Trident Electro Components

Additional Information:

• Delivery Time: 2 DAYS
• Packaging Details: SPQ

Additional Information:

• Delivery Time: 2 DAYS
• Packaging Details: SPQ

The MC1458P is a dual general-purpose operational amplifier (op-amp) IC from Texas Instruments, widely used in analog signal processing applications such as amplifiers, filters, and signal conditioning circuits.​

• Number of Amplifiers: 2

• Gain Bandwidth Product: 1 MHz

• Slew Rate: 0.5 V/µs

• Input Offset Voltage: Typically 1 mV

• Input Bias Current: Typically 80 nA

•

Additional Information:

• Delivery Time: READY STOCK
• Packaging Details: TUBE

The PIC18F1220-I/P is an 8-bit microcontroller from Microchip's PIC18 family, designed to provide a balance of performance, flexibility, and peripheral integration for a variety of embedded applications. It is especially suitable for applications requiring I/O handling, analog-to-digital conversion, and general-purpose control.

• Core: 8-bit PIC18 (Enhanced Mid-Range)
• Clock Speed: Up to 40 MHz (10 MIPS)
• Flash Memory: 8 KB
• RAM: 512 Bytes
• EEPROM: 256 Bytes
• Operating Voltage: 2.0V – 5.5V
• I/O Pins: 18
• Timers: 3 timers (16-bit and 8-bit)
• Communication Interfaces:
  • 1 x I²C
  • 1 x SPI
  • 1 x UART
• ADC: 10-bit, 4-channel
• PWM: 2 output channels
• Package: DIP-18 (18-pin)

• Clock Speed and Performance:

  • With a 40 MHz clock and 10 MIPS, the PIC18F1220 is capable of performing a range of embedded control tasks, offering good performance for medium-complexity systems.

• Memory and Storage:

  • 8 KB Flash memory for storing program code.
  • 512 Bytes RAM for temporary data storage and variable management.
  • 256 Bytes EEPROM for storing non-volatile data, such as configuration parameters or user settings.

• Analog-to-Digital Conversion (ADC):

  • 10-bit, 4-channel ADC for interfacing with analog sensors, allowing the microcontroller to read and process analog inputs.

• PWM Outputs:

  • 2 PWM output channels, enabling control of motors, lights, or other devices that require variable output, such as adjusting brightness or motor speed.

• Communication Interfaces:

  • I2C, SPI, and UART interfaces provide flexibility for connecting external components, peripherals, and other microcontrollers for communication and data exchange.

• Package Type:

  • Available in DIP-18 (18-pin) package, suitable for prototyping and space-constrained designs.

• Sensor interfacing (e.g., temperature, humidity, light sensors)
• Motor control (e.g., DC motors, stepper motors, servo control)
• Data acquisition systems
• Embedded communication systems
• Consumer electronics
• Industrial control systems
• IoT and remote monitoring systems

Additional Information:

• Packaging Details: TUBE

The PIC18F23K22-I/SO is an 8-bit microcontroller from Microchip's PIC18 family, designed to offer high performance and a wide range of integrated peripherals. It is ideal for applications that require a balance of processing power, memory, and versatile communication capabilities while maintaining low power consumption.

• Core: 8-bit PIC18 (Enhanced Mid-Range)
• Clock Speed: Up to 64 MHz (16 MIPS)
• Flash Memory: 16 KB
• RAM: 2 KB
• EEPROM: 256 Bytes
• Operating Voltage: 2.0V – 5.5V
• I/O Pins: 18
• Timers: 3 timers (16-bit and 8-bit)
• Communication Interfaces:
  • 1 x I²C
  • 1 x SPI
  • 1 x UART
• ADC: 10-bit, 8-channel
• PWM: 2 output channels
• Package: SOIC-20 (20-pin)

Additional Information:

• Packaging Details: TAPE AND REEL

The PIC12F1501-I/SN is an 8-bit microcontroller from Microchip Technology, housed in an 8-pin SOIC package. It is designed for compact, low-power embedded applications requiring analog-to-digital conversion and efficient control.​

• Program Memory: 1.75 KB Flash (1K x 14)

• Data Memory: 64 bytes RAM

• Clock Speed: Up to 20 MHz

• Operating Voltage: 2.3V to 5.5V

• I/O Pins: 5

• Package Type: SOIC-8​

Additional Information:

• Packaging Details: REEL

Additional Information:

• Packaging Details: TUBE

The PIC12F1571-I/P is an 8-bit microcontroller from Microchip Technology, housed in an 8-pin PDIP (Plastic Dual In-line Package). It is designed for compact, low-power embedded applications requiring analog-to-digital conversion and efficient control.​

• Program Memory: 1.75 KB Flash (1K x 14)

• Data Memory: 128 bytes RAM

• Clock Speed: Up to 32 MHz

• Operating Voltage: 2.5V to 5.5V

• I/O Pins: 6

• Package Type: PDIP-8

Additional Information:

• Packaging Details: TUBE

The PIC12F1572-I/SN is an 8-bit microcontroller from Microchip Technology, designed for compact, low-power embedded applications. Housed in an 8-pin SOIC (Small Outline Integrated Circuit) package, it offers a balance between functionality and space efficiency.​

• Program Memory: 3.5 KB Flash (2K x 14)

• Data Memory: 256 bytes RAM

• Clock Speed: Up to 32 MHz

• Operating Voltage: 2.5V to 5.5V

• Analog-to-Digital Converter (ADC): 10-bit resolution with 4 channels

• Digital-to-Analog Converter (DAC): 5-bit resolution

• Comparator: 1 channel

• Timers: Three 16-bit PWM modules with independent timers

• Communication Interfaces: EUSART, LINbus

• Low-Power Features: Power-on Reset (POR), Brown-out Reset (BOR), Watchdog Timer (WDT), Sleep mode

• Code Protection: Yes

Additional Information:

• Packaging Details: TUBE

The PIC12F1822-I/P is an 8-bit microcontroller from Microchip Technology, housed in an 8-pin PDIP (Plastic Dual In-line Package). It is designed for compact, low-power embedded applications requiring analog-to-digital conversion and efficient control.

• Program Memory: 3.5 KB Flash (2K x 14)

• Data Memory: 128 bytes RAM

• EEPROM: 256 bytes

• Clock Speed: Up to 32 MHz

• Operating Voltage: 1.8V to 5.5V

• I/O Pins: 6

• Package Type: PDIP-8​

• Analog-to-Digital Converter (ADC): 10-bit resolution with 4 channels

• Comparator: 1 channel

• Timers: Two 8-bit timers (TMR0 and TMR1)

• Pulse-Width Modulation (PWM): Enhanced Capture/Compare PWM module

• Communication Interfaces: I²C, SPI, and EUSART

• Low-Power Features: Power-on Reset (POR), Brown-out Reset (BOR), Watchdog Timer (WDT), Sleep mode

• Code Protection: Yes

• In-Circuit Serial Programming™ (ICSP™): Supported

Additional Information:

• Packaging Details: TUBE

Additional Information:

• Packaging Details: REEL

Additional Information:

• Delivery Time: 2 DAYS
• Packaging Details: SPQ

Additional Information:

• Delivery Time: 2 DAYS
• Packaging Details: SPQ

Additional Information:

• Delivery Time: 2 DAYS
• Packaging Details: SPQ

The PIC18F6520-I/PT is an 8-bit microcontroller from Microchip’s PIC18F family, featuring enhanced performance and a wide array of communication interfaces, including USB support for embedded applications.

• Core: 8-bit PIC18 (Enhanced Mid-Range)
• Clock Speed: Up to 40 MHz (10 MIPS)
• Flash Memory: 128 KB
• RAM: 3,968 Bytes (3.87 KB)
• EEPROM: 1 KB
• Operating Voltage: 2.0V – 3.6V (Low-power operation)
• I/O Pins: 64
• Timers: 5 timers (16-bit and 8-bit)
• Communication Interfaces:
  • 1 x USB 2.0 Full-Speed (12 Mbps, Device Mode)
  • 2 x I²C / SPI
  • 2 x UART
  • 1 x CAN (Controller Area Network)
  • 1 x Parallel Master Port (PMP)
• ADC: 10-bit, 13-channel
• PWM: 2 output channels
• Low Power Features:
  • nanoWatt XLP (eXtreme Low Power) technology
  • Multiple power-saving sleep modes
• Package: TQFP-64 (64-pin)

• USB 2.0 Full-Speed (12 Mbps)
• Supports device mode only (No host functionality)
• On-chip USB transceiver, simplifying external circuit requirements
• Supports HID, CDC, and Mass Storage protocols

• Integrated USB support for easy USB interfacing in embedded applications.
• Wide range of I/O pins (64), suitable for more complex embedded systems.
• CAN support for automotive or industrial communication applications.
• Low-voltage operation (2.0V – 3.6V) for energy-efficient designs.
• nanoWatt XLP technology for ultra-low power consumption, ideal for battery-operated devices.

Additional Information:

• Packaging Details: TRAY

The PIC18F45K80-I/P is an 8-bit microcontroller from Microchip's PIC18F K-Series. It is designed for applications requiring high performance, low power, and extensive peripheral functionality, including USB support for communication with external devices.

Additional Information:

• Packaging Details: TUBE

The PIC18F65J50-I/PT is an 8-bit microcontroller from Microchip’s PIC18F J-Series, specifically designed for USB applications and low-power operation.

• Core: 8-bit PIC18 (Enhanced Mid-Range)
• Clock Speed: Up to 48 MHz (12 MIPS)
• Flash Memory: 128 KB
• RAM: 3,968 Bytes (3.87 KB)
• EEPROM: None (Emulated in Flash)
• Operating Voltage: 2.0V – 3.6V (Low Voltage Operation)
• I/O Pins: 50
• Timers: 4 timers (16-bit and 8-bit)
• Communication Interfaces:
  • 1 x USB 2.0 (Full-Speed, 12 Mbps, Device Mode)
  • 2 x I²C / SPI
  • 2 x UART
• ADC: 10-bit, 13-channel
• PWM: 2 output channels
• Low Power Features:
  • nanoWatt Technology for power-saving
  • Multiple sleep and idle modes
• Package: TQFP-64 (64-pin)

Additional Information:

• Packaging Details: TRAY

The PIC12F1840-I/P is an 8-bit microcontroller from Microchip Technology, housed in an 8-pin PDIP (Plastic Dual In-line Package). It is designed for compact, low-power embedded applications requiring analog-to-digital conversion and efficient control.

• Program Memory: 7 KB Flash

• Data Memory: 256 bytes RAM

• EEPROM: 256 bytes

• Clock Speed: Up to 32 MHz

• Operating Voltage: 2.3V to 5.5V

• I/O Pins: 6

• Package Type: PDIP-8​

• Analog-to-Digital Converter (ADC): 10-bit resolution with 4 channels

• Comparator: 1 channel

• Timers: Two 8-bit timers (TMR0 and TMR1)

• Pulse-Width Modulation (PWM): Enhanced Capture/Compare PWM module

• Communication Interfaces: I²C, SPI, and EUSART

• Low-Power Features: Power-on Reset (POR), Brown-out Reset (BOR), Watchdog Timer (WDT), Sleep mode

• Code Protection: Yes

• In-Circuit Serial Programming™ (ICSP™): Supported​

Additional Information:

• Packaging Details: TUBE

The PIC12F510-I/SN is an 8-bit microcontroller from Microchip Technology, designed for compact, low-power embedded applications. It is housed in an 8-pin SOIC (Small Outline Integrated Circuit) package, offering a balance between functionality and space efficiency.

• Program Memory: 1.5 KB Flash

• Data Memory: 38 bytes RAM

• Clock Speed: Up to 8 MHz

• Operating Voltage: 2.0V to 5.5V

• I/O Pins: 5

• Package Type: SOIC-8​

• Analog-to-Digital Converter (ADC): 3 channels, 8-bit resolution

• Comparator: 1 channel

• Timers: One 8-bit timer (TMR0)

• Low-Power Features: Power-on Reset (POR), Watchdog Timer (WDT), Sleep mode

• Code Protection: Yes

• In-Circuit Serial Programming™ (ICSP™): Supported

Additional Information:

• Packaging Details: REEL

The PIC12F615-I/P is an 8-bit microcontroller from Microchip Technology, housed in an 8-pin PDIP (Plastic Dual In-line Package). It is designed for compact, low-power embedded applications requiring analog-to-digital conversion and efficient control.

• Program Memory: 1.75 KB Flash

• Data Memory: 64 bytes RAM

• Clock Speed: Up to 20 MHz

• Operating Voltage: 2.0V to 5.5V

• I/O Pins: 5

• Package Type: PDIP-8​

Additional Information:

• Packaging Details: TUBE

Additional Information:

• Production Capacity: 8-bit Microcontrollers - MCU 14KB 368 RAM 33 I/O
• Delivery Time: READY STOCK
• Packaging Details: TUBE PACKING

Additional Information:

• Delivery Time: 2 DAYS
• Packaging Details: SPQ

Additional Information:

• Item Code: PIC16F88x
• Production Capacity: 8-bit Microcontrollers - MCU 14KB Flash 368 RAM 25 I/O
• Delivery Time: READY STOCK
• Packaging Details: TUBE = 15PCS

The PIC18F13K50-I/SO is a low-power, 8-bit microcontroller from Microchip's PIC18 family with USB capabilities. It is designed for embedded applications that require USB communication along with high processing power, memory, and efficient peripheral integration. This microcontroller is well-suited for applications like USB device communication, sensor interfacing, and control systems.

• Core: 8-bit PIC18 (Enhanced Mid-Range)
• Clock Speed: Up to 48 MHz (12 MIPS)
• Flash Memory: 8 KB
• RAM: 512 Bytes
• EEPROM: 256 Bytes
• Operating Voltage: 2.0V – 5.5V
• I/O Pins: 18
• Timers: 3 timers (16-bit and 8-bit)
• Communication Interfaces:
  • USB 2.0 Full-Speed (12 Mbps)
  • 1 x I²C
  • 1 x SPI
  • 1 x UART
• ADC: 10-bit, 4-channel
• PWM: 2 output channels
• Package: SOIC-20 (20-pin)

• USB 2.0 Full-Speed:

  • Supports USB 2.0 full-speed communication (12 Mbps), making it ideal for USB peripherals, USB-to-serial converters, or USB data acquisition systems.

• Clock Speed and Performance:

  • 48 MHz clock and 12 MIPS, providing fast execution for communication tasks, control operations, and data processing.

• Memory and Storage:

  • 8 KB Flash memory for program storage.
  • 512 Bytes RAM for temporary data storage and processing.
  • 256 Bytes EEPROM for storing configuration or calibration data.

• Analog-to-Digital Conversion (ADC):

  • 10-bit, 4-channel ADC to interface with analog sensors and convert analog signals to digital values for processing.
  • Enables easy integration with various sensors or signal inputs.

• PWM Outputs:

  • 2 PWM output channels for controlling motors, LEDs, or other devices requiring precise signal output.

• Communication Interfaces:

  • USB 2.0 (Full-Speed), I2C, SPI, and UART enable versatile communication with other devices, controllers, or sensors.

• Package Type:

  • Available in SOIC-20 (20-pin) package, providing a compact design with 18 I/O pins for external connections.

Additional Information:

• Packaging Details: REEL

The PIC18F26K22-E/SS is an 8-bit microcontroller from Microchip’s PIC18 family, designed for high-performance applications that require moderate processing power, extensive peripheral support, and low-power operation. It is a versatile choice for a range of embedded applications in industrial, automotive, consumer, and communication systems.

• Core: 8-bit PIC18 (Enhanced Mid-Range)
• Clock Speed: Up to 64 MHz (16 MIPS)
• Flash Memory: 32 KB
• RAM: 2,048 Bytes (2 KB)
• EEPROM: 1 KB
• Operating Voltage: 2.0V – 5.5V
• I/O Pins: 28
• Timers: 5 timers (16-bit and 8-bit)
• Communication Interfaces:
  • 1 x I²C
  • 1 x SPI
  • 2 x UART
• ADC: 10-bit, 16-channel
• PWM: 3 output channels
• Package: SSOP-28 (28-pin)

• 64 MHz clock speed and 16 MIPS for fast processing, enabling high-performance applications.
• 32 KB Flash memory for storing application code, providing sufficient memory for medium-to-large embedded projects.
• 2 KB RAM for data handling, variables, and buffers.
• 1 KB EEPROM for non-volatile data storage, ideal for retaining settings, configuration, or calibration data.
• 16-channel, 10-bit ADC for precise analog-to-digital conversion, suitable for interfacing with various sensors.
• 3 PWM output channels for controlling motors, actuators, or LEDs.
• Communication support via I2C, SPI, and UART, which allows seamless communication with external devices.
• Wide operating voltage range (2.0V – 5.5V) to support different power supply configurations.

Additional Information:

• Packaging Details: REEL AND TAPE

The PIC16F88-I/P is an 8-bit microcontroller from Microchip's PIC16 family, designed for embedded systems that require a balance of processing power, memory, and peripheral functionality. This microcontroller is ideal for a variety of applications, including control systems, communication, and sensor interfacing.

• Core: 8-bit PIC16 (Mid-Range)
• Clock Speed: Up to 20 MHz (5 MIPS)
• Flash Memory: 7 KB
• RAM: 368 Bytes
• EEPROM: 256 Bytes
• Operating Voltage: 2.0V – 5.5V
• I/O Pins: 14
• Timers: 3 timers (16-bit and 8-bit)
• Communication Interfaces:
  • 1 x I²C
  • 1 x SPI
  • 1 x UART
• ADC: 10-bit, 8-channel
• PWM: 1 output channel
• Package: DIP-18 (18-pin)

• Clock Speed and Performance:

  • 20 MHz clock with 5 MIPS performance allows for efficient execution of embedded control tasks, such as handling sensors, controlling outputs, and managing data communication.

• Memory and Storage:

  • 7 KB Flash memory for program storage, offering enough space for medium-complexity applications.
  • 368 Bytes RAM for temporary data storage and processing.
  • 256 Bytes EEPROM for storing non-volatile data, such as calibration settings or user preferences.

• Analog-to-Digital Conversion (ADC):

  • 10-bit, 8-channel ADC enables the microcontroller to interface with a wide range of analog sensors and convert analog inputs to digital data.

• PWM Output:

  • 1 PWM output channel for controlling devices such as motors, LEDs, or other systems that require variable output, such as speed or brightness control.

• Communication Interfaces:

  • I2C, SPI, and UART provide flexible options for communication with external devices, sensors, and other microcontrollers.

• Package Type:

  • Available in DIP-18 (18-pin) package, making it suitable for prototyping and small embedded systems.

Additional Information:

• Packaging Details: TUBE

The PIC18F45K20-I/P is an 8-bit microcontroller from Microchip’s PIC18F K-series, offering a balance between performance, low power consumption, and a wide range of integrated peripherals. This microcontroller is ideal for embedded applications that require efficient power management and advanced I/O functionalities.

• Core: 8-bit PIC18 (Enhanced Mid-Range)
• Clock Speed: Up to 64 MHz (16 MIPS)
• Flash Memory: 64 KB
• RAM: 3,912 Bytes (3.82 KB)
• EEPROM: 1 KB
• Operating Voltage: 2.0V – 5.5V (Flexible voltage range)
• I/O Pins: 40
• Timers: 5 timers (16-bit and 8-bit)
• Communication Interfaces:
  • 1 x I²C
  • 1 x SPI
  • 2 x UART
  • 1 x CAN (Controller Area Network)
• ADC: 10-bit, 13-channel
• PWM: 4 output channels
• Low Power Features:
  • nanoWatt XLP (eXtreme Low Power) technology
  • Multiple power-saving modes
  • Fast wake-up from sleep mode
• Package: DIP-40 (40-pin)

• 64 MHz clock speed and 16 MIPS for strong processing power while maintaining low power consumption.
• Wide operating voltage range (2.0V – 5.5V) allows versatility in various power systems.
• 10-bit ADC with 13 channels for precision sensor and analog input measurement.
• CAN communication support for industrial, automotive, or networked applications.
• Four PWM outputs for motor control, lighting, and other applications requiring analog output control.
• nanoWatt XLP technology for low-power consumption, ideal for battery-operated and energy-efficient systems.

Additional Information:

• Packaging Details: TUBE

Additional Information:

• Delivery Time: 2 DAYS
• Packaging Details: SPQ

Additional Information:

• Delivery Time: 2 DAYS
• Packaging Details: SPQ

Additional Information:

• Delivery Time: 2 DAYS
• Packaging Details: SPQ

Additional Information:

• Delivery Time: 2 DAYS
• Packaging Details: SPQ

The PIC16F688-I/P is an 8-bit microcontroller from Microchip's PIC16 family, offering a good balance of performance, memory, and peripherals for various embedded applications. It is ideal for systems where space and power consumption are important considerations, yet you still need solid processing power and flexibility in interfacing with external components.

• Core Type: 8-bit RISC (Reduced Instruction Set Computing) architecture
• Clock Speed: Up to 20 MHz, which gives 5 MIPS (Million Instructions Per Second) of processing power.
• Operating Voltage: 2.0V – 5.5V, making it suitable for battery-powered applications or systems with variable power supply requirements.
• Low Power Consumption: Designed for energy-efficient operation, ideal for portable or energy-sensitive devices.

• Flash Memory: 3.5 KB (used to store the program code)
• RAM: 368 Bytes (used for temporary data storage)
• EEPROM: 256 Bytes (non-volatile storage for configuration or user data)

• GPIO Pins: 16 I/O pins (used to interface with external components like sensors, switches, LEDs, and motors)
• Timers:
  • 2 Timers (one 8-bit and one 16-bit) for precise time-based operations, event counting, or generating delays.
• Analog-to-Digital Converter (ADC):
  • 10-bit ADC, with 8 channels to interface with various analog sensors, such as temperature, pressure, or light sensors, converting the analog signals into digital values.
• PWM (Pulse Width Modulation):
  • 1 PWM output for controlling devices like motors, LEDs, or other systems that require variable speed or brightness.
• Communication Interfaces:
  • I²C (Inter-Integrated Circuit) for connecting with other devices such as sensors, displays, and memory modules.
  • SPI (Serial Peripheral Interface) for high-speed data communication between microcontrollers or external devices.
  • UART (Universal Asynchronous Receiver/Transmitter) for serial communication with external devices or other microcontrollers, enabling connectivity with PCs, Bluetooth modules, or other peripherals.
• Other Features:
  • Watchdog Timer (WDT): Ensures the microcontroller resets if the software fails or the program becomes unresponsive.
  • Brown-out Reset: Automatically resets the microcontroller if the supply voltage drops below a certain level, ensuring proper operation even in cases of fluctuating power supply.
  • In-circuit Debugging (ICD): Allows real-time debugging while the microcontroller is running within the circuit, making it easier to identify and fix issues during development.

• PDIP-18 (Plastic Dual In-line Package)
  • Pin Count: 18 pins, which provides a compact and convenient package for space-constrained applications while still offering adequate I/O and peripheral options.

Additional Information:

• Delivery Time: 2-3 DAYS
• Packaging Details: DIP - TUBE

The PIC16F684-I/SL is an 8-bit microcontroller from Microchip’s PIC16 family, designed for a range of embedded applications where low power, flexibility, and reliable performance are required. It combines memory, I/O options, and peripherals in a compact form, making it an excellent choice for various control and data acquisition tasks.

• Core Type: 8-bit RISC (Reduced Instruction Set Computing) architecture
• Clock Speed: Up to 20 MHz, delivering up to 5 MIPS (Million Instructions Per Second) processing power
• Operating Voltage: 2.0V – 5.5V, providing a broad range of operation suitable for battery-powered or energy-efficient devices
• Low Power Consumption: Designed for low power operation, making it ideal for portable devices and applications that require minimal energy usage.

• Flash Memory: 3.5 KB (for storing program code)
• RAM: 368 Bytes (used for temporary data storage during program execution)
• EEPROM: 256 Bytes (for non-volatile storage of data like settings, configuration, or calibration)

• GPIO Pins: 13 I/O pins (used for interfacing with external components like sensors, actuators, and displays)
• Timers:
  • 2 Timers (one 8-bit and one 16-bit) for generating delays, counting events, and other time-based operations.
• Analog-to-Digital Converter (ADC):
  • 10-bit ADC with 8 channels for converting analog sensor signals (e.g., temperature, pressure, or light sensors) to digital values that can be processed by the microcontroller.
• PWM (Pulse Width Modulation):
  • 1 PWM output for controlling devices like motors, LEDs, or other systems requiring variable control.
• Communication Interfaces:
  • I²C (Inter-Integrated Circuit) for connecting to external peripherals such as sensors, displays, and memory devices.
  • SPI (Serial Peripheral Interface) for high-speed communication with external devices, typically used for inter-microcontroller or sensor communication.
  • UART (Universal Asynchronous Receiver/Transmitter) for serial communication with other devices, such as a PC, Bluetooth modules, or another microcontroller.
• Other Features:
  • Watchdog Timer (WDT): Ensures the system is reset if the software malfunctions, improving system reliability.
  • Brown-out Reset: Automatically resets the microcontroller if the supply voltage drops below a safe operating level, preventing malfunction due to low voltage.
  • In-circuit Debugging (ICD): Facilitates real-time debugging while the microcontroller is in the circuit, reducing development and troubleshooting time.

Additional Information:

• Packaging Details: REEL AND TAPE

The PIC16F689-I/P is an 8-bit microcontroller from Microchip's PIC16 family, offering a good combination of memory, I/O options, and peripheral support. This microcontroller is designed for a wide range of embedded applications, from simple control systems to more complex data acquisition and communication tasks.

• Core Type: 8-bit RISC (Reduced Instruction Set Computing) architecture
• Clock Speed: Up to 20 MHz, providing 5 MIPS (Million Instructions Per Second) of processing power
• Operating Voltage: 2.0V – 5.5V, which provides flexibility in various power configurations, including battery-operated systems.
• Power Consumption: Designed for low power consumption, making it suitable for energy-efficient and portable devices.

• Flash Memory: 7 KB (for program storage)
• RAM: 368 Bytes (for temporary data storage during program execution)
• EEPROM: 256 Bytes (non-volatile storage for configuration settings, user data, etc.)

• GPIO Pins: 18 I/O pins (used for connecting external components like sensors, switches, LEDs, etc.)
• Timers:
  • 2 Timers (8-bit and 16-bit) for precise timing and event counting
• Analog-to-Digital Converter (ADC):
  • 10-bit, 8-channel ADC, allowing the microcontroller to interface with analog sensors and convert their signals to digital format for processing
• PWM (Pulse Width Modulation):
  • 1 PWM output for controlling motors, LED dimming, or other systems that require variable control
• Communication Interfaces:
  • 1 I²C (Inter-Integrated Circuit) for communication with peripheral devices, such as sensors, memory, or displays
  • 1 SPI (Serial Peripheral Interface) for high-speed communication with other devices
  • 1 UART (Universal Asynchronous Receiver/Transmitter) for serial communication with external devices or microcontrollers
• Other Features:
  • Watchdog Timer (WDT): Ensures the system is reset in case of a software failure or malfunction
  • Brown-out Reset: Automatically resets the microcontroller if the supply voltage drops below a safe level
  • In-circuit Debugging (ICD): Allows for real-time debugging while the microcontroller is still in the circuit, making development and troubleshooting easier

• PDIP-18 (Plastic Dual In-line Package)
  • Pin Count: 18 pins, making it a compact choice for embedded systems requiring fewer I/O pins while still providing adequate peripheral support.

Additional Information:

• Packaging Details: TUBE

The PIC18F2431-I/SP is an 8-bit microcontroller from Microchip's PIC18 family, designed to offer efficient performance and a wide range of integrated peripherals for embedded applications. It is particularly suitable for systems that require communication interfaces, analog-to-digital conversion, and control outputs.

• Core: 8-bit PIC18 (Enhanced Mid-Range)
• Clock Speed: Up to 40 MHz (10 MIPS)
• Flash Memory: 8 KB
• RAM: 1,024 Bytes (1 KB)
• EEPROM: 256 Bytes
• Operating Voltage: 2.0V – 5.5V
• I/O Pins: 28
• Timers: 4 timers (16-bit and 8-bit)
• Communication Interfaces:
  • 1 x I²C
  • 1 x SPI
  • 1 x UART
• ADC: 10-bit, 8-channel
• PWM: 2 output channels
• Package: DIP-28 (28-pin)

• Clock Speed and Performance:

  • Up to 40 MHz clock speed and 10 MIPS performance, providing fast execution of embedded tasks.

• Memory and Storage:

  • 8 KB Flash memory for storing program code.
  • 1 KB RAM for handling data storage and computation.
  • 256 Bytes EEPROM for non-volatile storage of settings or calibration data.

Additional Information:

• Packaging Details: TUBE

The PIC18F2520-I/SP is an 8-bit microcontroller from Microchip's PIC18 family, designed for embedded applications that require reliable performance, flexibility in communication, and effective analog signal handling. It is a versatile microcontroller suitable for a wide range of applications such as industrial control systems, data acquisition, and embedded communication devices.

• Core: 8-bit PIC18 (Enhanced Mid-Range)
• Clock Speed: Up to 40 MHz (10 MIPS)
• Flash Memory: 8 KB
• RAM: 1,024 Bytes (1 KB)
• EEPROM: 256 Bytes
• Operating Voltage: 2.0V – 5.5V
• I/O Pins: 28
• Timers: 4 timers (16-bit and 8-bit)
• Communication Interfaces:
  • 1 x I²C
  • 1 x SPI
  • 1 x UART
• ADC: 10-bit, 8-channel
• PWM: 2 output channels
• Package: DIP-28 (28-pin)

• 40 MHz clock speed with 10 MIPS, offering fast processing for most embedded applications.
• 8 KB Flash memory to store application code, making it suitable for medium-sized projects.
• 1 KB RAM for storing data, variables, and buffers for computations or sensor processing.
• 256 Bytes EEPROM for non-volatile storage of configuration or calibration data.
• 8-channel, 10-bit ADC to convert analog signals to digital data with reasonable accuracy.
• 2 PWM output channels for controlling motors, LEDs, or other analog systems.
• I/O Pins: 28 pins provide flexibility for peripheral connections.
• Wide voltage range (2.0V – 5.5V) suitable for different power configurations.

Additional Information:

• Packaging Details: TUBE
