Material	Aluminium
Model Name/Number	ELC100T30-1200
Automation Grade	Automatic
Color	Yellow (Base)
Usage/Application	Hand Protection
Brand	Leuze
Type of Display	LED
Thread Size	M12
No. of Pins	5

 Characteristic parameters  Protective field data  Optical data  Electrical data  Performance data  Inputs  Digital switching input 1

Response Time	9.5 ms
Operating Temperature	0 to 50 Deg C
Device Type	Receiver
Functions	Automatic start/restart
Supply Voltage	24 V, DC, -20 to 20%
Dimension (W x H x L)	34.7 mm x 1,215 mm x 39.3 mm
Type of Display	LED
Degree of Protection	IP 65

Safety light curtain receiver

Part no.: 72001312

ELC110R30-1200

Response Time	5.6 ms
Operating Temperature	0 to 50 DegreeC
Cable Length	300 mm
Dimension (W x H x L)	34.7 mm x 615 mm x 39.3 mm
Housing Material	Metal
Type of Display	LED
Degree of Protection	IP 65
Supply Voltage	24 V, DC, -20 to 20 %

Basic data Series ELC100 Device type Receiver Contains 2x sliding block Application Hand protection Functions Functions Automatic start/restart Characteristic parameters Type 4, IEC/EN 61496 SIL 3, IEC 61508 SILCL 3, IEC/EN 62061 Performance Level (PL) e, EN ISO 13849-1 PFHD 8E-09 per hour Mission time TM 20 years, EN ISO 13849-1 Category 4, EN ISO 13849 Protective field data Resolution 30 mm Protective field height 600 mm

Operating Range	0.5 to 6 m
Operating Temperature	0 to 50 Deg C
Wavelength	940 nm
Device Type	Transmitter
Light Source	LED, Infrared
Supply Voltage	24 V, DC, -20 to 20%
Dimension (W x H x L)	34.7 mm x 615 mm x 39.3 mm
Type of Display	LED
Degree of Protection	IP 65

Safety light curtain transmitter

Part no.: 72000306

ELC100T30-600

Operating Range	0.3 to 7 m
Operating Temperature	-30 to 60 Deg C
Housing Material	Metal
Minimum Object Diameter	20 mm
Supply Voltage	18 to 30 V DC
Thread Size	M12
Type	Male
Type of Display	LED
Degree of Protection	IP 65

Bracket for hanging safety curtain, reflector
