Vidhyut Technical Service

Current Rating	32 A
Number of Pins	5 Pin
Product Type	Socket
IP Rating	IP44
Phase	Three Phase
Brand	Mennekes

• screw terminals
• pre-wired for installation
• X-CONTACT
• switched

• mechanical DUO-interlock
• 3 pole switch
• receptacles can be padlocked

Current Rating	32 A
Number of Pins	5 Pin
Product Type	Socket
IP Rating	IP44
Phase	Three Phase
Brand	Mennekes

• screw terminals
• single part body

• cable gland and sealing
• strain relief and protection against kinking

Current Rating	32 A
Number of Pins	5 Pin
Product Type	Socket
IP Rating	IP44
Phase	Three Phase
Brand	Mennekes

• screw terminals
• single part body
• with highly heat resistant contact carrier

• nickel plated contacts
• cable gland and sealing
• strain relief and protection against kinking

Current Rating	16 A
Number of Pins	3 Pin
Product Type	Socket
IP Rating	IP44
Phase	Three Phase
Brand	Mennekes

• screw terminals
• single part body
• with highly heat resistant contact carrier

• nickel plated contacts
• cable gland and sealing
• strain relief and protection against kinking

Current Rating	16 A
Number of Pins	3 Pin
Product Type	Socket
IP Rating	IP44
Phase	Three Phase
Brand	Mennekes

• screw terminals
• single part body

• cable gland and sealing
• strain relief and protection against kinking

Current Rating	16 A
Number of Pins	3 Pin
Product Type	Socket
IP Rating	IP44
Phase	Three Phase
Mounting Type	Panel Mounted
Voltage Rating	230 V

• screw terminals
• frame terminals
• X-CONTACT
• highly heat resistant contact carrier
• cable gland and sealing

• strain relief and protection against kinking
• enclosure with thread lock
• two safety slides
• products with pilot contact: part no + index P

Current Rating	32A
Material	Polycarbonate
Brand	meennekes

• pre-wired for installation
• enclosure and insert made of AMAPLAST

• fusing behind a transparent cover

Current Rating	32A
Material	Polycarbonate
Brand	mennekes

• screw terminals
• LED voltage indicator
• pre-wired for installation
• X-CONTACT
• switched
• mechanical DUO-interlock

• highly heat resistant contact carrier
• nickel plated contacts
• 3 pole switch with auxiliary contact switch 1 NC and 1 NO
• receptacles can be padlocked
• sealed against dust, temporary submersion and high pressure cleaning

Current Rating	16 A
Number of Pins	3 Pin
Product Type	Socket
IP Rating	IP44
Phase	Three Phase
Brand	Mennekes
Mounting Type	Wall Mounted
Voltage Rating	230 V

• screwless spring terminals
• CEE and receptacle SCHUKO® in one enclosure

• also available with shock-proof receptacles to comply with French/Belgian and Swiss standards

Current Rating	16 A
Number of Pins	3 Pin
Product Type	Socket
IP Rating	IP44
Phase	Three Phase
Brand	Mennekes

• screwless spring terminals
• CEE and receptacle SCHUKO® in one enclosure

• with fuse holder, max. 10 A

Current Rating	16 A
Number of Pins	3 Pin
Product Type	Socket
IP Rating	IP44
Phase	Three Phase
Brand	Mennekes

• pre-wired for installation
• enclosure and insert made of AMAPLAST

• fusing behind a transparent cover

Current Rating

32 A

• screwless spring terminals
• highly resistant to chemicals
• suitable for through wiring

• with 2 external fixing points
• receptacles are designed for adding an auxiliary contact switch
• enclosure base can be turned 180°

Current Rating

32 A

• screwless, with insulation displacement technology
• X-CONTACT
• cable gland and sealing

• strain relief and protection against kinking
• enclosure with thread lock and safety slide

Current Rating

16 A

• screwless, with insulation displacement technology
• X-CONTACT
• cable gland and sealing

• strain relief and protection against kinking
• enclosure with thread lock and safety slide

Current Rating

63 A

• screw terminals
• X-CONTACT
• highly heat resistant contact carrier

• suitable for through wiring
• with fixing points for terminal strip part no. 40114 or 40115
• products with pilot contact on request

Current Rating	Above 80 A
Country of Origin	Made in India

• screw terminals
• X-CONTACT

• products with pilot contact on request

Current Rating

16 A

• screwless spring terminals
• highly resistant to chemicals
• suitable for through wiring

• with 2 external fixing points
• receptacles are designed for adding an auxiliary contact switch
• enclosure base can be turned 180°

Current Rating	125
IP Rating	67
Rated Voltage	440'
Interlock Facility	Yes
Brand	MENNEKES

MENNEKES plugs and sockets are well known all over the world – and naturally comply with the relevant national and international standards. Nowadays, more than half of our products are destined to international markets. This is why MENNEKES also has a global presence, with subsidiaries and agencies in more than 90 countries.

Voltage	24 V
Output Voltage	24V
Usage/Application	Industrial Automation
Current	25A
Brand	APC
Ripple Voltage	415
Efficiency	50 HZ
Input Voltage	24 V
Design	Smps
Display Type	LED
Series	CPE

The CP-E 24/2.5 is a power supply from the CP-E range. The primary switch mode power supply offers a wide range input of 85-264 V AC and 90-375 V DC, rated input voltage is 100-240 V AC. The rated output power is 60 W, rated output current is 2.5 A at an output voltage of 24 V DC. The output voltage is adjustable within a range of 24 to 28 V DC. The power supply provides a U/I output characteristic and allows parallel operation to enable redundancy. A further feature is the signalling output (transistor) for output voltage OK. A redundancy unit is available as accessory.

Additional Information:

• Item Code: 1SVR427032R0000
• Production Capacity: 1000
• Delivery Time: Ready stock
• Packaging Details: Box packing
