Total Quality Testing Equipments

Owing to our affluent industry acquaintance, we present Pensky Martens. In addition, experts check these products on diverse industry parameters to ensure the sturdy nature.

• FOR 20CM & 30CM DIA. SIEVES - same as above but carrier table and holder suitable to take 20cm as well as 30cm dia sieves.
• FOR 20CM DIA SIEVES - Specifications - This is similar to above sieve shaker but the gears are enclosed in a box on which the sieve carriage is mounted. In addition to the side rocking motion, there is also a taping action

Digital pull off adsion tester

• Specifications : It consists of a vertical pillar mounted on a base provided with levelling screws. The head, together with dial plunger rod and cone (or needle) slides on a pillar and can be clamped at any desired height. A rack & pinion and pointer assemble provides fine adjustment of needle or cone tip to sample. It incorporates a clutch mechanism which makes reading of penetration and subsequent resetting a simple and accurate operation. The dial is graduated in 400 1/10 and the millimeter sub-divisions and the needle pointer against figures makes easy reading. Supplied with a bitumen penetration needle, ring weight one each 50 gms, and two sample container.


•
  Accessories : Penetration cone for empirical estimation of penetration of lubricating grease, petroleum jelly etc.

• Penetrometer apparatus with containers and weights having penetration needle (Bitumen)

• Penetrometer apparatus with containers and weights having penetration CONE HOLLOW type (Grease)

• same as above – but with Geared arrangement for moving the arm with geared unit.

• Penetrometer with Brass Cone & Needle with DIGITAL TIMER DEVICE (Adjustable)

• --- same as above—but with geared arrangement for moving the arm with geared unit.

• Optional Accessories
• Spare Penetration Needle (Pack of two)
• Spare Penetration solid cone
• Spare Penetration brass hollow cone
• Grease worker hand operated
• Grease worker hand operated big handle (Lever type)
• Grease cutter as per IP 50
• Transfer Dish

Additional Information:

• Delivery Time: ready stock

Additional Information:

• Delivery Time: ready stock

The Vibratory Sieve Shaker offers everything you need for the fast determination of quantitative particle size distribution in the laboratory. As a shaking sieve system with an electromagnetic drive oscillates the sieve stack into regulated vertical oscillations and is the ideal solution for sieving sample quantities up to 2 kg and a measurement range from 5 μm to 63 mm.

This is low-noise, robust, and long-lasting. Perfect for quantitative particle size analysis of solids and suspensions of all kinds through dry or wet sieving with woven test sieves or micro precision sieving.

Having a sturdy cast iron body, the sieve shaker has an inclined sieve table which can accommodate a maximum of seven sieves of 150 mm or 200 mm diameter. To hold the sieves an adjustable top clamping plate is provided. The table has a gyratory motion in addition to tapping action. The operating gear assembly is enclosed in an oil bath fitted with a transparent oil level indicator window.

Suitable for operation on 220 V, 50 Hz, single phase supply.

Additional Information:

• Delivery Time: 10 DAYS
• Packaging Details: PLATIC BOX

The C310A provides the ability to examine the corrosion potential and to localise active corrosion in rebar in building structures. The procedure is virtually non-destructive and is performed by carrying out a grid based measurement.

The C310A Rebar Corrosion Detector is a specialized apparatus designed according to the electrochemical testing method (natural potential method). C310A tests the potential of concrete surfaces through a Cu/CuSO4 reference electrode, and determines the level of rebar corrosion.The C310A includes a two electrode handle system which provides flexibility for the operator to: Test using one electrode based on half cell potential method.

Test using two electrodes based on gradient method. In both cases, electrodes used are copper sulfate type. Based on lithium ion rechargeable batteries.

Additional Information:

• Delivery Time: 10 DAYS
• Packaging Details: PLASTIC BOX

We, "Total Quality Testing Equipments" are a "Manufacturer And Trader" of  high-quality Testing Machines, Testing Equipment, Ball Mill, Cube Testing Machine, Aggregate Crushing Valve, Permeability Apparatus etc. Our offered range consists of best grade products. In addition to this, our products are acknowledged for their points like easy to use, high quality, and long life.
 Our mentor "Mr. Amit Sharma" is the guiding force behind our rapid growth. He holds the deep expertise that encourages us to bring out a perfect innovation in our offered range.

With the proficiency of this field, we are capable to present an extensive range of Direct Shear Test Digital. In addition, we present these cabins in varied sizes and designs that meet on patron’s demand.

• Weight: 800
• Power: Hydraulic,0.75kW
• Voltage: 380v
• Material: Steel

With prosperous industry practice, our entity has gained huge appreciation in the market by presenting Hydraulic Extractor to our respected patrons.

We are the leading provider of Digital Water Bath. These products are identified amid patrons for their noticeable features such as longer life, durability and nominal cost.

The Benkelman Beam Apparatus is designed to determine the deflection of a flexible pavement or road surface under moving wheel loads.

The Benkelman Beam Apparatus Comprises:
The equipment is light weight and made of aluminum for easy portability and use at any test location, the length of the Benkelman beam is 250cm One end of the beam rests at a point under investigation while the beam is pivoted in the center.

The free end carries a dial gauge to record the deflections while the other end is kept on a stable platform.

Owing to the vast acquaintance, our firm is competent to present Liquid Limit Test. Our customers can avail this product as per their requirements

• Specification: The concrete permeability apparatus comprises of a brass/ gunmetal cell of squares cross section mounted on a stand and a pressure chamber is connected to the cell through copper tubing and T-connector mounted on the stand with sleeve packed valve and rubber hose pipe with end connections. The cell assembly consists of one base plate, one metal funnel and one top plate, and a pressure tube is supplied to develop pressure in the chamber. The apparatus is supplied with a measuring cylinder 500cc to measure percolated quantity of water. Pressure can also be applied by a pressure air line or by a compressor.
• Available for sample of size 150mm dia X 150mm high.
• Available for sample of size 100mm dia X 100mm high.

Keeping track of contemporary market development, we are devotedly occupied in providing an extensive series of Humidity Chamber.

• Carbide reagent, in bottles of 500 gms
• Each available on extra cost

With the constant endorsement of our diligent experts, we are engrossed in presenting a highly qualitative Folding Endurance Tester to the industry.

Backed by our prosperous industry acquaintance, we present Glass Pycnometer.This product is obtainable in varied patterns that meet on patron’s demand.
