Time Equipment Private Limited

The Caterpillar Inc. CAT 950H Wheel Loader is a mid-size, high-performance loader designed for heavy-duty applications like mining, quarry, road construction, and bulk material handling.

It is part of CAT’s H-Series, known for:

• Strong engine power & breakout force

• High productivity in loading operations

• Excellent fuel efficiency & durability

• Comfortable operator cabin for long working hours

👉 This machine is widely used where continuous loading + high output is required.

• Engine Model: CAT C7 ACERT

• Net Power: 197 HP (147 kW)

• Gross Power: ~216–217 HP

• Torque: 907 Nm @ 1400 RPM

• Displacement: ~7.2 L

• Cylinders: 6

• Operating Weight: 18,300 – 18,400 kg

• Bucket Capacity: 2.5 – 3.5 m³

• Max Bucket Capacity: 3.5 m³

• Tipping Load (Full Turn): ~10,800 kg

• Breakout Force: ~150–165 kN

• Engine Make: Ashok Leyland (H6C413323)

• Engine Type: Turbocharged, BS-IV compliant diesel

• Rated Power: 98 kW (133 HP) @ 2300 RPM

• Displacement: ~5760 cc

• Fuel System: Common rail injection (better fuel efficiency)

• Bucket Capacity: 1.53 – 3.0 m³

• Payload Capacity: ~3210 kg

• High Fill Factor Buckets: Performance series buckets for better loading

• Operating Weight: 11,600 – 11,700 kg

• Overall Length: ~7034 mm

• Overall Height: ~3207 mm

• Ground Clearance: 367 mm

• Pump Flow: ~196 LPM

• Hydraulic Tank Capacity: 90 Litres

• System Type: Joystick-controlled hydraulic system

• ENGINE GROSS POWER - 225 HP / 168 kW
• OPERATING WEIGHT - 17,650 Kg – 18,180 Kg
• BUCKET CAPACITY - 2.5 m3 - 5.0 m3

• The proven Cat Z-bar linkage geometry with Performance Series Buckets offer excellent penetration into the pile and high breakout forces. The results are low fuel consumption and exceptional production capabilities.

• C7.1 built on a proven block with a new injection system specifically designed for fuel available in emerging markets.

• Load sensing hydraulics produce flow and pressure for the implement system upon demand and only in amounts necessary to perform the needed work functions. This state of the art system results in low fuel consumption.

• Our electrical and hydraulic service centers, along with additional key serviceability features, help make servicing customer machines and in-field component exchange quick, easy, and efficient.

• Caterpillar design and manufacturing techniques assure outstanding service life.

• The spacious cab features easy and intuitive controls and excellent visibility. The cab provides a comfortable working environment for efficient all day operation.

Additional Information:

• Delivery Time: tommrow

JCB Wheel Loader

JCB offers some of the best wheeled loaders in India that lead to a perfection driven performance. Our new range of Wheeled Loaders is designed to lead the way in standards of Fuel Efficiency, Performance, Reliability, Operator Comfort, and Innovation.

Capable of performing for continuous hours, these wheeled loaders work with precision and perfection. Whether it’s about the transfer of material from stockpiles to trucks, or transport of material around job sites, Wheeled Loaders by JCB revolutionise the way loading processes happen.

Designed to deliver under the toughest conditions, the new JCB 437-4 Wheeled Loader is loaded for success. One of the most efficient wheeled loaders ever made, the new JCB 437-4 Wheeled Loader performs the ‘extraordinary’ on an ‘everyday’ basis. This incredible wheeled loader boasts of the highest levels of productivity.

This incredible machine can bring down your fuel cost by 10% and increase productivity by 2%

Additional Information:

• Item Code: 437-4
• Production Capacity: 12040 Kg
• Delivery Time: in 2 days
• Packaging Details: Designed to deliver under the toughest conditions, the new JCB 437-4 Wheeled Loader is loaded for success. One of the most efficient wheeled loaders ever made, the new JCB 437-4 Wheeled Loader performs the ‘extraordinary’ on an ‘everyday’ basis. This incredible wheeled loader boasts of the highest levels of productivity. This incredible machine can bring down your fuel cost by 10% and increase productivity by 2%.

• The Cat^® C7.1 engine features a fuel-injection system specifically designed for fuel available in emerging markets. The EIMS minimizes fuel consumption by reducing engine rpm after a specified amount of idle time.
• The 950 GC features a load sensing hydraulic system that only produces flow and pressure for the implement system when required, improving machine productivity and resulting in low fuel consumption.

Additional Information:

• Item Code: L956

Additional Information:

• Item Code: 25421
• Production Capacity: 10
• Delivery Time: 1
• Packaging Details: LiuGong Wheel loader at best price Precisely selection of Engine to ensure the unmatched performance to handle the toughest and heaviest jobs. Offering big capacity buckets large dump height and great stability on operation shown all time favourable features of LiuGong Wheel loader to its Customer Operating Weight 52,000 kg Bucket Capacity 7.0 m³ Rated Load 12,000 kg Total Cycle Time 14.6 s Tipping Load-full Turn 31,200 kg Bucket Breakout Force 395 kN Dump Clearance, Full Height Discharge 3,910 mm Dump Reach, Full Height Discharge 2,050 mm Model Cummins QSK19 Emissions EPA Tier 3 / EU Stage IIIA

• Operating weight(kg) 19600
• Bucket capacity(m³) 2.7~5.0
• Length×Width×Height(mm) 9160×3016×3460
• Dumping distance(mm) 1280
• Max. tractive force(kN) 170
• Gears() Forward 2 reverse 1

• Rated load(kg) 5800
• Wheel base(mm) 3400
• Max. dumping height(mm) 3380
• Steering angel(°) 36
• Max. breakout force(kN) 170
• Total time(s) 9.6
