Shape	Cylindrical
Supply Voltage	10 to 30 V, DC
Operating Frequency	500 Hz
Thread Size	M12
No. of Pin	4
Housing Material	Metal
Type of Display	LED
Operating Temperature	-25 to 70 Deg C
Degree of Protection	IP 67

Inductive switch

Part no.: 50129985

IS 118 MM/4NO-16N-M12

Material	Plastic
Type	Automotive Sensor
Activation current	0.01Sec
Operating temperature	ambient

Operating principleReflection principle Optical data Operating range0.1 ... 5 m, With reflector TK(S) 100x100Operating rangeGuaranteed operating rangeOperating range limit0.1 ... 6 m, With reflector TK(S) 100x100Operating range limitTypical operating rangeLight sourceLED, RedWavelength633 nmLED groupExempt group (in acc. with EN 62471)

Operating temperature	-20 to 60 Deg C
Mouth Width	3 mm
Mouth Depth	40 mm
Operating Voltage	10 to 30 V DC (incl. residual ripple)
Housing Base	PC Plastic
Weight	20 g (with cable), 70 g (with connector)
Protection Degree	IP 65

Physical data Mouth width 3mm Mouth depth 40mm Label width ≥ 2mm Label gap ≥ 2mm Light source 940nm (infrared light) Switching frequency max. 10kHz Conveyor speed with teach-in ≤ 20m/min (0.3m/s) Typ. response time 50μs Repeatability see diagrams Delay before start-up ≤ 300ms acc. to IEC 60947-5-2 Electrical data Operating voltage UB 1) 1) For UL applications: for use in class 2 circuits according to NEC only 10 … 30VDC (incl. residual ripple) Residual ripple ≤ 15% of UB Open-circuit current ≤ 30mA Switching output 2) …/6 switching signal in the label gap 2) The push-pull switching outputs must not be connected in parallel 1 push-pull switching output Pin 4: PNP gap signal, NPN label signal …/6D signal on the label 1 push-pull switching output Pin 4: PNP label signal, NPN gap signal Signal voltage high/low ≥ (UB-2V)/≤ 2V Output current ≤ 100mA Capacitive load ≤ 0.2μF 3) 3) Max. permissible input capacitance of a consumer connected to the switching output that can be switched without activation of short-circuit-current limiting. Indicators Green LED ready Green LED, flashing teach-in activated Yellow LED switching signal in the label gap Red LED (GS 61/… .2… only) teach error / function error Mechanical data Housing base PC plastic, black RAL 9005 Upper part of housing PC plastic, red RAL 3000 Optics PC plastic Weight 20g with connector 70g with cable Connection type M8 connector, 4-pin, or M8 connector, 3-pin, or cable 2m (cross section 5 x 0.2mm²) Tightening torque of fastening screws max. 3Nm Environmental data Ambient temp. (operation/storage) -20°C … +60°C/-30°C … +70°C

Sensor Type	Retro-Reflective
Sensing Distance	10 mm
Output Type	PNP
Operating Voltage	24 V DC
Light Source	Infrared LED
contact	NO

Operating principle:-Reflection principle,  Autocollimation, O/p:- 4-20 m A

Type	Light Sensor
Material	Metal
Accuracy	0.2 %
Activation current	4-20 m A

Photoelectric Sensor PRK3C.T3/4P-200-M12
Basic data Series 3C Operating principle Reflection principle Application Detection of highly transparent bottles Detection of transparent films Special version Special version Autocollimation Optical data Operating range 0 ... 3 m Operating range Guaranteed operating range Reference reflector With reflector TK(S) 100x100 Operating range limit Typical operating range Operating range limit 0 ... 3.6 m, With reflector TK(S) 100x100 Light source LED, Red Wavelength 635 nm Transmitted-signal shape Pulsed LED group Exempt group (in acc. with EN 62471) Electrical data Protective circuit Polarity reversal protection Short circuit protected Performance data Supply voltage UB 10 ... 30 V, DC, Incl. residual ripple Residual ripple 0 ... 15 %, From UB Open-circuit current 0 ... 15 mA Outputs Number of digital switching outputs 2 Piece(s) Switching outputs Voltage type DC Switching current, max. 100 mA Switching voltage high: ≥(UB -2V) low: ≤ 2 V Switching output 1 Assignment Connection 1, pin 4 Switching element Transistor, PNP Switching principle Light switching Switching output 2 Assignment Connection 1, pin 2 Switching element Transistor, PNP Switching principle Dark switching Time behavior Switching frequency 1,500 Hz Response time 0.33 ms Readiness delay 300 ms Response jitter 110 µs Connection 1 Function Signal OUT Voltage supply Type of connection Cable with connector Cable length 200 mm Sheathing material PUR Cable color Black Wire cross section 0.2 mm² Thread size M12 Type Male Material Metal No. of pins 4 -pin Encoding A-coded Mechanical data Dimension (W x H x L) 11.4 mm x 34.2 mm x 18.3 mm Housing material Plastic Plastic housing PC-ABS Lens cover material Plastic / PMMA Net weight 20 g Housing color Red Type of fastening Through-hole mounting Via optional mounting device

Sensor Type	Retro-Reflective
100	9500

Polarized retro-reflective photoelectric sensor. Part no.: 50136265, MAKE:- LEUZE

Technical data Basic data Series 3C Operating principle Reflection principle Application Detection of highly transparent bottles Detection of transparent films Special version Special version Autocollimation Teach input Optical data Operating range 0 ... 3 m (guaranteed operating range), With reflector TK(S) 100x100 Operating range limit 0 ... 3.6 m (typical operating range), With reflector TK(S) 100x100 Light source LED, Red Wavelength 635 nm Transmitted-signal shape Pulsed LED group Exempt group (in acc. with EN 62471) Electrical data Protective circuit Polarity reversal protection Short circuit protected Performance data Supply voltage UB 10 ... 30 V, DC, Incl. residual ripple Residual ripple 0 ... 15 %, From UB Open-circuit current 0 ... 15 mA Inputs Number of teach inputs 1 Piece(s) Teach inputs Type Teach input Voltage type DC Switching voltage high: ≥ 0.65 x UB low: ≤ 0.35 x UB Delay 1 ms Input resistance 20,000 Ω Teach input 1 Assignment Connection 1, pin 2 Function Keyboard lockout Light/dark switching Sensitivity adjustment Active switching state High Outputs Number of digital switching outputs 1 Piece(s) Switching outputs Type Digital switching output Voltage type DC Switching current, max. 100 mA Switching voltage high: ≥(UB -2V) low: ≤ 2 V Switching output 1 Assignment Connection 1, pin 4 Switching element Transistor, PNP Switching principle Dark switching Time behavior Switching frequency 1,500 Hz Response time 0.33 ms Readiness delay 300 ms Response jitter 110 µs Connection Number of connections 1 Piece(s) Connection 1 Function Signal IN Signal OUT Voltage supply Type of connection Connector Thread size M8 Type Male Material Metal No. of pins 4 -pin Mechanical data Dimension (W x H x L) 11.4 mm x 34.2 mm x 18.3 mm Housing material Plastic Plastic housing PC-ABS Lens cover material Plastic / PMM

Additional Information:

• Item Code: 85365090
• Production Capacity: 100
• Delivery Time: EX-STOCK
• Packaging Details: 1 SET, SENSOR CONNECTOR MODEL

Operating temperature	-40 to 60 Deg C
Wavelenght	620 nm
Switching Frequency	1500 Hz
Operational Voltage	10 to 30 V DC
Weight	60 g
Protection Class	IP 67, IP 69K

Retro-reflective photoelectric sensors with autocollimation optics for reliable detection of highly transparent bottles and tape  User-controlled sensitivity adjustment via 11-turn potentiometer or teach button  Temperature compensation ±20°C  High optical accuracy through calibrated optical system

Operating temperature	-40 to 60 Deg C
Housing Material	Plastic
Wavelength	645 nm
Supply Voltage	10 to 30 V DC
Switching Frequency	500 Hz
Dimension (W*H*L)	11 mm*32.4 mm* 20 mm
Net Weight	18 g
Display	LED
Degree of Protection	IP 67

PRK5B/4X-M8

Polarized retro-reflective photoelectric sensor

Part no.: 50145252

Operating temperature	-40 to 60 Deg C
Wavelength	620 nm (visible red light)
Switching Frequency	1500 Hz
Operating Voltage	10 to 30 V DC (Incl. residual ripple)
Operation	11-turn potentiometer or teach button
Protection Degree	IP 67, IP 69K

Retro-reflective photoelectric sensors with autocollimation optics for reliable detection of highly transparent bottles and tape  User-controlled sensitivity adjustment via 11-turn potentiometer or teach button  Temperature compensation ±20°C  High optical accuracy through calibrated optical system

Housing Material	Plastic
Wavelength	645 nm
Supply Voltage	10 to 30 V DC (Incl. residual ripple)
Switching Frequency	1000 Hz
Dimension (W x H x L)	11 mm x 32.4 mm x 20 mm
Type of Display	LED
Operating Temperature	-40 to 60 Deg C
Degree of Protection	IP 67

Technical data sheet Diffuse sensor with background suppression

Part no.: 50148001

HT5B/2

Operating temperature	-40 to 60 Deg C
Housing Material	Plastic
Wavelength	620 nm
Supply Voltage	10 to 30 V DC (Incl. residual ripple)
Switching Frequency	500 Hz
Cable Length	2000 mm
Type of Display	LED
Degree of Protection	IP 67

Polarized Retro-Reflective Photoelectric Sensor

Part no.: 50132421

PRK5/4

Sensor Type	Retro-Reflective
Sensing Distance	5 MM
Output Type	PNP
Operating Voltage	24 V
Light Source	Red LED

Detection of highly transparent bottles
Detection of highly transparent films and glass panes

Protection Rating	IP65
Sensor Type	Retro-Reflective
Brand	LEUZE
Output Type	PNP
Housing Type	Cylindrical M12
Sensing Mode	Background Suppress
Sensing Distance	1.5 mtr
Operating Voltage	24 V DC
Supply Voltage	10-30 V DC
Response Time	0.5 ms
Switching Output	NO + NC
Light Source	Red LED

RK46C.DL3/4P-200-M12Unpolarized retro-reflective photoelectric sensorPart no.: 50143108

Design	Rectangular
Triple Reflector Size	2.3 mm
Reflector Material	Plastic
Polarization-Changing	Yes
Mounting Dimension(W*H)	40.4 mm * 60 mm
Type of Fastening	Adhesive, Screw type

TKS 40 X 60
