Number of Channels	4
Model Name/Number	DS-7104HGHI-K1
Brand	Hikvision
Stream Type	Video, Video & Audio
Resolution	For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF
Camera Technology	Analog Camera
HDCVI input	1080p25
Network Protocols	TCP/IP

4-ch 1080p Lite Mini 1U H.265 DVR

• Deep learning based human and vehicle targets classification of Motion Detection 2.0
• H.265 Pro+/H.265 Pro/H.265 video compression
• HDTVI/AHD/CVI/CVBS/IP video input
• Audio via coaxial cable
• Up to 5-ch IP camera inputs (up to 2 MP)
• Up to 1080p Lite@15 fps encoding capability
• Max. 1200 m for 720p HDTVI signal

Brand	Hikvision
Usage/Application	Video Recording
Color	White
AHD input	2 MP
Number Of Channels	8 channela
Connector Type	Wired
Low Light Technology	Night Color

Product Detail:

• 8-ch 1080p Mini 1U H.265 DVR
• 8 channels and 1 HDD mini size DVR
• Efficient H.265 pro+ compression technology
• Encoding ability up to 1080p @ 15 fps
• 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
• Up to 12 network cameras can be connected

Network & Ethernet Access

• Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
• Max. 24/48/96 Mbps incoming bandwidth and output bandwidth limit configurable

Storage and Playback

• Smart search for efficient playback
• Support the 3rd party cloud storage

Compression and Recording

• H.265 Pro+ can improve encoding efficiency and reduce the data storage cost
• Full channel recording at up to 4 MP lite resolution

Video Input	Yes
Resolution	1080p
Type	DVR
Usage/Application	CCTV Recorder
Brand	Dahua
Net Weight (Without HDD)	1 kg
No.Of Channel	4 Channel
Color	Black

Dahua, as a technology leader, is always the first ever developed the shining new technology in the security industry ,and today we present Cooper Series XVR. Designed as a full compatibility product, XVR is able to provide end user the simplicity of analog system, namely lower system cost, simple installation and use of existing cable. And with the adoption of Smart H.265+/H.265, the series improves encoding efficiency, saving on bandwidth/storage costs. It is ideal for a wide range of civil applications such as retail store, home protection and so on. Featuring high performance with attractive costs, the Cooper Series offers a great solution for users facing budget constraints who both require quality and performance.

Smart H.265+ Smart Codec, H.265+ can reduce up to 90% bit rate and storage requirements compared with H.264 without having to invest in new cameras.

HDCVI/AHD/TVI/CVBS/IP Auto-detect The XVR can auto recognize the signal of front-camera without any setting. It makes operation more friendly and convenient.

IPC Input Supported The XVR4B04 supports up to 2MP IPC input, and XVR4B08 suppports up to 6MP IPC input.

Coaxial Audio/Upgrade/Alarm The integrated design can reduce wiring troubles which makes it much more cost-effective and convenient for installation

Long Distance Transmission The HDCVI system supports long distance transmission over coaxial cable and UTP, max. 800m for 1080P and 1200m for 720P

Smart Search This function helps you get more motion detect video during a short time through drawing a region when playback. It is very useful when an emergency occurs.

Perfect Image Quality High performance chip provides perfect image quality with better color reproduction.

P2P Monitor at anytime and anywhere. Easily and conveniently mange the device.

Experience the superior clarity of Dahua s 2 MP HDCVI cameras for vast coverage and superior image details The 2 MP HDCVI series leverages existing coax infrastructures to deliver forensic level images seamlessly and over long distances The camera uses a progressive scan CMOS sensor and next generation ISP chip technology developed by Dahua to deliver stunning video with a wide field of view This home grown ISP features the latest image processing algorithms and is optimized for surveillance camera operations With total control of the ISP features and production Dahua can offer the latest security systems at a cost effective price Three Signals over One Coaxial Cable HDCVI technology simultaneously transmits three signals video power and data over a single coaxial cable Dual way data transmission allows the HDCVI camera to communicate with an HCVR to send control signals or to trigger alarms HDCVI along with PoC technology delivers power to devices at the edge simplifying installation
