• Rigidity of flip tensioned spring: 785.0±40.0 (N/m), Work length of flip tensioned spring: 61.5.0± 0.3(mm)
• Location of flip hammer's hook release: "100" at the scale mark, Strike length of flip hammer: 75±0.3(mm) Test Hammer Strength Testing
• Sphere semi diameter at the end of the flip rod: 25±1.0 (mm),Hop location of the flip hammer: "0" at the graduated scale easy to adjust friction and more stable
• Length of pointer: 20.0±0.2 (mm), Friction of pointer: 0.65±0.15 (N)
• Various models with different impact energies to cover a wide range of applications
• LANGRY Concrete Rebound Hammer Concrete test hammer with calibration certificate
• made in inda

The quality of concrete is mainly judged by its compressive strength directly affecting the load-bearing capacity and durability of concrete structures. Proceq invented the Original Schmidt, the world’s first and now most widely used test hammer for analyzing the compressive strength of concrete properties.

The Original Schmidt will hit the concrete at a defined energy whereas its rebound is dependent on the hardness of the concrete and is measured by the instrument. The Original Schmidt is available in models with different impact energies, each test hammer designed for a specific test application, in order to meet the needs of the customers to investigate a wide range of material types and sizes, such as bridge decks, thin walls, cast stone components or small components.

•  Instant report generation on the go

•  Best-in-class strength correlation

•  Fully assess an entire test region in less than 10 minutes

• Applications:

  Estimation of compressive strength of concrete / Mapping of concrete uniformity / Estimation of compressive strength of high strength concrete / Control of concrete curing for formwork remova

SilverSchmidt PC/ST is the first integrated Digital Concrete Test Hammer. The unique design and high quality construction of the SilverSchmidt address all of these issues and makes rebound hammer testing quicker and more accurate than ever before.

Impact direction independent: The forward and the rebound velocity of the hammer mass are both measured in close proximity to the point of impact. The rebound value requires no angular correction.

Measurement accuracy and repeatability: The new measurement principle and the design of the mechanics enable the Proceq Silver Schmidt Hammer to outperform its predecessors.

Objective evaluation: A larger number of measurement points can be easily collected by the instrument and automatically evaluated according to statistical criteria.

PC connection: The application "Hammerlink" allows all data to be uploaded via USB. Firmware upgrades are also possible over this connection.

Additional Information:

• Delivery Time: 10 DAYS
• Packaging Details: PLASTIC BOX

Additional Information:

• Delivery Time: 2 DAYS

Proceq original schmidt Live is the latest generation Digital-Analog R-value hammer for non-destructive measurement of compressive strength of concrete. Original Schmidt Live provides a measurement range of 10 to 70 N/mm2 - Mean angle calculated, angle correction factor also applied automatically. Operates as a standalone analogue or as a digital hammer providing output results on an LCD Display or when connected to any smart phone with full productivity unleashed by the Schmidt Live app which significantly reduces the time required for testing and reporting.

Applications

Original Schmidt Live has multiple applications and is a favorite of the concrete and paper industries and in geology work.

• Concrete: strength estimations, formwork removal and to complement core testing.
• Paper: roll profiling in mills and converter plants.
• Geology: strength testing, ageing, weathering (field and lab).

Additional Information:

• Delivery Time: 10 DAYS
• Packaging Details: PLASTIC BOX

The Mechanical Concrete Test Hammer (Schmidt Hammer) test is the quickest, simplest and least expensive method for non-destructive evaluation of concrete and other masonry materials. It is most ideally suited to the measurement of material uniformity over large areas of structure. It provides a measure of relative material surface hardness and is used extensively for the testing of concrete and rock.

The hammer consists of a spring loaded plunger which when released, strikes the surface. During  the  rebound  stroke,  the mass  moves a pointer that indicates the maximum point of return and at the same  time indicates a reference value on the scale called the redound number. This number, when converted based on correlation table, gives the compression resistance value in respect of the impact angle.
